slide-1
SLIDE 1

Scalable Data Services with mongoDB

slide-2
SLIDE 2

High Performance High Availability

slide-3
SLIDE 3

for...

Managers Architects Developers (Web) Admins

slide-4
SLIDE 4

Data ...

slide-5
SLIDE 5

http://www.flickr.com/photos/annarbor/4350618884/in/set- 72157623414542180/

slide-6
SLIDE 6

Data Services ...

slide-7
SLIDE 7

services data for...

Dynamic Web Sites Mobile Applications

slide-8
SLIDE 8

data services are driven by...

Databases (on) Remote Servers

slide-9
SLIDE 9

mongo ...

slide-10
SLIDE 10

mongo what?

{ “type“: “db“, “name“: “mongo“ }

slide-11
SLIDE 11

mongo key features?

{ “tables“: false, “sql“: false, “documents“: true, “json“: true, “buzzword_bingo_compatible“: true }

slide-12
SLIDE 12

more mongo features?

{ “implemented_in“: “C++“, “has_replication“: true, “has_sharding“: true, “stores_files“: true, “commercial_support“: true }

slide-13
SLIDE 13

still more mongo features?

{ “documentation“: “excellent“, “speed“: “blazing_fast“, “level_to_start_with“: “low“, “stores_files“: true, “location_search“: true }

slide-14
SLIDE 14

mongo suited for?

{ “reads“: “a great many“ “writes“: “just a few“ }

slide-15
SLIDE 15

mongo not suited for?

{ “accuracy“: “must have“, “consistency“: “must have“, “internal_references“: “many“ }

slide-16
SLIDE 16

language access?

[ “php“, “ruby“, “java“, “python“ ]

slide-17
SLIDE 17

more language access?

[ “perl“, “javascript“, “scala“, “erlang“ ]

slide-18
SLIDE 18

still more language access?

“tl;dr“

slide-19
SLIDE 19

license?

{ “core“: “AGPL “ “drivers“: “Apache“ }

slide-20
SLIDE 20

No SQL ...

slide-21
SLIDE 21

tables?

PERSONS: id, firstname, lastname 1, "Christian", "Hartmann" ADDRESSES: street, zip, city, person_id "Katzlerstraße 9", 10829, "Berlin", 1 URLS: url, person_id “http://hartmann-it-design.de“, 1 “mailto:christian@hartmann-it-design.de", 1

slide-22
SLIDE 22

documents!

{ "firstname": "Christian", "lastname": "Hartmann", "postal": { "street": "Katzlerstraße 9", "zip": 10829, "city": "Berlin" }, "urls": [ "http://hartmann-it-design.de", "mailto:christian@hartmann-it-design.de", ], "rev": 1.0 }

slide-23
SLIDE 23

storing files ...

slide-24
SLIDE 24

storing files in database?

yes! small files and large files and even huge files and even across multiple servers “GridFS“

slide-25
SLIDE 25

GridFS?

{ “name“: “GridFS“, “type“: “collection“ } > (no) mount --type gridfs

slide-26
SLIDE 26

Scalability ...

slide-27
SLIDE 27

need for scalability

mass of data high performance

slide-28
SLIDE 28

scalability factors

amount of data performance

slide-29
SLIDE 29

replication (HA)

server 1: A-X server 2: A-X server 3: A-X automatic failover automatic desaster recovering with or without master multi data center

slide-30
SLIDE 30

sharding (HP)

server 1: A-F server 2: H-K server 3: L-P server 4: Q-T server 5: U-X

slide-31
SLIDE 31

for (SQL) Developers ...

slide-32
SLIDE 32

SQL?

no! sorry no sql here

slide-33
SLIDE 33

sql mappings...

ALTER TABLE users ADD ...

  • ops .. n/a (there is no alter table)
slide-34
SLIDE 34

more sql mappings...

SELECT * FROM users WHERE age=33 db.users.find({age:33})

slide-35
SLIDE 35

still more sql mappings...

SELECT order_id FROM orders o,

  • rder_line_items li WHERE

li.order_id=o.order_id AND li.sku=12345 db.orders.find({"items.sku":12345},{_id:1})

slide-36
SLIDE 36

syntactic shugar ...

db.users.find( { name: /^[JY]oe|^[JY]ö/i } )

slide-37
SLIDE 37

more syntactic shugar ...

db.users.find( {age: {'$exists': false}} ).count()

slide-38
SLIDE 38

can't stop with syntactic shugar ...

db.users.find( { homes : { $size: 2 } } )

slide-39
SLIDE 39

still more - it's annoying i know ...

db.meta.find( { name: { $notin : [ “foo“,“bar“ ] }} )

slide-40
SLIDE 40

map & reduce?

available no need for (if distributed storage reasoned)

slide-41
SLIDE 41

for Admins ...

slide-42
SLIDE 42

replication (master slave)

server 1: A-X (master) server 2: A-X (slave) [/etc/mongodb.conf] master = true # or slave = true source = master.example.com

slide-43
SLIDE 43

replication (replica set)

server 1: (primary) server 2: (secondary) server 3: (recovering) replSet = my_first_repl_set

slide-44
SLIDE 44

replication (replica set) cont...

> var config = { _id : “my_first_repl_set“, members : [ {_id : 0, host : “server1“ }, {_id : 1, host : “server2“ }, {_id : 1, host : “server3“ } ] } > rs.initiate(config)

slide-45
SLIDE 45

sharding (components)

shards (preferable replicated) config servers (preferable replicated) routing servers sharding key[s] chunks

slide-46
SLIDE 46
slide-47
SLIDE 47

sharding (simple config)

> db.runCommand( { “enablesharding“ : "test" } ) > db.runCommand( { “shardcollection“ : "test.users", “key“ : { “name“ : 1 } } )

slide-48
SLIDE 48

sharding (chunk config)

{ "ns" : "test.users", "min" : { "name" : "A" }, "max" : { "name" : "F" }, "shard" : "shard1" }

slide-49
SLIDE 49

GUI ? ...

slide-50
SLIDE 50
