Saturday Morning Sem inar: The Case of a Kidney w ith a Strange Constellation of Histologic Findings 66 th Annual Meeting California Society of Pathologists San Francisco, CA 12/ 4/ 2013 Jesse K McKenney, MD Director, Surgical Pathology

slide-1
SLIDE 1

Saturday Morning Sem inar: The Case of a Kidney w ith a Strange Constellation of Histologic Findings

Jesse K McKenney, MD Director, Surgical Pathology

66th Annual Meeting California Society of Pathologists San Francisco, CA 12/ 4/ 2013

slide-2
SLIDE 2
  • 44 year old woman with left renal

mass on CT (3 cm)

  • Prior history of right sided RCC
  • Underwent partial nephrectomy

Clinical Scenario

slide-3
SLIDE 3

3 cm Renal Mass

slide-4
SLIDE 4

3 cm Renal Mass

slide-5
SLIDE 5

3 cm Renal Mass

slide-6
SLIDE 6

3 cm Renal Mass

slide-7
SLIDE 7

3 cm Renal Mass

slide-8
SLIDE 8

3 cm Renal Mass

slide-9
SLIDE 9
  • Will it help?

Immunohistochemistry

slide-10
SLIDE 10

PAX-8 Renal Cell Carcinoma? Unclassified?

slide-11
SLIDE 11

Background Kidney- Incidental Lesions

slide-12
SLIDE 12

Background Kidney- Incidental Lesions

slide-13
SLIDE 13

PAX-8 HMB45

Positive in Spindle Cells Positive in Epithelial Cells

slide-14
SLIDE 14

Angiomyolipoma with Epithelial Cysts

slide-15
SLIDE 15
slide-16
SLIDE 16

Renal Cell Carcinoma, Unclassified + Prior RCC?? + AMLEC

Is there a connection?

Cystic, Eosinophilic, Hobnail Subtype? Specificity?

slide-17
SLIDE 17
slide-18
SLIDE 18

Prior Contralateral RCC…….Suptype?

slide-19
SLIDE 19

Prior Contralateral RCC…….Subtype?

slide-20
SLIDE 20

Prior Contralateral RCC…....Subtype?

slide-21
SLIDE 21

xxxxx Prior Contralateral RCC…….Subtype?

slide-22
SLIDE 22

Prior Contralateral RCC…….Subtype? CK7

slide-23
SLIDE 23

Renal Cell Carcinoma with Associated Smooth Muscle Stroma

  • r

Renal Angioadenomyomatous Tumor (RAT)

slide-24
SLIDE 24

Martignoni G et al. Renal cell carcinoma with smooth muscle stroma lacks chromosome 3p and VHL alterations. Modern Pathol 2013 Nov 8 [Epub ahead of print]

slide-25
SLIDE 25

Prior Contralateral Nephrectomy Adjacent Spindle Cells?

slide-26
SLIDE 26

Background kidney in prior resection?

slide-27
SLIDE 27

Background kidney in prior resection?

slide-28
SLIDE 28
slide-29
SLIDE 29

RCC, Unclassified + AMLEC + RCC with features of RAT + AMLEC + Young onset in female + Background kidney cysts with atypia

Emerging Picture?

slide-30
SLIDE 30

History of Tuberous Sclerosis?

Emerging Picture?

YES

slide-31
SLIDE 31

Tuberous Sclerosis: Neoplasia

  • Skin Angiofibromas
  • Renal Angiomyolipoma (AML)
  • Multiple, bilateral, may involve other organs
  • Other PEComa spectrum tumors
  • Lymphangioleiomyomatosis
  • Cardiac rhabdomyoma
  • Retinal hamartoma
  • Subependymal giant cell astrocytoma (SEGA)
  • Other renal tumors
  • RCC- case reports
slide-32
SLIDE 32

3 cm Renal Mass

slide-33
SLIDE 33
slide-34
SLIDE 34

Int J Surg Pathol 2010; 18: 409-418

slide-35
SLIDE 35

Diagnosis: RCC, Unclassified (Not a pattern in WHO) Associated with Tuberous Sclerosis

slide-36
SLIDE 36

No Increased Risk over General Population

slide-37
SLIDE 37
slide-38
SLIDE 38
slide-39
SLIDE 39

HMB-45

slide-40
SLIDE 40
slide-41
SLIDE 41

RCC: Eosinophilic and Cystic

slide-42
SLIDE 42

RCC: Chromophobe?

slide-43
SLIDE 43
  • Younger age at presentation
  • Multiple RCCs common
  • Associated AML common (often AMLEC)
  • Renal tubular atypia common
  • Renal cysts common

RCC Associated with Tuberous Sclerosis: A Clinicopathologic Study of 16 Patients with 28 Total Tumors

slide-44
SLIDE 44

RCC Associated with Tuberous Sclerosis: A Clinicopathologic Study of 16 Patients with 28 Total Tumors

  • RCC Morphology

– 40-50%: RAT-like pattern (smooth muscle stroma) – 30-40%: Chromophobe-like – 15-20%: Eosinophilic….cystic and hobnail

  • AML in 93% (AMLEC in 20%)

– Microscopic tumorlets common

slide-45
SLIDE 45

Eosinophilic with cysts: 40-50%

RCC AML

slide-46
SLIDE 46

Clear cells with smooth muscle stroma: 40-50%

slide-47
SLIDE 47

Clear cells with smooth muscle stroma: 40-50%

CK7

slide-48
SLIDE 48

Chromophobe-Like: 30-40%

slide-49
SLIDE 49

Chromophobe-Like: 30-40%

slide-50
SLIDE 50

Chromophobe-Like: 30-40%

slide-51
SLIDE 51

Eosinophilic with cysts: 40-50%

slide-52
SLIDE 52

Eosinophilic with cysts: 40-50% Solid Foci

slide-53
SLIDE 53

AMLEC-like foci: 20%

slide-54
SLIDE 54

AMLEC-like foci: 20%

slide-55
SLIDE 55
slide-56
SLIDE 56

Microscopic AML Tumorlets

slide-57
SLIDE 57

Microscopic AML Tumorlets

slide-58
SLIDE 58

Cysts with Cytoplasmic Eosinophilia

slide-59
SLIDE 59

Cysts with Cytoplasmic Eosinophilia

slide-60
SLIDE 60

Tubular Atypia

slide-61
SLIDE 61

Tubular Atypia

slide-62
SLIDE 62
slide-63
SLIDE 63

The Syndromes

  • von Hippel-Lindau
  • Hereditary Papillary RCC
  • Hereditary Leiomyomatosis-RCC
  • Birt-Hogg-Dubé
  • Tuberous Sclerosis
  • RCC Associated with Germline SDHB mutation
  • Other very rare examples…..
slide-64
SLIDE 64

Hereditary Leiomyomatosis RCC (HLRCC)

  • Spectrum of neoplasia

–Leiomyomas of skin and uterus

  • Most patients develop cutaneous

leiomyomas

  • Early hysterectomy for myomas

–Renal carcinomas

  • Often solitary and unilateral
  • Low penetrance (20-35%)
slide-65
SLIDE 65

Renal Cell Carcinoma in HLRCC

slide-66
SLIDE 66

Renal Cell Carcinoma in HLRCC

slide-67
SLIDE 67

Renal Cell Carcinoma in HLRCC: Perinucleolar Halo

slide-68
SLIDE 68

Birt-Hogg-Dubé Syndrome

  • Renal tumors (15-27%)
  • Cutaneous lesions

– Fibrofolliculoma – Trichodiscoma – Acrochordon

  • Spontaneous pneumothorax
  • Colorectal neoplasia
  • Medullary thyroid carcinoma
  • Lipomas
slide-69
SLIDE 69

HOT

Birt-Hogg-Dubé Associated Renal Neoplasm

slide-70
SLIDE 70

Birt-Hogg-Dubé Associated Renal Neoplasm

slide-71
SLIDE 71

Birt-Hogg-Dubé Associated Oncocytosis

slide-72
SLIDE 72

Birt-Hogg-Dubé Associated Oncocytosis

slide-73
SLIDE 73

Birt-Hogg-Dubé Associated Renal Neoplasm

slide-74
SLIDE 74

Birt-Hogg-Dubé Associated Renal Neoplasm

slide-75
SLIDE 75

SDH Mutant RCC

  • Families with hereditary paraganglioma

syndrome occasionally have members with RCC

– Type 4: Germline SDHB mutations (PGL4)

slide-76
SLIDE 76

SDH Mutant RCC: Solid

slide-77
SLIDE 77

SDH Mutant RCC: Cystic

slide-78
SLIDE 78

SDH Mutant RCC: Inclusions

slide-79
SLIDE 79

SDH Mutant RCC: Inclusions

slide-80
SLIDE 80

SDH Mutant RCC SDHB Courtesy of: Dr. Anthony Gill , Royal North Shore, Sydney

slide-81
SLIDE 81

Summary

  • Surgical pathologists play a role in the

identification of hereditary neoplasia syndromes

  • Increased recognition of less clinically

apparent forms of many syndromes

  • Utilize a comment discussing the possibility
  • f hereditary syndrome
slide-82
SLIDE 82

Summary

  • Tuberous Sclerosis
  • RCCs have some characteristic

clinicopathologic features

  • Background tubular atypia with cystic change
  • Angiomyolipomas (may have epithelial cysts)
slide-83
SLIDE 83

Jesse K McKenney, MD Director, Surgical Pathology Cleveland Clinic
