Senior Design Team 2008 UCEM Power Train Sponsor: UConn Electric Motorsports Club Team: Zachary Ahearn, Waleed Hussain, Dennis Basar, Spencer Arnold Advisor: Sung-Yeul Park Our Sponsor The UConn Electric Motorsports Team (UCEM) is a


slide-1
SLIDE 1

Senior Design Team 2008 UCEM Power Train

Sponsor: UConn Electric Motorsports Club Team: Zachary Ahearn, Waleed Hussain, Dennis Basar, Spencer Arnold Advisor: Sung-Yeul Park

slide-2
SLIDE 2

Our Sponsor

  • The UConn Electric Motorsports Team (UCEM) is a student-run, professional organization

that designs and builds an electric, open-wheeled formula style race car

  • Currently still in the designing and fabrication stage of “The Prometheus”
slide-3
SLIDE 3

Project Statement

  • Our team has three main objectives:

○ Evaluating the performance of a preselected motor and battery system, both individually and as a completed, integrated system ○ Developing an embedded system to display real-time information about the power train ○ Assisting the ME senior design team on integrating a cooling system for the full power train

  • Each team member will be responsible for heading one of four subsystems:

○ Battery Management System (BMS) → Dennis Basar ○ Battery and Battery Charger → Waleed Hussain ○ Motor and Motor Drive → Spencer Arnold ○ Embedded System → Zachary Ahearn

  • Our designs must adhere to Formula SAE rules and regulations
slide-4
SLIDE 4

Before We Begin

  • Information Acquisition

○ A majority of the first semester will be devoted to researching and understanding the choices of the previous years Senior Design teams

  • Safety Concern and Mitigation

○ High Voltage Training ○ Electric Safety Courses ○ Standard Operating Procedures are written and submitted for review ■ Proper PPE will be worn when working with the battery ■ In this case, Arc Flash Cat 2 PPE

slide-5
SLIDE 5

BMS and Battery System

slide-6
SLIDE 6

FSAE 2020 Specification For Battery and BMS

Battery:

  • Max power drawn from the

battery must not exceed 80kW.

  • Max voltage measured between

any two points must not exceed 300VDC.

  • Must be fuse protected

Battery Management System (BMS)

  • Must measure the voltage of

every cell to ensure they remain in maximum and minimum cell voltage levels.

  • Must measure the cell

temperatures of at least 20% of the cells, to ensure the temperature stays below 60°C

*All of the rules are covered in the FSAE rulebook found on their site

slide-7
SLIDE 7

2017 Team’s Selections - Battery and BMS

  • TNR18650-25R cells in Li8P25RT Building Blocks
  • 64 packs, 8 cells in each
  • Max voltage of 268VDC, 360A.
  • 5.2kWh / 20Ah capacity per pack
  • 2 fuses per pack
  • Orion BMS 2
  • Powered with 12VDC, 250mA
  • Measures the voltage of up to 72 units
  • Can monitor temperature of 8

thermistors

slide-8
SLIDE 8

2017 Team’s Selections - Charger and Contactor

  • Elcon PFC 2500 TCCH-216-10
  • Custom charging curves
  • 120V/60Hz input AC
  • Output voltage: nominal 216V,

maximum 289V DC

  • Output current: 6A maximum
  • CAN communication interface
  • KILOVAC LEV200 A4NAA
  • 500+ Amp, 12-900VDC

Contactor

  • High-current protection
  • 12VDC coil voltage
slide-9
SLIDE 9
  • Monitors 80 additional thermistors
  • Communicates via CAN
  • Allows measurement of every cell’s

temperatures Battery Thermistors ⇨ Thermistor Module ⇨ CANBUS ⇨ Microcontroller

Thermistor Expansion Module

slide-10
SLIDE 10

Temperature Monitoring

  • FSAE requires 13 thermistor modules to read cell temperatures

○ A thermistor expansion module, as well as 3 banks of thermistors will add the additional monitoring that we need ○ Not using the bank directly connected to the BMS, due to incompatibility

  • Need to work with M.E. senior design team to determine optimal place to place thermistors based
  • n their cooling system

Thermistors will not be in the way of their cooling system, however we must ensure the temperatures we’re reading are accurate across the entire battery array

slide-11
SLIDE 11

BMS Electric Load

Microcontroller/ Laptop

Battery System

slide-12
SLIDE 12

Battery Charging

  • We would like to ensure the battery system is fully functional before connecting it to the motor

system

  • We will be testing for:

○ Max voltage ○ Capacity ○ Charge time ○ Amperage ○ Temperature ○ How these change as the state of charge (SOC) changes

  • We will continue to perform these tests once the battery and motor are connected
slide-13
SLIDE 13

Battery Discharging

  • One FSAE test is a 30 minute endurance race
  • Looking at the discharge characteristics will give an idea how the battery will perform
  • Connecting to artificial load to test discharging characteristics
  • Again, looking at:

○ Voltage ○ Capacity ○ Discharge time ○ Amperage ○ Temperature ○ How these change as the state of charge (SOC) changes

  • Once the battery system is connected to the motor, these tests will be re-performed
slide-14
SLIDE 14

Motor System

slide-15
SLIDE 15

Motor System Specifications

  • Precharge and Discharge Circuit for the Motor Controller

○ According to the FSAE rules and our sponsors guidelines, the circuit “Must be charged to 90% within 5 seconds and discharge to 60V in under 5 seconds.”

  • The motor chosen had to provide a good amount of torque, while keeping power consumption in

mind.

○ Battery provide up to 268 Volts DC, and 360 Amps ○ Maximum power draw must be limited to 80kW

  • Motor had to handle maximum battery parameters, as well as have good software integration.
slide-16
SLIDE 16

2017 Team’s Selections - Motor

  • The motor chosen was the EMRAX 208

○ Max Voltage: 320 VDC ○ Max Current: 320 Amps ○ Max Power: 80kW ○ Continuous torque output of 80 Nm, with a peak of 140 Nm (59 and 103 ft-lbs.) ○ Lightweight, at only 9.4 kg (~21 lbs.)

slide-17
SLIDE 17

2017 Team’s Selections - Motor Controller

  • The motor controller chosen was the EMSISO

H300

○ Allows for Field Oriented Control (FOC) ○ Offers CAN protocol in order to interface with rest of electrical system. ○ Allows for regenerative braking

  • ption
slide-18
SLIDE 18

Motor and Motor Drive Approach

  • Motor system requires more testing before connected to the battery

○ Needs to be tested under dyno load, and tested with a temporary 3KW chiller ■ Torque and speed tests, both under and not under load ■ Chiller will be used until the ME’s cooling system is complete ○ Using EmDrive software and physical hardware, we can modify the parameters of the motor and control its various functions

  • Once testing is complete, we will connect it to the battery and ensure our parameters are correct
  • Microcontroller system will also display essential stats and send them to an LCD
slide-19
SLIDE 19

Testing Rectifier

  • Original testing power supply is currently unavailable, so we need a way to test the motor
  • Accomplished via a DC voltage rectifier circuit provided by Dr. Park

○ Wall provides 208V 3-phase AC ○ Plugs into AC source to control voltage and current ○ AC source connects to voltage rectifier circuit to output 268V to motor

slide-20
SLIDE 20

Microcontroller System

Temporary Chiller

Motor System

slide-21
SLIDE 21

Final Design

Microcontroller System Cooling System

Precharge/ Discharge Circuit

slide-22
SLIDE 22

Microcontroller System

slide-23
SLIDE 23

Embedded System

  • UCEM wants an embedded system to interface with BMS and motor controller
  • We intend to use a microprocessor system to display vital stats in the car on an LCD screen

○ State of Battery Charge ○ Throttle Level ○ Forward/Reverse

  • Using CAN (controller area network) to interface with systems directly from controllers

○ BMS uses a very common set of CAN addresses under the OBDII protocol, while

  • UCEM team working on microcontroller system as well for low-voltage system, so we are working

closely with them to create a system that can integrate both of our ideas

slide-24
SLIDE 24

Microcontroller

  • Raspberry Pi 3B+

○ Single-board computer running Raspbian Linux ○ 1.4GHz ARM processor, 1GB RAM ○ Four USB 2.0 ports, used to connect to the motor controller and BMS ○ DSI display port to connect a small screen, as well as HDMI for prototyping

slide-25
SLIDE 25

Interface

  • Ewert CANdapter

○ Converts between RS232 and USB, allowing for CAN signals to be directly read or written to ○ Up to 1Mbps baud rate ○ Developed by the same company who made the ORION ○ Creates a virtual serial port, that can be interfaced directly with the USB port of the microcontroller or a laptop (for use with BMS software)

slide-26
SLIDE 26

Embedded System Proposal

CANdapter LCD Display BMS Motor Controller

slide-27
SLIDE 27

Cooling System

  • Mechanical Engineering senior design team is working on a cooling system for the battery and

motor

○ One full loop water cooling system, still in the design/simulation phase ○ Must work closely with them in the spring semester to help implement into the full power train

  • This requires us to have communication with them as well in order to ensure any decisions we

make will not interfere with their cooling system

  • Eg. location of thermistors, correct temperature data, etc.
slide-28
SLIDE 28

Gantt Chart

slide-29
SLIDE 29

Budget

Component Qty. Unit Price Total Price Raspberry Pi 3B Kit 1 $45.99 $45.99 Arduino Mega 2560 1 $14.99 $14.99 Micro SD Card, 32GB 1 $5.32 $5.32 20x4 Char. LCD Screen 1 $7.99 $7.99 Quick Disconnect W/ Pins 2 $6.75 $11.50

  • Misc. Chiller Parts

1 $40.00 $40.00 Grand Total $127.29

slide-30
SLIDE 30

Issues and Concerns

  • We want to have a solid contact with UCEM.

○ Update our plans and timeline as we progress ○ Keep in close contact with our sponsor ○ Attend weekly meetings

  • Motor power supply (ABC-150) broken

○ Repairs too expensive, so we created our own rectifier to test the motor

  • Work with the mechanical engineering team to incorporate the cooling system with the battery

and motor

○ They need our help to help connect the electrical side of the cooling system ○ Their design is currently unfinalized, so we need to be prepared for things changing

slide-31
SLIDE 31

Thank You
