Securing your database servers from external attacks Alkin Tezuysal - - PowerPoint PPT Presentation

Securing your database servers from external attacks

Alkin Tezuysal (Sr. Technical Manager,Percona) David Busby (Information Security Architect, Percona)

2

Who we are?

David Busby (@icleus)

• Technical Security Evangelist
• Open Source Evangelist
• Certified Information Systems Security Professional
• Assistant Scout Leader
• Assistant Instructor computing for children
• Ju-Jitsu nidan and ex-Instructor

Alkin Tezuysal (@ask_dba)

• Open Source Database Evangelist
• Global Database Operations Expert
• Cloud Infrastructure Architect AWS
• Inspiring Technical and Strategic Leader
• Creative Team Builder
• Speaker, Mentor, and Coach
• Outdoor Enthusiast

3

Agenda

• Security Common Sense
• MySQL Security

○ MySQL Passwords ○ MySQL Communication ○ MySQL Encryption

• Security Best Practices
• MySQL Security in Cloud Operators (AWS)
• Q & A

Database Security Best Practices

Apply Common Sense here

5

Security Do’s

• Restrict access to database hosts

○ Not just to the Database service

• Create individual users, use roles MySQL 8.0
• Set a password for all users
• Remove anonymous and obsolete users
• Use up-to-date software
• Review, update, modify security policies as needed
• Always remember to secure internal before blocking

external vulnerabilities

6

Password Attacks

• Weak passwords?
• Reusing old passwords?
• Leverage password validation plugin!
• Old version of MySQL those not password feature

rich?

• MySQL unsha1 attack
• MySQL hash cracking OSS (john, hashcat, etc...)

7

Network Operations

• All connections must use SSL (or other encryption)

○ Performance impact is minimal versus risks

• Mysql ~>= 5.7 has SSL connection by default

○ Ensure >= 5.7.13

• Network encrypted tunnel options

○ N2N, openvpn (TLS), ssh tunnel, IPSEC, Links:

https://www.percona.com/blog/2017/06/27/ssl-connections-in-mysql-5-7/ https://www.percona.com/blog/2017/09/19/proxysql-improves-mysql-sslconnections/ http://databaseblog.myname.nl/2017/05/mysql-and-ssltls-performance.html https://github.com/ntop/n2n

8

MySQL Data Encryption

• Disk Volume encryption

○ BitLocker, FileVault2, LUKS, eCryptFS, Veracrypt, EBS encrypted volumes (please use KMS for encryption keys!)

• At-rest encryption for InnoDB tablespace
• At-rest encryption for binary logs

Links:

https://dev.mysql.com/doc/refman/5.7/en/faqs-tablespace-encryption.html https://docs.oracle.com/cd/E17952_01/mysql-5.7-en/innodb-tablespace-encryption.html https://www.percona.com/doc/percona-server/LATEST/management/data_at_rest_encryption.html

9

Connection Overhead

https://tinyurl.com/ycldtnpk https://tinyurl.com/y7v7jhmo

Security Features by MySQL

MySQL variants

11

MySQL Variants

• MySQL Community Edition 5.5 -> 8.0
• MySQL Enterprise Edition
• Percona Server 5.5 -> 5.7 -> 8.0
• MariaDB 5.5, 10.X
• Galera, Group Replication/InnoDB Cluster
• X Protocol/mysqlsh (33060) -> 8.0

Links:

https://dev.mysql.com/doc/internals/en/x-protocol.html https://dev.mysql.com/doc/internals/en/x-protocol-authentication-authentication.html

12

MySQL Security by Version

• GRANT (3.23)
• REVOKE (3.23)
• SET PASSWORD (3.23)
• SHOW GRANTS (3.23)
• DROP USER (4.1)
• SHOW PRIVILEGES (4.1)
• CREATE USER (5.0)
• RENAME USER (5.0)
• ALTER USER (5.6)
• SHOW CREATE USER (5.7)
• CREATE ROLE (8.0)
• DROP ROLE (8.0)
• SET ROLE (8.0)
• SET DEFAULT ROLE (8.0)

13

Important mysql.user table

< 5.5 host user password > 5.5 authentication_string > 5.6 password_expired > 5.7 account_locked password (removed) > 8.0 create_role_priv drop_role_priv

14

Security Features by MySQL Version

• 5.1 - McAfee Audit plugin
• 5.5 - pluggable authentication (MariaDB 5.2

backport), proxy users, changes in mysql.user table, client password warning; Enterprise provided Audit and PAM authentication (present again in Percona Server for MySQL and MariaDB Server)

• 5.6 - encrypted client credentials

(mysql_config_editor), sha256_password, password expiry, VALIDATE_PASSWORD_STRENGTH(),

• -random-passwords (optional random on

install), mysql.user password_expired column; Enterprise Firewall

• 5.7 - grep for root password on installation,

password expiry every ‘n’ days, user accounts can be locked/unlocked, mysql_ssl_rsa_setup, mysql.user.password removed, super_read_only, at rest tablespace encryption

• 8.0 - roles + mysql.user changes
• Percona Server

○

MySQL 5.5 - extended SHOW GRANTS, utility user, userstats , Audit Plugin

○

MySQL 5.6 - super_read_only

○

MySQL 5.7 - Vault plugin

15

Harden your MySQL Security

• Set a password for ‘root’
• Remove all anonymous users
• Remove ‘test’ database (gone on 8.0)
• Use mysql_secure_installation where possible (5.7)
• Install (and use!) validate_password plugin (>= 5.6)

○ There are methods which circumvent this however ...

■ ... IDENTIFIED BY ‘*ABC...’ (passing the hash, allows using a weak password)

• Ensure Path of Least Privilege

○ Stop using GRANT ALL on *.*... ○ ALL includes: FILE, CREATE_ROUTINE, SUPER, ○ Allowing write on mysql.users can allow injection of credentials that will be loaded at a later time!

MySQL Security in the Cloud

AWS Focused

17

Pillars of AWS Security

Data Protection Privilege Management Infrastructure Management Detective Controls

Security

18

AWS Security Best Practices

• Know shared responsibility model
• Manage AWS Accounts, IAM / MFA Users, Groups, and Roles
• EC2 Topology management

○ VPC

• RDS MySQL

○ RDS ○ AURORA

• AWS Tools

○ CloudTrail ○ CloudWatch ○ Config

19

AWS Security Best Practices

• RDS

○ Shared responsibility for container service

• EC2

○ Amazon Machine Images (AMIs) ○ Operating systems • Applications ○ Data in transit ○ Data at rest ○ Data stores ○ Credentials - Key pairs ○ Policies and configuration

20

AWS Shared Responsibility Model

21

AWS IAM is your friend

• Centrally manage users
• Manage security credentials

○ passwords, access keys, and permissions policies

• Beware of regions, availability zones, endpoints
• AWS API keys require strict protection

○ E.g. code pushed to Github, Bitbucket etc with keys

22

In addition to IAM

• AWS Key Management Service
• AWS CloudTrail

○ Audit logging, invaluable to know what occurred and when

• AWS Maice - Data Classification Service
• AWS Trusted Advisor

○ Automated tool to get reports on security groups etc (if you spend enough)

https://aws.amazon.com/premiumsupport/ta-faqs/

23

Pre-configure and harden EC2 AMI

• Disable root API access keys and secret key
• Require MFA for all IAM accounts
• Restrict access to instances from limited IP ranges using Security

Groups

• Password protect the .pem file on user machines
• Delete keys from the authorized_keys file on your instances when

someone leaves your organization or no longer requires access

• Rotate credentials (DB, Access Keys)
• Regularly run least privilege checks using IAM user Access Advisor and

IAM user Last Used Access Keys

• Use bastion hosts to enforce control and visibility

24

Utilizing AWS VPC

25

MySQL Data in Transit

• Web Layer

○ Encrypt data in transit using IPSec ESP and/or SSL/TLS ○ Authenticate data integrity using IPSec ESP/AH, and/or SSL/TLS ○ Use IPSec with IKE with pre-shared keys

• Database Layer

○ SSL/TLS is currently supported for connections to Amazon RDS MySQL ○ AWS provides a single self-signed certificate associated with the MySQL

26

AWS Trusted Advisory Tool Checks

• Limited access to common administrative ports to only a small subset of
• addresses. This includes ports 22 (SSH), 23 (Telnet) 3389 (RDP), and

5500 (VNC).

• Limited access to common database ports. This includes ports 1433

(MSSQL Server), 1434 (MSSQL Monitor), 3306 (MySQL), Oracle (1521) and 5432 (PostgreSQL).

• IAM is configured to help ensure secure access control of AWS

resources.

• Multi-factor authentication (MFA) token is enabled to provide two-factor

authentication for the root AWS account.

27

References and Credits

References:

• AWS Security Best Practices
• AIM Best Practices
• Amazon Virtual Private Cloud

Connectivity Options

• VPC Networking Components
• SSL Connections in MySQL 5.7
• ProxySQL Improves MySQL

SSL Connections

• Everything about MySQL Users

and Logins You Didn’t Know and Were Afraid to Ask Credits:

• Colin Charles
• Janos Ruzso
• Tibor Korocz
• Jervin Real
• Daniel van Eeden

Questions and Answer

29

Thank You Sponsors!!

30

Rate My Session
