Quantifying Abnormal Muscle Tone Due to Neurological Impairment

Thursday March 20th, 2014 Starts at 12:00 PM EST Presented by Elizabeth Brokaw, PhD

slide-2
SLIDE 2

Kinesia HomeViewTM Kinesia ProViewTM

2

slide-3
SLIDE 3

MyoSense

3

slide-4
SLIDE 4
  • Impact of Neurological Impairment

– Abnormal Muscle Tone

  • MyoSense

– Development – Bench Testing – Clinical Evaluation

Outline

4

slide-5
SLIDE 5
  • High incidence of

neurological disorders

– Abnormal muscle tone – Reduced independence

Individuals With Neurological Impairment

Stroke 795,000

Center for Disease Control; Jan 2006 Traumatic Brain Injury in the United States: Emergency Department Visits, Hospitalizations, and Deaths, 2002-2006

5

slide-6
SLIDE 6
  • Resistance force to passive movement
  • Abnormal muscle tone presents in many

different forms.

– Rigidity – Dystonia – Spasticity – Hypertonia

Abnormal Muscle Tone

6

slide-7
SLIDE 7

Rigidity

  • Parkinson’s Disease

– Stiffness or heaviness

  • Lead pipe
  • Cog wheel

Rigidity

UCD Medicine https://www.youtube.com/watch?v=sJqKvajUC3k

Lead Pipe

Speed/Position Force

7

Cog wheel

Position Force

slide-8
SLIDE 8
  • Cerebral Palsy

– Rigid/Posturing – Unintentional movement

Dystonia

http://www.localmatters.co.nz/ http://www.ndta.org/clinicians-corner.php?id=4

8

Rigid Dystonia

slide-9
SLIDE 9

Spasticity

  • Stroke and Traumatic Brain Injury

– Speed based – Catch

Spasticity

www.strokeassociation.org

9

slide-10
SLIDE 10

Hypertonia

  • Stroke and Traumatic Brain Injury

– Range of motion

Hypertonia

10

slide-11
SLIDE 11

Treatments

  • Various types of treatment

– Botox – Baclofen – Phenol injections – Surgical intervention – Deep brain stimulation

Treatments

http://jarrettwilsontbi.wordpress.com/ 2013/08/05/tbi-is-truly-stunning-botox-images/

11

slide-12
SLIDE 12

Tone Management

  • Abnormal tone types respond differently
  • Difficult to distinguish different types of tone

– Cerebral palsy

  • Research limited by current clinical outcome

measures Issues with Abnormal Tone Management

12

DBS Baclofen Dystonia Dystonia Spasticity Spasticity ? ?

slide-13
SLIDE 13

Clinical Scales

  • Specific aspects of abnormal tone
  • Modified Ashworth, Tardieu (spasticity)
  • Fahn Marsden Burke (dystonia)
  • Low resolution
  • Subjective interpretation

Clinical Scales

FMB Arm Evaluation No dystonia present 1 Slight dystonia. Clinically insignificant 2

  • Mild. Obvious dystonia but not disabling

3

  • Moderate. Able to grasp, with some manual function

4

  • Severe. No useful grasp

13

slide-14
SLIDE 14

MyoSense Development

MyoSense Development

  • Quantitative assessment of abnormal tone
  • Integrate with conventional practice

– Clinician worn

  • Reduce patient burden

– Typical Assessment

  • Speed
  • Position
  • Force

14

slide-15
SLIDE 15

Myosense

  • Prototype Hardware

– Flexiforce FSR sensors and XBee – GLNT Movement Sensor (bluetooth)

MyoSense

15

slide-16
SLIDE 16
  • Information

about

  • rientation and

speed

  • Correlate with

force data MyoSense Data

16

slide-17
SLIDE 17

MyoSense Bench Testing

17

slide-18
SLIDE 18

Simulated Abnormal Elbow Tone

Threshold set at 45 deg/s

18

slide-19
SLIDE 19

Distinguishing Profiles

  • Hypertonia Evaluation

– Move the simulated elbow at 5 deg/s

  • Position bins and

average force

  • Correlation to

theoretical = 0.93

19

slide-20
SLIDE 20

Distinguishing Profiles

  • Mod-Ashworth Evaluation

– Move the simulated elbow at 90 deg/s

  • Speed bins and average

force

  • Correlation to theoretical

= 0.80

  • High speed effects of

device mechanics

– Belts and filtering

20

slide-21
SLIDE 21
  • Issue

– High speed mechanical effects – Acceleration – Change in direction

  • Solution

– Track specific speeds – Examine the change across speed

Comparing Different Abnormal Tone Profiles

21

slide-22
SLIDE 22
  • Tracking specific speeds

– 5, 25, 45, 65, 85 deg/s

  • At each 20s trial

– Average speed and average force

Comparing Different Abnormal Tone Profiles

20

22

slide-23
SLIDE 23
  • Correlation of 0.99
  • Distinguish Profiles and Changes in magnitude

Comparing Different Abnormal Tone Profiles

23

slide-24
SLIDE 24
  • Successful pilot evaluation of MyoSense
  • Clinical evaluation with individuals with

spasticity, dystonia, and cerebral palsy Bench Testing Conclusion

24

slide-25
SLIDE 25

MyoSense Clinical Evaluation

25

slide-26
SLIDE 26

Clinical Evaluation Protocol

  • Subjects

– 10 Pure dystonia – 10 Pure spasticity – 10 Mixed dystonia and spasticity (Cerebral Palsy) – 30 Age matched controls

  • Clinician manipulates limb

– 5, 45, 90, 135, 180 – wrist, elbow, knee, ankle – Mod Ashworth and Fahn Marsden Burke

26

slide-27
SLIDE 27

Individual with Dystonia

Preliminary Results

FMB = 1 FMB = 0

Unimpaired Control

27

slide-28
SLIDE 28

Clinical Evaluation Goals

  • Goal from Clinical Evaluation

– Differentiate types of abnormal muscle tone – Examine correlation to clinical measures

  • Commercialization

– Effects of spasticity and dystonia – Effects of treatments

28

slide-29
SLIDE 29

Acknowledgements

  • Dr. Erwin Montgomery
  • Dr. Ilia Itin
  • Alexandria Wyant
  • Funding from NIH

National Institute of Neurological Disorders and Stroke (1R43NS076052-01A1)

29

slide-30
SLIDE 30

GLNT Movement Sensor

30

http://glneurotech.com/motion-sensor

slide-31
SLIDE 31

Questions?

For more information contact: Elizabeth Brokaw Ebrokaw@glneurotech.com
