SLIDE 1
Pyrolysis in late medieval foundry processes Georgius Agricola, De Re Metallica Libri XII, MDLVI English translation 1912 by Herbert Hoover
Pyrolysis & Char Processes Fernando Preto CanmetENERGY, Natural - - PowerPoint PPT Presentation
Pyrolysis & Char Processes Fernando Preto CanmetENERGY, Natural - - PowerPoint PPT Presentation
Pyrolysis & Char Processes Fernando Preto CanmetENERGY, Natural Resources Canada Charcoal Production & Use Pyrolysis in late medieval foundry processes Georgius Agricola, De Re Metallica Libri XII, MDLVI English translation 1912 by
SLIDE 2
SLIDE 3
Char Production How can we optimize char production?
SLIDE 4
Pyrolysis Stages
Temperature Process (Overlap) Major Products Heat
<200ºC Drying H20 IN 230ºC-250ºC Depolymerization Acetic acid, Methanol, CO2, CO IN 250ºC-280ºC Torrefaction Extractives, CO2, CO IN 280ºC-500ºC Devolatilization Organics, Tars, CO2,CO OUT 500ºC-700ºC Dissociation/Carbonization CO, H2 IN >700ºC Gasification H2, CO IN
SLIDE 5
Time to Complete Pyrolysis as f(size)
- X. Wang et al 2006
SLIDE 6
5 10 15 20 25 30 35 40
Yield %
2.5 secs 5 secs 20 secs
Vapour Residence Time Liquid Gas Solid
Yields vs Residence Time
T=500 C
SLIDE 7
Charcoal Yield as f(size)
- X. Wang et al 2006
SLIDE 8
Product(s) Yield as f(Temperature)
- X. Wang et al 2006
SLIDE 9
Product Distribution
A.V.Bridgwater
Mode Conditions Liquid Char Gas Fast pyrolysis Moderate temperature, short residence time 75% 12% 13% Slow Pyrolysis Low temperature, very long residence time 30% 35% 35% Gasification High temperature, long residence time. 5% 10% 85%
SLIDE 10
Species Migration: S, N
- J. Hrbek et al 2006
SLIDE 11
- J. Hrbek et al 2006
Species Migration: Cl, K
SLIDE 12
Yield of Traditional Charcoal Processes
- Batch processes:
- Earth pits and mounds
>10%
- Brick, concrete, and metal kilns
20-25%
- Retorts
30%
- Continuous processes:
- Retorts (Lambiotte)
30-35%
- Multiple hearth reactors (Herreshoff)
25-30%
FAO Rinsing Retort
SLIDE 13
Pyrolysis: Industrial Research in Canada
ABRI-Tech Airex Alterna Organic Power Titan Agritherm… ABRI-Tech Airex Agritherm Ensyn Dynamotive…
SLIDE 14
Courtesy NREL
SLIDE 15
Maximizing Charcoal Yield
SLIDE 16
Maximizing Charcoal Yield
- Low pyrolysis temperature (<400ºC)
(but also lower fixed carbon content)
- High process pressure (1 MPa)
(higher concentration of pyrolysis vapor increases rate of secondary reactions)
- Long vapor residence time
(extended vapor/solid contact promotes secondary coke forming reactions)
- Low heating rate
(slower formation and escape of organic vapors)
- Large biomass particle size
(low thermal conductivity of biomass results in slow heat and mass transfer rate within particles)
SLIDE 17
