04/07/15 Slide 1 Project Name: Distribution of Water Main Extension and Replacement Project ID: MED 625

Distribution Water Main Extension and Replacement – Multiple locations

Project ID: MED625

Entire Project duration: 2015-2017

Engineering Firm: KS Engineers, PC Contractor: Judlau Contracting, Inc.

04/07/15 Slide 2 Project Name: Distribution of Water Main Extension and Replacement Project ID: MED 625

Project Intent & Purpose:

Intent:

• Upgrade existing water mains (newer & bigger)

Purpose:

• Increased population (demand)
• Aging infrastructure (increase the useful life)

04/07/15 Slide 3 Project Name: Distribution of Water Main Extension and Replacement Project ID: MED 625

Scope of Work Water Main Extension & Replacement

Extension & Replacement of Existing 12” & 20” Distribution Water Mains. Roadway Restoration. Installation of Catch Basins and Basin Connections

04/07/15 Slide 4 Project Name: Distribution of Water Main Extension and Replacement Project ID: MED 625

Project Duration

May 2015 – August 2015

• Delancey Street (between Columbia Street and Pitt Street)
• Pitt Street (between Delancey Street and East Houston Street)
• Rivington Street (between Pitt Street and Clinton Street)

August 2015 – April 2016

• Bowery (between Canal Street and East 4th Street)
• First and Second Streets (between Bowery and Second Avenue)
• Second Avenue (between East 2nd Street and East Houston Street )

04/07/15 Slide 5 Project Name: Distribution of Water Main Extension and Replacement Project ID: MED 625

04/07/15 Slide 6 Project Name: Distribution of Water Main Extension and Replacement Project ID: MED 625

Allowable Work Days/Hours:

(as per NYC DOT Stipulations)

7:00AM-6:00PM: Monday-Friday

(Weekend Work as Needed)

• Bowery and auxiliary blocks between Spring Street and East 4th Street

10:00PM-6:00AM: Monday- Friday (Weekend Work as Needed)

• Bowery between Canal Street and Spring Street

TBD

• Delancey Street between Columbia Street and Pitt Street
• Pitt Street between Delancey Street and East Houston Street
• Rivington Street between Pitt Street and Clinton Street

04/07/15 Slide 7 Project Name: Distribution of Water Main Extension and Replacement Project ID: MED 625

New York City DOT Traffic Stipulations During Construction on Bowery between Canal Street & Spring Street

• Night Work 10PM-6AM
• 5ft pedestrian walkways
• Two 12ft wide Northbound lanes
• One 12ft wide Southbound lane
• No construction materials on Bowery
• 50ft X 8ft of curb lane on one-way streets for enclosed storage of materials
• On Delancey Street– Two 11ft wide Eastbound Lanes & Two 11ft wide Westbound

Lanes

• At other cross streets- One 10ft wide lane on one-way streets, Two 10ft wide lanes
• n two way streets

04/07/15 Slide 8 Project Name: Distribution of Water Main Extension and Replacement Project ID: MED 625

New York City DOT Traffic Stipulations During Construction on Bowery between Spring Street & East 4th Street

• Day Work 7AM-6PM
• 5ft pedestrian walkways
• Will not impact Northbound and Southbound traffic at the same time.
• One 12ft wide Southbound lane
• One 12ft wide Northbound lane
• No construction materials on Bowery
• 50ft X 8ft of curb lane on one-way streets for enclosed storage of

materials

• At Cross Streets– 11ft wide lanes for one-way traffic & Two 10ft wide lanes

for two-way traffic

04/07/15 Slide 9 Project Name: Distribution of Water Main Extension and Replacement Project ID: MED 625

COMMUNITY IMPACTS & WHAT TO EXPECT

04/07/15 Slide 10 Project Name: Distribution of Water Main Extension and Replacement Project ID: MED 625

COMMUNITY IMPACTS

• Pedestrian access will be maintained at all times
• Intermittent street closures and/or limited access may be necessary
• Bus routes affected by the project:
• Bowery (Canal St. – E. 4th St.) – M103
• DDC will monitor operation and work within DEP Noise Code regulations
• Sidewalk and/or loading dock access from the curb may be temporarily

restricted while work is conducted (coordination will be arranged on a case by case basis)

• Parking may be temporarily restricted during construction

04/07/15 Slide 11 Project Name: Distribution of Water Main Extension and Replacement Project ID: MED 625

Water Service Interruptions:

Water service disruption planned

• Typically 8hrs (not consecutive)
• 72 hour advance notice will be provided
• Specific instruction will be provided prior to water shutoff
• If your water service is not restored within 3 hours of the indicated on the

Shutoff notice, please contact the community construction Liaison (CCL) or 311 if after hours. Special Needs:

• Individuals with special needs should contact the CCL
• DDC field staff will work specially with those individuals to minimize certain

inconveniences Rodent Control:

• A rodent survey will be performed prior to construction
• Rodent Control Stations will be installed by a professional rodent control

contractor

04/07/15 Slide 12 Project Name: Distribution of Water Main Extension and Replacement Project ID: MED 625

Keeping You Informed

Office of Community Outreach & Notification, DDC

• DDC has assigned Amanda Girgis of KS Engineers, PC as the Community

Construction Liaison (CCL). She will keep the community informed by:

• Being the first point of contact between the project and the community
• Identifying, addressing and/or resolving field inquiries & issues as well as

any coordination between the project and needs of the affected stakeholders

• Providing regular updates/advisories for the community to better plan

around construction activities

• CCL contact information:
• Name:

Amanda Girgis

• Email:

MED625CCL@gmail.com

• Field Office:

84 Bowery, 6th Floor, New York NY 10013

• Telephone :

(646)-723-9925

• DDC Website: www.nyc.gov/ddc
• DDC Video: www.nyc.gov/webuild
• During Non-Working hours, please call 311 and give the Project ID: MED625
