Real-Time Databases

Meghan Russ Miriam Speert Pete Dempsey Sedat Behar Yevgeny Ioffe Zachi Klopman

Timeline

1:40 - 1:50: Introduction 1:50 - 3:00: Real-Time Databases/Scheduling 3:00 - 3:10: Break 3:10 - 4:00: Operator Scheduling in Aurora 4:00 - 4:25: Discussion 4:25 - 4:30: Comments

Real-Time Databases/Scheduling

• General Introduction
• Scheduling Policies
• Resource Allocation
• Properties of Data: consistency and

validity

• Conclusions

References

• http://www.fpa.org/newsletter_info2584/n

ewsletter_info.htm (info on scud missiles)

• http://www.fas.org/spp/starwars/gao/im9

2026.htm (info on Patriot Missile System)

Imagine this…

• We are at war with Iraq
• Our soldiers find a potential target
• Military intelligence consults a database

to determine course of action

Imagine this…

• We are at war with Iraq
• Air control system constantly monitors

hundreds of aircraft and records them in a database

• Intelligence systems constantly query the

database for potential threats

Suddenly…

• Hundreds of missiles are launched
• We suspect some are nuclear
• Need info which will allow us to

determine a course of action

• Need this info to make rapid decision
• The costs of indecision are catastrophic

What could go wrong?

• Limited number of missiles we can

intercept

• Once they’re launched, we have limited

time to react

• Our traditional database is slowed by less

critical queries

• Finally, our queries may not be answered

in time due to system load

We need a system that:

• Handles time-sensitive queries
• Returns only temporally valid data
• Supports priority scheduling
• Solution: Real-Time Databases!

Real-Time Databases and Streams

• Scheduling

– Streams: priority based on QoS optimization – Real-Time: priority based on deadlines

• Load Shedding

– Streams: dropping tuples from queues – Real-Time: missing deadlines

• Freshness of data:

– Streams: not guaranteed – Real-Time: resample

Real-Time Databases and Streams

• Scheduling

– Streams: priority based on QoS optimization – Real-Time: priority based on deadlines and user- supplied values

• Load Shedding

– Streams: dropping tuples from queues – Real-Time: missing deadlines, dropping transactions

• Freshness of data:

– Streams: not guaranteed – Real-Time: resample

Real-Time Databases

• An extension to traditional databases
• Motivated by class of applications that

require reliable responses

• Predictable (not necessarily fast)

Real-Time Database Features

• Priority

– Classification of transactions – Assigns value to transactions

• Deadlines

– Transactions specify explicit time requirements – Transaction scheduling takes time requirements into account – Predictability that transactions will complete by deadline or not at all

Transactions and Streams

• Operation on the database that perform

combinations of reads/writes in an atomic step

– Queries are a subset of transactions

• Streams are read-only data (may create

new tuples)

• Data Consistency

Characteristics of Transactions

• Manner in which transactions use data
• Nature of time constraints
• Significance of executing a transaction by its

deadline

– consequence of missing specified time constraints

Transaction Classification

• Effect of missing transaction deadlines
• Value to user is dependent on timeliness:

– Soft: have some value after deadline – Firm: have no value after deadline – Hard: have negative value after deadline

• Special case: no deadline
• Idea for Streams: Queries have periodic

deadlines

Scheduling and Streams

• Streams: schedules queries in terms of

QoS

• Real-Time Databases: schedule

transactions in terms of scheduling policy

Real-Time Databases/Scheduling

• General Introduction
• Scheduling Policies
• Resource Allocation
• Properties of Data: consistency and

validity

• Conclusions

Real-Time Databases/Scheduling

• General Introduction
• Scheduling Policies
• Resource Allocation
• Properties of Data: consistency and

validity

• Conclusions

Scheduling Policies

• Earliest deadline first (PMM, PAQRS)
• Highest value first
• Highest value per unit computation time

first

• Longest executed transaction first

PMM

• Priority Memory Management
• Admission Control

– Decide if we run a query.

• Memory Allocation

– How much memory does each running query get.

Memory Allocation: Two Strategies

• Max

– Queries get their maximum required memory

• r no memory at all.
• MinMax

– High priority queries get their maximum required memory and low priority queries get their minimum.

Admission Control

• Goal: minimize the miss ratio (number of

queries that miss their deadline/total queries).

• MultiProgramming Level (MPL) =

number of queries to run.

• Optimize system resource use: optimal

MPL.

Relating MPL to Streams

• Real-Time: One time queries
• Stream: Continuous Queries
• Possibilities for future DSMS:

– Using MPL for QoS

Oh no! Missiles are launched again.

• We are running two types of queries:

– Query1 – Where should CNN’s cameras face to see the missile? – Query2 – Should we shoot the missile down?

• Queries of type 2 are obviously more

important, but how does the db know?

• Consider: Applications for relative query

values in stream systems.

PAQRS – extension of PMM

• Priority Adaptation Query Resource

Scheduling.

• PMM only minimizes miss ratio for the entire

system.

• We would like to be able to specify a ratio

between query classes for missed deadlines.

• RelMissRatio (Relative Miss Ratio) = {99:1}

Query1:Query2.

Why do we care?

• Think of the missile example.

– Same problems still exist in stream systems.

• Potential Stream Additions:

– Relative Priority Scheduling.

• Not all queries are equal
• Another form of QoS

– Periodic Query Deadlines.

• Deadlines for continuous queries

Bias Control

• Puts queries into two groups:

– Regular – Queries run with normal priority – Reserve – Queries run with priority lower than regular.

• Manages groups on a per query basis

– Each class gets RegQuota regular queries. – The rest have to run as reserve queries.

Relative Weights

Weight should reflect a class’ RelMissRatio. Weighti = (1/RelMissRatioi)/Σj(1/RelMissRatioj) Weightcnn = (1/99)/(1/99 + 1) = .01 Weightmis = (1)/(1/99 + 1) = .99

Bias Control using Relative Weights WeightedMissRatio = Σ(Weighti * MissRatioi) All terms are equal when the ratio is correct. WeightMissRatioex=(.01*99x%) + (.99*x%) WeightMissRatioex=.99x% + .99x%

Back to Missiles and CNN

• The actual miss ratio is not correct, the

miss ratio is 50:50!

• RegQuotai

new = RegQuotai

• ld *

{(Weighti * MissRatioi)/ (WeightedMissRatio/NumClasses)}

Missiles and CNN Calculations

WeightedMissRate=(.01*.50)+(.99*.50)=.5 .005 ≠ .495 RegQuotacnnnew=RegQuotacnnold * (.01*.50)/(.5/2) RegQuotacnnnew=RegQuotacnnold *.02 (98% less) RegQuotamisnew=RegQuotamisold * (.99*.50)/(.5/2) RegQuotamisnew=RegQuotamisold *1.98 (98% more)

Does it really work?

Real-Time Databases/Scheduling

• General Introduction
• Scheduling Policies
• Resource Allocation
• Properties of Data:consistency & validity
• Conclusions

Real-Time Databases/Scheduling

• General Introduction
• Scheduling Policies
• Resource Allocation
• Properties of Data:consistency & validity
• Conclusions

Essence of Real Time

• Although adaptive systems give better

throughput, IT DOESN’T MATTER!

• RT is about dependability, not
• throughput. 1% miss rate is (usually)

unacceptable.

• Throughput can be handled (usually)

with extra hardware (i.e. money). Dependability needs a special design.

Resources in Databases

• Logical

– Locks

• Physical

– CPU(s) – Memory

• Cache
• Work Area

– I/O Bandwidth

• Disks & Storage
• Network for

Distributed Processing

– Time...

Cost of a Transaction

• Waiting for locks to release
• Work memory needed (e.g. O(n) for in-memory

hash join, O(sqrt(n)) for disk-assisted)

• I/O amount (e.g. worst case join: multiplication)
• CPU needed to process
• Cost of aborting a transaction (negligible for

queries) If success cannot be guaranteed, don't start!

Physical Resources – Now and Then

4 (16) 10

# Disks

6 16.7

Disk Latency (ms)

Latency is Forever…

8192 (1GB) 256

Disk Cache (kB)

120 (1TB) 1

Disk Size (GB)

100 10

I/O Bandwidth (MB/s)

800 20

Memory Buffers (MB)

2 X 2500 40

CPU Speed (MIPS) 2003 (opt.RAID) 1995 (Paper)

Memory Allocation Strategies (I)

• Max

– all memory needed or nothing (don't admit)

• MinMax

– all memory needed for high-priority – min memory needed for low-priority

• M&M

– feedback-based allocation – adaptive – small amount of memory set aside for small transactions

Memory Allocation Strategies (II)

• Multiclass Dependent

– Small get all the memory they need – Large get a minimum amount – Medium get according to level load

• Classes are:

– Small – less than 10% of memory – Large – more than memory – Medium – between them.

Allocating Memory

S M L M S L S

Multi-Class Resource Allocation

Single Queue Multiple Queues

S S M L L S M L M S M L SP Resources LP MP Resources MP SP SP LP LP

Locking Strategies for Transactions

• Wait patiently…

– Bad idea – can wait forever for lower priority or deadlock

• Upgrade priority of lock holder

– Will complete less important job and then continue

• Abort transaction with lower priority

– Need to asses time of abort… RT systems are not tolerant about lock delays!

Locks for Queries (Cursors)

• Grab all locks

– Long wait, holds other transactions

• Disregard locks (“dirty read”)

– May read inconsistent data or data to be discarded

• Read only committed data (“committed read”)

– May read stale data – data may change while acting upon it

• Lock current record (“cursor stability”)

– Other parts of the set may change while active – may interfere with transactions

Costs of Distributed Processing

• Two phase commit protocol
• Aborting a transaction
• I/O for Queries
• Network delays (use dedicated

connections)

Relevance to Streams

NO

• Locks
• Rollbacks

YES

• Memory allocation
• Disk latency
• I/O Bandwidth
• Deadlines?

Real-Time Databases/Scheduling

• General Introduction
• Scheduling Policies
• Resource Allocation
• Properties of Data:consistency & validity
• Conclusions

Real-Time Databases/Scheduling

• General Introduction
• Scheduling Policies
• Resource Allocation
• Properties of Data:consistency & validity
• Conclusions

Properties of Data

• Consistency

– Temporal – Absolute – Relative

• Validity and Timestamp

– Validity interval = how long reading is accurate after arrives in system (timestamp)

Temporal Consistency

• R-T imposes temporal constraints not

present in streaming systems

• Need to preserve temporal validity of

data to reflect state of environment

• If transaction must meet deadline, valid

data must be in R-T system

• Consists of absolute and relative

consistency

Looking at Fresh Data

• How do we look at relevant data in streams?

– No guarantee data is fresh – Shed older data; as new data comes in, older data is flushed from system to make room

• How do we look at fresh data in Real-Time

databases?

– Make sure data hasn’t expired – absolute consistency

Absolute Consistency

• B/w state of environment and its

reflection in database

• Necessary to ensure controlling system is

aware of actual state of environment

• Example:

– A reading is taken indicating which reporter is with the 3rd infantry on April 8th; this reading is valid for 24 hours

Formal Definition: Absolute Consistency

• Data item d is described by:

(value, avi, timestamp) dvalue = current state of d dtimestamp = time when observation concerning d was made davi=d’s absolute validity interval: length of time following d during which d has absolute validity

Validity b/w Data in Streams

• Suppose: Want tuple1 and tuple2 to have

been created within given time interval

• Implicit notion of relative validity

– Data isn’t persistent in streaming systems less likely have relative inconsistency b/c as data becomes stale, less likely to be in system – If time interval is important, specify in query

• E.g. window joins

Relative Consistency: R-T

• Data must be consistent in a group used

to derive other data

– Data used to derive other data must be produced close together

• Example:

– If we are taking the average temperature of 3 locations, readings for the 3 areas should be taken within proximity of each other

Formal Definition: Relative Consistency

• Set of data items used to derive other

data is a relative consistency set, R

• Rrvi = relative validity interval
• R is relatively consistent if:

– ∀ d’ ∈ R, | dtimestamp – d’timestamp | ≤ Rrvi

Illustration

• Scud missile is traveling at 500 mph SW at –

45º, at an altitude of 100 ft

• Patriot missile is traveling at 1500 mph NE at

60º

• Can compute certain calculations to see if they

will intercept

• Readings must be taken within some time

interval I, to ensure computation is possible

Observe…

• Scud_speedavi=4 ms, patriot_speedavi = 2

ms, and Rrvi = 1; time = 12:33

• Scud_speed = (500, 4, 12:30)
• Patriot_speed1 = (1500, 2, 12:31)
• Patriot_speed2 = (1500, 2, 12:32)
• All have absolute consistency, but R’s

relative consistency is violated

Achieving Validity Intervals

• avi:

– R-T: realized by frequent sampling of real-world data; – Streams: can’t do this

• rvi:

– R-T: rvi w/avi smallest avi belonging to relative consistency set will prevail; – Streams: specified in query – Note: only necessary to achieve rvi of RC Set R if data is being derived from R

Timestamps of Derived Data

• How to assign timestamp to derived data

d’?

• One possibility: give d’ timestamp of
• ldest item from which derived:

d’timestamp = mind ∈ R (dtimestamp)

• Alternative: d’timestamp = some function of

data from which derived

Another Note on Consistency

• avi and rvi may change with system

dynamics

– Streams: if querying soldier’s heartbeat and see it stabilize can issue query less often – R-T: if system notices heartbeat is steady, may increase validity interval

Real-Time relation to Streams

• Real-Time can have streaming queries
• Temporal validity of data vs. window

joins

• Load shedding based on user-defined

priorities (QoS); R-T sheds transactions

• vs. Streams shed tuples

Conclusions

• Parallels between Streams and Real-

Time Databases:

– Scheduling (Streams: based on QoS; R-T: based on priority and deadlines) – Load Shedding (Streams: tuple-based; R-T: based on ability to meet deadlines) – Freshness of Data (Streams: defined in query; R-T: defined in data)

Discussion Questions

• What are the pros and cons of building

notion of relative consistency into DSMS itself instead of its queries?

• Is it worthwhile to define QoS for a

DSMS in terms of a ratio between queries? For example a relative periodic query scheduling policy.

Discussion Questions

• Should it possible to dynamically update

the Relative Miss Ratio? What are some situations that would benefit from this? In streams?

• Low priority queries miss their deadlines

and do not run, what is the parallel to this in a DSMS?

Real-Time Databases/Scheduling

• General Introduction
• Scheduling Policies
• Resource Allocation
• Properties of Data: consistency and

validity

• Conclusions

Real-Time Databases/Scheduling

• General Introduction
• Scheduling Policies
• Resource Allocation
• Properties of Data: consistency and

validity

• Conclusions

Persistence of Memory (Dali, 1931)

databases are persistent. data streams, like memory, fade with time…
