HIGH TECHNOLOGICAL & COST EFFECTIVE SOLUTIONS FOR FOOD INDUSTRY

Integrated Thermal Printer (Optional)

Ekomilk iBond Ultrasonic Milk Analyzers are

designed for fast and cost effective analysis of the key milk ingredients content - fat, solids non fat (SNF), protein, milk density (CLR) of cow, buffalo or mixed (cow/buffalo) milk and added water to milk as well. Along with the milk parameters measurement this new generation of ultrasonic milk Analyzer provides on the field comfortable, fast and cost effective way for collecting, processing and saving all data about the volume and quality of the milk supplied by each of the milk vendors. These Analyzers also provide a flexible way for fast (real time) calculating

• f the payment amounts for each of the milk vendors. All these

data can be easily transferred later by an USB Flash drive (pen), SMS or e-mail to a PC, FTP Server.

Key Features:

• Fast Analysis - allows a large number of measurements

to be done;

• Simple and lightweight design;
• +12V DC and 220V (or 110V optional) AC Power supply;
• Cost effective:

Low power consumption; Very small quantity of milk required; No acid or other chemicals are used;

• One year full warranty;
• Measuring accuracy adjustment can be done by the

user;

• Two independent RS 232 COM ports;
• Four USB Host ports with Mass Storage, and Numeric

keyboard support;

• ESC Printer Support on both RS232 and USB interfaces.
• Data Collection System with vast (practically unlimited)

memory space.

Integrated Milk Collection Station

Automatic Ekomilk Ultra Milk Analyzer Ultrasonic Processor Data Processing Unit Integrated GPRS Module (Optional)

i

VENDORS

MILK

Acknowledgement Slip SMS / Acknowledgement Slip Bank Payment Transfer on Personal Account

MILK COLLECTION POINTS VILLAGE VENDOR CENTERS

COMPANY MANAGING CENTERS

MIDDLE COMPANY CENTERS

FTP/COMPANY SERVER

INTEGRATED MILK COLLECTION ENVIRONMENT

← Vendor List ← Milk Rates ← Rates Management ← Vendor Category ← Pen Drive ← E-mail ← GSM/GPRS ← Vendor List ← Milk Rates ← Rates Management ← Vendor Category HIGH LEVEL MANAGEMENT ← Vendor List ← Milk Rates ← Rates Management ← Vendor Category

CM CENTER

SMS Notification on Payment Receipt

MILK PRODUCERS

BANK

A - Administrator S - Supervisor O - Operator

LOGIN LEVELS DEVICE PROFILES

• Corporate FTP
• Corporate
• Local

CONFIGURATION MENU DEVICE PROFILES

• CORP. GPRS/FTP
• CORP. GPRS

LOCAL A* S O A S O A S O

RATES Manual Rate Generation No No No No No No Yes Yes No Manual Rate Editing No No No No No No Yes Yes No COMMON CONFIG SETTINGS (Printer, Weighing Scale, Data Collection, Time & Date, PC Connection etc.) Update through FTP Yes Yes Yes No No No No No No Update Manually Yes Yes No Yes Yes No Yes Yes No Update through USB Flash drive Yes Yes No Yes Yes No Yes Yes Yes Device Features For viewing only Yes Yes Yes Yes Yes Yes Yes Yes Yes Coll Point Yes Yes No Yes Yes No Yes Yes No Settings Print out Common Settings Yes Yes Yes Yes Yes Yes Yes Yes Yes Extended Settings Yes No No Yes No No Yes Yes No GSM Pin Set/Change, APN Update through Any method Yes Yes No Yes Yes No Yes Yes No FTP/SMTP related Settings & Login password configuration Manual Yes No No Yes No No Yes Yes No Update through USB Flash drive Yes Yes No Yes No No Yes Yes No Update through FTP Yes Yes Yes No No No Yes Yes No DEVICE PROFILES Select Device Profile Yes No No Yes No No Yes No No

REPORTS MENU

Shift Sunnary Report Email/SMS: SendMail, SendSMS Yes No No Yes No No Yes Yes No Account Settings Yes Yes No Yes Yes No Yes Yes No

DATA MANAGEMENT MENU

Download Files (vendors/rates) Via FTP (also check at Power Up) Yes Yes Yes No No No No No No Via Flash Drive Yes Yes No Yes Yes No Yes Yes No Upload Files (DATA/ARCHIVE/DIAG) Via FTP Yes Yes Yes No No No Yes Yes No Via Flash Drive Yes Yes Yes Yes Yes Yes Yes Yes Yes Manual Entry Yes Yes No Yes Yes No Yes Yes No Edit Vendor Yes Yes No Yes Yes No Yes Yes No Add Vendor Yes Yes Yes Yes Yes Yes Yes Yes Yes Backup/Restore Yes Yes No Yes Yes No Yes Yes No Firmware Update Via FTP (also check at Power Up) Yes Yes Yes No No No Yes Yes Yes Flash Drive Yes Yes No Yes Yes No Yes Yes No Format SD Card Yes Yes No Yes Yes No Yes Yes No

CALIBRATION

Yes No No Yes No No Yes No No

SYSTEM

Yes No No Yes No No Yes No No

USER CATEGORY PERMISSIONS

SHIFT SUMMARY REPORT → Use Printer → Use e-mail/SMS* → SETTINGS

This report represents all measurements done within one shift (see the sample on the right site). Records are ordered by milk type and by time within every milk type. Input data:

• Start time
• End time

Calculations: Amount = Rate * Qty. There is an option to edit e-mail and/or SMS Recipients List of Shift Summary Report.

MILK BILL REPORT

Milk Bill represents measurements done within certain period of

• time. Data is ordered by
• vendor. All

measurements done for

• ne vendor are grouped

by milk type. The total milk quantity and payment amount are printed at the end of each milk type. The average value of the milk parameters is printed as

• well. The same

parameters calculated for all milk types supplied by this vendor are printed at the end of the Milk Bill for this vendor.

BILL SUMMARY REPORT

This report is just a summary of Milk Bill report. It represents all measurements done within a period and every line shows the total parameters for every milk vendor. The report ends with grand total parameters.

THANK YOU!

Contact Us:

19, Industrial Area 6000 Stara Zagora, Bulgaria tel..: 0035942 626 019; 00359 888 714 711; fax: 0035942 615564; E-mail: eonbg@eonbg.com; www.eonbg.com
