Quantitative estimates of a drainage network model Rahul Roy Indian Statistical Institute, New Delhi joint work with Kumarjit Saha and Anish Sarkar.

Hurst exponent

A river basin network is an anisotropic system defined by a longitudinal length L∥ = L and a typical perpendicular length L⊥ ≤ L. The history of the Hurst exponent in fractional Brownian motion comes from when Harold Hurst studying the Nile river postulated the scaling L⊥ = LH, 0 ≤ H ≤ 1. The basin is said to be self affine if H < 1 and self-similar if H = 1 1.

1For Nile, Hurst obtained H = 0.90.

Hack’s law

The Hurst exponent can be viewed as a measure of the meandering

• f the river and the tributaries it gathers in the process.

Hack’s law studies the length, l, of the longest stream vis-` a-vis the drainage area, a, of the basin, i.e. the area of the land which collects the precipitation contributing to the network. John Hack observed that l ∼ ah where h is the Hack exponent 2.

2For the Shenandoah valley in Virginia, Hack calculated h = 0.571.

Fella river basin

Figure : Fella river network in Northern Italy.

From Maritan et al, Phy. Rev. E 1996

River network

‘A river network is a spanning tree defined in a lattice of arbitrary size and shape3.’ We study the Howard’s model of ‘headward growth and branching in a random fashion’ 4. There are various river network models proposed by geologists. We first discuss a few of them. Rodriguez-Iturbe and Rinaldo [1997] (Fractal River Basins) presents a survey of the development of this field.

3Maritan et al, Phy. Rev. E 1996 4Rodriguez-Iturbe and Rinaldo (1997)

Scheidegger Model

Scheidegger (1967) introduced a drainage model consisting of a two dimensional grid where each square, representing a unit area, is to be drained, to one of its two neighbours in a preferred direction. Here, the flow can happen along the chosen direction. The preferred direction is assumed to be direction of the slope. Thus, the drainage network forms an oriented network.

Part of the 2-dimensional oriented lattice (L): ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅

• ❄

Direction

Each vertex chooses one of the two downward edges with equal probability. ✉

• ✠

✉ ❅ ❅ ❘ ✉

• ✠

✉

• ✠

✉ ❅ ❅ ❘ ✉ ❅ ❅ ❘ ✉

• ✠

✉

• ✠

✉

• ✠

✉ ❅ ❅ ❘ ✉ ❅ ❅ ❘ ✉

• ✠

✉

• ✠

✉ ❅ ❅ ❘ ✉

• ✠

✉

• ✠

✉ ❅ ❅ ❘ ✉

• ✠

✉ ❅ ❅ ❘ ✉

• ✠

✉ ❅ ❅ ❘ ✉ ❅ ❅ ❘ ✉ ❅ ❅ ❘ ✉

• ✠

✉ ❅ ❅ ❘ ✉

• ✠

✉

• ✠

✉ ❅ ❅ ❘ ✉ ❅ ❅ ❘ ✉

• ✠

✉ ❅ ❅ ❘ ✉

• ✠

✉

• ✠

✉ ❅ ❅ ❘ ✉ ❅ ❅ ❘ ✉

• ✠

✉

• ✠

✉

• ✠

✉ ❅ ❅ ❘ ✉

• ✠

✉ ❅ ❅ ❘ ✉ ❅ ❅ ❘ ✉ ❅ ❅ ❘ ✉

• ✠

✉

• ✠

✉

• ✠

✉ ❅ ❅ ❘ ✉

• ✠

✉ ✉ ✉ ✉ ✉ ✉ ❄ Direction

The Graph

• ✠

❅ ❅ ❘

• ✠
• ✠

❅ ❅ ❘ ❅ ❅ ❘

• ✠
• ✠
• ✠

❅ ❅ ❘ ❅ ❅ ❘

• ✠
• ✠

❅ ❅ ❘

• ✠
• ✠

❅ ❅ ❘

• ✠

❅ ❅ ❘

• ✠

❅ ❅ ❘ ❅ ❅ ❘ ❅ ❅ ❘

• ✠

❅ ❅ ❘

• ✠
• ✠

❅ ❅ ❘ ❅ ❅ ❘

• ✠

❅ ❅ ❘

• ✠
• ✠

❅ ❅ ❘ ❅ ❅ ❘

• ✠
• ✠
• ✠

❅ ❅ ❘

• ✠

❅ ❅ ❘ ❅ ❅ ❘ ❅ ❅ ❘

• ✠
• ✠
• ✠

❅ ❅ ❘

• ✠

Observations

From a vertex there is exactly one edge going down. So no loops are possible. The graph is either

▶ a connected infinite tree ▶ each component a connected infinite tree

Questions :

▶ How many trees are there? ▶ Are they bi-infinite in both the direction?

Howard’s Model

Howard [1971] removed the restriction of drainage to a neighbouring square and modelled a network to include “headward growth and branching in a random fashion”. This was a model for a region where the gradient is very high and not all points are sources. The flow happens between the sources.

Howard’s Model - Source (black) Points

Declare points open with probability 0 < p < 1, independently of each other. Open points act as the sources. ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉

Every open point connects to the closest open point in the next level. If there is a choice of points, one among the choices, is chosen with equal probability. Note, unlike the Scheidegger Model, the edges are not connecting nearest neighbours.

✒✑ ✓✏ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ❄ ❄ ❄ ❄ ❄ ❅ ❅ ❅ ❅ ❅ ❘ ❄

• ✠

✟ ✟ ✟ ✟ ✟ ✟ ✟ ✟ ✟ ✟ ✙ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✾ ✁ ✁ ✁ ✁ ✁ ✕

has a choice

Each source has exactly one child, but some may not have any ancestor. ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✉ ✒✑ ✓✏ ✉

has no ancestors

• ✠

❄ ❄ ❄ ❄ ❄ ❅ ❅ ❅ ❅ ❅ ❘ ❄

• ✠

✟ ✟ ✟ ✟ ✟ ✟ ✟ ✟ ✟ ✟ ✙ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✘ ✾ ❙ ❙ ❙ ❙ ❙ ✇

Directed Spanning Forest (DSF)

Baccelli and Bordenave (2007) introduced a model which they called directed spanning forest. DSF appears as an essential tool for the asymptotic analysis of the Radial Spanning Tree. We start with a homogeneous Poission point process of unit intensity

• n R2. Each vertex in the point process connects to the nearest point
• f the process having a strictly smaller y co-ordinate.

Geometry of the network

All these models have two common geometric properties: (i) For d = 1 and d = 2, the graph consists of a single tree almost surely and, for d ≥ 3, the graph has infinitely many disjoint trees. (ii) There is no bi-infinite path almost surely for any d ≥ 1.

Howard’s Model: d = 1

We study Howard’s model for d = 1 only.

Notation

For an open vertex (u, t) let h(u, t) denote the open vertex on the line {y = t + 1} such that < (u, t), h(u, t) > is an edge of the random graph. Thinking of h(u, t) as the progeny of (u, t), hk(u, t) := h(hk−1(u, t) is the k th generation progeny of (u, t) on the line {y = t + k}. For an open vertex (v, s) set Ck(v, s) := {(u, s − k) ∈ V : hk(u, s − k) = (v, s)}, the k-th generation ancestors of (v, v), and, C(v, s) := ∪k≥0Ck(v, s). the set of all ancestors of (v, s).

Notation

In the terminology of drainage networks, |C(v, s)| represents the amount of water that is drained through the points (v, s). We define, H(v, s) := inf{k ≥ 1 : Ck(v, s) = ∅}, the height to the mouth of the river. Since there are no bi-infinite paths, H(v, s) < ∞ almost surely.

Notation

On the event, {H(x, t) > n}, define, for 0 ≤ k ≤ n, Rk(x, t) = max{y : (y, t − k) ∈ Ck(x, t)} and Lk(x, t) = min{y : (y, t − k) ∈ Ck(x, t)}. Clearly Rk(x, t) ≥ Lk(x, t). Set Dk = (Dk(x, t) =) Rk(x, t) − Lk(x, t). Define, a process in C[0, 1] as follows: for s ∈ [0, 1], W(x,t)

n

(s) = D[ns] + (ns − [ns])(D[ns]+1 − D[ns]) √n .

Main results: 1

Theorem 1. Exact tail decay for cluster height lim

n→∞

√nP(H(0, 0) > n) = 1 σ√π where σ(p) is a positive constant, depending on p only. Theorem 2. Scaling limit of conditional cluster width process 1 √ 2σ W(0,0)

n

|{H(0, 0) > n} ⇒ B+ where B+ is the standard Brownian meander process.

Main results: 2

Corollary 1. For u > 0, we have √nP(|Cn(0, 0)| > uσ √ 2n) → exp(−u2/2p2) σ√π where |A| denotes the cardinality of the set A. Corollary 2. For u > 0, we have P(

n

∑

k=0

|Ck(0, 0)| ≤ uσ √ 2n3|H(0, 0) > n) → P(pI ≤ u) where I = ∫ 1

0 B+(t)dt.

Brownian meander

Let {Bt : t ≥ 0} be a standard 1-dimensional Brownian motion starting from 0 and let τ := sup{t ∈ [0, 1] : Bt = 0}, the Brownian meander5 is the process B+

t

:= 1 1 − τ |Bτ+t(1−τ)|, t ∈ [0, 1].

5Durett, Iglehart, Miller (1977)

The transition density is given by: For 0 < s < t ≤ 1 and x, y > 0 ps,t(x, y)dy := P(B+

t

∈ dy|B+

s = x)

= (φt−s(y − x) + φt−s(y + x)) Φ1−t(y) − 1/2 Φ1−s(y) − 1/2, where φt and Φt are, respectively, the density and distribution functions of a N(0, t) random variable. In particular B+

1 has a Rayleigh distribution, i.e.

density f(y) = ye−y2/2, y > 0.

The Brownian Web

Intuitively, the Brownian web is a collection of 1-dimensional coalescing Brownian motions starting from every point (x, t) in the space-time plane R2 Technical difficulty: there are an uncountable number of coalescing Brownian motions! It arises naturally as the diffusive scaling limit of a system of 1-dimensional coalescing random walks starting from every vertex of the space-time lattice Zd. Arratia, 1978, 1981, T´

• th & Werner, 1998, Fontes, Isopi, Newman &

Ravishankar 2004

B1 B2 B3 B4

Formally, the Brownian web is a random variable taking values in the space H of compact sets of paths equipped with the Hausdorff metric

• dH. The space (H, dH) is also a complete separable metric space.

Let BH be the Borel σ-algebra associated with dH. The Brownian web W is an (H, BH)-valued random variable.

Theorem

There exists an (H, BH)-valued random variable W (the Brownian web) whose distribution is uniquely determined by the following: (a) For each deterministic z ∈ R2, almost surely there is a unique path πz ∈ W(z). (b) For any finite deterministic set of points z1, . . . , zk ∈ R2, the collection (πz1, . . . , πzk) is distributed as coalescing Brownian motions. (c) For any deterministic countable dense subset D ⊂ R2, almost surely, W is the closure of {πz : z ∈ D} in (Π, d). Fontes, Isopi, Newman & Ravishankar 2004

This theorem shows that the Brownian web is in some sense separable: even though there are uncountably many coalescing Brownian motions in the Brownian web, the whole collection is a.s. determined uniquely by a countable skeletal subset of paths. Under this set-up we can apply the standard theory of weak convergence to prove the convergence of various 1-dimensional coalescing systems to the Brownian web.

Howard’s model – scaled

For each (x, t) ∈ V, i.e. (x, t) an open point, let π(x,t) := {∪k≥0 < hk((x, t), hk+1(x, t) >}, i.e. the open path starting at (x, t) in the random graph, and, for n ≥ 1 and σ > 0, χ = {π(x,t) : (x, t) ∈ V} χn(σ) = {( u(1) σ√n, u(2) n ) : (u(1), u(2)) ∈ χ } χn(σ) is the set of all diffusively scaled paths from the random graph. Colletti, Dias and Fontes [2009] showed that in (H, BH) ¯ χn(σ) ⇒ W for an appropriate σ.

Duality

▶ Dual graph on 1 2Z × Z also consists of a single tree almost surely. ▶ There is no bi-infinite path almost surely.

Denote by ˆ V the set of dual vertices. Define, for the dual process ˆ π(ˆ

x, ˆ t) – the path formed by the dual edges,

ˆ χ(σ) = {ˆ π(ˆ

x, ˆ t) : (ˆ

x,ˆ t) ∈ ˆ V} and ˆ χn(σ) = {( u(1) σ√n, u(2) n ) : (u(1), u(2)) ∈ ˆ χ } . Theorem 3. (¯ χn(σ), ¯ ˆ χn(σ)) ⇒ (W, ˆ W) for an appropriate σ.

Proof of theorem 1

To show lim

n→∞

√nP(H(0, 0) > n) = 1 σ√π We start with a (H, BH) valued random variable K and for t > 0, t0, a, b ∈ R with a < b define ηK(t0, t, a, b) := |{π(t0 + t) : π ∈ K, σπ ≤ t0 and π(t0 + t) ∈ [a, b]}|, where σπ is the y-co-ordinate of the starting point of π.

(1,1) (0,1) η(0, 1, 0, 1) = 3

E(ηχn(0, 1, 0, 1)) = E ([√nσ] ∑

k=0

1[

H(k,n)>n

]) =([√nσ] + 1)E ( 1[

H(0,0)>n

]) from translation invariance =([√nσ] + 1)P(H(0, 0) > n). Can prove:

▶ ηχn(0, 1, 0, 1) ⇒ ηW(0, 1, 0, 1) (need Reimer’s inequality). ▶ The family {ηχn(0, 1, 0, 1) : n ∈ N} is uniformly integrable.

Conclusion: as n → ∞, E(ηχn(0, 1, 0, 1)) → E(ηW(0, 1, 0, 1)).

By comparing with the limit of the nearest neighbour random walk we may show E(ηW(0, 1, 0, 1)) = 1 √π to give lim

n→∞

√nP(H(0, 0) > n) = 1 σ√π

Nearest neighbour random walk

Denote the scaled nearest neighbour paths by ∆n. Same arguments show that, as n → ∞ E(η∆n(0, 1, 0, 1)) → E(ηW(0, 1, 0, 1)). Now, we have E(η∆n(0, 1, 0, 1)) = E ([√n/2] ∑

k=0

1[

H(2k,n)>n

]) =([√n/2] + 1)E ( 1[

H(0,0)>n

]) = ([√n/2] + 1)P(H(0, 0) > n) =([√n/2] + 1)P(2 simple symmetric random walks starting at 0 and 2 do not meet until time n) → 1 √π .

Brownian meander

We show two things:

▶ Convergence of the finite dimensional distributions. ▶ Tightness of the family.

We need to study a quantity similar to ηW(0, 1, 0, 1). For any (H, BH) valued random variable K and for 0 < t1 < t2 < . . . < tk ≤ 1 and for a1, a2, . . . , ak ∈ R define ηK(0, 1, 0, 1, t1, a1 . . . , tk, ak) = |{(x, 1) : x ∈ [0, 1], there exists π ∈ K0 with σπ ≤ 0π(1) = x, for each i = 1, . . . , k there exists π1

i , π2 i ∈ Kti

with |π1

i (ti) − π2 i (ti)| ≥ ai, π1 i (1) = π2 i (1) = x}|.

(0,1) (1,1)

a1 a2 a3 t1 t2 t3 t3

References [GRS04] S. Gangopadhyay, R. Roy, and A. Sarkar (2004) Random

• riented Trees: a Model of drainage networks. Ann. Appl.
• Probab. 14, 1242 -1266.

[FINR04] L.R.G. Fontes, M. Isopi, C.M. Newman and K. Ravishankar (2004) The Brownian web: characterization and convergence.

• Ann. Probab. 32, 2857 - 2883.

[CFD09] C.F . Coletti, L.R.G. Fontes, and E.S. Dias (2009) Scaling limit for a drainage network model. J. Appl. Probab. 46, 1184 - 1197. [Bol76] E. Bolthausen (1976) On a functional central limit theorem for random walks conditioned to stay positive. Ann. Probab. 4, 480 - 485. [R00] D. Reimer (2000) Proof of the van den Berg-Kesten conjecture.

• Combin. Probab. Comput. 9, 27 - 32.
