SLIDE 1
SAFETY and URBAN DESIGN Transition Zones on National Roads Eimear - - PowerPoint PPT Presentation
SAFETY and URBAN DESIGN Transition Zones on National Roads Eimear - - PowerPoint PPT Presentation
SAFETY and URBAN DESIGN Transition Zones on National Roads Eimear Fox Landscape Architect TII It requires different design solutions for different contexts . Published August 2018 A supplement to DMURS Website www. dmurs.ie 2019 DMURS version
SLIDE 2
SLIDE 3
Website www. dmurs.ie 2019 DMURS version and Supplementary Material/ 5 Advice Notes Launched August 2019
SLIDE 4
SLIDE 5
SLIDE 6
Transition Zones ‘It requires different design solutions for different contexts.’
page 1 DN-GEO-03084
Understanding Local Context
SLIDE 7
RURAL FRINGE
Boundary – hedgerow and trees Footpath – none Kerb – none Access – infrequent or limited to farmland Road width – carriageway only Street lighting – none Built form – infrequent Speed limit - greater than 60kph
TRANSITION ZONE
Boundary – hedgerow and garden hedges with occasional boundary walls and gates Footpath – commencing to one side Kerb – occasional to one side Access – increased individual access Road width – carriageway, including setback/layby Street lighting – occasional or none Built form – occasional buildings offset from road Speed limit –50-60kph
TOWN/SETTLEMENT
Boundary – garden hedges, walls, railings Footpath –both sides Kerb – continuous dropped at crossings Access –individual, school and housing access Road width – carriageway only, no setback or parking Street lighting –one side Built form – closer to road, more regular building line Speed limit – 30-50-60kph
Transition Zone Rural Fringe Town/ Settlement
SLIDE 8
Transition Zone N24 Carrick on Suir, Co Tipperary
Analysis of Local Context
N24
SLIDE 9
Transition Zone N24 Carrick on Suir, Co Tipperary
school/park school gateway gateway key area key area links links links
Analysis of Local Context
N24 park
SLIDE 10
SCHOOL ZONES ‘a need to especially focus traffic calming and landscape elements at school zones where the users are particularly vulnerable to heavy traffic.’
Page 3 DN-GEO-03084
SLIDE 11
school school
School Zone in Transition Zone N24 Carrick on Suir, Co Tipperary
N24
SLIDE 12
School Zones
p3 DN-GEO-03084
- usage who/when
- safety
- connections
- cycle/bus function
- meeting place
- local identify
N24 school school
SLIDE 13
Transition Zone - Design Tools 1. Reduce the actual width of Carriageways 2. Reduce the perceived width of Carriageways 3. Changes to Surface Materials 4. Introducing Vertical Elements
N24
SLIDE 14
Traffic Calming ‘Generally as part of traffic calming there will be a reallocation of the public space in our towns and villages.’
Page 2 DN-GEO-03084
SLIDE 15
village gateway village gateway inner gateway crossing/ key area N76 school
SLIDE 16
village gateway village gateway inner gateway crossing/ key area N76 school
SLIDE 17
Transition Zone - Design Tools 1. Reduce the actual width of Carriageways 2. Reduce the perceived width of Carriageways 3. Changes to Surface Materials 4. Introducing Vertical Elements 5. Identify Gateways and key areas
N76
SLIDE 18
Allocation of existing space
street width - 20m wide
SLIDE 19
street width - 20m wide
Allocation of existing space
SLIDE 20
Reallocation of space Allocation of existing space
street width - 20m wide
SLIDE 21
TII
graphics by Pat Kane, TII Architects Dept.
N76
SLIDE 22
Transition Zone Killeagh, Co Cork
N25
SLIDE 23
GATEWAYS
Calms traffic by informing drivers of a change in driving conditions ahead, change of context. Can align with existing speed limits.
Gateway location chosen ‘ appropriate to a villages specific characteristics’
Page 31 DN-GEO-03084
SLIDE 24
Transition Zone and Gateway N69 Kilcornan, Co Limerick
school/ sports zone N69
SLIDE 25
Transition Zone and Gateway N69 Kilcornan, Co Limerick
N69
SLIDE 26
Transition Zone and Gateway N69 Kilcornan, Co Limerick
Water pump N69
SLIDE 27
TRANSITION ZONES How many areas are we talking about?
SLIDE 28
www.waterfordcouncil.ie/departments/roads-parking/speed-limits.htm
SLIDE 29
www.waterfordcouncil.ie/departments/roads-parking/speed-limits.htm
SLIDE 30
