Reliable metering systems

Neil Macleod

slide-2
SLIDE 2

Metering hierarchy

  • Transfer meters to ensure an accurate

determination of SIV

  • Zone or district meters to facilitate analysis of

consumption

  • Customer meters for billing purposes
  • Deduction meters for multiple family

developments

slide-3
SLIDE 3

Transfer meters

  • High accuracy metering (multiple head

ultrasonic or magflow meters) are justified for high volume transfer points

  • Regular drop testing or electronic calibration is

essential

  • In Durban 17 meters out of more than 80 in

total, measure more than 95% of the total

  • SIV. Make use of the Pareto principle !
slide-4
SLIDE 4

Zone and district meters

  • Data logging at this level of measurement is

most effective for determination of minimum night flows and ILI values.

  • These meters should be read on the same day

that the customer meters in the zone it supplies are read.

slide-5
SLIDE 5

Customer metering 1

  • We prepare positive displacement meters to

inferential meters for domestic or residential customers

  • ICI customers are metered using inferential

meters primarily

  • Inferential meters require strict compliance

with installation instructions to ensure accuracy

slide-6
SLIDE 6

Customer metering 2

  • Meter accuracy is affected by water quality,

time and the total volume of water that has passed through the meter.

  • Our domestic meters remain compliant with

the Trade Metrology Act until they are about 15 years old.

  • Positive displacement meters that are 20 years
  • ld, under-read by 7% and it is cost effective

to change them at that point

slide-7
SLIDE 7

Pre-paid or credit meters ?

  • Prepaid meter installations typically cost in

excess of R1500 compared to R500 for conventional installations

  • Tampering is a consideration if meter

installations are not visited regularly

  • Flow limiters as a credit control mechanism
slide-8
SLIDE 8

Flow limiter

slide-9
SLIDE 9

Meter reading

  • Monthly reading and billing based on actual

readings and not estimates is essential

  • Reading rates vary from 200 reads per meter

reader per day in CBD blocks to over 700 in townships

  • Technology choice is critical: minimum

features today for a hand held terminal must include; GPS, a camera, sufficient memory to store up to 1000 readings, robust and water proof construction and a 10 hour battery life

slide-10
SLIDE 10

Multi-unit metering

  • Bulk meter in the name of the body corporate
  • Individual meters to each unit with accounts in

the name of the occupants of each unit

  • A charge of R7 per reading to each customer.
  • This allows each customer to become a direct

customer of the municipality and pay for the actual water used. Credit management is more targeted.

  • The difference between the total consumption

and the sum of the consumption at each unit is billed to the body corporate at ICI rates

slide-11
SLIDE 11

performance

  • Collection rate of about 95%
  • Bill 98% of urban customers on actual

readings each month

  • Customers still want proof that their meter is

read each month

  • Photographic record makes for unintended

efficiencies

  • Aim to continually improve performance
