3D PRINTING AT BROOKS RUNNING 1 Kenny Krotzer | Brooks Running Associate Footwear Developer Sam Green | Stratasys Product Marketing Lead, Rapid Prototyping 2 STRATASYS / A GLOBAL LEADER IN APPLIED ADDITIVE TECHNOLOGY SOLUTIONS 3D PRINTING

SLIDE 1 1

3D PRINTING AT BROOKS RUNNING

SLIDE 2 2

STRATASYS / A GLOBAL LEADER IN APPLIED ADDITIVE TECHNOLOGY SOLUTIONS

Kenny Krotzer | Brooks Running Associate Footwear Developer Sam Green| Stratasys Product Marketing Lead, Rapid Prototyping

SLIDE 3

3D PRINTING AT

SLIDE 4

BROOKS RUNNING

Focus on the run

Founded in 1914
2001 – we go all-in on running
Performance running shoes and apparel only
Headquartered in Seattle, WA
661 employees globally
Footwear manufacturing in Vietnam and China

SLIDE 5

SLIDE 6

LIFE AT BROOKS

SLIDE 7

DEVELOPMENT

SLIDE 8

DEVELOPMENT

Footwear Development = short timelines

Work on 3 seasons of footwear

concurrently

Fall 2018, Spring 2019, and Fall 2019
4-5 designs must be reviewed and

confirmed in one week

Quick iterations of designs is our key to

success

SLIDE 9

FOOTWEAR DESIGN

Iteration until perfection

1. Designer sketches 2D blueprint of a shoe’s midsole/outsole
2. Blueprint is sent to Asia development/engineering team
3. Asia development/engineering redraws in 3D CAD
3. 3D file is sent back to US HQ for review
4. 3D part is printed to confirm it matches our design vision

Repeat until perfect

SLIDE 10

BEFORE 3D PRINTING

Wooden CNC Model

SLIDE 11

3D PRINTED PARTS

Our specs

Currently, our Connex3 is used to validate our designs

Non-functional 3D models
VeroGrey, VeroBlack, VeroWhite, SUP706
We can print four midsole/outsole parts on our 3D printer at once
Print times range from 7-26 hours

SLIDE 12

PRINTING PROCESS

3D printing = saving time and money

3-4 days to confirm and validate designs
Connex 3 = 2 chances to review
3D printing on our Connex3 saves $500-$800 each model we print
If we print only 2 versions of each shoe…
= $8000 saved per season
Time saved = invaluable

SLIDE 13

THE FUTURE

In our perfect world…

3D printing will comprise 100% of the whole development/design

process

We will be able to print fully functional prototypes

with perfect material composition

Leverage 3D printing as future method for

manufacturing

SLIDE 14

Powering Rapid Prototyping

SLIDE 15

STRATASYS / A GLOBAL LEADER IN APPLIED ADDITIVE TECHNOLOGY SOLUTIONS

WHY RAPID PROTOTYPING WITH 3D PRINTING?

Quicker time-to-market Save money Mitigate risk Clear communication Market feedback Design & geometric freedom

SLIDE 16

STRATASYS / A GLOBAL LEADER IN APPLIED ADDITIVE TECHNOLOGY SOLUTIONS

>1500 colors with rigid/rubber-like

properties.

Multi-material sporting goods in

white/gray/black Digital Material shades with an additional vibrant color

Sleek, glossy surfaces
Colorful soft-touch elements
Functional performance testing
Superior consistency and repeatability
Ideal for the high demand RP shop

CONNEX3: DESIGN AND FUNCTIONAL TESTING OF CONSUMER GOODS

SLIDE 17

STRATASYS / A GLOBAL LEADER IN APPLIED ADDITIVE TECHNOLOGY SOLUTIONS

STRATASYS J750: FINAL PRODUCT VISUALIZATION, INCREASED PRODUCTIVITY

Full Color (CMYKW) and multi material
Incredible texture mapping capability
Endless combinations of color, transparency and

flexibility

High productivity 24/7 workhorse
New Agilus30 material – new levels of tear resistance
Coming very soon: flexible full color/full

texture/transparency combinations for shoe uppers, toys, packaging, cosmetics and more

SLIDE 18

STRATASYS / A GLOBAL LEADER IN APPLIED ADDITIVE TECHNOLOGY SOLUTIONS

PROFESSIONAL RAPID PROTOTYPING CRITICAL TO BUSINESS

SLIDE 19

QUESTIONS?

SLIDE 20

20 STRATASYS / A GLOBAL LEADER IN APPLIED ADDITIVE TECHNOLOGY SOLUTIONS

KEEP THE CONVERSATION GOING…

Stratasys Rapid Prototyping http://www.stratasys.com/solutions/rapid-prototyping

SLIDE 21

www.stratasys.com

THANK YOU
