Contaminated Sediments Virtual Workshop: Session 4: Long-term Monitoring Role of Passive Sampling and Porewater Remedial Guidelines (PWRGs) in Long-term Monitoring (Part 1) ROBERT M BURGESS U.S. ENVIRONMENTAL PROTECTION AGENCY, ORD/NHEERL,

slide-1
SLIDE 1
  • 24th Annual NARPM Training Program

Contaminated Sediments Virtual Workshop: Session 4: Long-term Monitoring

Role of Passive Sampling and Porewater Remedial Guidelines (PWRGs) in Long-term Monitoring (Part 1)

ROBERT M BURGESS U.S. ENVIRONMENTAL PROTECTION AGENCY, ORD/NHEERL, NARRAGANSETT, RHODE ISLAND 02882 USA

Office of Research and Development National Health and Environmental Effects Research Laboratory, Atlantic Ecology Division, Narragansett, RI, USA Contaminated Sediments Virtual Workshop: Session 4: Long term Monitoring, 20 November 2019

1

slide-2
SLIDE 2
  • 24th Annual NARPM Training Program

1

Outline

  • What passive sampling tells us
  • Why do we care about the freely dissolved concentration

(Cfree)

  • Preparing, deploying, recovering, and storing passive

samplers

  • Applications in long-term monitoring

Office of Research and Development National Health and Environmental Effects Research Laboratory, Atlantic Ecology Division, Narragansett, RI, USA Contaminated Sediments Virtual Workshop: Session 4: Long term Monitoring, 20 November 2019

  • Focus on nonionic organic contaminants (no metals)

PCBs DDTs Dioxins PAHs Furans

2

PBDEs Pyrethroids

slide-3
SLIDE 3
  • 24th Annual NARPM Training Program

2

What Passive Sampling Tells Us

(1) Freely dissolved concentrations (Cfree) of contaminants of

√

concern (COC) in water around passive sampler

  • Surrogate for bioavailable concentrations of COC

– Pore water (Interstitial Water) – Water column

  • Compare to Water Quality Criteria (WQC), other water

quality standards, sediment guidelines or water-only toxicity data for exceedances (2) Concentration of COCs in passive sampler

√

  • Good correlation with bioaccumulation by aquatic organisms
  • Serve as surrogates for biomonitoring organisms

– Benthic and water column organisms – Fish consumed by humans

Office of Research and Development National Health and Environmental Effects Research Laboratory, Atlantic Ecology Division, Narragansett, RI, USA Contaminated Sediments Virtual Workshop: Session 4: Long term Monitoring, 20 November 2019

3

slide-4
SLIDE 4
  • 24th Annual NARPM Training Program

3

Why Do We Care about the Freely Dissolved Concentration (Cfree)?

å

exposure to bioavailable chemicals?

  • Sediment?
  • Food?
  • Pore Water = Freely dissolved concentration (Cfree)?

For benthic organisms: What media is an effective surrogate for

Chironomus tentans

=

å

Adams et al. (1985) first addressed this question

  • Two Kepone-amended sediments (same levels)
  • 1.5% and 12.3% sediment organic carbon

Kepone

  • Freshwater midge (Chironomus tentans)
  • Exposure-response relationships
  • Survival versus exposure

Office of Research and Development National Health and Environmental Effects Research Laboratory, Atlantic Ecology Division, Narragansett, RI, USA Contaminated Sediments Virtual Workshop: Session 4: Long term Monitoring, 20 November 2019

4

slide-5
SLIDE 5
  • 24th Annual NARPM Training Program

4 Concen a on (µg re wa

Why Do We Care about the Freely Dissolved Concentration (Cfree)?

What media is an effective

100

surrogate for exposure to bioavailable chemicals?

75

1.5% Organic carbon/Kg 12.3 % Organic sediment (dry) carbon/Kg

50

sediment (dry) 1.5% Organic carbon/Kg sediment (dry) 12.3 % Organic carbon/Kg

25

sediment (dry)

20 40 60 80

Sediment tr ti Pore Water Concentration Freely Dissolved Concentration (Cfree) (mg Kepone/Kg sediment (dry)) Kepone/L Po ter) (µg Kepone/L Pore water)

Office of Research and Development National Health and Environmental Effects Research Laboratory, Atlantic Ecology Division, Narragansett, RI, USA Contaminated Sediments Virtual Workshop: Session 4: Long term Monitoring, 20 November 2019

Midge Survival (%) Food Sediment Pore Water Freely Dissolved Concentration

5

slide-6
SLIDE 6
  • 24th Annual NARPM Training Program

5

Preparing, Deploying, Recovering, and Storing Passive Samplers

(-4 ˚C wrapped (3) Storage (2) Deployment and Recovery (~ 30 days) Passive Sampler (1) Solvent Cleaning in foil) (PE or POM) (~24 hours) (4) Solvent Extraction (48 hours) (6) GC/MS Quantification and (5) Volume reduction (~ 1 hour) Data Analysis/Interpretation

Office of Research and Development National Health and Environmental Effects Research Laboratory, Atlantic Ecology Division, Narragansett, RI, USA Contaminated Sediments Virtual Workshop: Session 4: Long term Monitoring, 20 November 2019

6

slide-7
SLIDE 7
  • 24th Annual NARPM Training Program

6

Preparing, Deploying, Recovering, and Storing Passive Samplers Water Column Deployment

Copper tubing housing

Office of Research and Development National Health and Environmental Effects Research Laboratory, Atlantic Ecology Division, Narragansett, RI, USA Contaminated Sediments Virtual Workshop: Session 4: Long term Monitoring, 20 November 2019

7

slide-8
SLIDE 8
  • 24th Annual NARPM Training Program

7

Preparing, Deploying, Recovering, Pore Water Deployment and Storing Passive Samplers

Aluminum or stainless steel frame Copper tubing housing

Office of Research and Development National Health and Environmental Effects Research Laboratory, Atlantic Ecology Division, Narragansett, RI, USA Contaminated Sediments Virtual Workshop: Session 4: Long term Monitoring, 20 November 2019

8

slide-9
SLIDE 9
  • 24th Annual NARPM Training Program

8 Superfund Sites where Passive Sampling has been used (Updated October 2019) (Lambert et al. 2019):

Allegany Ballistics Laboratory (Region 3) Aniston PCB (Region 4) Berry’s Creek (Region 2) Brodhead Creek (Region 3) Columbia Slough (Region 10) Donna Reservoir (Region 6) Dover Gas Light (Region 3) Diamond Alkali (Region 2) GLLA River Basin AOC (Region 5) Grand Calumet (GLNPO-Region 5) Grasse River (Region 2) Kerr-McGee/Tronox (Region 4) Lake Hartwell (Region 4) Lower Duwamish Waterway (Region 10) Manistique River (Region 5) McCormick and Baxter (Region 10) Metal Bank (Region 3) MW Manufacturing (Region 3) Naval Station Newport (Region 1) New Bedford Harbor (Region 1) Ordot Landfill (Region 9) Pacific Sound Resources (Region 10) Palos Verdes Shelf (Region 9) Portland Harbor (Region 10) San Jacinto Waste Pits (Region 6) Tennessee Products (Region 4) United Heckathorn (Region 9) Whitmoyer Laboratories (Region 3) Wyckoff (Region 10)

Office of Research and Development National Health and Environmental Effects Research Laboratory, Atlantic Ecology Division, Narragansett, RI, USA Contaminated Sediments Virtual Workshop: Session 4: Long term Monitoring, 20 November 2019

9

slide-10
SLIDE 10
  • 24th Annual NARPM Training Program

9 Most Commonly used Passive Samplers:

Office of Research and Development National Health and Environmental Effects Research Laboratory, Atlantic Ecology Division, Narragansett, RI, USA Contaminated Sediments Virtual Workshop: Session 4: Long term Monitoring, 20 November 2019

10

slide-11
SLIDE 11
  • 24th Annual NARPM Training Program

10

s s s t n n t

  • n

e e i e t s s e s s m n a m v e l u e m i r c t s u c c u e a f f A e E a e M

  • y

t i i B d S x e u y / m l t F c i e x i R T

  • Use of Passive Sampling at Superfund Sites (n = 22)

(Lambert et al. 2019)

2 4 6 8 10 12 # of sites

Office of Research and Development National Health and Environmental Effects Research Laboratory, Atlantic Ecology Division, Narragansett, RI, USA Contaminated Sediments Virtual Workshop: Session 4: Long term Monitoring, 20 November 2019

11

slide-12
SLIDE 12

and low dissolved oxygen conditions environmental relevance

  • 24th Annual NARPM Training Program

11

  • ●
  • ●
  • ●● ●
  • ●
  • ●
  • ●

Applications in Long-term Monitoring

  • Fall 2014

Total PCBs (ng/g lipid or polymer)

  • Use of passive sampling as a surrogate for deploying organisms in long-

term biomonitoring

  • New Bedford Harbor Superfund Site
  • (New Bedford, MA, USA)
  • Advantages

Year-round deployments

  • ●
  • Deployable under toxic
  • Cost-effective

Disadvantage

  • Potential loss of
  • Sediments contaminated with elevated
  • concentrations of PCBs
  • Water column biomonitoring with blue
  • mussels since early 1990s at three stations

Evaluate Relationship &

  • In 2014, started assessing use of passive

Provide Guidance sampling to RPMs

  • Parallel deployments for three years

1990 2000 2010 2020 1995 2005 2015

Year

Office of Research and Development National Health and Environmental Effects Research Laboratory, Atlantic Ecology Division, Narragansett, RI, USA Contaminated Sediments Virtual Workshop: Session 4: Long term Monitoring, 20 November 2019

12

slide-13
SLIDE 13
  • 24th Annual NARPM Training Program

12

Applications in Long-term Monitoring

  • Use of passive sampling to measure contaminant fluxes and capping-

effectiveness in long-term monitoring

20

Water Column Magnitude of transfer to water column Water Column

15 10

Cap effectiveness Cap

5

  • 5
  • 10
  • 15

Sediment & Pore water Sediment & Pore water

  • 20

Office of Research and Development National Health and Environmental Effects Research Laboratory, Atlantic Ecology Division, Narragansett, RI, USA Contaminated Sediments Virtual Workshop: Session 4: Long term Monitoring, 20 November 2019

Depth (cm)

13

slide-14
SLIDE 14
  • 24th Annual NARPM Training Program

13

Applications in Long-term Monitoring

Office of Research and Development National Health and Environmental Effects Research Laboratory, Atlantic Ecology Division, Narragansett, RI, USA Contaminated Sediments Virtual Workshop: Session 4: Long term Monitoring, 20 November 2019

14
