_________________________ Solutions for solar energy Rev.1 Contents Few Basics of PV Module String Sizing Power Ratio Optimisation Different kind of I nverters Rev.1 Rev.1 Rev.1 Rev.1 Rev.1 Rev.1 Rev.1 Rev.1 Rev.1 Example sizing

slide-1
SLIDE 1

_________________________ Solutions for solar energy

Rev.1

slide-2
SLIDE 2

Contents

Rev.1

Few Basics of PV Module String Sizing Power Ratio Optimisation Different kind of I nverters

slide-3
SLIDE 3

Rev.1

slide-4
SLIDE 4

Rev.1

slide-5
SLIDE 5

Rev.1

slide-6
SLIDE 6

Rev.1

slide-7
SLIDE 7

Rev.1

slide-8
SLIDE 8

Rev.1

slide-9
SLIDE 9

Rev.1

slide-10
SLIDE 10

Rev.1

slide-11
SLIDE 11

Rev.1

Example sizing verification

slide-12
SLIDE 12

Rev.1

slide-13
SLIDE 13

Rev.1

slide-14
SLIDE 14

Rev.1

slide-15
SLIDE 15

Rev.1

slide-16
SLIDE 16

Rev.1

Efficiency curve of various kind of I nverters

slide-17
SLIDE 17

RPS TL Made-to-measure for your installation.

Product overview

Main features:

  • power range from 280 kWp to 1580 kWp
  • modular design ensuring highest system

availability

  • Master-Slave or Multi-MPPT configuration

to optimise Photovoltaic field output

  • max.efficiency: 98.6%
  • advanced grid management features

Target application: Large rooftop/utility scale

Rev.1

slide-18
SLIDE 18

RPS TL

Product overview

Bonfiglioli Modular System

Rev.1

slide-19
SLIDE 19

RPS TL: Master-Slave configuration (1)

Depending on the operating conditions, Master-Slave configurations can offer significant advantages over standard central PV inverters.

Product overview

Higher conversion efficiency and longer daily production time

Rev.1

slide-20
SLIDE 20

RPS TL: Master-Slave configuration (2)

Master-Slave systems manage the working load of each module, maximising conversion efficiency, optimising the consumption of each module and guaranteing an extended working life.

Longer expected lifetime

Product overview

Rev.1

slide-21
SLIDE 21

PV Power plants with Master Slave system

RPS Station

Sivaganga, Tamilnadu – I ndia

Solar park equipped with Bonfiglioli inverters (2010): 5 MW

EPC Contractor: Moserbaer Solar Limited

RPS TL

References

“ B “ Bonfiglioli invert ers r reached t t he follow ing availabilit y i in % : 99.7% ” ” – R.Ganagaraj , Senior r Manager r O& M at Mose ser r Baer r

Rev.1

slide-22
SLIDE 22

RPS TL: Multi-MPPT configuration (1)

Using an inverter with multiple independent MPPT trackers proves highly advantageous under conditions of non-uniform production from the connected arrays.

Product overview

Rev.1

slide-23
SLIDE 23

PV power plant with Multi MPPT system

Rev.1

“ Sol

  • lar

ar Sem icon

  • nduct or
  • r - Gaj anan p

plant - AP AP w it h Bonfiglioli invert ers reached peak yield per r MW as s 7.35MW h/ day” y”

slide-24
SLIDE 24

RPS TL: Multi-MPPT configuration (2)

In RPS TL modular systems, only the faulty module ceases operation, while all other modules remain active. This greatly reduces the impact of faults.

Higher fault-immunity

Product overview

Rev.1

slide-25
SLIDE 25

RPS TL Modular Outdoor

Main features:

  • IP54 rated outdoor inverter modules with 220 kWp

individual power rating

  • up to 7 modules can be connected to a common transformer

station (220 to 1540 kWp)

  • compact inverter modules can be distributed around the PV

field (maximum connection lenght 100m)

  • indipendent MPPT tracker in each inverter module
  • inverter modules resistant to direct sunlight and ambient

temperatures up to 45°C

Target application: Large rooftop/utility scale

Flexibility and robustness whatever the location.

Product overview

Rev.1

slide-26
SLIDE 26

RPS TL Modular Outdoor

Product overview

Grouped configuration (up to 7 modules) Distributed configuration (up to 5 modules)

Rev.1

slide-27
SLIDE 27

RPS Endurance The right answer to growing photovoltaic markets.

Main features:

  • rated Power: 500 kWac
  • maximum input voltage: 1000 V
  • compact dimensions: 1200 x 2100 x 600 mm
  • low weight: < 1000 kg
  • innovative cooling and double ambient protection

concept (IP54)

  • floating and grounded PV array connection
  • advanced Grid Management (BDEW compliant,

anti-islanding protection)

  • target Efficiency: 98.6 %
  • easy installation and maintenance
  • numerous self-protection features

Target application: Utility scale

Product overview

Rev.1

slide-28
SLIDE 28

RPS Station

Main features:

  • broad choice of power ratings, from 280 to 3150 kWp, suitable for a wide range of roof and

ground installations

  • Plug & Play product
  • cabin in vibrated, reinforced concrete or other materials according to the application
  • fully equipped logistic service for transport via road, rail, air or sea.

Target application: Large rooftop/utility scale

Turnkey solutions customised for your own market.

Product overview

Rev.1

slide-29
SLIDE 29

RPS Station

Bonfiglioli’s RPS Station cabins are delivered pre-cabled, fully installed, commissioned and ready to manage the entire photovoltaic field.

Product overview

Rev.1

slide-30
SLIDE 30

Pre-sales service & Commissioning

Service

Rev.1

slide-31
SLIDE 31

After-sales service

Service

Rev.1

slide-32
SLIDE 32

Coverage levels: choose your style!

Service

Uptime

PRE – SALES. BOS OPTI MI ZATI ON / COMMI SSI ONI NG / ANOMALY FAI LURE RECOVERI NG

Rev.1

slide-33
SLIDE 33

www.bonfiglioli.com
