SLIDE 1

Sequential Monte Carlo Methods “Particle Filter”

Martin Ulmke

Head of Research Group Distributed Sensor Systems Sensor Data and Information Fusion Fraunhofer FKIE Lecture: Introduction to Sensor Data Fusion 12 December 2018

SLIDE 2

Inhalt

1

Dynamic State Estimation Problem setting Conditional Probability Density:

2

Monte Carlo Methods

3

Sequential Bayesian Estimation Linear Gaussian Systems Grid-based methods Non-linear, non-Gaussian systems

4

Sequential Monte Carlo Methods “Sequential Importance Sampling”, SIS “Sampling Importance Resampling”, SIR

5

Multitarget Tracking “Combinatorial Desaster” Probability Hypothesis Density

6

Extensions and Variants of Particle Filters

7

Summary

8

Literatur

1/33

SLIDE 3

Dynamic State Estimation Problem setting

Dynamic State Estimation

Zustandsraum Zeit t Zieltrajektorie (unbekannt) t=0 k

Target trajectory: X(t)

2/33

SLIDE 4

Dynamic State Estimation Problem setting

Dynamic State Estimation

Zustandsraum Zeit t Zieltrajektorie (unbekannt) t=0 k Messungen k=1 . k=2 . . Falschalarm Ausfaller

Target trajectory: X(t) Measurements: Z1:k = {z1, · · · , zk}

2/33

SLIDE 5

Dynamic State Estimation Problem setting

Dynamic State Estimation

Zustandsraum Zeit t Zieltrajektorie (unbekannt) t=0 k Messungen k=1 . k=2 . . Wahrsch.-Dichte

Target trajectory: X(t) Measurements: Z1:k = {z1, · · · , zk} Probability density: p(X0:k|Z1:k) with X0:k ≡ {x0, · · · , xk}

2/33

SLIDE 6

Dynamic State Estimation Conditional Probability Density:

Conditional Probability Density: p(X0:k|Z1:k) contains our collective knowledge on the target state X0:k = {x0, · · · , xk} at time instances tj (j = 1, · · · , k), given measurements Z1:k ≡ {z1, · · · , zk} and given prior knowledge , e.g., about target dynamics.

3/33

SLIDE 7

Dynamic State Estimation Conditional Probability Density:

Conditional Probability Density: p(X0:k|Z1:k) contains our collective knowledge on the target state X0:k = {x0, · · · , xk} at time instances tj (j = 1, · · · , k), given measurements Z1:k ≡ {z1, · · · , zk} and given prior knowledge , e.g., about target dynamics. Specific marginalized densities:: p(xk|Z1:k) =

p(X0:k|Z1:k) dX0:k−1

filter estimation p(xj|Z1:k) =

p(X0:k|Z1:k)

i=j dxi

retrodiction (j < k) Expectation values: E [f (X0:k)] =

p(X0:k|Z1:k) f (X0:k) dX0:k

3/33

SLIDE 8

Dynamic State Estimation Conditional Probability Density:

Conditional Probability Density: p(X0:k|Z1:k) contains our collective knowledge on the target state X0:k = {x0, · · · , xk} at time instances tj (j = 1, · · · , k), given measurements Z1:k ≡ {z1, · · · , zk} and given prior knowledge , e.g., about target dynamics. Specific marginalized densities:: p(xk|Z1:k) =

p(X0:k|Z1:k) dX0:k−1

filter estimation p(xj|Z1:k) =

p(X0:k|Z1:k)

i=j dxi

retrodiction (j < k) Expectation values: E [f (X0:k)] =

p(X0:k|Z1:k) f (X0:k) dX0:k

In general, integrals not analytically solvable ⇒ “Monte Carlo Methods” Replace integral by a sum of weighted “random paths”. E [f (X0:k)] ≈

N

i=1

w (i)

k f (X(i) 0:k)

⇔ p(X0:k|Z1:k) ≈

N

i=1

w (i)

k δ(X0:k − X(i) 0:k)

3/33

SLIDE 9

Monte Carlo Methods Zustandsraum Zeit t Zieltrajektorie (unbekannt) t=0 k Wahrsch.-Dichte k=1 . k=2 . . Teilchen-Trajektorien

Random path (trajectory): X(i)

0:k

Weight: w (i)

k

p(X0:k|Z1:k) ≈

N

i=1

w (i)

k δ(X0:k − X(i) 0:k)

4/33

SLIDE 10

Monte Carlo Methods Zustandsraum Zeit t Zieltrajektorie (unbekannt) t=0 k Wahrsch.-Dichte k=1 . k=2 . . Teilchen-Trajektorien

Random path (trajectory): X(i)

0:k

Weight: w (i)

k

p(X0:k|Z1:k) ≈

N

i=1

w (i)

k δ(X0:k − X(i) 0:k)

How to determine X(i)

0:k and w (i) k ?

4/33

SLIDE 11

Monte Carlo Methods

Sampling a) simple sampling: X(i)

0:k equally distributed

w (i)

k

∝ p(X(i)

0:k|Z1:k)

→ very inefficient

X p

5/33

SLIDE 12

Monte Carlo Methods

Sampling a) simple sampling: X(i)

0:k equally distributed

w (i)

k

∝ p(X(i)

0:k|Z1:k)

→ very inefficient

X p

b) perfect sampling: X(i)

0:k ∼ p(X(i) 0:k|Z1:k)

ptimal sampling

w (i)

k

= 1/N

f phase space

→ sampling ∼ p difficult

X p

5/33

SLIDE 13

Monte Carlo Methods

Sampling a) simple sampling: X(i)

0:k equally distributed

w (i)

k

∝ p(X(i)

0:k|Z1:k)

→ very inefficient

X p

b) perfect sampling: X(i)

0:k ∼ p(X(i) 0:k|Z1:k)

ptimal sampling

w (i)

k

= 1/N

f phase space

→ sampling ∼ p difficult

X p

c) importance sampling: X(i)

0:k ∼ q(X(i) 0:k|Z1:k)

w (i)

k

∝

p(X(i)

0:k |Z1:k )

q(X(i)

0:k |Z1:k )

→ q arbitrary (in principle)

X p q

5/33

SLIDE 14

Sequential Bayesian Estimation

Often, quantities at time step k can be calculated recursively from the former time step k − 1.

p(X0:k|Z1:k) =

1 p(zk |Z1:k−1)

p(zk|X0:kZ1:k−1) p(X0:k|Z1:k−1) (Bayes)

6/33

SLIDE 15

Sequential Bayesian Estimation

Often, quantities at time step k can be calculated recursively from the former time step k − 1.

p(X0:k|Z1:k) =

1 p(zk |Z1:k−1)

p(zk|X0:kZ1:k−1) p(X0:k|Z1:k−1) (Bayes) ∝ p(zk|X0:kZ1:k−1) p(xk|X0:k−1Z1:k−1) p(X0:k−1|Z1:k−1)

6/33

SLIDE 16

Sequential Bayesian Estimation

Often, quantities at time step k can be calculated recursively from the former time step k − 1.

p(X0:k|Z1:k) =

1 p(zk |Z1:k−1)

p(zk|X0:kZ1:k−1) p(X0:k|Z1:k−1) (Bayes) ∝ p(zk|X0:kZ1:k−1) p(xk|X0:k−1Z1:k−1) p(X0:k−1|Z1:k−1) = p(zk|xk) p(xk|xk−1) p(X0:k−1|Z1:k−1)

↑ ↑

.

Measurement does not depend on history. Markov dynamics

6/33

SLIDE 17

Sequential Bayesian Estimation

Often, quantities at time step k can be calculated recursively from the former time step k − 1.

p(X0:k|Z1:k) =

1 p(zk |Z1:k−1)

p(zk|X0:kZ1:k−1) p(X0:k|Z1:k−1) (Bayes) ∝ p(zk|X0:kZ1:k−1) p(xk|X0:k−1Z1:k−1) p(X0:k−1|Z1:k−1) = p(zk|xk) p(xk|xk−1) p(X0:k−1|Z1:k−1)

↑ ↑

.

Measurement does not depend on history. Markov dynamics

Measurement eq.: zk = hk(xk, uk), p(zk|xk) =

δ(zk − hk(xk, uk)) pu(uk) duk

Markov dynamics: xk = fk(xk−1, vk), p(xk|xk−1) =

δ(xk − fk(xk−1, vk)) pv(vk) dvk

uk ∼ pu(u) : measurement noise vk ∼ pv(v) : process noise

6/33

SLIDE 18

Sequential Bayesian Estimation

p(X0:k|Z1:k) ∝ p(zk|xk) p(xk|xk−1) p(X0:k−1|Z1:k−1) Often, only current estimates xk are needed, not the history X0:k.

dX0:k−1 · · · −

→ recursive filter equation for time step k : p(xk|Z1:k) ∝ p(zk|xk) p(xk|Z1:k−1) p(xk|Z1:k−1) =

dxk−1 p(xk|xk−1) p(xk−1|Z1:k−1)

measurement update prediction

7/33

SLIDE 19

Sequential Bayesian Estimation

p(X0:k|Z1:k) ∝ p(zk|xk) p(xk|xk−1) p(X0:k−1|Z1:k−1) Often, only current estimates xk are needed, not the history X0:k.

dX0:k−1 · · · −

→ recursive filter equation for time step k : p(xk|Z1:k) ∝ p(zk|xk) p(xk|Z1:k−1) p(xk|Z1:k−1) =

dxk−1 p(xk|xk−1) p(xk−1|Z1:k−1)

measurement update prediction ☛ ✡ ✟ ✠ In general, this is only a conceptional solution. Analytically solvable in special cases, only.

7/33

SLIDE 20

Sequential Bayesian Estimation Linear Gaussian Systems

Linear Gaussian Systems

Target dynamics: xk = Fk xk−1 + vk, vk ∼ N(o, Dk) Measurement eq.: zk = Hk xk + uk, uk ∼ N(o, Rk) Then, conditional densities normally distributed: p(xk−1|Z1:k−1) = N(xk−1; xk−1|k−1, Pk−1|k−1) p(xk|Z1:k−1) = N(xk; xk|k−1, Pk|k−1) p(xk|Z1:k) = N(xk; xk|k, Pk|k) with Kalman filter equations: ✗ ✖ ✔ ✕

xk|k−1 = Fk xk−1|k−1, Pk|k−1 = FkPk−1|k−1FT

k + Dk

xk|k = xk|k−1 + Wk

zk − Hkxk|k−1
,

Pk|k = Pk|k−1 − WkSkWT

k

Wk = Pk|k−1HT

k S−1 k ,

Sk = HkPk|k−1HT

k + Rk

(see Lecture II)

8/33

SLIDE 21

Sequential Bayesian Estimation Grid-based methods

Grid-based methods Finite number of discrete target states x(i)

k (i = 1 · · · N)

Be P(xk−1 = x(i)

k−1|Z1:k−1) ≡ w (i) k−1|k−1 given. Then:

✬ ✫ ✩ ✪

p(xk|Z1:k−1) =

N

i=1

w (i)

k|k−1 δ(xk − x(i) k )

p(xk|Z1:k) =

N

i=1

w (i)

k|k δ(xk − x(i) k )

mit

w (i)

k|k−1

=

N

j=1

w (i)

k−1|k−1 p(x(i) k |x(j) k−1)

w (i)

k|k

∝ w (i)

k|k−1 p(zk|x(i) k )

9/33

SLIDE 22

Sequential Bayesian Estimation Grid-based methods

Grid-based methods Finite number of discrete target states x(i)

k (i = 1 · · · N)

Be P(xk−1 = x(i)

k−1|Z1:k−1) ≡ w (i) k−1|k−1 given. Then:

✬ ✫ ✩ ✪

p(xk|Z1:k−1) =

N

i=1

w (i)

k|k−1 δ(xk − x(i) k )

p(xk|Z1:k) =

N

i=1

w (i)

k|k δ(xk − x(i) k )

mit

w (i)

k|k−1

=

N

j=1

w (i)

k−1|k−1 p(x(i) k |x(j) k−1)

w (i)

k|k

∝ w (i)

k|k−1 p(zk|x(i) k )

Optimal filter for arbitrary densities. p(x(i)

k |x(j) k−1) and p(zk|x(i) k )

9/33

SLIDE 23

Sequential Bayesian Estimation Grid-based methods

Grid-based methods Finite number of discrete target states x(i)

k (i = 1 · · · N)

Be P(xk−1 = x(i)

k−1|Z1:k−1) ≡ w (i) k−1|k−1 given. Then:

✬ ✫ ✩ ✪

p(xk|Z1:k−1) =

N

i=1

w (i)

k|k−1 δ(xk − x(i) k )

p(xk|Z1:k) =

N

i=1

w (i)

k|k δ(xk − x(i) k )

mit

w (i)

k|k−1

=

N

j=1

w (i)

k−1|k−1 p(x(i) k |x(j) k−1)

w (i)

k|k

∝ w (i)

k|k−1 p(zk|x(i) k )

Optimal filter for arbitrary densities. p(x(i)

k |x(j) k−1) and p(zk|x(i) k )

Approximation for continuous target states.

9/33

SLIDE 24

Sequential Bayesian Estimation Grid-based methods

Grid-based methods Finite number of discrete target states x(i)

k (i = 1 · · · N)

Be P(xk−1 = x(i)

k−1|Z1:k−1) ≡ w (i) k−1|k−1 given. Then:

✬ ✫ ✩ ✪

p(xk|Z1:k−1) =

N

i=1

w (i)

k|k−1 δ(xk − x(i) k )

p(xk|Z1:k) =

N

i=1

w (i)

k|k δ(xk − x(i) k )

mit

w (i)

k|k−1

=

N

j=1

w (i)

k−1|k−1 p(x(i) k |x(j) k−1)

w (i)

k|k

∝ w (i)

k|k−1 p(zk|x(i) k )

Optimal filter for arbitrary densities. p(x(i)

k |x(j) k−1) and p(zk|x(i) k )

Approximation for continuous target states. Not feasible for higher dimensional systems!

9/33

SLIDE 25

Sequential Bayesian Estimation Non-linear, non-Gaussian systems

Non-linear, non-Gaussian systems

Target dynamics: xk = fk(xk−1, vk), vk ∼ pv(v) Measurement eq.: zk = hk(xk, uk), uk ∼ pu(u)

10/33

SLIDE 26

Sequential Bayesian Estimation Non-linear, non-Gaussian systems

Non-linear, non-Gaussian systems

Target dynamics: xk = fk(xk−1, vk), vk ∼ pv(v) Measurement eq.: zk = hk(xk, uk), uk ∼ pu(u) Non-linear target dynamics

pilot / driver behavior
different maneuvers
influence of terrain
constraints (maximal velocity, roads, coastlines, ...)

10/33

SLIDE 27

Sequential Bayesian Estimation Non-linear, non-Gaussian systems

Non-linear, non-Gaussian systems

Target dynamics: xk = fk(xk−1, vk), vk ∼ pv(v) Measurement eq.: zk = hk(xk, uk), uk ∼ pu(u) Non-linear target dynamics

pilot / driver behavior
different maneuvers
influence of terrain
constraints (maximal velocity, roads, coastlines, ...)

Non-linear measurement equation

coordinate transformation
integration over state space sector
detection-target assignments

10/33

SLIDE 28

Sequential Bayesian Estimation Non-linear, non-Gaussian systems

Non-linear, non-Gaussian systems

Target dynamics: xk = fk(xk−1, vk), vk ∼ pv(v) Measurement eq.: zk = hk(xk, uk), uk ∼ pu(u) Non-linear target dynamics

pilot / driver behavior
different maneuvers
influence of terrain
constraints (maximal velocity, roads, coastlines, ...)

Non-linear measurement equation

coordinate transformation
integration over state space sector
detection-target assignments

non-Gaussian process or measurement noise

10/33

SLIDE 29

Sequential Bayesian Estimation Non-linear, non-Gaussian systems

Non-linear, non-Gaussian systems

Target dynamics: xk = fk(xk−1, vk), vk ∼ pv(v) Measurement eq.: zk = hk(xk, uk), uk ∼ pu(u) Non-linear target dynamics

pilot / driver behavior
different maneuvers
influence of terrain
constraints (maximal velocity, roads, coastlines, ...)

Non-linear measurement equation

coordinate transformation
integration over state space sector
detection-target assignments

non-Gaussian process or measurement noise In general, arbitrary multi-modal probability densities p(xk|Z1:k) possible.

10/33

SLIDE 30

Sequential Bayesian Estimation Non-linear, non-Gaussian systems

Example: single target with Pd < 1 and pf = 0

Measurement at time step k of mk detections: zk = {z(1)

k , . . . , z(mk) k

}

Measurement eq.: z(i)

k = hk(xk, uk),

p1(z(i)

k |xk) =

δ(z(i)

k − hk(xk, uk)) pu(uk) duk

Markov dynamics: xk = fk(xk−1, vk), p(xk|xk−1) =

δ(xk − fk(xk−1, vk)) pv(vk) dvk

uk: measurement noise; vk: process noise

11/33

SLIDE 31

Sequential Bayesian Estimation Non-linear, non-Gaussian systems

Example: single target with Pd < 1 and pf = 0

Measurement at time step k of mk detections: zk = {z(1)

k , . . . , z(mk) k

}

Measurement eq.: z(i)

k = hk(xk, uk),

p1(z(i)

k |xk) =

δ(z(i)

k − hk(xk, uk)) pu(uk) duk

Markov dynamics: xk = fk(xk−1, vk), p(xk|xk−1) =

δ(xk − fk(xk−1, vk)) pv(vk) dvk

uk: measurement noise; vk: process noise

Possible assignments detection ↔ target for likelihood function: p(zk|xk) =

mk

j=1

pf (z(j)

k ) [

1 − Pd

nly false alarms

+ Pd

mk

i=1

p1(z(i)

k |xk)

pf (z(i)

k )

ne detection

]

11/33

SLIDE 32

Sequential Bayesian Estimation Non-linear, non-Gaussian systems

Example: single target with Pd < 1 and pf = 0

Measurement at time step k of mk detections: zk = {z(1)

k , . . . , z(mk) k

}

Measurement eq.: z(i)

k = hk(xk, uk),

p1(z(i)

k |xk) =

δ(z(i)

k − hk(xk, uk)) pu(uk) duk

Markov dynamics: xk = fk(xk−1, vk), p(xk|xk−1) =

δ(xk − fk(xk−1, vk)) pv(vk) dvk

uk: measurement noise; vk: process noise

Possible assignments detection ↔ target for likelihood function: p(zk|xk) =

mk

j=1

pf (z(j)

k ) [

1 − Pd

nly false alarms

+ Pd

mk

i=1

p1(z(i)

k |xk)

pf (z(i)

k )

ne detection

] ☛ ✡ ✟ ✠ − → Multi-modal structure even for linear, Gaussian system equations.

11/33

SLIDE 33

Sequential Monte Carlo Methods

Approximate p(X0:k|Z1:k) by weighted random paths X(i)

0:k !

✬ ✫ ✩ ✪ p(X0:k|Z1:k) ≈

N

i=1

w (i)

k δ(X0:k − X(i) 0:k)

X(i)

0:k ∼ q(X(i) 0:k|Z1:k),

w (i)

k

∝ p(X(i)

0:k|Z1:k)

q(X(i)

0:k|Z1:k)

12/33

SLIDE 34

Sequential Monte Carlo Methods

Approximate p(X0:k|Z1:k) by weighted random paths X(i)

0:k !

✬ ✫ ✩ ✪ p(X0:k|Z1:k) ≈

N

i=1

w (i)

k δ(X0:k − X(i) 0:k)

X(i)

0:k ∼ q(X(i) 0:k|Z1:k),

w (i)

k

∝ p(X(i)

0:k|Z1:k)

q(X(i)

0:k|Z1:k)

Reminder (sequential estimation): p(X0:k|Z1:k) ∝ p(zk|xk) p(xk|xk−1) p(X0:k−1|Z1:k−1) q in principle arbitrary; optimal was q ≡ p. Ansatz: q(X0:k|Z1:k) = q(xk|xk−1zk) q(X0:k−1|Z1:k−1) Inserting p and q in w (i)

k

gives ...

12/33

SLIDE 35

Sequential Monte Carlo Methods “Sequential Importance Sampling”, SIS

“Sequential Importance Sampling”, SIS Recursive calculation of particle weights:

✓ ✒ ✏ ✑

w (i)

k

∝ w (i)

k−1

p(zk|x(i)

k )p(x(i) k |x(i) k−1)

q(x(i)

k |x(i) k−1zk)

dX0:k−1 · · · −

→ Filtered density: p(xk|Z1:k) ≈

N

i=1

w (i)

k δ(xk − x(i) k )

“Importance density”: q(xk|x(i)

k−1zk)

arbitrary

13/33

SLIDE 36

Sequential Monte Carlo Methods “Sequential Importance Sampling”, SIS

“Sequential Importance Sampling”, SIS Recursive calculation of particle weights:

✓ ✒ ✏ ✑

w (i)

k

∝ w (i)

k−1

p(zk|x(i)

k )p(x(i) k |x(i) k−1)

q(x(i)

k |x(i) k−1zk)

dX0:k−1 · · · −

→ Filtered density: p(xk|Z1:k) ≈

N

i=1

w (i)

k δ(xk − x(i) k )

“Importance density”: q(xk|x(i)

k−1zk)

arbitrary SIS-Algorithmus:

✤ ✣ ✜ ✢

Initialize {x(i)

0 }, {w (i) 0 }

For k = 1, 2, . . . Sample N “particles” x(i)

k ∼ q(xk|x(i) k−1zk)

Calculate {w (i)

k }

13/33

SLIDE 37

Sequential Monte Carlo Methods “Sequential Importance Sampling”, SIS

SIS-Algorithmus:

✤ ✣ ✜ ✢ Initialize {x(i)

0 }, {w (i) 0 }

For k = 1, 2, . . . Sample N “particles” x(i)

k ∼ q(xk|x(i) k−1zk)

Calculate {w (i)

k }

14/33

SLIDE 38

Sequential Monte Carlo Methods “Sequential Importance Sampling”, SIS

SIS-Algorithmus:

✤ ✣ ✜ ✢ Initialize {x(i)

0 }, {w (i) 0 }

For k = 1, 2, . . . Sample N “particles” x(i)

k ∼ q(xk|x(i) k−1zk)

Calculate {w (i)

k }

Properties: DEMO converges ∼ 1/ √ N

14/33

SLIDE 39

Sequential Monte Carlo Methods “Sequential Importance Sampling”, SIS

SIS-Algorithmus:

✤ ✣ ✜ ✢ Initialize {x(i)

0 }, {w (i) 0 }

For k = 1, 2, . . . Sample N “particles” x(i)

k ∼ q(xk|x(i) k−1zk)

Calculate {w (i)

k }

Properties: DEMO converges ∼ 1/ √ N easy to implement

14/33

SLIDE 40

Sequential Monte Carlo Methods “Sequential Importance Sampling”, SIS

SIS-Algorithmus:

✤ ✣ ✜ ✢ Initialize {x(i)

0 }, {w (i) 0 }

For k = 1, 2, . . . Sample N “particles” x(i)

k ∼ q(xk|x(i) k−1zk)

Calculate {w (i)

k }

Properties: DEMO converges ∼ 1/ √ N easy to implement easy to parallelize

14/33

SLIDE 41

Sequential Monte Carlo Methods “Sequential Importance Sampling”, SIS

SIS-Algorithmus:

✤ ✣ ✜ ✢ Initialize {x(i)

0 }, {w (i) 0 }

For k = 1, 2, . . . Sample N “particles” x(i)

k ∼ q(xk|x(i) k−1zk)

Calculate {w (i)

k }

Properties: DEMO converges ∼ 1/ √ N easy to implement easy to parallelize does not work (usually) Reason: “degeneracy”: After few iterations, almost all weights occupied by a few particles (or by one).

14/33

SLIDE 42

Sequential Monte Carlo Methods “Sequential Importance Sampling”, SIS

“Degeneracy”

Quantity for degeneracy: estimated effective particle number Neff = 1/

N

i=1
w (i)

k

2 1 ≤ Neff ≤ N, Neff = N f¨ ur w (i)

k

≡ 1/N Improvement of degeneracy problem: many, many particle (not always possible) sensible choice of “importance density” q(xk|x(i)

k−1zk)

“resampling”

15/33

SLIDE 43

Sequential Monte Carlo Methods “Sequential Importance Sampling”, SIS

Optimal “Importance Density”

q(xk|x(i)

k−1zk) = p(xk|x(i) k−1zk) = p(zk|xk) p(xk|x(i) k−1)

p(zk|x(i)

k−1)

Statistical weights: w (i)

k

∝ w (i)

k−1 p(zk|x(i) k−1)

independent of x(i)

k !

= w (i)

k−1

dx′

k p(zk|x′ k) p(x′ k|x(i) k−1)

16/33

SLIDE 44

Sequential Monte Carlo Methods “Sequential Importance Sampling”, SIS

Optimal “Importance Density”

q(xk|x(i)

k−1zk) = p(xk|x(i) k−1zk) = p(zk|xk) p(xk|x(i) k−1)

p(zk|x(i)

k−1)

Statistical weights: w (i)

k

∝ w (i)

k−1 p(zk|x(i) k−1)

independent of x(i)

k !

= w (i)

k−1

dx′

k p(zk|x′ k) p(x′ k|x(i) k−1)

Drawbacks: How to sample x(i)

k ∼ p(xk|x(i) k−1zk) ??

How to calculate integral efficiently?? ⇒ Applicable in special cases, only. DEMO

16/33

SLIDE 45

Sequential Monte Carlo Methods “Sequential Importance Sampling”, SIS

Choice of “Importance Density” Example: Gaussian random mover in d dimensionen

10

1

10

2

10

3

10

4

10

5

10

−2

10

−1

10

"Markov" importance density number of particles error

d=1 d=2 d=4 d=6 d=8 d=10 d=16 10

1

10

2

10

3

10

4

10

5

10

−2

10

−1

10 number of particles error d=1 d=4 d=6 d=8 d=16

ptimal importance density

d=1 d=12 d=10

Required particle number for given accuracy −

→

2 4 6 8 10 12 14 16 10

2

10

3

10

4

10

5

dimension number of particles

ptimal importance density

"Markov" importance density

17/33

SLIDE 46

Sequential Monte Carlo Methods “Sequential Importance Sampling”, SIS

Choice of “Importance Density” Example: Gaussian random mover in d dimensionen

10

1

10

2

10

3

10

4

10

5

10

−2

10

−1

10

"Markov" importance density number of particles error

d=1 d=2 d=4 d=6 d=8 d=10 d=16 10

1

10

2

10

3

10

4

10

5

10

−2

10

−1

10 number of particles error d=1 d=4 d=6 d=8 d=16

ptimal importance density

d=1 d=12 d=10

Required particle number for given accuracy −

→

2 4 6 8 10 12 14 16 10

2

10

3

10

4

10

5

dimension number of particles

ptimal importance density

"Markov" importance density

“Curse of Dimensionality”

17/33

SLIDE 47

Sequential Monte Carlo Methods “Sequential Importance Sampling”, SIS

Resampling

Idea (similar principle as “importance sampling”): Replace sample {x(i)

k } with weights {w (i) k } by a new

sample {˜ x(i)

k } with constant weights { ˜

w (i)

k } ≡ 1/N.

X w X w

18/33

SLIDE 48

Sequential Monte Carlo Methods “Sequential Importance Sampling”, SIS

Resampling

Idea (similar principle as “importance sampling”): Replace sample {x(i)

k } with weights {w (i) k } by a new

sample {˜ x(i)

k } with constant weights { ˜

w (i)

k } ≡ 1/N.

X w X w

Method (“genetic” element): replicate particles with large weight eliminate particles with small weight ⇒ particle number in state i: Ni ∝ w (i)

k

remark: can be done in O(N) operations

18/33

SLIDE 49

Sequential Monte Carlo Methods “Sampling Importance Resampling”, SIR

“Sampling Importance Resampling”, SIR simple application:

“Importance density”=“Markov density”

q(xk|x(i)

k−1zk) = p(xk|x(i) k−1)

⇒ w (i)

k

∝ w (i)

k−1 p(zk|x(i) k )

“Resampling” in each iteration

⇒ w (i)

k

∝ p(zk|x(i)

k )

19/33

SLIDE 50

Sequential Monte Carlo Methods “Sampling Importance Resampling”, SIR

“Sampling Importance Resampling”, SIR simple application:

“Importance density”=“Markov density”

q(xk|x(i)

k−1zk) = p(xk|x(i) k−1)

⇒ w (i)

k

∝ w (i)

k−1 p(zk|x(i) k )

“Resampling” in each iteration

⇒ w (i)

k

∝ p(zk|x(i)

k )

SIR-Algorithmus:

✬ ✫ ✩ ✪

Initialize {x(i)

0 }, {w (i) 0 }

For k = 1, 2, . . .

Generate new states acc. to target dynamics:

x(i)

k = fk(x(i) k−1, v(i) k )

Calculate w (i)

k

acc. to measurement equation.
Generate new sample by “resampling”

19/33

SLIDE 51

Sequential Monte Carlo Methods “Sampling Importance Resampling”, SIR

SIR-Algorithmus

Propagation (Zieldynamik) Resampling

{x }

(i) k

{x }

(i) k

,{w }

(i) k

{x }

(i) k+1 ,{w } (i) k+1

Propagation

{x }

(i) k-1

Gewichte (Messgleichung)

res.

20/33

SLIDE 52

Sequential Monte Carlo Methods “Sampling Importance Resampling”, SIR

SIR-Algorithmus

Propagation (Zieldynamik) Resampling

{x }

(i) k

{x }

(i) k

,{w }

(i) k

{x }

(i) k+1 ,{w } (i) k+1

Propagation

{x }

(i) k-1

Gewichte (Messgleichung)

res.

Properties: converges ∼ 1/ √ N easy to implement

20/33

SLIDE 53

Sequential Monte Carlo Methods “Sampling Importance Resampling”, SIR

SIR-Algorithmus

Propagation (Zieldynamik) Resampling

{x }

(i) k

{x }

(i) k

,{w }

(i) k

{x }

(i) k+1 ,{w } (i) k+1

Propagation

{x }

(i) k-1

Gewichte (Messgleichung)

res.

Properties: converges ∼ 1/ √ N easy to implement not so easy to parallelize (resampling) Measurement does not enter into propagation → possibly inefficient “impoverishment”: for small process noise, all particles descend from same ancester. DEMO

20/33

SLIDE 54

Multitarget Tracking

Joint multitarget probability density: p(Xk|Z1:k) For the joint state of all targets: Xk = (x(1)

k , . . . , x(n) k )T high dimensional!

(s. Kastella, Mahler, Stone, 1995 ff.)

21/33

SLIDE 55

Multitarget Tracking

Joint multitarget probability density: p(Xk|Z1:k) For the joint state of all targets: Xk = (x(1)

k , . . . , x(n) k )T high dimensional!

(s. Kastella, Mahler, Stone, 1995 ff.) ☛ ✡ ✟ ✠ For fixed target number n (formally) the usual Bayesian filter equations hold: p(Xk+1|Z1:k) =

p(Xk+1|Xk) p(Xk|Z1:k)dXk

p(Xk+1|Z1:k+1) ∝ p(Zk+1|Xk) p(Xk+1|Z1:k) prediction filtering

21/33

SLIDE 56

Multitarget Tracking

Joint multitarget probability density: p(Xk|Z1:k) For the joint state of all targets: Xk = (x(1)

k , . . . , x(n) k )T high dimensional!

(s. Kastella, Mahler, Stone, 1995 ff.) ☛ ✡ ✟ ✠ For fixed target number n (formally) the usual Bayesian filter equations hold: p(Xk+1|Z1:k) =

p(Xk+1|Xk) p(Xk|Z1:k)dXk

p(Xk+1|Z1:k+1) ∝ p(Zk+1|Xk) p(Xk+1|Z1:k) prediction filtering

Kinematic prior: potentially complex, correlated target dynamics (convoys, air combat, . . . ) likelihood: many assignment possibilities (exponential in n and mk) Methods: NN, PDAF,JPDAF, MHT, Particle filter, . . .

21/33

SLIDE 57

Multitarget Tracking

Multitarget dynamics

Example: independent targets p(Xk+1|Xk) =

n

l1=···=lnk =1

n

j=1

pt

k(x(lj) k+1|x(j) k ) k k+1 k k+1

sum over all single-target assignments pt

k: Single target Markov density

e.g. for Gauss-Markov dynamics: xk+1 = Fk+1xk + vk+1 pt

k(x(i) k+1|x(j) k ) = N(x(i) k+1 ; Fk+1 x(j) k , Dk+1 )

22/33

SLIDE 58

Multitarget Tracking

Multitarget likelihood function

Beispiel: independent detektions, uncorrelated clutter, PD < 1

p(Zk|Xk) =

min(m,n)

j=0

P0(m, n, j)

m

m1=···=mj =1

n

n1<···<nj =1

j

l=1

p1(z(ml )

k

|x(nl )

k

)

Weighted sum over all single-target-detection assignments P0(m, n, j) = Pj

d(1 − Pd)n−j

e−λV (m − j)! λm−j

(V : size of field of view; λ : false alarm density; j : number of detected target)

p1 : Single-target-detection likelihood function, e.g., for linear measurement model: zk = Hkxk + uk p1(z(i)

k |x(j) k ) = N(z(i) k ; Hkx(j) k , Rk)

23/33

SLIDE 59

Multitarget Tracking “Combinatorial Desaster”

“Combinatorial Desaster”

Number of possible assignments grows exponentially with number of targets n and number of detections. m.

Example: Three targets, six detections Example: Six and eight targets

Meldung Meldung Meldung Meldung

x x x x x x x x x x x x x x x x x x x x x x x

Ziel

x

Detektion Falschalarm 2 4 6 8 10 12 14 16 18 20 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 x 10

7

Anzahl Meldungen Anzahl Zuordnungsmoeglichkeiten

6 Ziele 8 Ziele

· · · N(m, n) =

min{m,n}

j=0

j! m j n j

24/33

SLIDE 60

Multitarget Tracking “Combinatorial Desaster”

Simple szenario; unknown target number Two groups of road targets with two targets each Starting from different ends, crossing, turning, following Road partially not visible ⇒ number of detectable targets varies: (0,2,4) PD =0.9, 0.8, 30 false alarm on average sequential ratio test for target number estimation Szenario

−14000 −12000 −10000 −8000 −6000 −4000 −2000 −2000 2000 4000 6000 8000 x[m] y[m]

25/33

SLIDE 61

Multitarget Tracking “Combinatorial Desaster”

Simple szenario; unknown target number Two groups of road targets with two targets each Starting from different ends, crossing, turning, following Road partially not visible ⇒ number of detectable targets varies: (0,2,4) PD =0.9, 0.8, 30 false alarm on average sequential ratio test for target number estimation Szenario

−14000 −12000 −10000 −8000 −6000 −4000 −2000 −2000 2000 4000 6000 8000 x[m] y[m]

True and estimated target number

20 40 60 80 100 120 140 1 2 3 4 Scan−No target number

Extraction and tracking of a joint 4-target state (10,000 particles!)

25/33

SLIDE 62

Multitarget Tracking Probability Hypothesis Density

Simplification: Probability Hypothesis Density

Probability that in a certain, small part of state space a target exists Identy of targets and true assignment to detections often not interesting. For the joint pdf (identical targets): p(x(1)

s , . . . , x(n) s )

v(xs|n) = n

p(xs, y(1)

s , . . . , y(n−1) s

)dy(1)

s

. . . dy(n−1)

s

PHD: v(xs) =

∞

n=0

v(xs|n) P(n)

Dimension of a single target density

26/33

SLIDE 63

Multitarget Tracking Probability Hypothesis Density

Simplification: Probability Hypothesis Density

Probability that in a certain, small part of state space a target exists Identy of targets and true assignment to detections often not interesting. For the joint pdf (identical targets): p(x(1)

s , . . . , x(n) s )

v(xs|n) = n

p(xs, y(1)

s , . . . , y(n−1) s

)dy(1)

s

. . . dy(n−1)

s

PHD: v(xs) =

∞

n=0

v(xs|n) P(n)

Dimension of a single target density

Cardinality distribution: P(n) In an area:

v(xs)dxs =

∞

n=0

n P(n) = n (Target number estimator) If P(n) = 0 for n > 1 : v(xs) = P(1) p(xs) (Single target pdf)

26/33

SLIDE 64

Multitarget Tracking Probability Hypothesis Density

PHD filter equations

Iterative filter equations (Mahler 2003) for: Independent targets Target independent Poisson clutter Poisson distributed cardinalty distribution P(n) Probabilities for target “birth” (b) and “death” (d),

27/33

SLIDE 65

Multitarget Tracking Probability Hypothesis Density

PHD filter equations

Iterative filter equations (Mahler 2003) for: Independent targets Target independent Poisson clutter Poisson distributed cardinalty distribution P(n) Probabilities for target “birth” (b) and “death” (d), Prediction: vk|k−1(xs) = b(xs) +

pk|k−1(xs|ys) vk−1|k−1(ys) (1 − d(ys))dys

Update: vk|k(xs) = vk|k−1(xs)

(1 − Pd(x)) +
s

Pd(x) p(zs|xs) λ +

Pd(ys) p(zs|ys) vk|k−1(ys)dys
Target number:

nk|k =

dxs vk|k(xs)

27/33

SLIDE 66

Multitarget Tracking Probability Hypothesis Density

Properties of PHD filter equations

Multitarget tracking avoiding combinatorial desaster PHD vk(xs): dimension of a single target unknown and variable target numbers non-linear filter equations

28/33

SLIDE 67

Multitarget Tracking Probability Hypothesis Density

Properties of PHD filter equations

Multitarget tracking avoiding combinatorial desaster PHD vk(xs): dimension of a single target unknown and variable target numbers non-linear filter equations

linear, Gaussian systems (Gaussian mixture densities)
particle filter (Vo et al. 2005)

track extraction using clustering techniques

28/33

SLIDE 68

Multitarget Tracking Probability Hypothesis Density

PHD-SMC application

Variable target number in clutter (s. Vo et al. 2005)

29/33

SLIDE 69

Multitarget Tracking Probability Hypothesis Density

PHD-SMC application

Variable target number in clutter (s. Vo et al. 2005)

29/33

SLIDE 70

Extensions and Variants of Particle Filters

Avoiding/improvement of degeneracy and impoverishment: regularized particle filter auxiliary particle filter “Rao-Blackwellization’ ... Further applications: Robotic: localization Sensor management Polymeres and protein folding DNA sequential analysis Statistical physics Financial mathematics ... Under various names: particle filter population monte carlo diffusion monte carlo transfer matrix monte carlo projection monte carlo Green function monte carlo “go with the winners” ...

30/33

SLIDE 71

Summary

Advantages of sequential Monte Carlo methods: Non-linear system equations Non-Gaussian noise Rather easy implementation Efficient implementation ∼ O(N) Dynamical adaptation and concentration to statistically relevant parts of the state space.

31/33

SLIDE 72

Summary

Advantages of sequential Monte Carlo methods: Non-linear system equations Non-Gaussian noise Rather easy implementation Efficient implementation ∼ O(N) Dynamical adaptation and concentration to statistically relevant parts of the state space. Therefore: Use particle filters and forget the rest !?

31/33

SLIDE 73

Summary

. . . please, don’t, because: Convergency guaranteed only for N → ∞ If assumption are fulfilled, Kalman and grid-based filters are optimal and, hence, preferable. Extended and unscented Kalmanfilter and Gaussian mixtures etc., often, are sufficiently precise, using less CPU and storage. Then: Particle filter useful as numerical “benchmark”.

32/33

SLIDE 74

Literatur

Literature

1

A. Doucet, N. de Freitas, and N. Gordon, eds., Sequential Monte Carlo Methods in Practice,

Springer, 2001.

2

S. Arulampalam, S. Maskell, N. Gordon, and T. Clapp, “A tutorial on Particle Filters for on-line

nonlinear/non-Gaussian Bayesian tracking,” IEEE Transactions on Signal Processing, vol. 50, no. 2,

pp. 174–188, 2002.

3

B. Ristic, S. Arulampalam, and N. Gordon, Beyond the Kalman Filter: Particle Filters for Tracking

Applications, Artech House, 2004.

4

B. Vo, S. Singh, and A. Doucet, “Sequential Monte Carlo methods for Multi-target Filtering with

Random Finite Sets” IEEE Trans. AES, Vol. 41, No. 4, pp. 1224-1245, 2005.

5

R. Mahler, “Statistical Multisource-Multitarget Information Fusion”, Artech House, 2007.

6

O. Cappe, S. J. Godsill, and E. Moulines, “An Overview of Existing Methods and Recent Advances

in Sequential Monte Carlo,” in Proceedings of the IEEE, Vol. 95 (5), pp. 899-924, 2007.

7

A. Doucet and A. M. Johansen, “A Tutorial on Particle Filtering and Smoothing: Fifteen years

Later,” Chapter 8.1 in The Oxford Handbook of Nonlinear Filtering, D. Crisan and B. Rozovskiieds (eds.), 2011.

8

T. B. Sch¨
n, F. Gustafsson, and R. Karlsson, “The Particle Filter in Practice,” Chapter 8.4 ibid.

9

B. Ristic, “Particle Filters for Random Set Models,” Springer 2013.

33/33
