Safety to the Weak!

Security Through Feebleness: An Unorthodox Manifesto

Rick McGeer, US Ignite

Outline

• What does malware exploit?
• Why can’t we find bugs?
• The Turing Hierarchy and the Verification Hierarchy
• Language Matters: A Cautionary Tale
• A Practical Example: Verifying Software-Defined Networks
• An Extension to Software-Defined Infrastructure
• A Wild Idea: Is Verifying a Turing Machine Really

Undecidable?

• Closing Thoughts: Multi-Model Descriptions

How Does Malware Work?

• In general, exploits a bug
• Broad categories cover most:
• Memory safety (e.g. buffer overflow and dangling pointer bugs)
• Race condition
• Insecure input and output handling
• Faulty use of an API
• Improper use case handling
• Improper exception handling
• Resource leaks, often but not always due to improper exception

handling

• Preprocessing input strings after they are checked for being

acceptable.

Prevent Bugs, Stay Safe

Easier Said Than Done! Why Can’t We Find Bugs?

• All this guy’s fault!
• Turing’s Theorem: Determining if a

Turing Machine Halts is Undecidable

⇒ Can’t tell if a line of code is executed ⇒ Can’t find a bug deterministically

• But: Do We Really Need Turing

Machines for everything?

Turing-Complete Languages

✓ Easy to build ✓ Powerful

○ “I can do anything in language XYZ”

✗ Often more powerful than required ✗ Impossible to verify

The Turing Hierarchy And the Verification Hierarchy

Model of Computation Complexity of Verification Logic-Free (Isomorphism Check) Polynomial State-Free NP-Complete Finite-State Various from NP-Complete to P-Space Complete* Turing Complete Undecidable

* Depends on exact variant of temporal logic being used Powerful enough for many applications but largely unused in programming!

A Cautionary Tale: Verilog and VHDL

• Hardware (Chips) are finite-state

○ “Datapath” is combinatory (state-free) ○ “Control” is a collection of finite-state machines

• Many Verification Technologies!

○ BDD-based, powerful SAT tools... ○ Products from every major Electronic Design Automation vendor ○ Various startups over the years…

• But...hard to get designs described in appropriate

languages

• Design-tool ecosystem has grown up around Verilog and

VHDL...

Verilog and VHDL

• Both date from the 1980’s

○ Before Formal Verification in the early ‘90s ○ Era of 1980’s:

■ Mostly hand design (of logic, at least) ■ Only really prevalent EDA tool (for logic) was simulation

○ Grew up as simulator programming languages

• Verilog: hacked-together commercial product without

clean semantics

○ Metaphors appealing to designers

• VHDL: Born from losing Ada effort

Verilog and VHDL

• Mixed Simulator Control With Hardware Description
• Result

○ Hard to tell what the hardware was ○ Couldn’t formally verify a design ○ Couldn’t even “synthesize” (aka, compile) it into hardware

• Finally

○ “Synthesis” semantics (aka, figure out what was really hardware) ○ “Synthesizable” subsets of languages

• Imagine…

○ “Computational” semantics of C/Java/Python/etc… ○ “Compilable” subsets of programming languages….

A Positive Tale: How Networking Became Verifiable

Control Plane Data Plane Forwarding Tables (State-Free) Packets Packets Control Signaling Control Signaling Traditional Switch

• Network Did

Control + Data Turing Machine ✓ Ran autonomously (no external control) ✗ Verification Undecidable

Software-Defined Networking: Off With Its Head!

Data Plane Forwarding Tables (State-Free) Packets Packets SDN Switch

• Network Forwards

Packets, sends state information to controller ✗ Requires External Controller ✓ Verification In NP

External Controller

State Information

Key Points

• Done to make networks programmable (controller could

be programmed) but also provided verification

• Network of Forwarding Tables isomorphic to state free

logic network

○ Could verify network of forwarding tables with SAT engine

• Verification Methodology

○ Don’t verify controller -- verify its output before updating network

• Better: Safe Update

○ Update schedule that preserved invariants (aka, bug-free network)

• Still better: Network specifications often state-free

Anatomy of an SDN Ecosystem

Desired Network Specifications Controller State-Free Forwarding Table State-Free Forwarding Table Desired Network Specifications Finite-state or state-free, verifiable! State-free, verifiable!

Input verifiable,

• utput verifiable

⇒ System verifiable

Extension to SDI Deployment

• SDI: Collection of VMs, containers, networks tuned to

particular application

• Key problem: Configuring underlying infrastructure to

accomplish task

○ Allocate VMs and Containers ○ Use SDN to configure networks ○ Use Orchestration Engines (Ansible, Heat, e.g.)

■ Finite-state or restricted-state

• Can we verify/what-ifs about SDI deployment and action?
• Key task: extract formal model from Ansible/Heat OR extend

SDN specification languages to generate SDI Specs

Wild Speculation...Is Verifying Turing Machines Really Undecidable?

• Sure, but…
• Notice that a software-defined networks still has an

unverifiable TM at its heart

• But network as a whole is verifiable

○ Verify the inputs to the TM and its outputs

• Can we do the same with programs?

○ Surround the program with a verifiable model and verify that

A “Verifiable” Program

Program Inputs Outputs Unverifiable Finite-State Program Verifiable Finite-State Input Generator Finite-State Output Spec

A “Verifiable” Program

Program Inputs Outputs Finite-State Program Finite-State Input Generator Finite-State Output Spec Finite-State Input Generator

Runtime Correspondence Checking

• Already informally done through assert statements
• But mixed with execution code
• Complicates execution and makes model hard to extract
• Not coupled to FV
• Significant Research Opportunity

A Final Word...

• We need to design computational

environments/languages with an eye to verification

• Need a mix of models -- weak for verification, strong for

execution

• Key is clean separability for each task
• Use runtime information to validate correspondence
