Smart Grid Infrastructure – Asset Management

  • Dr. Balakrishna Pamulaparthy

Assistant Professor School of Electrical Sciences IIT Bhubaneshwar

slide-2
SLIDE 2

9/16/2018 2

About Myself

Smart Grid Course - Balakrishna. P

  • Dr. Balakrishna Pamulaparthy, PhD

Assistant Professor, School of Electrical Sciences, IIT Bhubaneswar

  • M. Tech and PhD from Indian Institute of Technology, Madras.
  • 10 Years of Industrial Experience at GENERAL ELECTRIC in Design,

Engineering, Application, Validation and R&D in the areas of Smart Grid.

  • Publications: 17 Patents, 6 Journals and 16 Conferences.
  • Recipient of Inventor of the Year Award in 2010, GE Silver Award for

10+ Patents, Ramanujan Young Achiever Award in 2011, Imagination and Courage Award in 2012 and Empower and Inspire Global Award in 2015.

  • Research Interests: Smart Grid, Substation/Distribution Automation,

Grid Monitoring & Data Analytics, Asset Management, DMS, SCADA and AMI.

slide-3
SLIDE 3

9/16/2018 3

Why Smart Grid?

Smart Grid Course - Balakrishna. P

slide-4
SLIDE 4

9/16/2018 4

Smart Grid Definition

Smart Grid Course - Balakrishna. P

slide-5
SLIDE 5

9/16/2018 5

Smart Grid

Smart Grid Course - Balakrishna. P

slide-6
SLIDE 6

9/16/2018 6

Smart Grid…

Smart Grid Course - Balakrishna. P

slide-7
SLIDE 7

9/16/2018 7

Smart Grid…

Smart Grid Course - Balakrishna. P

slide-8
SLIDE 8

9/16/2018 8

Smart Grid Technology Areas

Smart Grid Course - Balakrishna. P

slide-9
SLIDE 9

9/16/2018 9

Smart Grid in Nutshell

Smart Grid Course - Balakrishna. P

slide-10
SLIDE 10

Asset Management Challenges

10 9/16/2018

slide-11
SLIDE 11

Asset Management Future

11 9/16/2018

slide-12
SLIDE 12

Integration of Smart Grid Devices for Improved Asset Management

slide-13
SLIDE 13

Introduction

13

 “New indirect benefits can result from the smart grid devices and systems, when properly integrated with additional smart grid capabilities” – European Commission Research Report, 2012.  “Increased asset data and intelligence should enable advanced control and improved operator understanding” – Power Grid Corporation of India Ltd, Smart Grid Report,2015.

9/16/2018

slide-14
SLIDE 14

Traditional Protection Relay

14 9/16/2018

slide-15
SLIDE 15

Advanced Protection Relay

15

In the Era of Industrial Internet, Protection Relays are not just tripping devices.

9/16/2018

slide-16
SLIDE 16

Advanced Transformer Management System

slide-17
SLIDE 17

Transformer Operation Today…

17

Transformer Electrical Characteristics Transformer Mechanical Characteristics

  • Continuous monitoring of electrical parameters (V, I. P, Q etc.)
  • Internal or external fault detection and electrical data collection
  • Software for fault analysis with electrical data - transient record

and fault report

  • Transformer incipient fault detection using continuous monitoring
  • f single or multiple gas parameters and models
  • Transformer component fault detection using OLTC, Bushing

monitoring devices

  • Software for Transformer condition based monitoring and fleet

management No Convergence of Physics & Chemistry Protection Relay M&D Devices

9/16/2018

slide-18
SLIDE 18

Transformer Relay and DGA

18 9/16/2018

slide-19
SLIDE 19

A Simple Analogy

19

Stressed Heart Blood Test ECG Record 2D-Echo Model TMT - Stress Report

Asset DGA V & I Xfmr Models Reports

9/16/2018

slide-20
SLIDE 20

Novel Integrated Method

Relay

M&D

Convergence of Protection System and M&D System for Advanced Transformer Asset Management

9/16/2018

slide-21
SLIDE 21

Proposed Methodology

21

Bushing Monitor DGA Analyzer

OLTC parameters such as moisture level, current conductive system condition, mechanism timing characteristics, contact wear and insulation condition.

OLTC Monitor

Overcurren t Fault

Event Impact Index

9/16/2018

slide-22
SLIDE 22

Case Study

22

EII = 16.42/20

9/16/2018

slide-23
SLIDE 23

Advanced Motor Management

slide-24
SLIDE 24

Motor Operation Today…

24

Motor Electrical Characteristics Motor Mechanical Characteristics

  • Continuous monitoring of motor parameters (V, I. P, Q etc.)
  • Internal or external fault detection and electrical data collection
  • Software for fault analysis with electrical data - transient record

and fault report

  • Motor incipient fault detection using offline monitoring of

insulation and impedance parameters

  • Motor sub-system fault detection using Vibration monitoring or

ESA devices (online or offline)

  • Software for motor condition based monitoring and fleet

management Protection Relay M&D Devices

9/16/2018

slide-25
SLIDE 25

Motor Mechanical Abnormalities

25 9/16/2018

slide-26
SLIDE 26

Motor Current Signature Analysis

26 9/16/2018

slide-27
SLIDE 27

Integrated M&D in Relay

27

Why converge motor M&D in a P&C IED? With a motor protection IED installed on every critical motor, there are huge cost savings achieved by eliminating the need for:

  • Additional devices to install and maintain
  • Extra sensors or wiring
  • New communication interfaces to SCADA or DCS systems
  • Contact input/output wiring for alarm and control.

9/16/2018

slide-28
SLIDE 28

Broken Rotor Bar Detection

28 9/16/2018

slide-29
SLIDE 29

Insulation Monitoring in Relay

29 9/16/2018

slide-30
SLIDE 30

Faults Detection in Relay

30

Bearing Outer Race Fault Broken Rotor Bar Fault Eccentricity Fault Stator Fault

9/16/2018

slide-31
SLIDE 31

Why Integrated M&D in Relay?

31 9/16/2018

slide-32
SLIDE 32

Why Integrated M&D in Relay?

32 9/16/2018

slide-33
SLIDE 33

Integration of Smart Grid Systems for Improved Asset Management

slide-34
SLIDE 34

Motivation

9/16/2018 34

http://sites.ieee.org/igcc/home/ www.befutureready.com www.elp.com www.sgip.org http://www.smartgridupdate.com/distributionautomation/pdf/Ron-Pate.pdf

Smart Grid Course - Balakrishna. P

slide-35
SLIDE 35

AMI Load Data Modelling

slide-36
SLIDE 36

DA-AMI System Architecture

9/16/2018 36 #Multi-tech Communications for DA-AMI Convergence – Available [Online], http://www.elstersolutions.com/assets/downloads/MultiTechCommunication.pdf Smart Grid Course - Balakrishna. P

slide-37
SLIDE 37

Proposed DPR Method

9/16/2018 37 (hours) Smart Grid Course - Balakrishna. P

slide-38
SLIDE 38

9/16/2018 38

Distribution Power Restoration

Objectives

  • Restore as many loads as possible considering priority of

loads.

  • Do not violate operational and engineering constraints.
  • Maintain load and phase balance within the limits.
  • Compute in a short interval of time.
  • Maintain radial network structure after reconfiguration.
  • Any of the network components should not be over-loaded.

Constraints

  • Proper load allocation of a feeder.
  • Maintain voltage values within the regulatory limits.
  • Priority loads must be restored without compromise.
  • Address security and reliability.
  • Consider distributed generation.
  • Meet load dynamics.

*Inseok Hwang et al, “A Survey of Fault Detection, Isolation and Reconfiguration methods”, IEEE Transactions on Control Systems Technology, Vol. 18, No. 3, pp – 636-653, May 2010.

Smart Grid Course - Balakrishna. P

slide-39
SLIDE 39

Application to DPR*

39

~ ~

Tie Switch Feeder A Feeder B Source A Source B Recloser A Recloser B A1 A2 A3 A4 A5 B5 B4 B3 B2 B1

FD 1 FD 2 FD 4 FD 6 FD 7 FD 3 FD 5 FD 8 FD 9

DPR – Distribution Power Restoration 9/16/2018

slide-40
SLIDE 40

9/16/2018 40

Insights of Proposed DPR Method

  • AMI system consists of thousands of smart meters/sensors installed across each of

the low voltage distribution systems connected to various 11kV feeders through 11kV/400V distribution transformers.

  • It looks illogical to route or send each meter data as feedback to DA system on

communication media.

  • There should be some smart logic in place in order to send only required meter’s

data selectively & strategically as feedback based on DA application need.

Requirements for proposed restoration method:

  • Phase Identification of Meters
  • Load Segmentation and Network mapping
  • AMI data feedback mechanism
  • Feasible WAN based communication link

Smart Grid Course - Balakrishna. P

slide-41
SLIDE 41

https://www.arcgis.com/

Load Segmentation for DPR

Distribution System GIS Based System

DPR – Distribution Power Restoration

slide-42
SLIDE 42

9/16/2018 42

Conclusion

Smart Grid Course - Balakrishna. P

slide-43
SLIDE 43

9/16/2018 43

Future Vision

Smart Grid Course - Balakrishna. P
