Public Information Meeting Update on Conditions and Environmental Actions at the Former Kerr-McGee Wood Treatment Facility Springfield, MO Marc Weinreich, Managing Principal Lauri Gorton, Director of Environmental Programs Amber Igoe,

slide-1
SLIDE 1

Update on Conditions and Environmental Actions at the Former Kerr-McGee Wood Treatment Facility Springfield, MO

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

Public Information Meeting

Marc Weinreich, Managing Principal Lauri Gorton, Director of Environmental Programs Amber Igoe, Springfield Site Project Manager September 14, 2016

slide-2
SLIDE 2

Public Meeting Agenda

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

  • Welcome and Introductions
  • Meeting objectives
  • Brief history of site ownership
  • Introduction to Multistate Environmental Response

Trust

  • Historic site operations and activities
  • Current understanding of site conditions
  • Multistate Trust remediation activities
  • Follow-up contacts
  • Questions and discussion
slide-3
SLIDE 3

Tonight’s Objectives

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

Provide community with:

  • An update about Site activities
  • An opportunity to raise questions and

express concerns that may help guide Multistate Trust’s future investigations

  • An understanding of how potential exposure

risks are identified and managed

slide-4
SLIDE 4

Location of Former Kerr-McGee Wood Treatment Facility

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

slide-5
SLIDE 5

Brief History of Site Ownership

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

  • 1907: 68-acre Facility treated

railroad ties with creosote wood preservative

  • 1964–2004: Kerr-McGee

acquired and operated Facility

  • 2004: Kerr-McGee closed

Facility

  • 2005: Kerr-McGee spins

Facility and other liabilities into subsidiary, Tronox

slide-6
SLIDE 6

Brief History of Site Ownership

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

  • 2006–2009: Tronox struggles

financially to meet obligations

  • 2009: Tronox files bankruptcy
  • 2011: Court-appointed

Multistate Trust takes title to Springfield Site and 100s of

  • ther contaminated former

Kerr-McGee sites

  • 2015: Court finds Kerr-McGee

committed fraud and awards Multistate Trust $22M to investigate and clean up Site

slide-7
SLIDE 7

What Is the Multistate Trust?

  • A unique public/private entity
  • Its sole purpose is to protect human health

and the environment (not motivated by profit or gain)

  • Created to remediate 100s of sites

contaminated by Kerr-McGee and Tronox

  • perations
  • Established as part of 2011 global Tronox

bankruptcy settlement

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

slide-8
SLIDE 8

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

slide-9
SLIDE 9

What is the Multistate Trust?

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

  • Independent, court-appointed trustee
  • Has duty of good faith and loyalty to

beneficiaries

  • Reports directly to beneficiaries—United States

and State of Missouri

  • Has cooperative, collaborative relationship with
  • beneficiaries. Both sit on “same side of table”
  • Governed by Tronox Settlement and Trust

Agreement

slide-10
SLIDE 10

Multistate Trust Responsibilities

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

  • Own in trust, remediate and facilitate reuse of 100s of

former Kerr-McGee sites in 31 states

  • Received $1.2B for Site remediation ($22M for

Springfield) in 2015

  • Implement investigations and remediation of

Springfield Site, under EPA and MoDNR oversight, to manage current and potential future risks

  • Can use Springfield funds only for environmental

actions at Springfield

slide-11
SLIDE 11

MoDNR & EPA Site Responsibilities

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

Lead Agency: Missouri Department of Natural Resources (MoDNR)

  • Approves all Multistate Trust remediation plans, activities,

and budgets

  • Approves environmental contractors hired by Multistate

Trust

  • Confirms completion of environmental actions
  • Not responsible for Site work or conditions

Beneficiaries: MoDNR and EPA

  • Approve sale, conveyance, or transfer of property
  • MoDNR may consult EPA on remediation plans
slide-12
SLIDE 12

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

Kerr-McGee/Tronox Site Remedy

slide-13
SLIDE 13
  • 1988: Kerr-McGee closed wastewater

impoundments used to treat hazardous waste

  • 1992: Kerr-McGee performed/completed

RCRA Facility Investigation

  • - Identified nature and extent of

hazardous waste releases

  • - Found creosote on and off-site

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

Kerr-McGee/Tronox Site Remedy

slide-14
SLIDE 14
  • 1993: Kerr-McGee completed Corrective

Measure study

  • 1993–2002: Kerr-McGee installed approved

Corrective Measures under MoDNR oversight

  • 2002: MoDNR issued post-closure care

permit

  • 2005: Kerr-McGee spins Site into Tronox to

avoid liability

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

Kerr-McGee/Tronox Site Remedy

slide-15
SLIDE 15
  • Kerr-McGee was forced to close:
  • -Several solid waste management units
  • -3 surface impoundments
  • -Land farm treatment unit
  • Closure involved contaminated soil

removal and placement of caps on surface impoundments

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

Kerr-McGee Remedy Actions Under MoDNR Oversight

slide-16
SLIDE 16

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

CREOSOTE TANKS H i g h S t Clifton Ave Fulbright Ave Hillcrest Ave Chicago St T u r n e r S t Drury Ave Aline Ave Truman St Cottage Ave M a r g a r e t S t Colgate Ave Ethyl Pl Atlantic St Hillcrest Ave Drury Ave MAINTENANCE SHOP OFFICE FUEL STORAGE SEPARATORS EQUIPMENT STORAGE CHEMICAL FEED TANKS BLACK TIE STORAGE AREA PRODUCTION PROCESS AREA O R I G I N A L C E L L A R E A E X P E R I M E N T A L L A N D F A R M ORIGINAL RCRA CELL CLOSED IMPOUNDMENT 3 CLOSED IMPOUNDMENT 1 CLOSED IMPOUNDMENT 2 WASTE WATER TREATMENT AREA S p r i n g B r a n c h enfield_Enviro_Trust\15-Springfield MO\Project_GIS\Project_mxds\Figure2_2_Historical_Features.mxd, Date: July 19, 2012 11:13:48 AM

Kerr-McGee Remedy Actions Under MoDNR Oversight

slide-17
SLIDE 17
  • Trenches and pumps
  • Recover creosote
  • Remove contaminated groundwater
  • Limit movement of groundwater
  • On-site treatment system
  • Collect creosote
  • Treat groundwater
  • Groundwater wells to monitor conditions

and remediation effectiveness

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

Kerr-McGee Remedy Actions Under MoDNR Oversight

slide-18
SLIDE 18

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

" ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) " ) ! ! ! Trench #2 Trench #3 Trench #4 Trench #1 Pumping Center 7 Pumping Center 6 Pumping Center 4 Pumping Center 5 Pumping Center 3 Pumping Center 1 Pumping Center 2 RW-6 RW-5 RW-4 RW-3 RW-2 RW-16 RW-15 RW-14 RW-1 RW-25 RW-9 RW-8 RW-7 RW-23 RW-22 RW-13 RW-24 RW-20 RW-19 RW-18 RW-17 RW-12R RW-11R RW-10R 150 300 Feet

Ü

1 inch = 150 feet

Uppermost Flow Zone Recovery Well and Pumping Center Location Map

MAP NOTES: Date: March 30, 2015 Data Sources: ESRI, GSI 2013

Legend

" ) Recovery Well ! Influent Meter Trenches Trench #1 Trench #2 Trench #3 Trench #4 Remediation System Piping Group 1 Group 2 Group 3 Water Course Pumping Centers Fence Property Boundary

Recovery Trenches and Pumps Located in Contaminated Areas

slide-19
SLIDE 19
  • 2005 – MoDNR, Missouri Department
  • f Health & Senior Services, and

Federal Agency for Toxic Substances and Disease Registry (ATSDR) examined residents’ exposure to possible petroleum contamination in residential soils in Golden Hills Subdivision and Vich/Woodlawn Spring

  • 2006 – ATSDR concluded that the areas

presented “no apparent public health

hazard”

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

Prior Investigation of Golden Hills and Spring

slide-20
SLIDE 20

What Is Creosote?

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

  • Thick, oily liquid used to preserve wood
  • Primary contaminant of concern at Site
  • Major chemicals in creosote: polycyclic

aromatic hydrocarbons (PAHs), phenol, and creosols

slide-21
SLIDE 21
  • 2006–2011: Under MoDNR oversight, Tronox

continued to operate protective systems installed by Kerr-McGee

  • 2009: Tronox filed for bankruptcy
  • 2011–2015: With limited funds ($2M) and no

guarantee of future funds, Multistate Trust assumed status quo operation of existing systems:

  • Groundwater/creosote recovery and treatment
  • Maintenance of closed impoundments
  • Groundwater monitoring and reporting

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

Tronox Bankruptcy and Transition to Multistate Trust

slide-22
SLIDE 22
  • Additional data required to evaluate corrective

measure effectiveness of monitoring network

  • Current recovery system may need optimization to

fully control plume migration and remove creosote

  • Potential exposure risks for soil, groundwater and

surface water exposure are limited

  • Additional evaluations may be required for potential

vapor exposer risks, if any additional groundwater contamination is found

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

Multistate Trust Findings To Date

slide-23
SLIDE 23

How Do We Identify Potential Exposure Risk?

  • 1. Is contamination present at concentrations

above levels established to be protective of human health?

  • 2. Is contamination moving in the environment?
  • By wind or in the air
  • With surface water or groundwater
  • 3. Can people be exposed to the contamination?
  • Direct contact (touching with skin)
  • Ingestion (eating/drinking)
  • Inhalation (breathing)

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

slide-24
SLIDE 24

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

Existing Data Has Not Identified Potential for Contact/Ingestion for Soil or GW

  • Off-Site Soils: Previous limited off-site soil tests

showed no impacts to off-site soils

  • On-Site Soils: Site fencing and closure prevents

human contact with on-site soils

  • On and Off-Site Groundwater typically 1 to 4 feet

below ground surface

  • Unlikely to be touched
  • No record of public or private drinking wells or
  • ther wells in area
slide-25
SLIDE 25

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

Evaluation of Potential Inhalation Exposure Risks

  • Sampled subsurface utility

corridors recently and found no pathway for workers

  • Will be collecting additional

information on vapors/odors if additional groundwater contamination is found

  • Will report on findings after

sampling and analyses are complete

slide-26
SLIDE 26

Multistate Trust’s New Site Work

  • 2015–2016: With receipt of additional remedy

funds:

  • - Multistate Trust completed initial field

evaluation

  • - Multistate Trust prepared Supplemental

Investigation Plan (includes vapor and

  • ther new studies) for MoDNR review/approval
  • 2016: Multistate Trust’s initial evaluation resulted

in replacement of Pumping Center 1 Trunk Line

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

slide-27
SLIDE 27

Objectives of Multistate Trust’s 2016 Supplemental Investigation

  • Provide comprehensive, up-to-

date, independent understanding of Site conditions

  • Delineate location and potential

migration and impacts of groundwater plume

  • Obtain technical data to
  • Evaluate current exposure

potential

  • Inform additional remedial

action, if required

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

REMEDIAL ACTION OPTIMIZATION WORK PLAN Former Tronox Facility 2800 West High Street, Springfield, Missouri RCRA Permit Number MOD007129406 Submitted by:

Greenfield Environmental Multistate Trust LLC, Trustee of the Multistate Environmental Response Trust

Prepared by: For Submittal to: Missouri Department of Natural Resources P.O. Box 176 Jefferson City, Missouri 65102-0176 August 8, 2016

slide-28
SLIDE 28

Next Steps: Planned Activities in 2016 and Beyond

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

  • Additional soil and groundwater sampling to

update and confirm current understanding of Site conditions

  • Depending on sampling results, additional

remedial actions may be proposed to maintain protective conditions at the Site

slide-29
SLIDE 29

Next Steps: Planned Activities in 2016 and Beyond

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

  • Specifically, Multistate Trust will address

uncertainties associated with current understanding of Site (monitoring wells installed 15-30 years ago)

  • Multistate Trust will determine whether existing

systems are adequate or should be modified to ensure overall protectiveness of remedy.

slide-30
SLIDE 30

Areas Being Investigated in Fall 2016

slide-31
SLIDE 31

Areas Being Investigated in Fall 2016

slide-32
SLIDE 32

Current Schedule

  • Fall 2016
  • Field sampling and analyses – Fall 2016
  • Recovery and treatment system evaluation
  • Winter 2016–2017
  • Data validation and evaluation
  • Draft report submittal and MoDNR review
  • Late Winter/Spring 2017
  • Final report available
  • Additional investigation and remedial actions, if

needed

Multistate Trust Will Take Immediate Action if New Exposure Potential is Discovered

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

slide-33
SLIDE 33

Who Can You Contact for Additional Information?

Springfield-Greene County Health Department

  • Erica Little (417) 864-1408

MoDNR

  • Don Dicks (573) 751-3553
  • Heidi Rice (573) 291-1417

Multistate Trust

  • Marc Weinreich (617) 512-8063
  • Amber Igoe (850) 322-8033

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

slide-34
SLIDE 34

Additional Information Resources

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

  • Missouri Department of Health & Senior Services

(573) 751-6102

  • Springfield-Greene County Health Department

(417) 864-1658

  • Agency for Toxic Substances and Disease Registry

(ATSDR) (800) 232-4636

  • Site Document Repository – The Library Center

Springfield-Greene County Library (417) 882-0714

slide-35
SLIDE 35

Questions?

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

slide-36
SLIDE 36

Former Kerr-McGee Wood Treatment Facility Springfield, MO

Greenfield Environmental Multistate Trust LLC Trustee of the Multistate Environmental Response Trust

Greenfield Environmental Multistate Trust LLC, Trustee of the Multistate Environmental Response Trust

Public Information Meeting

Marc Weinreich, Managing Principal Lauri Gorton, Director of Environmental Programs Amber Igoe, Springfield Site Project Manager

September 14, 2016
