METERING SKIDS METERING SKIDS YEAR 2012 YEAR 2012

TOBRUK Client : J&P Owner : LASMO Lybia Meter : PD meter Design : 2 metering runs Size : 8” Class : ANSI 300 Flow rate: 365 m 3 /h Fluid : crude oil Year : 2000

EKO-OKTA Client : HELPE Owner : HELPE Greece Meter : Turbine + PD Design : Design : 2 skids with 2 runs 2 skids with 2 runs +1 master meter Size : 6” (turbine) 8” (PD) Class : Class : ANSI 300 ANSI 300 Flow rate: 320 m 3 /h Fluid : crude oil Year : 2001

NEKA REY Client : FMC SYSTEMS Owner : Neka Rey Meter : PD meter Design : Three metering streams Size : 10” Class : ANSI 300 Flow rate: 950 m 3 /h Fluid : refining products g p Year : 2002

ELEPHANT LIBYA Client : FMC SYSTEMS Owner : Elephant Libya Meter : PD Meter Design : Four metering streams Size : 8” Class : ANSI 600 Flow rate: 1200 m 3 /h Fluid : refining products g p Year : 2003

IGC Client : FMC SYSTEMS Owner : IGC/MTBE Iran Meter : Turbine Design : 4 metering runs Size : 4” & 6” Class : ANSI 600 Flow rate: 600 m 3 /h Fluid : refining products Year : 2003

Bir Berkine Algeria Client : FMC SYSTEMS Owner : ABB Algeria Meter : Turbine Design : 2 meter runs Size : 4’’ Class : ANSI 300 Flow rate: 170 m 3 /h Fluid : Crude oil Year : 2004.

NEKA REY EXTENSION Client : FMC SYSTEMS Owner : Neka Rey Meter : PD meter Design : Four metering streams Size : 8” Class : ANSI 300 Flow rate: 950 m 3 /h Fluid : refining products g p Year : 2005

BILLABRI NIGERIA Client : FMC SYSTEMS Owner : Bergensen Type : Turbine Design : Three metering streams Size : 12” Class : ANSI 150 Flow rate: 6000 m 3 /h Fluid : Crude oil Year : 2006.

ORMEN LANGE NORWAY Client : FMC SYSTEMS Owner : NORSK HYDRO Type : Coriolis Design : Five metering streams Size : 12” Class : ANSI 150 Flow rate: 6000 m 3 /h Fluid : Condensate Year : 2005.

Alvheim Norway Client : FMC Systems Owner : Marathon Norway Type : Turbine Design : Design : Three metering Three metering streams Size : 12 ” Class : Class : ANSI 150 ANSI 150 Flow rate: 6000 m 3 /h Fluid : Crude Oil Year : 2005.

CPF Russia Client : FMC Systems Owner : Rosneft Russia Type : Turbine meters Design : Four metering Streams Size : 10” Class : ANSI 150 Flow rate: 4980 m 3 /h Fluid : crude oil Year : 2008.

PURPE RUSSIA Client : FMC Systems Owner : Rosneft Russia Type : Turbine meters Design : Four metering runs Size : 10” Class : ANSI 150 Flow rate: 4980 m 3 /h Fluid : crude oil Year : 2008

YAZHNY BALYK RUSSIA Client : FMC Systems Owner : Rosneft Russia Type : Turbine meters Design: Ten metering streams Size : 8” Class : ANSI 300 Flow rate: 7150 m 3 /h Fluid : Crude oil Year : 2009

MELUT BASIN SUDAN Client : FMC Technologies Owner : Petrodar Sudan Type : PD meters Design : Nine Metering streams Size : 16 ” Class : ANSI 150 Flow rate: 14.000 m 3 /h Fluid : Crude Oil Year : 2009

LPG Angola Client : OREY Owner : SONAGOL Type : Coriolis Design : Four metering runs Size : 6” Class : ANSI 300 Flow rate: 180 m 3 /h Fluid : LPG Year : 2008

PARADIP REFINERY INDIA Client : Krohen Oil & Gas Owner : Paradip Refinery Type : Ultasonic/Turbine Design : Duty/stand by and master meter Size : Various Class : ANSI 150/300 Flow rate: From 300 to 2200 m 3 /h Fluid : refining products Year : 2011

WAHA OIL LIBYA Client : J&P Owner : Waha Oil Type : PD Meters Design : Duty/stand by Size : 4’’ Class : ANSI 300 Flow rate: 140 m 3 /h Fluid : Condensate Year : 2009

ATASU AMACY KAZAKHKHSTAN Client : E+H Owner : Kaztransoil Type : Coriolis Meters Design : Three runs Size : 6’’ Class : ANSI 600 Flow rate: 568 m 3 /h Fluid : Crude Oil Year : 2011

NATIONAL REFINERY PAKISTAN Client : E+H Owner : National Refinery Ltd Type : Coriolis Meters Design : Two runs Size : 8’’ Class : ANSI 600 Flow rate: 415 m 3 /h Fluid : Diesel Oil Year : 2009
