Slide 1 / 159 Slide 2 / 159 Pre-Calculus Vectors 2015-03-24 - - PowerPoint PPT Presentation

Slide 1 / 159

Slide 2 / 159

Pre-Calculus

Vectors

www.njctl.org 2015-03-24

Slide 3 / 159

Table of Contents

Intro to Vectors Operations with Vectors Addition Subtraction Dot Product Scalar Multiples Angle Between Vectors 3-Dimensional Space Vectors, Lines, and Planes Vector Equations of Lines Converting Rectangular and Polar Forms

Slide 4 / 159

Intro to Vectors

Return to Table of Contents

Slide 5 / 159

Drawing A Vector

Remember displacement is the distance away from your initial position, it does not account for the actual distance you moved

A vector is always drawn with an arrow at the tip indicating the direction, and the length of the line determines the magnitude.

Intro to Vectors

Slide 6 / 159

Determining magnitude and direction

anti-parallel

All of these vectors have the same magnitude, but vector B runs anti-parallel therefore it is denoted negative A.

Intro to Vectors

Slide 7 / 159

Draw a vector to represent: a plane flying North-East at 500 mph a wind blowing to the west at 50 mph

Intro to Vectors

Teacher

Teacher

Slide 8 / 159

Draw a vector to represent: a boat traveling west at 4 knots a current traveling south at 2 knots

Intro to Vectors

Teacher

Teacher

Slide 9 / 159

1 Which vector represents a car driving east at 60 mph?

A

B C D

Intro to Vectors

Teacher

Teacher

Slide 10 / 159

2 Which vector represents a wind blowing south at 30 mph if the given vector represents a car driving east at 60mph?

A

B C D

Intro to Vectors

Teacher

Teacher

Slide 11 / 159

3 A rabbit runs east 30 feet and then north 40 feet, which vector represents the rabbits displacement from its starting position?

A

B C D

Intro to Vectors

Teacher

Teacher

Slide 12 / 159

There are 2 kinds of vectors drawn on a coordinate grid: Those that start from the origin: Those that don't start at the origin: joins (2 , -4) to (4 , 4)

Intro to Vectors

Slide 13 / 159

A vector can be broken down into its component forces. ux is the horizontal part. uy is the vertical part. In ux = 8 uy = 6

Intro to Vectors

Slide 14 / 159

joins (2 , -4) to (4 , 4)

Intro to Vectors

Teacher

Teacher

Slide 15 / 159

4 Which vector is in standard position?

A

B C D

Intro to Vectors

Teacher

Teacher

Slide 16 / 159

5 What is ?

Intro to Vectors

Teacher

Teacher

Slide 17 / 159

6 What is ?

Intro to Vectors

Teacher

Teacher

Slide 18 / 159

7 What is ?

Intro to Vectors

Teacher

Teacher

Slide 19 / 159

8 What is ?

Intro to Vectors

Teacher

Teacher

Slide 20 / 159

9 What is ?

Intro to Vectors

Teacher

Teacher

Slide 21 / 159

10 What is ?

Intro to Vectors

Teacher

Teacher

Slide 22 / 159

11 What is ?

Intro to Vectors

Teacher

Teacher

Slide 23 / 159

12 What is ?

Intro to Vectors

Teacher

Teacher

Slide 24 / 159

After a vector is broken down into its component forces,the magnitude of the vector can be calculated. ux is the horizontal part. uy is the vertical part. In ux = 8 uy = 6 8 6 = magnitude (length) of

Intro to Vectors

Teacher

Teacher

Slide 25 / 159

A plane is traveling with an eastern component of 40 miles and a northern component of 75 miles, every hour. Draw a representation of this, include the vector of the planes actual path. What is the planes displacement traveled after one hour?

Intro to Vectors

Teacher

Teacher

Slide 26 / 159

13 If a car under goes a displacement of 3 km North and another of 4 km to the East what is the car's displacement?

A 5#2

B 7 C 5 D 4

E 3

3 km 4 km x

Intro to Vectors

Teacher

Teacher

Slide 27 / 159

14 If a car under goes a

displacement of 7 km North and another of 3 km to the West what is the car's displacement?

A

B C D

E

3 km 7 km x

Intro to Vectors

Teacher

Teacher

Slide 28 / 159

15 If a car under goes a

displacement of 12 km South and another of 5 km to the East what is the car's displacement?

A

B C D

E

Intro to Vectors

Teacher

Teacher

Slide 29 / 159

16 What is the magnitude of ?

Intro to Vectors

Teacher

Teacher

Slide 30 / 159

17 What is the magnitude of ?

Intro to Vectors

Teacher

Teacher

Slide 31 / 159

18 What is the magnitude of that connects (2,1) to (5,10)?

Intro to Vectors

Teacher

Teacher

Slide 32 / 159

19 What is the magnitude of that connects (-4,3) to (-5,-3)?

Intro to Vectors

Teacher

Teacher

Slide 33 / 159

20 The components of vector A are given as follows:

A 2.9

B 6.9 C 9.3 D 18.9

E 47.5 The magnitude of A is closest to:

Intro to Vectors

Teacher

Teacher

Slide 34 / 159

21 The components of vector A are given as follows:

A 4.2

B 8.4 C 11.8 D 18.9

E 70.9 The magnitude of A is closest to:

Intro to Vectors

Teacher

Teacher

Slide 35 / 159

Slide 36 / 159

A plane is traveling with an eastern component of 40 miles and a northern component of 75 miles, every hour. Draw a representation of this, include the vector of the planes actual path. How many degrees North of East is the plane traveling? This is called the vectors direction.

Intro to Vectors

Teacher

Teacher

Slide 37 / 159

22 What is the direction of that connects (2,1) to (5,10)?

Intro to Vectors

Teacher

Teacher

Slide 38 / 159

23 What is the direction of that connects (-4,3) to (-5,-3)?

Intro to Vectors

Teacher

Teacher

Slide 39 / 159

24 The components of vector A are given as follows:

A 52.7

B

55.3

C

62.3

D

297.7 E 307.3 The direction of A,measured counterclockwise from the east, is closest to:

Intro to Vectors

Teacher

Teacher

Slide 40 / 159

25 The components of vector A are given as follows:

A 37.3

B

52.7

C

139.6

D

307.3

E

322.7

The direction of A,measured counterclockwise from the east, is closest to:

Intro to Vectors

Teacher

Teacher

Slide 41 / 159

Converting Rectangular and Polar Forms

Return to Table of Contents

Slide 42 / 159

A vector in standard position can be written in 2 ways: When a vector is given as (x,y) it is in rectangular form. When a vector is given (r,#) it is in polar form.

Converting Rectangular and Polar Forms

Slide 43 / 159

Teacher

Teacher

To Convert from Rectangular to Polar

(-6,8)

Converting Rectangular and Polar Forms

Slide 44 / 159

26 Vector A is in standard position and in rectangular form (2,7). What is its magnitude (ie radius)?

Converting Rectangular and Polar Forms

Teacher

Teacher

Slide 45 / 159

27 Vector A is in standard position and in rectangular form (2,7). What is its direction?

Converting Rectangular and Polar Forms

Teacher

Teacher

Slide 46 / 159

28 Vector A is in standard position and in rectangular form (-3,8). What is its magnitude (ie radius)?

Converting Rectangular and Polar Forms

Teacher

Teacher

Slide 47 / 159

29 Vector A is in standard position and in rectangular form (-3,8). What is its direction?

Converting Rectangular and Polar Forms

Teacher

Teacher

Slide 48 / 159

Slide 49 / 159

30 Vector A is in standard position and in polar form (3,70). What is Ax?

Converting Rectangular and Polar Forms

Teacher

Teacher

Slide 50 / 159

31 Vector A is in standard position and in polar form (3,70). What is Ay?

Converting Rectangular and Polar Forms

Teacher

Teacher

Slide 51 / 159

32 Vector A is in standard position and in polar form (3,110). What is A

x?

Converting Rectangular and Polar Forms

Teacher

Teacher

Slide 52 / 159

33 Vector A is in standard position and in polar form (3,110). What is Ay?

Converting Rectangular and Polar Forms

Teacher

Teacher

Slide 53 / 159

Operations with Vectors

Return to Table of Contents

Slide 54 / 159

Scalar Multiples

Return to Table of Contents

Slide 55 / 159

Scalar versus Vector

A scalar has only a physical quantity such as mass, speed, and time. A vector has both a magnitude and a direction associated with it, such as velocity and acceleration. A vector is denoted by an arrow above the variable,

Scalar Multiples

Slide 56 / 159

A car travels East at 50 mph, how far does it go in 3 hours? East at 50 mph is represented by a vector 3 hours is a scalar multiplier, which is why there are 3 vectors. The car traveled 150 miles in 3 hours.

Scalar Multiples

Slide 57 / 159

34 What is speed?

A Vector

B

Scalar

Scalar Multiples

Teacher

Teacher

Slide 58 / 159

35 Which diagram represents a person walking Northeast at 4 mph for 2 hours?

A

B C D

Scalar Multiples

Teacher

Teacher

Slide 59 / 159

When vectors are on the coordinate plane a scalar can be used on the ordered pair(s). joins (2 , -4) to (4 , 4) joins (4, -8) to (8 , 8) What happened to the magnitude? What happen to the direction?

Scalar Multiples

Teacher

Teacher

Slide 60 / 159

Given and Find:

Scalar Multiples

Teacher

Teacher

Slide 61 / 159

36 Given vector =(4, 5) what is

A

(8 , 10)

B

(6 , 7)

C

(16 , 25)

D

(8, 7)

Scalar Multiples

Teacher

Teacher

Slide 62 / 159

37 Given vector =(4, 5) what is

A

(8/3 , 10/3)

B

(2 , 7/3)

C

(16/3 , 25/3)

D

(8/3, 7/3)

Scalar Multiples

Teacher

Teacher

Slide 63 / 159

38 Given vector =(4, 5) what is

A

(1 , 2)

B

(12 , 15)

C

(-12 , 15)

D

(-12, -15)

Scalar Multiples

Teacher

Teacher

Slide 64 / 159

39 Given find

Scalar Multiples

Teacher

Teacher

Slide 65 / 159

Addition

Return to Table of Contents

Slide 66 / 159

Vector Addition

Addition

Slide 67 / 159

Vector Addition Methods

Tail to Tip Method

Addition

Slide 68 / 159

Vector Addition Methods

Move the vectors to represent the following operation. Draw the resultant vector.

Addition

Teacher

Teacher

Slide 69 / 159

Vector Addition Methods

Parallelogram Method Place the tails of each vector against one

• another. If you finish

drawing the parallelogram with dashed lines and draw a diagonal line from the tails to the other end of the parallelogram to find the vector sum.

Addition

Slide 70 / 159

Slide 71 / 159

Given Find the resultant vector:

Addition

Teacher

Teacher

Slide 72 / 159

40 What is the resultant vector for if

A

(5 , 5)

B

(4 , 6)

C

(5 , 6)

D

(4 , 5)

Addition

Teacher

Teacher

Slide 73 / 159

41 What is if

Addition

Teacher

Teacher

Slide 74 / 159

42 The components of vectors

A 5

B #17 C 17 D 10

E 8 and are given as follows: Solve for the magnitude of

Addition

Teacher

Teacher

Slide 75 / 159

Subtraction

Return to Table of Contents

Slide 76 / 159

Anti- Parallel Vectors

Subtraction

Slide 77 / 159

Teacher

Teacher

Subtraction

Slide 78 / 159

Vector Addition Method for Subtraction

Draw the vectors to represent the following operation. Draw the resultant vector.

Subtraction

Teacher

Teacher

Slide 79 / 159

Vector Addition Method for Subtraction

Draw the vectors to represent the following operation. Draw the resultant vector.

Subtraction

Teacher

Teacher

Slide 80 / 159

Vector Addition Method for Subtraction

Draw the vectors to represent the following operation. Draw the resultant vector.

Subtraction

Teacher

Teacher

Slide 81 / 159

Vector Addition Method for Subtraction

Draw the vectors to represent the following operation. Draw the resultant vector.

Subtraction

Teacher

Teacher

Slide 82 / 159

43

A

B

C D

Subtraction

Teacher

Teacher

Slide 83 / 159

44

A

B

C D

Subtraction

Teacher

Teacher

Slide 84 / 159

45

A

B C D

Subtraction

Teacher

Teacher

Slide 85 / 159

Slide 86 / 159

Given Find the resultant vector:

Subtraction

Teacher

Teacher

Slide 87 / 159

46 What is the resultant vector for if

A

(3 , 1)

B

(-3 , -1)

C

(5 , 5)

D

(3 , -1)

Subtraction

Teacher

Teacher

Slide 88 / 159

47 What is if

Subtraction

Teacher

Teacher

Slide 89 / 159

48 The components of vector A and B are given as follows:

A 10.17

B 4.92 C 2.8 D 9.7

E 25 The magnitude of B-A, is closest to:

Subtraction

Teacher

Teacher

Slide 90 / 159

Vector Equations

• f Lines

Return to Table of Contents

Slide 91 / 159

Vector Equation for a Line

R S

Consider the line through R and S. There is a unique congruent vector, in standard position. The difference between any two points on the line is where t is a real number.

Vector Equations of Lines

Slide 92 / 159

Vector Equation for a Line

R S Example: Find the equation of the line through R(2,6) and is parallel to v.

Vector Equations of Lines

Teacher

Teacher

Slide 93 / 159

Draw a graph of the line through (2, 7) and parallel to v=(1,4) Write the equation of the line. Write the equation of the line in parametric form.

Vector Equations of Lines

Teacher

Teacher

Slide 94 / 159

Draw a graph of the line through (3, -7) and parallel to v=(-2,6) Write the equation of the line. Write the equation of the line in parametric form.

Vector Equations of Lines

Teacher

Teacher

Slide 95 / 159

49 Which of the following is the vector equation of the line through (-3, -4) and parallel to u=(6, 1)?

A

(x+4, y+3) = t(6,1)

B

(x-4, y-3) = t(6,1)

C

(x+3, y+4) = t(6,1)

D

(x-3, y-4) = t(6,1)

Vector Equations of Lines

Teacher

Teacher

Slide 96 / 159

50 Which of the following is parametric form of the equation

• f the line through (-3, -4) and parallel to u=(6, 1)?

A

B C D

Vector Equations of Lines

Teacher

Teacher

Slide 97 / 159

51 Which of the following is the vector equation of the line through (5, 2) and parallel to u=( -7, 1)?

A

(x -1, y+7) = t(5,2)

B

(x+7, y-1) = t(5,2)

C

(x+5, y+2) = t(-7,1)

D

(x-5, y-2) = t(-7,1)

Vector Equations of Lines

Teacher

Teacher

Slide 98 / 159

52 Which of the following is parametric form of the equation

• f the line through (5, 2) and parallel to u=( -7, 1)?

A

B C D

Vector Equations of Lines

Teacher

Teacher

Slide 99 / 159

Find the parametric equation of the line through (4, 7) and (2, 8)

Vector Equations of Lines

Teacher

Teacher

Given two points (x1,y1) and (x2,y2), the parametric equations of the line are: x = x1 + t*(x2 - x1) y = y1 + t*(y2 - y1)

Slide 100 / 159

Find the parametric equation of the line through (3, -5) and (8, 9)

Vector Equations of Lines

Teacher

Teacher

Slide 101 / 159

53 Which of the following is a parametric form of the equation

• f the line through ( -2, 0) and (4, 7)?

A

B C D

Vector Equations of Lines

Teacher

Teacher

Slide 102 / 159

54 Which of the following is a parametric form of the equation

• f the line through (4, 9) and (8,3)?

A

B C D

Vector Equations of Lines

Teacher

Teacher

Slide 103 / 159

Find the vector equation of:

Vector Equations of Lines

Teacher

Teacher

Slide 104 / 159

Slide 105 / 159

Dot Product

Return to Table of Contents

Slide 106 / 159

The dot product, also called a scalar product, returns a single numerical value between 2 vectors. Example: Given: Find:

Dot Product

Teacher

Teacher

Slide 107 / 159

Given Find the resultant vector:

Dot Product

Teacher

Teacher

Slide 108 / 159

56Given , find

Dot Product

Teacher

Teacher

Slide 109 / 159

57Given , find

Dot Product

Teacher

Teacher

Slide 110 / 159

58Given , find

Dot Product

Teacher

Teacher

Slide 111 / 159

Vectors are perpendicular/orthogonal/normal, if their dot product is zero.

If and Are the vectors perpendicular? Justify your answer.

Dot Product

Teacher

Teacher

Slide 112 / 159

Vectors form an

• btuse angle if

dot product < 0 Vectors form an acute angle if dot product > 0

If and What kind of angle do the vectors form? Justify your answer.

Dot Product

Teacher

Teacher

Slide 113 / 159

Slide 114 / 159

59Are these vectors perpendicular?

Yes No

Dot Product

Teacher

Teacher

Slide 115 / 159

60Are these vectors orthogonal?

Yes No

Dot Product

Teacher

Teacher

Slide 116 / 159

61Are these vectors normal?

Yes No

Dot Product

Teacher

Teacher

Slide 117 / 159

62What kind of angle is formed by the following vectors?

A

acute

B

right

C

• btuse

Dot Product

Teacher

Teacher

Slide 118 / 159

63What kind of angle is formed by the following vectors?

A

acute

B

right

C

• btuse

Dot Product

Teacher

Teacher

Slide 119 / 159

64What kind of angle is formed by the following vectors?

A

acute

B

right

C

• btuse

Dot Product

Teacher

Teacher

Slide 120 / 159

Angle Between Vectors

Return to Table of Contents

Slide 121 / 159

Angle Between Vectors is the dot product of the vectors is the product of the magnitudes

Angle Between Vectors

Slide 122 / 159

Find the angle between and

Angle Between Vectors

Teacher

Teacher

Slide 123 / 159

Recall that during the study of dot product that an angle was obtuse if its dot product was negative. cos-1 returns an obtuse value only if And the only way for is if

Angle Between Vectors

Slide 124 / 159

65Find the angle between and

Angle Between Vectors

Teacher

Teacher

Slide 125 / 159

66Find the angle between and

Angle Between Vectors

Teacher

Teacher

Slide 126 / 159

67Find the angle between and

Angle Between Vectors

Teacher

Teacher

Slide 127 / 159

68A cruise ship is being towed by 2 tug boats. The first is pulling the ship 100m east and 20m north. The second is pulling the ship 40m east and 75m north. What is the angle between the tow lines?

Angle Between Vectors

Teacher

Teacher

Slide 128 / 159

69A cruise ship is being towed by 2 tug boats. The first is pulling the ship 100m east and 20m north. The second is pulling the ship 40m east and 75m north. What is the angle the ship is going relative to east?

Angle Between Vectors

Teacher

Teacher

Slide 129 / 159

3-Dimensional Space

Return to Table of Contents

Slide 130 / 159

y z x (-) (-) (-) (+) (+) (+)

3-Dimensional Space

Slide 131 / 159

y z x (-) (-) (-) (+) (+) (+) Graph (2,3,4)

3-Dimensional Space

Slide 132 / 159

y z x (-) (-) (-) (+) (+) (+) Graph (-2, 3, -4)

3-Dimensional Space

Slide 133 / 159

y z x (-) (-) (-) (+) (+) (+) Graph (0,3,5)

3-Dimensional Space

Slide 134 / 159

Slide 135 / 159

70What are the coordinates of the point?

A

(1,3,6)

B

(1,6,3)

C

(3,1,6)

D

(3,6,1)

1 3 6

3-Dimensional Space

Teacher

Teacher

Slide 136 / 159

71What are the coordinates of the point?

A

(5,0,2)

B

(0,2,5)

C

(2,0,5)

D

(2,5,0)

2 5

3-Dimensional Space

Teacher

Teacher

Slide 137 / 159

72What is the distance between (2,3,4) and (-2,-3,-4)?

3-Dimensional Space

Teacher

Teacher

Slide 138 / 159

73What is the distance between (3,0,7) and (-6,-2,5)?

3-Dimensional Space

Teacher

Teacher

Slide 139 / 159

74What is the length of a diagonal ofa box with dimesions 4 x 6 x 7?

3-Dimensional Space

Teacher

Teacher

Slide 140 / 159

Slide 141 / 159

Slide 142 / 159

Slide 143 / 159

Slide 144 / 159

Vectors, Lines, and Planes

Return to Table of Contents

Slide 145 / 159

Vector Operations in 3-Space Addition: Subtraction: Scalar Multiplication: Dot Product: Angle Between Vectors: Orthogonal Vectors: Dot product =0

Vectors, Lines, & Planes

Slide 146 / 159

Find: What is the angle between and

Vectors, Lines, & Planes

Teacher

Teacher

Slide 147 / 159

Lines in Space Point P = (2, 6, -3) is on line m and parallel to v = (4, -4, 2). Write the equation of m. Vector Equation Parametric

Vectors, Lines, & Planes

Slide 148 / 159

Equation of a Plane

3x +4y +2z =12

4 3 6

The intersection of the plane and the xy-plane is

• line. So although the

figure looks like a triangle it continues forever.

Vectors, Lines, & Planes

Slide 149 / 159

Equation of a Plane

3x +4y +2z =12

4 3 6

The vector v=(3, 4, 2) is perpendicular to the plane.

Vectors, Lines, & Planes

Slide 150 / 159

Example: Write the equation of the line perpendicular to 3x +8y - 12z =24 passing through P=(1, -5, 7).

Vectors, Lines, & Planes

Teacher

Teacher

Slide 151 / 159

Example: Write the equation of plane passing through (1, 3, 5) and perpendicular to v = (-2, 3, 4).

Vectors, Lines, & Planes

Teacher

Teacher

Slide 152 / 159

79What is the x-intercept of 3x + 8y + 12z = 24?

Vectors, Lines, & Planes

Teacher

Teacher

Slide 153 / 159

80What is the y-intercept of 3x + 8y + 12z = 24?

Vectors, Lines, & Planes

Teacher

Teacher

Slide 154 / 159

81What is the z-intercept of 3x + 8y + 12z = 24?

Vectors, Lines, & Planes

Teacher

Teacher

Slide 155 / 159

82Which is the equation of the line perpendicular to 3x +8y +12z = 24 and passing through (2, -4, 6)?

A

(x+2, y-4, z+6)=t(3, 8, 12)

B

(x-2, y+4, z-6)=t(3, 8, 12)

C

(x+2, y+4, z+6)=t(3, 8, 12)

D

(x-2, y-4, z-6)=t(3, 8, 12)

Vectors, Lines, & Planes

Teacher

Teacher

Slide 156 / 159

83Which is the equation of the line perpendicular to x -2y +7z = 14 and passing through (-1, 4, -8)?

A

(x+1, y-4, z+8)=t(1, -2, 7)

B

(x+1, y-4, z+8)=t(-1, 2, -7)

C

(x-1, y+4, z-8)=t(1, -2, 7)

D

(x-1, y+4, z-8)=t(-1, 2, -7)

Vectors, Lines, & Planes

Teacher

Teacher

Slide 157 / 159

Cross Product 2 non-parallel (or anti-parallel) vectors lie in one plane. The Cross Product finds a vector perpendicular to that plane.

Vectors, Lines, & Planes

Slide 158 / 159

Cross Product Find a vector perpendicular to plane formed by

Vectors, Lines, & Planes

Teacher

Teacher

Slide 159 / 159

84Which of the following is perpendicular to the plane formed by a= (3, -1, 2) and b= (4, -5, 6)

A

B C D

Vectors, Lines, & Planes

Teacher

Teacher
