Reflector Antennas Prof. Girish Kumar Electrical Engineering Department, IIT Bombay gkumar@ee.iitb.ac.in (022) 2576 7436 Flat Reflector Antennas Corner Plane Curved Reflector Antennas Prime Focus Reflector Cassegrain Reflector Vertical


slide-1
SLIDE 1

Reflector Antennas

  • Prof. Girish Kumar

Electrical Engineering Department, IIT Bombay

gkumar@ee.iitb.ac.in (022) 2576 7436

slide-2
SLIDE 2

Flat Reflector Antennas

Corner Plane

slide-3
SLIDE 3

Curved Reflector Antennas

Prime Focus Reflector Cassegrain Reflector

slide-4
SLIDE 4

Vertical Dipole Antenna over Infinite Perfect Ground Plane (Reflector)

slide-5
SLIDE 5

Directivity and Radiation Resistance of Vertical Dipole Antenna over Infinite Reflector

Directivity and radiation resistance of a vertical infinitesimal dipole as a function of its height above an infinite perfect electric conductor

slide-6
SLIDE 6

Radiation Pattern of Vertical Dipole Antenna

  • ver Infinite Ground Plane (Reflector)

Elevation patterns of a vertical infinitesimal dipole for different heights above an infinite perfect electric conductor

slide-7
SLIDE 7

Horizontal Dipole Antenna over Infinite Ground Plane (Reflector)

slide-8
SLIDE 8

Directivity and Radiation Resistance of Horizontal Dipole Antenna over Infinite Reflector

Directivity Radiation Resistance

Radiation resistance and directivity of a horizontal infinitesimal electric dipole as a function of its height above an infinite perfect electric conductor

slide-9
SLIDE 9

Radiation Pattern of Horizontal Dipole Antenna

  • ver Infinite Ground Plane (Reflector)

Elevation patterns of a horizontal infinitesimal dipole for different heights above an infinite perfect electric conductor

slide-10
SLIDE 10

Corner Reflector Antenna

Top View of Corner Reflector Antenna Wave incident at 900 Corner Reflector reflects back in the same direction

slide-11
SLIDE 11

Corner Reflector Antenna

Prospective View Wire Grid Arrangement

slide-12
SLIDE 12

Images for Corner Reflector Antennas

3 Images for 900 Corner Reflector Antenna 5 Images for 600 Corner Reflector Antenna

slide-13
SLIDE 13

Images for Corner Reflector Antennas

7 Images for 450 Corner Reflector Antenna 11 Images for 300 Corner Reflector Antenna

  • No. of Images = 360/α - 1
slide-14
SLIDE 14

90° Corner Reflector Antenna

         

1 1 2 2 3 3 4 4

, , , , , , , , , , E r E r E r E r E r              

Total field will be sum of contributions from the feed and its images.

slide-15
SLIDE 15

Array Factor for 90° Corner Reflector Antenna

Array factor of the 90° Corner Reflector Antenna: In the Azimuthal Plane, ( = /2)      

, 2 cos sin cos cos sin sin E AF ks ks E             

     

/ 2, 2 cos cos cos sin E AF ks ks E             

slide-16
SLIDE 16

Radiation Pattern of 900 Corner Reflector Antenna

For s > 0.7λ, main beam splits. For s = λ, null in the broadside direction.

slide-17
SLIDE 17

Array Factor of Corner Reflector Antenna for other α

 

= 60 , 4sin cos cos 3 2 2 2

  • For

X X Y AF                             

 

= 45 , 2 cos( ) cos( ) 2cos cos 2 2

  • For

X Y AF X Y                          

= 30 3 3 , 2 cos( ) 2cos cos cos( ) 2cos cos 2 2 2 2

  • For

Y X AF X X Y Y                                           

sin cos X ks    sin sin Y ks   

where

slide-18
SLIDE 18

S-Limit for Corner Reflector Antennas

S < 0.7λ α = 900

There is Limit on S-value for single lobe in the radiation pattern.

slide-19
SLIDE 19

Parabolic Reflector Antenna

For Parabola: OP + PQ = constant = 2f OP = r’ and PQ = r’cos’ So, r’ (1+ cos’) =2f

slide-20
SLIDE 20

Parabolic Reflector Antenna Equations

1 1 2 2

1 2 2 tan tan 1 16 16 f d d d f f f d 

 

               

f/d 0.4 0.5 0.6 0.7 0.8 1.0 θ0 64.0 53.1 45.2 39.3 34.7 28.1

slide-21
SLIDE 21

Gain and Aperture Efficiency of Parabolic Reflector Antenna

  • 𝐓𝐪𝐣𝐦𝐦𝐩𝐰𝐟𝐬 𝐟𝐠𝐠𝐣𝐝𝐣𝐟𝐨𝐝𝐳 (∈𝒕): fraction of the total power that

is radiated by the feed, intercepted, and collimated by the reflecting surface.

  • 𝐔𝐛𝐪𝐟𝐬 𝐟𝐠𝐠𝐣𝐝𝐣𝐟𝐨𝐝𝐳 (∈𝒖) :uniformity
  • f

the amplitude distribution of the feed pattern over the surface of the reflector.

  • 𝐐𝐢𝐛𝐭𝐟 𝐟𝐠𝐠𝐣𝐝𝐣𝐟𝐨𝐝𝐳 (∈𝒒): phase uniformity of the field over

the aperture plane.

  • 𝐐𝐩𝐦𝐛𝐬𝐣𝐭𝐛𝐮𝐣𝐩𝐨 𝐟𝐠𝐠𝐣𝐝𝐣𝐟𝐨𝐝𝐳 (∈𝒚): polarization uniformity of

the field over the aperture plane

  • 𝐂𝐦𝐩𝐝𝐥𝐛𝐡𝐟 𝐟𝐠𝐠𝐣𝐝𝐣𝐟𝐨𝐝𝐳 (∈𝒄)
  • 𝑺𝒃𝒐𝒆𝒑𝒏 𝑭𝒔𝒔𝒑𝒔 𝑭𝒈𝒈𝒋𝒅𝒋𝒇𝒐𝒅𝒛 (∈𝒔)
slide-22
SLIDE 22

Effect of Feed Pattern on Efficiency

slide-23
SLIDE 23

Spillover and Taper Efficiencies of Parabolic Reflector Antenna

Reflector Aperture Angle, θ0 Spillover Efficiency Taper Efficiency

Reflector Aperture Angle, θ0 (in degrees)

slide-24
SLIDE 24

Aperture Efficiency of Parabolic Reflector Antenna

Reflector Aperture Angle, θ0 (in degrees)

slide-25
SLIDE 25

Cassegrain Reflector Antenna

slide-26
SLIDE 26

Gain of Large Reflector Antennas
