PRS I NTERNATI ONAL BV

COMPANY I NTRODUCTI ON

PRS I nternational B.V. is based in The Netherlands and is a fast grow ing I ndustrial service com pany for, both

• nshore and offshore. Offering Specialized Services,

solutions and equipm ent for the pipeline, petrochem ical and refinery industry. PRS I nternational B.V. is able to offer the specialized services throughout Europe, the Middle East and the Far East either from the base in The Netherlands or through one of the I nternational Offices. Expertise com bined w ith advanced technologies deliver effective cleaning, drying, testing and other process and pipeline solutions.

W elcom e

I ntroduction

• Pipeline I nspections ( I LI & DCVG)
• Pipeline I ntergrity Consultancy
• Pipeline Pigging
• Pipeline Testing & Drying
• Pipeline Pneum atic Leak Testing
• Pipeline I nhibitor pigging
• Pipeline Cleaning On- & Off-line
• Pipeline I nsitu Coating
• Pipeline Chem ical Cleaning
• Pipeline Decom m issioning

Pipeline Services

Nitrogen Services

• Leak & Pressure Testing
• Helium Leak Detection
• Accelerated Reactor Cooldow n
• Pipeline Freezing Plugs
• Nitrogen Purging & I nerting
• Nitrogen Drying of Pipelines &

Process Plants

• Pipeline Displacem ents
• Foam I nerting

• Jet-blast Cleaning
• Hot-oil Flushing
• Chemical Cleaning
• High Pressure Cleaning
• Bolt-torquing/ Tensioning

Process Services

• Steam & Air Blow Services
• Chemical Cleaning
• Final Drying
• Gas-up And Consultancy

Com m issioning Services

PI PELI NE PRE-COMMI SSI ONI NG SERVI CES;

• Pipeline Flooding Testing And Dewatering
• Pipeline Geometry Survey
• Pipeline Drying Using Air
• Pipeline Drying Using Nitrogen

PI PELI NE CLEANI NG SERVI CES;

• Pipeline Product Displacements
• Mechanical Cleaning (Pigging)
• Chemical Cleaning

PI PELI NE MAI NTENANCE SERVI CES;

• Internal Coating
• Temporary Pipeline Repairs

Pipeline Pre-Com m issioning

• Preparing pipelines for pigging & inspections
• Hydrostatic testing
• High pressure nitrogen testing
• Nitrogen / helium leak testing
• Fully equipped test cabins

TEST PERSONNEL CERTIFIED FOR:

 BS8010, BRITISH GAS BGC/ PS/ PT1 &PT3  DVGW G469  GASUNIE CSW-19-N

Pipeline Services

Portable Data Logging Tool

• Provides data in operational parameters and

Analysis of pig behavior.

• Measuring: pressures, temperature, rotation,

acceleration – 3d * NO DIRECT DISTANCE MEASUREMENT*

Pipeline Pigging

Portable Data Logging tool Studded pigs for scale rem oval BiDi pigs for batching and cleaning. Foam pigs for drying and brushing

Pipeline Pigging

TRANSMITTER

Pipeline Pigging

• Online cleaning, removal of dust, liquids and sand
• Wax, paraffin and asphaltene removal from crude and fuel oil pipelines
• De-oiling, for pipelines that will be prepared for other products
• De-rusting of oxygen- and product pipelines
• Inhibitor pig runs for H2S pipelines

Pipeline Cleaning

Pipeline I nsitu Coating Pipeline Rehabilitation Services Process:

In-Situ coating application whereby a two compound Epoxy coating will be applied to inside pipe-wall between pigs. This will allow several kilometers of pipeline to be coated without cutting the pipeline.

Uncoated Coated

SILENCE R

NITROGEN

PRODUCT

product SILENCER

Tank storage Filters Flaring Nitrogen can be used to pig and displace pipelines using the expansion capacities of liquid nitrogen. Products can be send to storage facilities or through filters in other pipeline sections or just vented off through flares,

Pipeline Displacem ents

Reactor Cool-dow n Services

Are developed to accelerate the cool-down process minimizing down time prior to catalyst change and lower the reactor entry temperature for safer and faster work. Basic procedures:

• Using LN2 to cool down the recycle gas (most efficient).
• Once trough method.

Nitrogen Services

After the initial cool-down to temperatures of 150 – 250˚c the accelerated cooldown process will take over and the cool-down rate will be increased using cold Nitrogen gas to temperatures < 40˚c Nitrogen can also be used for the hot stripping of hydrocarbons from the catalyst.

Nitrogen Services

Helium Leak Testing Services

Pressurizing process systems to 95% of the PSV setting using Nitrogen with 1% Helium as a tracer. Flanges will be taped off and checked for leaks.

Nitrogen Services

Nitrogen Foam I nerting

PRS’s Nitrogen foam in-erting is a simple yet effective process that enables hot work to be carried out on hydrocarbon handling systems in complete safety. The Nitrogen foam is injected into a process system at a low point and allowed to completely fill the vessel and pipework, rendering the internal atmosphere inert. On completion of hot work operations, the Nitrogen foam degenerates into small amounts of water, surfactant and gaseous Nitrogen.

Nitrogen Services

Typical foam in-erting applications include vessel and pipework modification and / or replacement, hot cutting and system de- commissioning. All components of nitrogen foam are biodegradable and non-bio accumulative.

Nitrogen Services

Pipe Freezing Services

Pipe-freezing is an essential tool in the maintenance of all types of liquid storage, process and transfer plant. The range of applications in which pipe-freezing can provide cost effective solutions is both extensive and diverse, from a small domestic water pipe to a huge oil pipeline, from a hospital heating system to a brewery bulk storage system, the freeze can be applied quickly and the results are reliable.

TYPICAL FREEZE PLUG SET-UP ALLOWING TEMPORARY PIPELINE ISOLATIONS.

Nitrogen Services

Under Ground Tank & Line Leak Testing

The portability and light weight of the PRS heli-test equipment (varian PHD-4) plays a major role in this application. Underground pipelines and storage tanks (ugst) are pressurized with Helium which, due to its high mobility, can escape through small leaks and migrate to the surface. There it can be easily detected by the phd-4.

Nitrogen Services

Chemical Cleaning

In addition to the standard cleaning methods, PRS International offers a broad range of chemical cleaning services for pipelines, process systems in the process industry and power plants. Using solvents and/or surfactant bases cleaning chemicals are more effective than the traditional mechanical cleaning methods. Chemical cleaning is widely used for commissioning and de-commissioning

• f pipelines and process plants to increase productivity (throughput) and

efficiency, to improve inspections results, to maintain the quality of the product. In pipelines the use solvents and/or surfactant based cleaning chemicals are more effective than the mechanical cleaning using only pigs.

Chem ical Cleaning

Steam And Air Blow ing Services

Steam blowing and air blowing are basically alternative techniques used during the commissioning of new steam raising plant. They are performed to ensure that potentially damaging debris is removed from the steam lines before the steam is admitted to equipment that may be damaged by such debris, in particular steam turbines.

Typical steam -blow operation in progress

Steam & Airblow Services

PRS I nternational B.V. Modem 3 2 7 7 4 1 MJ – Coevorden The Netherlands

• Tel. : + 3 1 5 2 4 5 9 9 9 8 0
• Fax. : + 3 1 5 2 4 5 9 9 9 8 8

Em ail : info@prs-international.nl

Contact
