PUUHA SPORTS OY David City Line Outdoor Training Equipment Product Development History Product Technical Information User Experience & Awards Product Development History The project Started from a request to design a new type of outdoor

slide-1
SLIDE 1

PUUHA SPORTS OY

David City Line Outdoor Training Equipment

slide-2
SLIDE 2

Product Development History Product Technical Information User Experience & Awards

slide-3
SLIDE 3

The project Started from a request to design a new type of outdoor traning equipment line for City of Helsinki

Product Development History

ü Durable under any weather condition ü Safe and effecitve exercise for all users ü Low maintanance needed ü EN16630:2015 Standard compliance ü Adjustable loading weight ü Deliver optimal training response

slide-4
SLIDE 4
  • Basic exercises with natural movement patterns for indoor and outdoor use
  • Numerous setup alternatives too meet the needs of every customer
  • Meeting the highest quality standards, very durable products made in Finland
  • Biomechanically sound devices for user safety and optimal training response

David City Line 100% Finnish Product

slide-5
SLIDE 5
  • User safety has been the fundamental factor throughout the design process
  • Design and manufacturing in compliance with EN16630-2015 European Standard
  • All units have been tested and approved for all-weather conditions in co-operation with the City of

Helsinki

  • 20 years warranty on structural frame construction, all steel profiles with 4-6 mm wall thickness (Ref.

Terms of warranty)

  • 5 years waranty on moving parts, bearings and urethane coated plywood components (Ref. Terms of

warranty)

David City Line Safe and Durable

slide-6
SLIDE 6
  • The core value is that all units are suitable to a wide variety of users regardless of age and fitness

level

  • Patented, adjustable Large Scale Loading System is a unique feature in outdoor training

equipment

  • Sleek and simple in design, the equipment blends well with urban and rural environments
  • Multiple color options according to the Classic RAL Color Chart

David City Line Product Highlights

slide-7
SLIDE 7

David City Line Product Technical Information

CL10 Squat product information

Length: 2040 mm Width: 930 mm Height: 1880 mm

  • 20 – 60 kg (1 x weight unit) total weight 169kg
  • 20 – 90 kg (2 x weight unit) total weight 227kg

Wall thickness: 4 - 6 mm

slide-8
SLIDE 8

CL23 Low row product information

Length: 1930 mm Width: 920 mm Height: 1120 mm

  • 20 – 70 kg (1 x weight unit) total weight 158kg

Wall thickness: 4 - 6 mm

David City Line Product Technical Information

slide-9
SLIDE 9

CL30 Bench press product information

David City Line Product Technical Information

Length: 2700 mm Width: 930 mm Height: 870mm

  • 15 – 55 kg (1 x weight unit) total weight 170kg
  • 10 – 85 kg (2 x weight unit) total weight 228kg

Wall thickness: 4 - 6 mm

slide-10
SLIDE 10

CL31 Incline bench press product information

Length: 2700 mm Width: 930 mm Height: 870mm

  • 15 – 55 kg (1 x weight unit) total weight 170kg
  • 10 – 85 kg (2 x weight unit) total weight 228kg

Wall thickness: 4 - 6 mm

David City Line Product Technical Information

slide-11
SLIDE 11

CL41 Front press product information

David City Line Product Technical Information

Length: 2350 mm Width: 930 mm Height: 1250 mm

  • 15 – 55 kg (1 x weight unit) total weight 174kg
  • 10 – 85 kg (2 x weight unit) total weight 232kg

Wall thickness: 4 - 6 mm

slide-12
SLIDE 12
  • Loading with 5 kg increments
  • Easy to use release lever
  • Maintenance free wheels
  • Safety locking mechanism
  • Double compression springs

Adjustable Loading Mechanism

  • pat. 127344– ”Arrangement and Method for adjusting load in Training Equipment”
slide-13
SLIDE 13

CL20 Back extension product information

Length: 1960 mm Width: 750 mm Height: 1000 mm

  • 49 kg (equipment weight)
  • 91 kg (with mounting post)

Wall thickness: 4 - 6 mm

David City Line Product Technical Information

slide-14
SLIDE 14

David City Line Product Technical Information

CL81 Dip product information

Length: 870 mm Width: 770 mm Height: 840 mm

  • 13 kg (equipment weight)
  • 55 kg (with mounting post)

Wall thickness: 4 - 6 mm

slide-15
SLIDE 15

CL90 Abdominal bench product information

David City Line Product Technical Information

Length: 1880 mm Width: 410 mm Height: 610 mm

  • 35 kg (equipment weight)
  • 77 kg (with mounting post)

Wall thickness: 4 - 6 mm

slide-16
SLIDE 16

David City Line

CL 20, CL81 and CL90 combinations

slide-17
SLIDE 17

Solutions against corrosion on steel / protection by duplex system

  • Zinc or zinc rich layer covered with top coating
  • Two layer system that combines cathodic protection and barrier

effect Advantages:

  • Greater anticorrosion protection
  • Limitless color choices

Double Layer Surface Treatment (1/2)

slide-18
SLIDE 18

Key features

  • Outstanding anticorrosion resistance on grit blasting
  • Ideal for usage in public areas
  • Smooth surface finish in comparison to other zinc rich primers

Typical uses

  • Street furniture
  • Garden furniture
  • Steel cladding and fences
  • Handrails and staircases

Interpon PZ 790 (ALZ90F) / Zinc Rich Primer - Duplex

Double Layer Surface Treatment (2/2)

Interpon PZ 790 (ALZ90F) / Zinc Rich Primer - Duplex

slide-19
SLIDE 19
  • English, Swedish, Finnish (other languages are up to request)
  • Detailed instructions
  • Detailed illustrations
  • User safety instructions
  • QR-codes for instructional videos
  • 1. Nosta kahva 2.Valitse kuormitus (kg) 3. Varmista lukitus
  • 1. Lyft handtaget 2. Välj vikt (kg) 3. Granska låsningen
  • 1. Lift the handle 2. Select the weight (kg) 3. Secure the handle
Kuormitus / Vikt / Weight selection David Sports Oy, Linnapellontie 8, 24910 Halikko, Finland David CL10 Squat • Manufactured 2017 • EN 16630 : 2015

CL10

JALKAKYYKKY KNÄBÖJ SQUAT
  • Pat. pending: FI20155623
Varmista terveydentilasi lääkäriltä • Perehdy käyttöohjeeseen • Varmista, ettei laitteen lähellä ole muita • Keskeytä, jos voit huonosti Konsultera läkaren • Läs instruktioner ovanför • Försäkra dig
  • m att ingen är i närhet • Avbryt träning om du blir illamående
Consult a physician • Read the instructions • Make sure no one is close to the unit • Stop training if you feel faint, dizzy or exhausted Ennen harjoittelua • Innan träning • Before you start! 1. 2. 3. 20 10 40 50 Lukitus / Låsspaken / Release Lever Laske liikevarsi ja paina kahva lukitusasentoon Sänk stången och tryck ner låsspaken Lower the movement arm and secure by pulling the handle
  • Astu laitteeseen ja aseta hartiat tangon alle, nouse
suorille jaloille, jolloin lukitus vapautuu automaattisesti
  • Ställ dig under stången och placera den på axlarna,
sträck knäna och låset frigörs automatiskt
  • Position the cross-bar on your shoulders, extend
your knees and the movement arm will be released
  • Ota kiinni kahvoista tangon edessä, laskeudu
kyykkyyn ja nouse suorille jaloille, toista liike
  • Tag i handtagen framför dig, böj knäna och sträck
upp dig igen, upprepa rörelsen
  • Grasp the handles in front of the cross-ba r, bend
your knees, extend your knees and repeat Made in Finland

Safety And User Instructions

slide-20
SLIDE 20

David CL 10 David CL 20 David CL 23 David CL 30 David CL 31 David CL 41 David CL 81 David CL 90 David City Line / QR-codes

slide-21
SLIDE 21

Installation site: City of Helsinki, Pirkkola Sports Park Area: Fenced area with optical sensors (2 entrances) Equipment: 8 David City Line units + Big Rig FTR 0382H Time period: 15.04.2016 – 30.09.2017 Number of visits: 160 038 visits (in average 284 visits / day)

Pirkkola Sports Park, Helsinki, Finland

slide-22
SLIDE 22

In 2015 David City Line Received The Sports Product Of The Year Award

slide-23
SLIDE 23

David City Line In 3D

slide-24
SLIDE 24

Address Lintulahdenkuja 10 FI-00500 Helsinki Finland Contact

  • Tel. +358 400 340 392

info@davidsports.fi Davidsports.fi

Thank you

Erica Wang Export manager +358 40 3500 380 erica.wang@davidsports.fi
