SLIDE 1
RestGate - Enterprise Integration Server
MSE PROJECT Phase II Report
1
Scope Review
2
RestGate - Enterprise Integration Server MSE PROJECT Phase II - - PowerPoint PPT Presentation
RestGate - Enterprise Integration Server MSE PROJECT Phase II - - PowerPoint PPT Presentation
RestGate - Enterprise Integration Server MSE PROJECT Phase II Report 1 Scope Review 2 Original Scope 3 Original Scope Subscribed Senders Request - Reply Polling Senders Content Based Router P2P Channel Message Filter Publish -
SLIDE 2
SLIDE 3
Original Scope
3
SLIDE 4
Original Scope
Subscribed Senders Polling Senders P2P Channel Publish - Subscribe Channel Validated Structure Channel Guaranteed Channel Dead Letter Channel Message Expiration Message Sequence Request - Reply Content Based Router Message Filter Splitter Aggregator Message Processor Published Message Queue Published Message List Receiver Subscription 3
SLIDE 5
Original Scope
Subscribed Senders Polling Senders P2P Channel Publish - Subscribe Channel Validated Structure Channel Guaranteed Channel Dead Letter Channel Message Expiration Message Sequence Request - Reply Content Based Router Message Filter Splitter Aggregator Message Processor Published Message Queue Published Message List Receiver Subscription 4
SLIDE 6
New Scope
Polling Senders P2P Channel Publish - Subscribe Channel Guaranteed Channel Message Expiration Content Based Router Message Filter Message Processor Published Message Queue Published Message List
5
SLIDE 7
New Scope*
Polling Senders P2P Channel Publish - Subscribe Channel Guaranteed Channel Message Expiration Content Based Router Message Filter Message Processor Published Message Queue Published Message List
*All Marked in Red have been Implemented.
6
SLIDE 8
Architectural Model
7
SLIDE 9
Use Case Views
8
SLIDE 10
Use Case Views
8
SLIDE 11
Use Case Views
8
SLIDE 12
Use Case Views
8
SLIDE 13
Message State Diagram
9
SLIDE 14
Overall Data Flow
10
SLIDE 15
11
SLIDE 16
Architectural Layers
12
SLIDE 17
13
SLIDE 18
Channel Types
Guaranteed Channels Implemented with Delayed Jobs. Uses a Database as process queue. Fast Channels Implemented with Starling. Uses a MemCache as process queue.
SLIDE 19
15
SLIDE 20
Class Diagrams
16
SLIDE 21
17
SLIDE 22
17
SLIDE 23
17
SLIDE 24
17
SLIDE 25
17
SLIDE 26
17
SLIDE 27
17
SLIDE 28
17
SLIDE 29
17
SLIDE 30
Configuration Script
18
SLIDE 31
Quality and Testing
19
SLIDE 32
Code Statistics
+----------------------+-------+-------+---------+---------+-----+-------+ | Name | Lines | LOC | Classes | Methods | M/C | LOC/M | +----------------------+-------+-------+---------+---------+-----+-------+ | Controllers | 88 | 68 | 3 | 6 | 2 | 9 | | Helpers | 5 | 4 | 0 | 0 | 0 | 0 | | Models | 91 | 74 | 2 | 15 | 7 | 2 | | Libraries | 326 | 272 | 5 | 49 | 9 | 3 | | Integration tests | 0 | 0 | 0 | 0 | 0 | 0 | | Unit tests | 4 | 3 | 1 | 0 | 0 | 0 | | Model specs | 241 | 200 | 0 | 3 | 0 | 64 | | View specs | 34 | 28 | 0 | 1 | 0 | 26 | | Controller specs | 140 | 113 | 0 | 3 | 0 | 35 | | Helper specs | 11 | 7 | 0 | 0 | 0 | 0 | | Library specs | 537 | 435 | 3 | 10 | 3 | 41 | | Routing specs | 63 | 49 | 0 | 0 | 0 | 0 | | Integration specs | 4 | 3 | 0 | 0 | 0 | 0 | +----------------------+-------+-------+---------+---------+-----+-------+ | Total | 1544 | 1256 | 14 | 87 | 6 | 12 | +----------------------+-------+-------+---------+---------+-----+-------+ Code LOC: 418 Test LOC: 838 Code to Test Ratio: 1:2.0
SLIDE 33
RSpec Statistics
126 Tests written so far. Full code coverage. 836 Lines of Test Code. Code to Test Ratio 1:2
SLIDE 34
Performance Testing
Four different levels of message complexity Small - Integer - 3 Bytes Normal - Strings - 250 Bytes Large - Long Strings - 2.5 KB Huge - Long Strings - 25.5 KB
SLIDE 35
Testing Configuration
3 to 7 BEOCAT Nodes Types of Tests: 1 Sender - 1 Receiver 3 Senders - 1 Receiver 3 Senders - 3 Receivers
SLIDE 36
Testing Configuration
RestGate Server Running in Separated Node. 1 WebServer Instance 7 Worker Processes Running Tests were performed with both Guaranteed and Fast Channels
SLIDE 37
Guaranteed vs Fast
1,000 2,000 3,000 4,000 Small Normal Large Huge
Guaranteed Channel Fast Channel
25
SLIDE 38
Guaranteed Channel Bottleneck
SLIDE 39
Testing Observations
Fast channels perform around 10% faster than guaranteed channels. Most messages are delivered in around 1 second. The sender spends at most 150 ms to make a delivery request.
SLIDE 40
Testing Observations
Messages with non string fields are slower to process. Memory usage was around 2 GBs of RAM At most 7 processors were ever active for more than 1 minute.
SLIDE 41
Testing Observations
Guaranteed channels start slowing down in a linear manner as message size and congestion increases. Fast channels exhibited a stable behavior
- n all test cases.
