Guidelines for Investigating & Assessing Product Endotoxin Failures Richard Fitzpatrick & Aoife Brady

2

Content

• Summary of Irish Pharmaceutical/Medical Device Industry
• Background on Endotoxin

– What are endotoxins – Where endotoxins are found – Physiological effect of endotoxin on the body

• Regulatory requirements for endotoxin testing of medical devices

– AMI-ST72, USP 85, USP 161

• Implications of endotoxin Failures

– Patient Perspective – Business Perspective

• Guidelines for Investigating Product Endotoxin Failures

– 5 Step guide for conducting product endotoxin investigations – Examples of Product Endotoxin Root Causes

3

• Over 120 pharma companies base in Ireland
• Nine of the top 10 largest pharma companies base

in Ireland

• Pharma sector worth 50.8 billion
• Employs over 25,000 people directly,

100,000 people indirectly

• Over 180 medical device companies base in Ireland
• Eleven of the of the top fifteen largest medical device

companies base in Ireland

• €8 billion industry supplying cardiovascular,
• rthopaedic & diagnostic devices
• Employs over 27,000 people directly

Employs over 100,000 people indirectly

Summary of Irish Pharmaceutical/Medical Device Industry

Synergy Lotus Wallstent

Cardiology Peripheral Intervention

Mustang

4

Summary on Bacterial Endotoxins

• Endotoxins are components of the cell wall of Gram

negative bacteria

• Specifically endotoxins are the lipopolysaccharides

in the outer membrane of Gram negative bacteria

• The primary source of Gram negative bacteria for

medical devices is water to which the product is exposed

• Upon entering the body endotoxins can induce

septic shock and can be fatal

• Endotoxins are not destroyed by sterilization

therefore control & prevention of endotoxin contamination is central to advoiding endotoxin issues

• Estimated that 1 x105 Gram negative bacteria

equivalent to 1 EU To exceed 20 EU in excess of 2 x107 Gram negative bacteria would have to contaminate the device

5

Physiological effect of endotoxin exposure

6

Implications of product endotoxin failures

• Patient Perspective
• Upon entering the body endotoxins

can induce…..

– Septic shock – Fever – Organ Failure – Death

• Business Perspective
• Endotoxin failures including

inadvertent release of contaminated product for human use or inadequate investigations can lead to …..

– Product Recall – Back Orders – Lost of earnings from scrappage of impacted batches – Penalties from competent authorities

7

Examples of FDA 483s for Product Endotoxin Issues

Case Study 1 Company: Sanquin: Holland Plasma Products 44 Batches Rejected Reason

• Insufficient Investigation
• Investigation concluded alteration in

cleaning process was source of endotoxin

• All tests on equip were negative for both

endotoxin and bioburden

• Investigation failed to link a leak as the

possible source of the endotoxin contamination

• No additional investigation for

subsequent batches that had endotoxin alert levels Case Study 2 Company: Sanofi Pasteur: France Vaccine Products 13 batches rejected Reason

• 13 batches failed over a 4 year period

and no root cause identified

• A component was identified as the root

cause but was only used in 4 of the impacted batches

• The impacted component was

continually used in subsequent batches

8

Regulatory Requirements for endotoxin testing

• All companies have a

responsibility to access their products for routine endotoxin testing

• As per AMI ST72 Products

that have direct or indirect contact with vascular, neurological or ophthalmic tissue require routine endotoxin testing

Interventional Cardiology Cardiac Rhythm Management Urology Neuromodulation Electrophysiology Peripheral Intervention. Endoscopy.

Watchout: FDA update to its 510(k) Sterility Review Guidance document 2016 calls out for endotoxin testing for all implants

9

• Validated method for product endotoxin testing: AMI-ST72, USP161, USP85
• Rational for endotoxin testing of product Pre vs Post sterilization: AMI-ST72, USP161
• Batch Definition: AMI-ST72
• Routine product endotoxin sampling plan: AMI-ST72
• Control/Link Batch Release with Product Endotoxin Results AMI-ST72
• “Conduct an adequate & timely investigation” AMI-ST72

What scale of investigation satisfies an adequate investigation ???

Regulatory Requirements for Endotoxin Sampling Plan

Batch Size # of samples <30 2 30-100 3 >101 3% of lot, up to maximum of 10

10

Responding to Product Endotoxin Failures

“Production”

The batch needs to be released today !!

“Product Release”

We are going into back order ! Release the batch? We havent even started the investigation !!

Do we have an Investigation Plan…..????????????

HELP

11

Investigative Endotoxin Testing to Identify Root Cause

12

Five Step Guide for Investigating Endotoxin Failures

• 1. Conduct Lab OOS and confirm endotoxin result
• 2. Conduct initial investigation

– Assemble investigation team – Contain product – Assess impact to subsequent batches – Conduct a line walk of the production process – Apply Investigation tools such as

• Is/Is Not – Helps define the scope of the problem
• Fish bone diagram – helps to identify root causes of the endotoxin failure

3.Conduct review of endotoxin controls

– Product Bioburden Trends – Product Endotoxin Trends – Cleanroom Environmental Trends – Process solutions that come in contact with product – Change of suppliers/production staff or manufacturing process – People behaviour/GMP/cleaning

• 4. Conduct investigative endotoxin testing to identify root cause
• 5. Evaluate investigative results and determine product disposition strategy

13

BET Assay Assessment Flow Chart

Assay Criteria met

%CV standard (<10%) Slope/R2 >0.98 Blank reaction< Lowest standard Sample criteria met %CV of sample <20% Spike recovery 50-200% Endotoxin result within specification Test Passes

Result OOs Test Fails

OOS investigation

14

Laboratory Error – Potential Causes

OOS Result Negative Controls Ok Correct procedure? Training Records Any unusual events during testing? Contamination in other test? Glucans? Technician Error ? Change in product formulation? Test equipment Test reagents Test consumables Contamination during dilution

• Retest originals
• Retest new samples

Sample

• Correct sample?
• Sampled correctly
• Condition

15

Five Step Guide for Investigating Endotoxin Failures

• 1. Conduct Lab OOS and confirm endotoxin result
• 2. Conduct initial investigation

– Assemble investigation team – Contain product – Assess impact to subsequent batches – Conduct a line walk of the production process – Apply Investigation tools such as

• Is/Is Not – Helps define the scope of the problem
• Fish bone diagram – helps to identify root causes of the endotoxin failure

3.Conduct review of endotoxin controls

– Product Bioburden Trends – Product Endotoxin Trends – Cleanroom Environmental Trends – Process solutions that come in contact with product – Change of suppliers/production staff or manufacturing process – People behaviour/GMP/cleaning

• 4. Conduct investigative endotoxin testing to identify root cause
• 5. Evaluate investigative results and determine product disposition strategy

16

Schematic representation of production batch where all test units pass endotoxin testing and batch is released

• Batch consist of 60 lot
• Each lot consist of 20 units
• Batch period is defined as a weeks

production Mon-Fri

• Batch consist of 1200 units

estimated value 250K

• As per AMI ST72 ten units are

required for endotoxin testing and batch release (batch>100 units)

• 2 units are randomly pulled on each

day of production. Randomly selecting 2 units from each day of production improves the power of the sampling plan

• In this scenario all units passed

endotoxin testing and batch can be released

17

Schematic representation of production batch where two units selected from Wednesday production failed endotoxin testing and batch is contained

• Two units selected from

Wednesday’s production failed endotoxin testing. Batch is contained

• All other units selected throughout

the batch passed endotoxin testing

• Initial assessment of results

suggests endotoxin failure is not systemic throughout the batch

18

Guidelines for conducting investigative endotoxin testing to determine root cause

• Hypothetical situation: 2 units from lot 32 failed

batch release endotoxin testing

• Step1: Test 10 additional units for endotoxin from

the impacted lot to determine if the root cause of the endotoxin failure is systemic within the lot

• Step 2: Test 10 additional units for endotoxin from

lots either side of the impacted lot ie lot 31 and lot 33 to determine if root cause is confined to lot 32

• r is more systemic in nature
• Step 3: Test 2 units from each of the 60 lots to

determine if root cause is systemic throughout the batch or is confined to a specific process/component batch

• Note test results obtained from investigative

testing can not be used for batch release. Pending investigation outcome a 2nd round of batch release testing is required to enable batch release

19

Case Study 1. All units selected for investigative endotoxin testing throughout the batch failed

• All units selected for endotoxin

testing failed

• Root cause for endotoxin testing

is systemic throughout the batch

• Manufacturing process is not in

control

• Impacted batch should be

scrapped and manufacturing ceased until root cause is identified

20

Case Study 2. All units selected from a specific days production failed endotoxin testing

• All units selected from a Wednesdays

production failed endotoxin testing

• All other units selected from the weeks

production passed endotoxin testing

• This indicates that root cause for the

failure is confined to a specific process / component lot unique to Wednesday.

• Test 10 additional units derived from

Monday, Tuesday, Thursday & Fridays production lots for batch release testing

• If the 2nd round of batch release testing

passes all units manufactured on Monday, Tuesday, Thursday & Friday can be released. All units manufactured

• n Wednesday should be scrapped

21

Case Study 3. All units selected for investigative endotoxin testing throughout the batch passed

• All units selected for investigative

endotoxin testing throughout the batch passed

• Consideration should be give to whether

the two units that failed endotoxin testing in lot 32 are

– Atypical to lot 32 – Atypical to Wednesday production – Atypical to the entire batch production

• Review all investigative results to

establish if the batch can be released on the basis that the two failed units are atypical to the batch

• Conduct 2nd round of batch release

testing to disposition batch

22

Examples Product Endotoxin Root Causes

• Contaminated Coating soln

– Inproper storage of glassware following washing facilitated formation of Gram negative biofilim

• Contaminated Component Supply by external vendor

– Water used in the manufacturing process highly contaminated with endotoxin

• Labels used to identify units for endotoxin testing

– Labels manufactured using recycled paper which was highly contaminated with endotoxin

• Saliva

– Saliva contains high amounts of endotoxin …800 EU/ml – Hand mouth contact absolutely avoided in cleanroom

23

Conclusion

• Five Step Guide for Investigating Endotoxin Failures:
• 1. Conduct Lab OOS and confirm endotoxin result
• 2. Conduct initial investigation
• 3. Conduct review of endotoxin controls
• 4. Conduct investigative endotoxin testing to identify root cause
• 5. Evaluate investigative results and determine product disposition strategy
• The goal of this 5 step guide is to facilitate an informed, structured and

timely conclusion to the endotoxin OOS investigation and the fate of the impacted batch

24

Responding to Product Endotoxin failures

An informed & structured Investigation Plan will facilitate a timely conclusion to the endotoxin OOS investigation and the fate of the impacted batch Where do I start ?!
