SAFETY ISSUE #8 Santa Cruz Traffic & Bike Lanes Reconfiguration Solution Challenges no bike lanes no guidance for vehicles & cyclists at Y no mans land at Y Limited width of SCA (64) High Traffic Volume - especially at Peak

slide-1
SLIDE 1

SAFETY ISSUE #8

Santa Cruz Traffic & Bike Lanes — Reconfiguration

slide-2
SLIDE 2

Solution Challenges

no bike lanes no guidance for vehicles & cyclists at Y no mans land at Y Limited width of SCA (64’) High Traffic Volume - especially at Peak Center Turn Lane — required Eastside Parking — required

slide-3
SLIDE 3

Center Turn Lane 2 Travel Lanes each direction Eastside Parking Sharrow Lanes

Current Configuration of SCA

40”

slide-4
SLIDE 4

No Center Turn Lane 2 Travel Lanes each direction Eastside Parking 6’ / 5’ Bike Lanes (NB w/buffer)

KimleyHorn Alternative 1

40”

slide-5
SLIDE 5

No Center Turn Lane 2 Travel Lanes each direction Eastside Parking 5’ Bike Lanes (NB w/buffer)

KimleyHorn Alternative 2

40”

slide-6
SLIDE 6

Center Turn Lane 2 Travel Lanes NB — Single Lane SB Eastside Parking 6’ Bike Lanes (NB is inside bike lane)

Roadway width is 59’ and 5’ is used for wider sidewalks

KimleyHorn Alternative 3

40”

slide-7
SLIDE 7

Center Turn Lane 2 Travel Lanes NB — Single Lane SB Eastside Parking (8’ lane) 6’ /5’ Bike Lanes

Roadway width is 62’ and 2’ is used for wider sidewalks

KimleyHorn Alternative 4

slide-8
SLIDE 8

Center Turn Lane 2 Travel Lanes each direction Eastside Parking SB shared lane / NB 5’ Bike Lane

Safe Issue #8.2

slide-9
SLIDE 9

Center Turn Lane 2 NB Travel Lanes — SB Single Shared Lane Eastside Parking 7’/6’ Bike Lane (NB w/buffer)

Safe Issue #8.3
