RHyTHM: A Randomized Hybrid Scheme To Hide in the Mobile Crowd Mohammad Khodaei, Andreas Messing, and Panos Papadimitratos Networked Systems Security Group (NSS) www.ee.kth.se/nss Royal Institute of Technology (KTH) Stockholm, Sweden Nov. 28,

slide-1
SLIDE 1

RHyTHM: A Randomized Hybrid Scheme To Hide in the Mobile Crowd

Mohammad Khodaei, Andreas Messing, and Panos Papadimitratos

Networked Systems Security Group (NSS) www.ee.kth.se/nss Royal Institute of Technology (KTH) Stockholm, Sweden

  • Nov. 28, 2017
  • M. Khodaei, A. Messing, P. Papadimitratos

(KTH) IEEE VNC 2017

  • Nov. 28, 2017

1 / 13

slide-2
SLIDE 2

Secure Vehicular Communication (VC) Systems

Vehicular Public Key Infrastructure (VPKI) Root Certification Authority (RCA) Long Term CA (LTCA) Pseudonym CA (PCA) Resolution Authority (RA) Lightweight Directory Access Protocol (LDAP) Roadside Unit (RSU) Trust established with RCA,

  • r through cross certification

RSU 3/4/5G

PCA LTCA PCA LTCA RCA PCA LTCA B A A certifies B Cross-certification Communication link Domain A Domain B Domain C RA RA RA B

X-Cetify

LDAP LDAP Message dissemination {Msg}(Piv),{Pi

v}(PCA)

{Msg}(Piv),{Pi

v}(PCA)

  • M. Khodaei, A. Messing, P. Papadimitratos

(KTH) IEEE VNC 2017

  • Nov. 28, 2017

2 / 13

slide-3
SLIDE 3

Pseudonym Refilling Strategies

Preloading schemes Computationally costly, inefficient utilization, cumbersome revocation On-demand schemes Efficient in utilization & revocation; effective in fending off misbehavior The more frequent interactions, the more dependent on connectivity

❵❵❵❵❵❵❵❵❵❵❵❵❵ ❵ Metrics Strategies Preloading & Overlapping Preloading & Nonoverlapping On-demand & Overlapping On-demand & Nonoverlapping Storage size large large small small Pseudonym quantity fixed & low volume fixed & high volume varying varying Pseudonym lifetime long short varying varying

V-VPKI communication frequency low low high high Communication overhead low low high high Efficient pseudonym utilization very low very low high high Pseudonym revocation difficult & challenging difficult & challenging no need (lower risk) no need (lower risk) Pseudonym vulnerability window wide wide narrow narrow

Resilience to Sybil-based misbehavior ×

  • ×
  • User privacy protection (probability of linking

sets of pseudonyms based on timing information) privacy protection: high (probability of linking: low) privacy protection: low (probability of linking: high) privacy protection: high (probability of linking: low) privacy protection: low (probability of linking: high) User privacy protection (duration for which a pseudonym provider can trivially link sets of pseudonyms for the same vehicle; the longer the duration, the higher the chance to link sets of pseudonyms) privacy protection: low (long duration) privacy protection: low (long duration) privacy protection: high (short duration) privacy protection: high (short duration) Effect on safety application operations low low high high Deployment cost (e.g. RSU) low low high high

Proposals & schemes C2C-CC [1], PRESERVE [2], CAMP VSC3 [3, 4] SeVeCom [5], Safety Pilot SRAAC [6], V-tokens [7], CoPRA [8] VeSPA, SEROSA, SECMACE [9, 10], PUCA [11]

  • M. Khodaei et al., “Evaluating On-demand Pseudonym Acquisition Policies in Vehicular Communication Systems,” in

Proceedings of the IoV/VoI, Paderborn, Germany, July 2016.

  • M. Khodaei, A. Messing, P. Papadimitratos

(KTH) IEEE VNC 2017

  • Nov. 28, 2017

3 / 13

slide-4
SLIDE 4

On-demand Pseudonym Acquisition Policies

User-controlled policy (P1) Oblivious policy (P2) Universally fixed policy (P3) ΓP3 ΓP3 ΓP3 System Time

Trip Duration

}

τP

}

τP

}

τP

}

τP

}

τP

}

τP

}

τP

}

τP

ΓP2 ΓP2

}

τP

}

τP

}

τP

}

τP

}

τP

}

τP

}

τP

}

τP

}

τP

}

τP

}

τP

Unused Pseudonyms

tstart

Expired Pseudonym

tend

P1 & P2: Requests could act as user “fingerprints”; the exact time of requests and all subsequent requests until the end of trip could be unique, or one of few [12] P3: Requesting intervals fall within “universally” fixed interval ΓP3, and pseudonyms are aligned with VPKI clock [12]

  • M. Khodaei et al., “Evaluating On-demand Pseudonym Acquisition Policies in Vehicular Communication Systems,” in

Proceedings of the IoV/VoI, Paderborn, Germany, July 2016.

  • M. Khodaei, A. Messing, P. Papadimitratos

(KTH) IEEE VNC 2017

  • Nov. 28, 2017

4 / 13

slide-5
SLIDE 5

Problem Statement

Challenges

How to ensure vehicle operation without harming user privacy, if the VPKI is unreachable? Intermittent coverage (sparsely-deployed RSUs), highly overloaded cellular infrastructure, VPKI under an attack, e.g., DDoS [9] Baseline hybrid scheme: issuing on-the-fly self-certified pseudonyms [13] Vehicles without VPKI-provided pseudonyms would “stand out in a crowd”: different certificate format (Group Signatures (GS)-based) and timing information

Contributions

RHyTHM: A cooperative & adaptive scheme Improving privacy for VPKI-disconnected vehicles without deteriorate the privacy of others At the expense of a reasonable computational overhead

Strong adversarial model

Increased protection against honest-but-curious VPKI entities [9] Correct execution of protocols but motivated to profile users Compromising RHyTHM by performing Sybil-based misbehavior or DoS attacks

  • M. Khodaei, A. Messing, P. Papadimitratos

(KTH) IEEE VNC 2017

  • Nov. 28, 2017

5 / 13

slide-6
SLIDE 6

Our Solution: RHyTHM

Protocol 1 RHyTHM Initiation Protocol

1: procedure RHyTHMInit(ts, te) 2:

for i:=1 to n do

3:

Begin

4:

Generate(K i

v, ki v)

5:

ζ ← (K i

v, ti s, ti e)

6:

(K i

v)Σki

v ← Sign(gskv, ζ)

7:

End

8:

Flagrhythm ← True

9:

CAM ← {Fields, Flagrhythm, tnow}

10:

(CAM)σki

v ← Sign(CAM, K i

v)

11: end procedure Registration phase: LTCA and Group Manager (GM) A universally fixed interval, Γ, to refill pseudonyms pool Aligning pseudonyms lifetimes Elliptic Curve Digital Signature Algorithm (ECDSA) key pairs If b = True, the vehicle will utilize its self-certified pseudonym; otherwise, it relies

  • n its VPKI-provided pseudonym.

VPKI-provided pseudonyms Self-certified pseudonyms V1 V4 V2 V3 V5 Processing time to generate a self-certified pseudonym

} } } } }

τ

P

τ

P

τ

P

τ

P

τ

P

Γ

System Time tnow

b = True b = True b = False b = True b = False b = False b = True b = False b = True b = False b = False b = False b = False b = True b = True b = True

Baseline Scheme RHyTHM Scheme

300 600 900 1200 1500 1800

System Time [sec]

0.0 0.2 0.4 0.6 0.8 1.0

Percentage of Nodes

Using VPKI-provided Pseudonyms Using Self-certified Pseudonyms 300 600 900 1200 1500 1800

System Time [sec]

0.0 0.2 0.4 0.6 0.8 1.0

Percentage of Nodes

Using VPKI-provided Pseudonyms Using Self-certified Pseudonyms

1% of nodes run out of pseudonyms (τP = 60 sec, r = 0.5)

  • M. Khodaei, A. Messing, P. Papadimitratos

(KTH) IEEE VNC 2017

  • Nov. 28, 2017

6 / 13

slide-7
SLIDE 7

Security & Privacy Analysis

Non-repudiation, authentication and integrity

Pseudonyms, group signing key, and digital signatures

Thwarting Sybil-based misbehavior

Hardware Security Module (HSM) ensures signatures under one private key of a single valid pseudonym Employing “n-times anonymous authentication” scheme [14, 13]

Revocation

Interacting RA with the PCA, GM, and LTCA, to resolve and possibly revoke a misbehaving vehicle Distributing Certificate Revocation Lists (CRLs)

Thwarting clogging Denial of Service (DoS) attack

Ignoring RHyTHM initiation query if VPKI is reachable RHyTHM only lasts while the VPKI is out of reach

  • M. Khodaei, A. Messing, P. Papadimitratos

(KTH) IEEE VNC 2017

  • Nov. 28, 2017

7 / 13

slide-8
SLIDE 8

Security & Privacy Analysis (cont’d)

N: Vehicles with VPKI-provided pseudonyms, joining RHyTHM M: Vehicles without VPKI-provided pseudonyms, joining RHyTHM r: The probability of switching to self-certified pseudonyms Privacy metric: Probability of linking two pseudonyms belonging to the same vehicle If all vehicles join RHyTHM: Baseline scheme: Prvpki-2-vpki = 1

N

RHyTHM scheme: Prvpki-2-vpki =

(1−r) N−(r×N) = 1 N

RHyTHM scheme Prvpki-2-selfcertifed=

r M+(r×N) = 1 N+ M

r

(

1 N+ M r

< 1

N , if M > 0)

20 40 60 80 100

M

0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0

Probability of Linking The Baseline Scheme

With VPKI Psnyms Without VPKI Psnyms 20 40 60 80 100

M

0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0

The RHyTHM Scheme

With VPKI Psnyms Without VPKI Psnyms

20 40 60 80 100 0.00 0.05 0.10 0.15 0.20 20 40 60 80 100 0.00 0.05 0.10 0.15 0.20

Figure : Comparing the probability of

linking two successive pseudonyms using baseline and RHyTHM schemes (N = 100, r = 0.2).

  • M. Khodaei, A. Messing, P. Papadimitratos

(KTH) IEEE VNC 2017

  • Nov. 28, 2017

8 / 13

slide-9
SLIDE 9

Security & Privacy Analysis (cont’d)

A fraction of vehicles never join RHyTHM K: Vehicles with VPKI-provided pseudonyms, never joining RHyTHM

Pr =

K [K+(N−K)×(1−r)]2 + N−r×(N−K)−K [K+(N−K)×(1−r)]2 × (1 − r)

If K=0 or K=N, the probability of linking on average becomes

1 N .

The probability of linking two successive VPKI-provided pseudonyms, if participating in RHyTHM, is always less than the one if not joining RHyTHM.

20 40 60 80 100

K

0.006 0.008 0.010 0.012 0.014 0.016 0.018 0.020

Probability of Linking

Average Probability Vehicles Not Using RHyTHM Vehicles Using RHyTHM

Figure : Probability of linking two

VPKI-provided pseudonyms, belonging to a given vehicle (N = 100, r = 0.5).

  • M. Khodaei, A. Messing, P. Papadimitratos

(KTH) IEEE VNC 2017

  • Nov. 28, 2017

9 / 13

slide-10
SLIDE 10

Performance Evaluation

VPKI Hybrid RHyTHM 100 200 300 400 500 600 Entire Time [ms]

573 422 21 28 135 142 12 12 19

Key Generation VPKI Delay CSR Process GS Process

(a) End-to-end latency

20 40 60 80 100 120 140 Number of Neighboring Vehicles 200 400 600 800 1000 Processing Overhead [ms]

VPKI-provided Pseudonyms Hybrid Scheme RHyTHM Scheme

(b) Cryptographic overhead Figure : (a) End-to-end latency to acquire 10 pseudonyms, averaged over 500 runs.

(b) Processing overhead as a function of the neighborhood size (τP = 30 sec, ratio of received messages: up to 60 beacon/sec, r = 0.5). Emulating a large neighborhood with 7 PRESERVE Nexcom boxes: dual-core 1.66 GHz, 2GB Memory C, OpenSSL, an implementation of short group signature [15]: Pairings in C (https://github.com/IAIK/pairings_in_c)

  • M. Khodaei, A. Messing, P. Papadimitratos

(KTH) IEEE VNC 2017

  • Nov. 28, 2017

10 / 13

slide-11
SLIDE 11

Conclusions and Future Work

Conclusions

RHyTHM enhances the privacy of disconnected users with a reasonable computation overhead Vehicles with VPKI-provided pseudonyms: if using RHyTHM, gaining higher privacy protection; if not, their privacy slightly decreases

Future Work

Investigating the provision of incentives to participate in RHyTHM Optimal probability of switching to utilizing self-certified pseudonyms Degree of propagating RHyTHM initiation query in actual scenarios Rigorous analysis of the security and privacy protocols

  • M. Khodaei, A. Messing, P. Papadimitratos

(KTH) IEEE VNC 2017

  • Nov. 28, 2017

11 / 13

slide-12
SLIDE 12

Bibliography

[1] Car-to-Car Communication Consortium (C2C-CC), http://www.car-2-car.org/. [2] “Preparing Secure Vehicle-to-X Communication Systems - PRESERVE,” http://www.preserve-project.eu/. [3]

  • W. Whyte et al., “A Security Credential Management System for V2V Communications,” in VNC, Boston, Dec. 2013.

[4]

  • V. Kumar et al., “Binary Hash Tree based Certificate Access Management for Connected Vehicles,” in ACM WiSec,

Boston, USA, July 2017. [5]

  • P. Papadimitratos et al., “Secure Vehicular Communication Systems: Design and Architecture,” IEEE CommMag,
  • vol. 46, no. 11, pp. 100–109, Nov. 2008.

[6]

  • L. Fischer et al., “Secure Revocable Anonymous Authenticated Inter-vehicle Communication (SRAAC),” in ESCAR,

Berlin, Germany, Nov. 2006. [7]

  • F. Schaub et al., “V-tokens for Conditional Pseudonymity in VANETs,” in IEEE WCNC, NJ, USA, Apr. 2010.

[8]

  • N. Bißmeyer et al., “CoPRA: Conditional Pseudonym Resolution Algorithm in VANETs,” in WONS, Canada, Mar. 2013.

[9]

  • M. Khodaei et al., “Towards Deploying a Scalable & Robust Vehicular Identity and Credential Management

Infrastructure,” in IEEE VNC, Paderborn, Germany, Dec. 2014. [10]

  • M. Khodaei, et al., “SECMACE: Scalable and Robust Identity and Credential Management Infrastructure in Vehicular

Communication Systems,” in the IEEE TITS, Mar. 2018. Online: https://arxiv.org/abs/1707.05518. [11]

  • D. F¨
  • rster et al., “PUCA: A Pseudonym Scheme with User-Controlled Anonymity for Vehicular Ad-Hoc Networks

(VANET),” in IEEE VNC, Paderborn, Germany, Dec. 2014. [12]

  • M. Khodaei et al., “Evaluating On-demand Pseudonym Acquisition Policies in Vehicular Communication Systems,” in

Proceedings of the IoV-VoI, Paderborn, Germany, pp. 7–12, July 2016. [13]

  • G. Calandriello et al., “On the Performance of Secure Vehicular Communication Systems,” IEEE TDSC, vol. 8, no. 6,
  • pp. 898–912, Nov. 2011.

[14]

  • J. Camenisch et al., “How to Win the Clonewars: Efficient Periodic n-Times Anonymous Authentication,” in ACM

CCS, NY, USA, Oct. 2006, pp. 201–210, Oct. 2006. [15]

  • D. Boneh, X. Boyen, and H. Shacham, “Short Group Signatures,” in Advances in Cryptology CRYPTO.

Springer, 2004.

  • M. Khodaei, A. Messing, P. Papadimitratos

(KTH) IEEE VNC 2017

  • Nov. 28, 2017

12 / 13

slide-13
SLIDE 13

RHyTHM: A Randomized Hybrid Scheme To Hide in the Mobile Crowd

Mohammad Khodaei, Andreas Messing, and Panos Papadimitratos

Networked Systems Security Group (NSS) www.ee.kth.se/nss Royal Institute of Technology (KTH) Stockholm, Sweden

  • Nov. 28, 2017
  • M. Khodaei, A. Messing, P. Papadimitratos

(KTH) IEEE VNC 2017

  • Nov. 28, 2017

13 / 13

slide-14
SLIDE 14

Probability of Linking Pseudonyms with RHyTHM

Pr =

K [K+(N−K)×(1−r)]2 + N−r×(N−K)−K [K+(N−K)×(1−r)]2 × (1 − r)

The first term:

K [K+(N−K)×(1−r)]: the probability of the pseudonym being in K set. 1 [K+(N−K)×(1−r)]: the probability of linking it to its successive pseudonym.

The denominator is the size of the entire VPKI-provided pseudonym set.

The second term:

N−(r)×(N−K)−K [K+(N−K)×(1−r)]: the probability of a pseudonym belonging to a vehicle

using RHyTHM.

(1−r) [K+(N−K)×(1−r)]: the probability of linking it to its successive pseudonym.

  • M. Khodaei, A. Messing, P. Papadimitratos

(KTH) IEEE VNC 2017

  • Nov. 28, 2017

13 / 13

slide-15
SLIDE 15

Linkability based on Timing Information of Credentials

5 10 15 20 25 30 35 40 45 50 55 60 System Time [min.] 1 2 3 4 5 6 7 8 9 10 τP= 5 min. 5 10 15 20 25 30 35 40 45 50 55 60 System Time [min.] 1 2 3 4 5 6 7 8 9 10 τP= 5 min., ΓP2= 15min. 5 10 15 20 25 30 35 40 45 50 55 60 System Time [min.] 1 2 3 4 5 6 7 8 9 10 τP= 5 min., ΓP3= 15min.

User-controlled policy (P1) Oblivious policy (P2) Universally fixed policy (P3)

Non-overlapping pseudonym lifetimes from eavesdroppers’ perspective Distinct lifetimes per vehicle make linkability easier Uniform pseudonym lifetime results in no distinction among obtained pseudonyms set, thus less probable to link pseudonyms

  • M. Khodaei, A. Messing, P. Papadimitratos

(KTH) IEEE VNC 2017

  • Nov. 28, 2017

13 / 13
