Rechargeable Batteries By: Nathan Bourne, Nathan Asad, Joshua Burdine, Divya Sharma, and Sophia Schaeffer Overview Rechargeable Batteries: Cathode (+) Anode (-) Separator Electrolyte wikimedia Research Lab Development of

SLIDE 1

Rechargeable Batteries

By: Nathan Bourne, Nathan Asad, Joshua Burdine, Divya Sharma, and Sophia Schaeffer

SLIDE 2

Overview Rechargeable Batteries:  Cathode (+)  Anode (-)  Separator  Electrolyte

wikimedia

SLIDE 3

Research Lab Development of Lithium-Ion Cells in the Lab  Types of synthesis  6ZSonochemistry

Solid-State
Hydrothermal

 Slurry/Laminate Production  Anode and Cathode Production  Assembly

SLIDE 4

Lithium Ion  Energy dense  High voltage output  No memory  Light  Sensitive charging  No full discharge Lithium Cobalt Oxide Lithium Sulfur Sodium Ion

SLIDE 5

Lithium Sulfur  High specific energy capacity  Safe and inexpensive  Stability decreases rate of

verheating or catching fire

 Rechargeable due to high energy density and low weight  Airplanes tested with solar panels

SLIDE 6

LiCoO2 - Lithium Cobalt Oxide Advantages  High energy density  Large number of mechanical cell sizes available  High voltage  Active development Disadvantages  High cost  Safety requires more care

Buchmann

SLIDE 7

Sodium Ion  Cheap, non-toxic, and more abundant  Not power dense  Journal of the American Chemical Society study

SLIDE 8

Economics and Policy Policy and Results:  1996 “The Battery Act”  Hindered Production, Increased Acceptance Pricing:

 Current decrease in Li-IOn cost.  Cheap options already available.

SLIDE 9

Future  Improve Cycles (lithium sulfur-chemd)  Cathode blockage  Silicon  Limited lithium

SLIDE 10

Conclusion Lithium Ion batteries consist of  Cathode (+), Anode (-), Separator, Electrolyte Lithium Sulfur  Chemical (Capacity reduced per cycle) Lithium Cobalt Oxide  Most common, but expensive Sodium Ion  Cheap, less power dense

SLIDE 11

Works Cited

Amos, Jonathan. "Solar Plane Makes Record Flight." BBC News. BBC, 24 Aug. 2008. Web. 21 June 2016. Baum, Michael. "Lithium Sulfur: A Battery Revolution on the Cheap?" Lithium Sulfur: A Battery Revolution on the Cheap? NIST, 3 June 2014. Web. 24 June 2016. Buchmann, Isidor. "The High-power Lithium-ion." High-Power Cobalt-Based Lithium-ion Battery. Cadex Electronics Inc., 2016. Web. 24 June 2016. "Energy Technologies Area." Holistic Cell Design by Berkeley Lab Scientists Leads to High-Performance, Long Cycle-Life Lithium-Sulfur Battery. Allan Chen, 2016. Web. 21 June 2016. Feit, John P. "The Gavel Comes down against the NSA." The Gadgeteer. The Gadgeteer, 10 May 2015. Web. 22 June 2016. Lithium Ion Polymer Battery. "Lithium Cobalt Oxide (LiCoO2) - Intellect Pioneering Battery Tech., Co., Ltd." Lithium Cobalt Oxide (LiCoO2) - Intellect Pioneering Battery Tech., Co., Ltd. Intellect Pioneering Battery Technology Co., Ltd, n.d. Web. 21 June 2016. Rechargeable Battery Cartoon. Digital image. Rechargeable Battery. Cartoonstock, 2015. Web. 23 June 2016. United States. Cong. Implementation of the Mercury-Containing and Rechargeable Battery Management Act: Closing the Loop with Rechargeable Batteries. Cong. Doc. Washington, DC: U.S. Environmental Protection Agency, Solid Waste and Emergency Response, 1997. Print. Zyga, Lisa. "Na-ion Batteries Get Closer to Replacing Li-ion Batteries." Materials Science. Phys, 3 Mar. 2015. Web. 21 June 2016. "Research." ViPER -. N.p., n.d. Web. 24 June 2016. https://www.google.com/search?q=lithium+ion+battery+diagram&safe=strict&espv=2&biw=1920&bih=955&tbm=isch&imgil=zImuBXrrShFTdM%25 3A%253BJTRSny4mEN9IUM%253Bhttp%25253A%25252F%25252Fpubs.rsc.org%25252Fen%25252Fcontent%25252Farticlehtml%25252F2014%2 5252Fcs%25252Fc3cs60199d&source=iu&pf=m&fir=zImuBXrrShFTdM%253A%252CJTRSny4mEN9IUM%252C_&usg=__DR_Vf_zUCufJbXmlNr vtTdUbEY4%3D&ved=0ahUKEwiI7dfzwsHNAhVi0oMKHeAGBcUQyjcINQ&ei=vpptV4iWIeKkjwTgjZSoDA#imgrc=Yy4nbEdBQHlCeM%3A
