seismic imaging tutorial exploding reflector modeling/migration Paul Sava Center for Wave Phenomena Colorado School of Mines psava@mines.edu WSI assignment modify the acquisition parameters to explore the illumination at different

SLIDE 1

WSI

seismic imaging tutorial

“exploding reflector” modeling/migration Paul Sava

Center for Wave Phenomena Colorado School of Mines psava@mines.edu

SLIDE 2

WSI

assignment modify the acquisition parameters to explore the illumination at different locations in the subsurface

SLIDE 3

WSI

import packages

from r s f p r o j import ∗ import sigsbee , fdmod

SLIDE 4

WSI

setup main parameters

par=s i g s b e e . paramwin () # Sigsbee2A parameters par [ ’ nt ’ ]=3001 # time steps ( samples ) par [ ’ kt ’ ]=100 # wavelet delay ( samples ) par [ ’ dt ’ ]=0.001 # time sampling (ms) par [ ’ nb ’ ]=100 # boundary s i z e ( g r i d p o i n t s ) fdmod . param ( par ) # p l o t t i n g parameters

SLIDE 5

WSI

source coordinates

# source c o o r d i n a t e s ( exploding r e f l e c t o r s ) fdmod . boxarray ( ’ ss ’ ,6 ,2 ,1 ,12 ,8 ,1 , par ) # p l o t sources Plot ( ’ ss ’ , fdmod . s s p l o t ( ’ p l o t f a t =1 symbol=. ’ , par ))

SLIDE 6

WSI

receiver coordinates

par [ ’ j r ’ ]=4 # r e c e i v e r jump ( g r i d p o i n t s ) par [ ’ nr ’ ]=120 # number of r e c e i v e r s par [ ’ f r ’ ]=100 # r e c e i v e r s

r i g i n

( g r i d p o i n t s ) # r e c e i v e r c o o r d i n a t e s fdmod . h o r i z o n t a l ( ’ t t ’ , par [ ’ oz ’]+ par [ ’ dz ’ ] , par ) Flow ( ’ r r ’ , ’ t t ’ , ’ window n2=%(nr )d j2=%(j r )d f2=%(f r )d ’%par ) # p l o t r e c e i v e r s Plot ( ’ r r ’ , fdmod . r r p l o t ( ’ ’ , par ))

SLIDE 7

WSI

velocity/density models

# get v e l o c i t y s i g s b e e . g e t s t r v e l w i n ( ’ v s t r ’ , par ) Flow ( ’ velo ’ , ’ v s t r ’ , ’ smooth rect1 =100 rect2 =100 repeat=1 ’ ) # p l o t v e l o c i t y Plot ( ’ velo ’ , fdmod . cgrey ( ’ a l l p o s=y b i a s =1.43 ’ , par )) Result ( ’ velo ’ , [ ’ velo ’ , ’ ss ’ , ’ r r ’ ] , ’ Overlay ’ ) # p l o t d e n s i t y Flow ( ’ dens ’ , ’ velo ’ , ’ math output=1 ’ )

SLIDE 8

WSI

SLIDE 9

WSI

source wavelet

# c o n s t r u c t wavelet fdmod . wavelet ( ’ wav ’ ,15 , par ) # transpose wavelet Flow ( ’wav ’ , ’ wav ’ , ’ transp ’ ) # p l o t wavelet Result ( ’wav ’ , ’ window n2=1000 | ’ + fdmod . waveplot ( ’ ’ , par ))

SLIDE 10

WSI

SLIDE 11

WSI

FD modeling

# run FD modeling fdmod . awefd1 ( ’ temp ’ , ’ wfld ’ , ’wav ’ , ’ velo ’ , ’ dens ’ , ’ ss ’ , ’ r r ’ , ’ f r e e=n ’ , par )

SLIDE 12

WSI

plot wavefield

# generate w a v e f i e l d movie Plot ( ’ wfld ’ , fdmod . wgrey ( ’ p c l i p =99 ’ , par ) , view=1) # p l o t w a v e f i e l d frames for i in range ( 1 0 ) : tag = ’−%02d ’ %( i ∗3) fdmod . wframe ( ’ wfld ’+tag , ’ wfld ’ , i ∗3 , ’ p c l i p =99 ’ , par ) Result ( ’ wfld ’+tag , [ ’ wfld ’+tag , ’ ss ’ , ’ r r ’ ] , ’ Overlay ’ )

SLIDE 13

WSI

SLIDE 14

WSI

SLIDE 15

WSI

SLIDE 16

WSI

SLIDE 17

WSI

SLIDE 18

WSI

SLIDE 19

WSI

SLIDE 20

WSI

SLIDE 21

WSI

SLIDE 22

WSI

SLIDE 23

WSI

plot data

# undo wavelet delay Flow ( ’ data ’ , ’ temp ’ , ’ ’ ’ window squeeze=n f2=%(kt )d | pad end2=%(kt )d | put o2=%(ot ) g ’ ’ ’ %par ) # p l o t data Result ( ’ data ’ , ’ window j2=4 | transp | ’ + fdmod . dgrey ( ’ ’ , par ))

SLIDE 24

WSI

SLIDE 25

WSI

FD migration

# run FD migration fdmod . zom( ’ imag ’ , ’ j d a t ’ , ’ data ’ , ’ velo ’ , ’ dens ’ , ’ r r ’ , ’ r r ’ , ’ f r e e=n ’ , par )

SLIDE 26

WSI

plot image

# p l o t image Plot ( ’ imag ’ , ’ bandpass f l o =2 | ’ + fdmod . cgrey ( ’ p c l i p =99.9 ’ , par )) Result ( ’ imag ’ , [ ’ imag ’ , ’ r r ’ ] , ’ Overlay ’ )

SLIDE 27

WSI

SLIDE 28

WSI

closing rules

End ()

SLIDE 29

WSI

the contest

◮ random sources in the subsurface ◮ random receivers on the surface
