Click to edit Master title style Mobile Wireless Ultrasound with GPU Beamforming Jesper Mosegaard , PhD Head of Computer Graphics Lab Alexandra Institute Denmark The Alexandra Institute Click to edit Master title style Private

slide-1
SLIDE 1

Click to edit Master title style

Jesper Mosegaard, PhD Head of Computer Graphics Lab Alexandra Institute Denmark

Mobile Wireless Ultrasound with GPU Beamforming

slide-2
SLIDE 2

Click to edit Master title style

  • Private not-for-profit company within IT

– Technology transfer from University research through GTS institutes (Danish model)

  • Application oriented research
  • Consultancy for companies

The Alexandra Institute

slide-3
SLIDE 3

Click to edit Master title style

FutureSonic

  • ” A new platform and

business model for

  • n-demand diagnostic

ultrasound imaging“

  • 2013-2018
  • Budget: 23 mio US$

19/03/15 3

slide-4
SLIDE 4

Click to edit Master title style

  • Center for Fast Ultrasound Imaging, Technical

University of Denmark

– Martin Christian Hemmsen – Borislav G. Tomov – Jørgen Arendt Jensen

  • BK Medical

– Carsten Kjær

  • Computer Graphics Lab, Alexandra Institute

– Thomas Kim Kjeldsen – Lee Lassen – Jesper Mosegaard

Joint work

19/03/15 Page 4

slide-5
SLIDE 5

Click to edit Master title style

Presentation based on publications

19/03/15 Page 5

  • M. C. Hemmsen, T. Kjeldsen, L. Larsen, C. Kjaer, B. G. Tomov, J. Mosegaard,

and J. A. Jensen, “Implementation of synthetic aperture imaging on a hand- held device,” in Proceedings of 2014 ieee international ultrasonics symposium, 2014, pp. 2177-2180.

  • T. Kjeldsen, L. Lassen, M. C. Hemmsen, C. Kjaer, B. G. Tomov, J. Mosegaard, and J. A. Jensen,

“Synthetic aperture sequential beamforming implemented on multi-core platforms,” in Proceedings of 2014 ieee international ultrasonics symposium, 2014, pp. 2181-2184.

slide-6
SLIDE 6

Click to edit Master title style

Medical Ultrasound

19/03/15 6 http://www.bkmed.com/products_en.htm

slide-7
SLIDE 7

Click to edit Master title style

Mobile transducer

slide-8
SLIDE 8

Click to edit Master title style

Leveraging disruptive technology

19/03/15 8

slide-9
SLIDE 9

Click to edit Master title style

Ultrasound

  • From acoustic (pressure) waves to images

19/03/15 9 http://www.sensorwiki.org/doku.php/sensors/ultrasound

Medium Velocity (m/ sec) Fat 1450 Water 1480 Soft tissue 1540 Kidney 1560 Blood 1570 Muscle 1580 Bone 4080

slide-10
SLIDE 10

Click to edit Master title style

Beamforming to reconstruct images

19/03/15 10

slide-11
SLIDE 11

Click to edit Master title style

Shooting for a number of scanlines

19/03/15 Page 11

slide-12
SLIDE 12

Click to edit Master title style

Dynamic Receive beamforming

19/03/15 Page 12 19/03/15 Page 12

Scanline Dynamic focus point Multiple transducer elements

slide-13
SLIDE 13

Click to edit Master title style

  • Traditional beamforming requires a high data bandwidth.
  • A typical system could have 128 channels and use a 12-

bit 40 MHz sampling system.

  • This generates 128 × 40 × 106 Hz × 2B = 9.54 GB/s

Beamforming

19/03/15 Page 13

slide-14
SLIDE 14

Click to edit Master title style

  • Simple first stage

– Single focal point for both transmit and receive

  • Advanced second stage

– combining information from multiple first stage focused scan lines

  • Reduction in data-transfer requirement

– Reduced by a factor of receive elements (192)

SASB – dual beamforming

19/03/15 Page 14

  • M. C. Hemmsen, J. M. Hansen, and J. A. Jensen, “Synthetic Aperture

Sequential Beamformation applied to medical imaging using a multi element convex array transducer,” in EUSAR , Apr. 2012, pp. 34–37.

slide-15
SLIDE 15

Click to edit Master title style

Algorithmic engineering

19/03/15 15

slide-16
SLIDE 16

Click to edit Master title style

  • 1. stage: Fixed focus transmit and receive

19/03/15 Page 16

First stage line Fixed focus point Receiver r receives at time a+2*b +c a b c

slide-17
SLIDE 17

Click to edit Master title style

  • 2. stage: reconstruct focus

19/03/15 Page 17

  • 1. Find index

scanline entries

  • 2. Add contribution
slide-18
SLIDE 18

Click to edit Master title style

The math behind it

19/03/15 Page 18

slide-19
SLIDE 19

Click to edit Master title style

for all image samples p with polar coordinates (i,j) for all first stage scanlines k a = calculateWeight(i,k) d = calculateDelay(i,k) s = getScanline(d,k) l(i,j) += a*s

Pseudo code

19/03/15 Page 19

slide-20
SLIDE 20

Click to edit Master title style

Three implementations

19/03/15 Page 20

AVX Multithreaded

slide-21
SLIDE 21

Click to edit Master title style

Benchmark, simple implementation

19/03/15 Page 21

600,000 ¡ 2950 ¡ 699 ¡ 3.05 ¡ 0 ¡ 1 ¡ 10 ¡ 100 ¡ 1,000 ¡ 10,000 ¡ 100,000 ¡ 1,000,000 ¡ Matlab ¡ C ¡(1 ¡thread) ¡ C ¡(8 ¡threads) ¡ OpenCL ¡ ms ¡per ¡frame ¡

Simple ¡

Simple ¡

Intel Core i7 2600 Nvidia GTX 680 GPU

slide-22
SLIDE 22

Click to edit Master title style

  • Sampling the beamforming directly in the scan line sample

locations

Algorithmic optimization

19/03/15 Page 22

slide-23
SLIDE 23

Click to edit Master title style

Weights and delays precalculated

19/03/15 Page 23

r k Apodization Delays r k

slide-24
SLIDE 24

Click to edit Master title style

l = 0 for all image samples p with polar coordinates (i,j) for all first stage scanlines k - up to N(ri) a = getWeight(i,k) if a=0 then break d = getDelay(i,k) s = getScanline(d,j+k) l(i,j) += a*s if (k>0) then s = getScanline(d,j-k) l(i,j) += a*s

Pseudo code

19/03/15 Page 24

slide-25
SLIDE 25

Click to edit Master title style

Benchmark, Optimization

19/03/15 Page 25

600,000 ¡ 2950 ¡ 699 ¡ 3.05 ¡ 20.9 ¡ 5.4 ¡ 0.49 ¡ 0 ¡ 1 ¡ 10 ¡ 100 ¡ 1,000 ¡ 10,000 ¡ 100,000 ¡ 1,000,000 ¡ Matlab ¡ C ¡(1 ¡thread) ¡ C ¡(8 ¡threads) ¡ OpenCL ¡ ms ¡per ¡frame ¡ Simple ¡ OpAmizaAon ¡

Intel Core i7 2600 Nvidia GTX 680 GPU

slide-26
SLIDE 26

Click to edit Master title style

Resulting image quality

19/03/15 Page 26

Matlab SIMD/Multicore OpenGL OpenCL RMSE 0.0044 0.0042 0.0040 PSNR 47.23dB 47.79dB 48.01dB

slide-27
SLIDE 27

Click to edit Master title style

Going mobile (OpenGL ES 3.0)

19/03/15 Page 27

slide-28
SLIDE 28

Click to edit Master title style

Mobile hardware

19/03/15 Page 28

LG G2 Samsung Galaxy Tab Samsung Nexus 10 Nvidia Jetson TK1 HTC Nexus 9 SoC Snadragon 800 Exynos 5 Exynos 5220 Tegra K1 Tegra K1 GPU Adreno 300 Mali T628 Mali T604 Kepler Kepler Screen 1920x1080 2560x1600 2560x1600 1920x1080 2048x1536 OS Android Android Android Linux4Tegra Android

slide-29
SLIDE 29

Click to edit Master title style

  • Need 25.3 MB/s à IEEE 802.11ac

Mobile WIFI capabilities

19/03/15 Page 29

28.8 ¡ 18.5 ¡ 11.2 ¡ 43.4 ¡ 35 ¡ 0 ¡ 5 ¡ 10 ¡ 15 ¡ 20 ¡ 25 ¡ 30 ¡ 35 ¡ 40 ¡ 45 ¡ 50 ¡ LG ¡G2 ¡ Galaxy ¡Tab ¡Pro ¡ Nexus ¡10 ¡ ¡ Jetson ¡TK1 ¡+ ¡Intel ¡ 7260HMW ¡ Nexus ¡9 ¡ MB/s ¡

WIFI ¡throughput ¡

slide-30
SLIDE 30

Click to edit Master title style

Mobile performance

19/03/15 Page 30

0 ¡ 10 ¡ 20 ¡ 30 ¡ 40 ¡ 50 ¡ 60 ¡ 70 ¡ LG ¡G2 ¡(Adreno ¡330) ¡ Galaxy ¡Tab ¡Pro ¡(Mali ¡ T628) ¡ Nexus ¡10 ¡(Mali ¡T604) ¡ Jetson ¡TK1 ¡(Tegra ¡K1) ¡ Nexus ¡9 ¡(Tegra ¡K1) ¡ ms ¡

Timings ¡

Scanconversion ¡ BeamformaAon ¡ IQ ¡demodulaAon ¡ Datatransfer ¡ Total ¡Aming ¡

slide-31
SLIDE 31

Click to edit Master title style

Going mobile, Nexus 9

19/03/15 Page 31

slide-32
SLIDE 32

Click to edit Master title style

Digital or wireless?

19/03/15 32

slide-33
SLIDE 33

Click to edit Master title style
