PUBLIC MEETING & PRESENTATION JANUARY 19, 2011 CUY-90-10.62 - PowerPoint PPT Presentation

INTERSTATE 90 NOISE ABATEMENT PUBLIC MEETING & PRESENTATION JANUARY 19, 2011 CUY-90-10.62 & CUY-90-12.37 Public Meeting for PID 80821 & 88600 I-90 Noise Abatement Public Meeting Options to be discussed at todays meeting:


  1. INTERSTATE 90 NOISE ABATEMENT PUBLIC MEETING & PRESENTATION JANUARY 19, 2011 CUY-90-10.62 & CUY-90-12.37 Public Meeting for PID 80821 & 88600

  2. I-90 Noise Abatement Public Meeting Options to be discussed at today’s meeting:  Vegetative Screening  Noise Barriers  Nothing at All

  3. I-90 Noise Abatement Public Meeting A Noise Analysis was completed, and noise abatement in the form of noise barriers was justified at most locations between West 117 th Street and West 25 th Street.

  4. Proposed Sale Dates of Potential Projects

  5. Example of Meeting Display Boards

  6. I-90 Noise Abatement Public Meeting Question for Residents: Which option do you prefer?  Vegetative Screening  Noise Barriers  Nothing at All Answer this by completing the Noise Abatement Questionnaire , please include your Name and Address.

  7. Noise Abatement Questionnaire

  8. Noise Abatement Website http://www.dot.state.oh.us/districts/D12/PlanningPrograms/Pages/NoiseAbatement.aspx

  9. I-90 Noise Abatement Public Meeting If you choose Noise Barriers:  City Officials recommended using a Red Brick Pattern on the residential and highway faces of the barriers. IR-71 in Cleveland (Residential View)

  10. About Concrete Noise Barriers with Brick Patterns  An absorptive material is applied on the highway side.  This limits the reflection of noise waves.  The surface has a porous appearance.  Buff colored concrete posts and caps will be used.  The panels will be sealed completely with one color, red brick.  The grout lines will not appear in a different color.  This has be done throughout the region.  Icons may be added if selected by City Officials.

  11. Example of End of Noise Barrier Run IR-71 in Cleveland

  12. Example of Fire Hydrant Access IR-71 in Cleveland IR-71 in Cleveland (Residential View)

  13. About Icons City Officials can request picture icons.  They can develop a maximum of five simplified picture icons to be installed on the highway face.  In addition a nameplate will be installed on the highway side. Provide comments regarding icons on the Noise Abatement Questionnaire , in the “Other Comments” section.

  14. Example of Icon IR-77 in Independence

  15. I-90 Noise Abatement Public Meeting If you choose NO Noise Barriers:  Vegetative Screening is available in lieu of noise barriers.  Vegetative Screening does NOT reduce highway noise.  Vegetative Screening is limited by the amount of space available.  It may take several years to fully establish.  Or the existing condition can remain as is.

  16. Typical Vegetative Screening Plan

  17. Example of Vegetative Screening SR-176 (Jennings Freeway) near Jennings Road

  18. Example of Vegetative Screening SR-176 (Jennings Freeway) near Jennings Road

  19. Example of Vegetative Screening SR-176 (Jennings Freeway) near Jennings Road

  20. Public Involvement Results

  21. Public Involvement Results

  22. Public Involvement Results

  23. Public Involvement Results

  24. Public Involvement Results

  25. Public Involvement Results

  26. I-90 Noise Abatement Public Meeting Options discussed today are:  Vegetative Screening  Noise Barriers  Nothing at All

  27. I-90 Noise Abatement Public Meeting Your opinion is important! Please respond by February 4, 2011 Complete the Noise Abatement Questionnaire.  Your responses of the questionnaire and public meeting will be presented to Cleveland City Council Members.  Written Concurrence from the Council Members is required for the construction of noise barriers and vegetative screening.  If Noise Barriers are selected, construction is estimated to start in the Fall of 2012.  If Vegetative Screening is selected, construction may begin in the Fall of 2012.

  28. I-90 Noise Abatement Public Meeting Questions or Comments? Thank you for your interest. Public Meeting October 28, 2010
