shows: Finger Thoracostomy Vs Chest Tube Insertion Vs Needle - - PowerPoint PPT Presentation

What the evidence shows: Finger Thoracostomy Vs Chest Tube Insertion Vs Needle Decompression

Cynthia Griffin D.O., EMT-P University of Wisconsin MedFlight Fellow 2014 April 21, 2015

Objectives

• Review a quick history of trauma chest

decompression

• Review the procedure, pathophysiology, &

complications that can occur with needle thoracostomy (NT) while reviewing the literature

• Discuss if NT mandates tube thoracostomy (TT)
• Review the prehospital literature on NT vs TT
• Review the simple thoracostomy (ST) procedure

and the literature behind this

• Discussion and Questions

• M. Fitzgerald et al. Injury, Int. J. Care Injured (2008) 39, 9—20

Possible Positions of Needle Thoracocentesis

M Fitzgerald , Injury, Int. J. Care Injured (2008) 39, 9—20

Possible Positions of Needle Thoracocentesis

M Fitzgerald , Injury, Int. J. Care Injured (2008) 39, 9—20

German Study N=54 N=51

N=111 N=110 N=1

Possible Positions of Needle Thoracocentesis

M Fitzgerald , Injury, Int. J. Care Injured (2008) 39, 9—20

Possible Positions of Needle Thoracocentesis

M Fitzgerald , Injury, Int. J. Care Injured (2008) 39, 9—20

Possible Positions of Needle Thoracocentesis

M Fitzgerald , Injury, Int. J. Care Injured (2008) 39, 9—20

Injury, Int. J. Care Injured (2008) 39, 9—20 Emerg Med J (2005);22:788 N=25

http://3.bp.blogspot.com/-D7PpDFIofPc/VLT_ikG0v- I/AAAAAAAAJTM/ERLVw5aSsCk/s1600/intercostal_space.jpg

N=75

“Generally safe and rapid procedure” N=114

39 was 0.2% of their calls

“Judicious decompression prior to definitive care in the ED is a potentially life saving maneuver in the paramedics armamentarium”

N=39

Injury, Int. J. Care Injured (2008) 39, 9—20

Now, lets take a look at Chest Tubes…

Picture courtesy

• f Mr Ian Civil

Picture courtesy of Mr Adrian Pick

Injury, Int. J. Care Injured (2008) 39, 9—20

N=1

N=51

“78% w neg CXR initially s/p NT developed PTX of which 2 were tPTX”

“The laws of physics dictate that the clinician should consider PTX expansion as a risk assoc. w intratransport ascent and decreasing ambient pressure”

N=66

belly

“With proper technique we consider pre-hospital TT to be a safe technique for the Rx of suspected tPTX w/out increased risk of iatrogenic injury.”

N=76

“There was no significant difference in the rate of malposition in the on scene vs in hospital placed chest tubes”

N = 24scene, 77 ED

“NT generally safe and rapid rx for tPTX in field TT should be adjunctive if NT fails & can be performed w out complications or worsening outcomes” “TT was associated with less DOA, than NT”

N=106 TT, 169 NT

“Aeromedical crews appear to appropriately select MTVs to undergo field NT or TT. “

N = 136

“Swine model of thoracic insufflation showed NT w High failure rate for relief of tension physiology & for Rx of the tPTX induced PEA which was due to both mechanical failure & inadequate evacuation.”

N=40

“Prehospital use of TT by qualified professionals does not introduce additional risks of complications compared w/in Hosp therefore is a lifesaving & valuable addition to prehospital care.”

N > 162

• TT on scene vs ED
• “There appeared to be no differences

between chest tubes inserted in the emergency room or at the scene”

• Beware of the complications with TT ~13

http://www.trauma.org/archive/thoracic/images/chestdrain01.jpg

http://www.trauma.org/archive/thoracic/CHESTdrain.html

N=45

“Demonstrated ST to be a safe & effective method of chest drainage without major complications or infections related to field

• thoracostomy. Moreover,

no recurrent tension PNX

• ccurred”

N=55

“Finger Thoracostomy” 10-30-2013

Summary of Recommendations

• Not all rushes of air means NT

is successful.

• NT has limitations although

may be used as a temporizing measure.

• Decompression with

breaching the pleural space is definitive treatment for tPTX.

• Giving them the finger with

ST has data supporting this as effective and safe.

References

• Biewener A, Aschenbrenner U, Rammelt S, Grass R, Zwipp H. Impact of helicopter transport and hospital level on mortality of polytrauma patients. J Trauma 2004; 56:94–98.
• Delooz HH. Training manual: emergency medicine residency. Leuven, Belgium: University Department of Emergency Medicine; 1991. [Context Link]
• Fitzgerald M et al. Pleural decompression and drainage during trauma reception and resuscitation. Injury, Int. J. Care Injured (2008) 39, 9—20
• Fuld H. Simple device for control of tension pneumothorax. BMJ. 1944;2:503.3
• http://www.ctsnet.org/article/history-thoracic-drainage-ancient-greeks-wound-sucking-drummers-digital-monitoring
• Ferrie et al. The right place in the right space. Awareness of Site of needle thoracosentesis. Emerg Med J 2002;19:176-177
• Ferrie E.P., Collum N., and McGovern S.: The right place in the right space? Awareness of site for needle thoracocentesis. Emerg Med J 2005; 22: pp. 788-789
• Deakin C.D., Davies G., and Wilson A.: Simple Thoracostomy Avoids Chest Drain Insertion in Prehospital Trauma. J Trauma 1995; 39: pp. 373-374
• Heng K., Bystrzycki A., Fitzgerald M., et al: Complications of intercostal catheter insertion using EMST techniques for chest trauma ANZ. J Surg 2004; 74: pp. 420-423
• Beckett A, Savage E, Pannell D, et al. Needle Decompression for Tension Pneumothorax in Tactical Combat Casualty Care: Do Catheters Placed in the Midaxillary Line Kink More Often Than Those in

the Midclavicular Line? The Journal of Trauma: Injury, Infection, and Critical Care 2011;71:S408–12. doi:10.1097/TA.0b013e318232e558 [PMID 22071996]

• S. Bitten, S.H. Palmer, T.M. Snow. Needle thoracocentesis in tension pneumothorax; insufficient cannula length and potential failures, Injury, 27 (1996), pp321-322
• Givens ML. Needle Thoracostomy: Implications of Computed Tomography Chest Wall Thickness. Academic Emergency Medicine 2004;11:211–3. doi:10.1197/j.aem.2003.09.015 [PMID 14759970]
• Stevens RL, Rochester AA, Busko J, et al. Needle Thoracostomy for Tension Pneumothorax: Failure Predicted by Chest Computed Tomography. Prehosp Emerg Care 2009;13:14–7.

doi:10.1080/10903120802471998 [PMID 19145519]

• download.springer.com/static/pdf/222/art%253A10.1007%252Fs00134-014-3434-1.pdf?auth66=1425310437_db07b031374ad1de2ee348ad76bab12e&ext=.pdf
• Waydhas C, Sauerland S. Prehospital Decompression for Susupected Tension Pneumothorax, Resuscitation 2007, Jan;72 (1) 11-25 Epub 2006 Nov 22. PMID: 17118508
• Herron H et al. Prehospital Decompression for Suspected Tension Pneumothorax. Air Medical Journal: 14:2, April-June 1995
• Eckstein M., Suyehara D. Needle Thoracostomy in the PreHospital Setting. Prehospital Emergency Care 1998;2:132-135
• Warner KJ, Copass MK, Bulger EM. Paramedic Use of Needle Thoracostomy in the prehospital environment. Prehospital emergency care, vol 12 number 2, april/june 2008
• Leigh-Smith S., and Harris T.: Tension pneumothorax, time for a rethink? Emerg Med J 2005; 22: pp. 8-16
• Beards S.C., and Lipman J.: Decreased cardiac index as an indicator of tension pneumothorax in the ventilated patient. Anaesthesia 1994; 49: pp. 137-141
• Struck MF et al. Bilateral False-Positive Tube Thoracostomy in Helicopter Emergency Medical Services. Air Medical Journal Assoc. Editorial 2015
• Paul AO et al. Malfunction of a Heimlich flutter valve causing tension pneumothorax: case report of a rare complication. Patient Safety in Surgery. 2010:10;8
• Dominguez KM et al. Is routine thoracostomy necessary after prehospital need decompression for tension pneumothorax?. American Journal of Surgery (2013) 205: pp 329-332
• Braude D, Tutera D, Tawil I, Pirkl G. Air transport of patients with pneumothorax: is tube thoracostomy required before flight?. Air Med J. 2014 Jul-Aug;33(4):152-6. doi: 10.1016/j.amj.2014.04.009.
• Knotts D et al. Pneumothorax Volume Expansion in Helicopter Emergency Medical Services Transport. Air Medical Journal 32:3, 2013
• Schmidt, U et al. Chest Tube Decompression of Blunt Chest Injuries by Physicians in Field: Effectiveness and Complications. Journal of Trauma-Injury Infection & Critical Care Jan 1998, Vol 44 Issue 1

pp98-100

• Huber-Wagner S, et al. Emergency Chest Tube Placement in Trauma Care – Which approach is preferable? Resuscitation June 28 2006
• Barton, ED, Epperson, M, Hoyt, BD, Fortiage, D, Rosen P. PreHospital Needle aspiration and tube thoracostomy in trauma victims: a six year experience with aeromedical crews. Journal of

Emergency Medicine Vol 13, No 2, pp155-161; 1995

• Davis, D et al. The safety and efficacy of prehospital needle and tube thoracostomy by aeromedical personnel. Prehospital Emergency Care [1090-3127] Davis yr:2005 vol:9 iss:2 pg:191 -7
• Martin M., Satterly S., Inaba K., Blair K. Does Needle Thoracostomy provide adequate and effective decompression of tension pneumothorax? Journal of Trauma Acute Care Surgery 2012
• Spanjersberg W et al. Prehospital Chest Tube Thoracostomy: Effective treatment or Additional Trauma? Journal of Trauma-Injury Infection & Critical Care. July 2005, Vol 59 Issue 1, pp96-101
• Aylwn CJ et al. Pre-hospital and in-hospital thoracostomy: indications and complications. Ann R Coll Surg Engl 2008;90:54-57
• Waydhas C, Sauerland S. Pre-Hospital pleural decompression and chest tube placement after blunt trauma: a systematic review. Resuscitation 2006
• Deakin C.D., Davies G., Wilson A. Simple Thoracostomy avoids chest drain insertion in Prehospital Trauma. The Journal of trauma: Injury, Infection and Critical Care. Vol 39 (2), August 1995, pp 373-

374

• Massuratti D, et al. Simple thoracostomy in prehospital trauma management is safe and effective: a 2 yr experience by helicopter emergency medical crews, European Journal of Emergency

Medicine Vol 13 No 5. 2006 ,pp276-280

• Karrer A., et al. Simple Thoracostomy: Moving Beyond Needle Decompressionin Traumatic Cardiac Arrest. Journal of mergency Medical Services. 3-28-2014
• Weingart S. “Finger Thoracostomy Podcast” emcrit.org 10-30-2013
