SLIDE 1

Product Catalog for the automation of machine tools

ProMotion

Workpiece handling 4–9 Pallet handling 10–13 Tool handling 14–15

Special Edition

More than 4100 implemented projects speak for themselves.

For the Perfect Automation

• f Machine Tools

Product Catalog for the automation of machine tools

Unique Module System

SLIDE 2 2 ProMotion Special Edition

Our processes

At Promot Automation, business processes are continuously advanced. Since 1989 we have been working with our own ERP software, since 1993 with 3D

• CAD. Due to permanent training all our employees have

internalized the stable processes. This has enabled us to install plants of high quality in due time for many years.

Promot Automation promotes your success by automating machine tools.

Promot Automation is the acknowledged leading brand for the automation of machine tools. With special competence in metal cutting. This is our vision. And also our task. Our name has stood for the intelligent, fully automatic and inexpensive handling

• f workpieces, pallets

and tools. For more than 30 years. Because your success is our mission.

Our employees

The backbone of the organization of Promot Automation are

• ur employees. They all are excellently trained and have years
• f experience and a strong dedication. Our manage

ment team, as well as the sales department and the engineering department feature high continuity. Our entire team identify wholeheartedly with the company, their loyalty is extraordinarily high, and they are all very well-practised. To fulfil the wishes of our customers we ensure a perfect project management at all levels. Since 1980 we have already implemented more than 4100 different projects, automating machine tools of more than 250 different manufacturers.

SLIDE 3 ProMotion Special Edition 3

Flexible modules – making up a module system

Automation cells are extremely different. As different as workpieces, manufacturing philosophies, logistics, transport containers, or cutting processes. Our machines are based on the needs and processes of the customer, to which we adapt

• ur cell layout. Due to an intelligent and flexible module system our machines have

become variable enough to adapt the layout of the machines to the manufacturing, process and logistics philosophies of our customers. Since 1985.

Structure of the module systems

For the module systems workpiece handling, pallet handling and tool handling the market requirements have been defined for the relevant weight classes. In parallel to the weight classes, the module systems have been subdivided into the functionalities base frames, moving, gripping, workpiece magazines, auxiliary stations, electrical equipment and control system, and software. Within the functionalities there are various modules of different sizes depending on the task. Within the various sizes we also differentiate between designs. An example: The module linear gantry is avail- able in 5 sizes to cover the weight range from 1 to 500 kg. Within the sizes there are the designs “Basic” and “Crane loading”. 4 ProMotion Special Edition ProMotion Special Edition 5 Module system Software

Workpiece handling

Revolving station 1 5 10 20 35 50 100 150 250 >250 Centrifugal station 1 5 10 20 35 50 100 150 250 >250 Cleaning station 1 5 10 20 35 50 100 150 250 >250 Gantry system box 1 5 10 20 35 50 100 150 250 >250 SPC (NOK) drawer 1 5 10 20 35 50 100 150 250 >250 NOK (SPC) chute 1 5 10 20 35 50 100 150 250 >250 Interface ERP/PPS Machine data acquisition Visualization Remote alarm NC/PLC basic NC/PLC acc. to functional specification Control computer Interface machine Auxiliary stations 5.1 7.1 7.5 7.2 7.6 7.3 7.7 7.4 7.8 5.4 5.2 5.5 Base frame Linear gantry PL 1 5 10 20 35 50 100 150 250 >250 Linear meter gantry PL-LM 1 5 10 20 35 50 100 150 250 >250 Jib arm gantry PA 1 5 10 20 35 50 100 150 250 >250 Area gantry PF 1 5 10 20 35 50 100 150 250 >250 Linear gantry PL-Jet 1 5 10 20 35 50 100 150 250 >250 Robot cell RZ 1 5 10 20 35 50 100 150 250 >250 Loading hatch 1 5 10 20 35 50 100 150 250 >250 Door module 1 5 10 20 35 50 100 150 250 >250 Media module 1 5 10 20 35 50 100 150 250 >250 1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 Moving Linear slide 1 5 10 20 35 50 100 150 250 >250 Jib arm slide 1 5 10 20 35 50 100 150 250 >250 Cross slide 1 5 10 20 35 50 100 150 250 >250 Slide for jet robot 1 5 10 20 35 50 100 150 250 >250 Slide for swivel arm 1 5 10 20 35 50 100 150 250 >250 Gantry arm 1 5 10 20 35 50 100 150 250 >250 Telescopic arm 1 5 10 20 35 50 100 150 250 >250 Swivel arm 1 5 10 20 35 50 100 150 250 >250 Swivel drive NC 1 5 10 20 35 50 100 150 250 >250 2.1 2.2 2.3 2.4 2.5 2.6 2.7 2.8 2.9 Cellmaster CM-S 1 5 10 20 35 50 100 150 250 >250 Cellmaster CM-D 1 5 10 20 35 50 100 150 250 >250 Cellmaster CM-EKM 1 5 10 20 35 50 100 150 250 >250 4.7 4.8 4.9 Bottom roller conveyor WS-BRB 1 5 10 20 35 50 100 150 250 >250 Pallet conveyor WS-Uni 1 5 10 20 35 50 100 150 250 >250 Accumulating conveyor WS-FR 1 5 10 20 35 50 100 150 250 >250 Plate conveyor WS-PL 1 5 10 20 35 50 100 150 250 >250 Shaft magazine WS-W 1 5 10 20 35 50 100 150 250 >250 Pallet accumulating conveyor WS-PSB 1 5 10 20 35 50 100 150 250 >250 Multi deck pallet magazine WS-ES 1 5 10 20 35 50 100 150 250 >250 Workpiece magazines 4.1 4.4 4.10 4.2 4.5 4.3 4.6 5.3 5.6 Gripping 3-point centric gripper 1 5 10 20 35 50 100 150 250 >250 Front gripper 1 5 10 20 35 50 100 150 250 >250 Parallel gripper 1 5 10 20 35 50 100 150 250 >250 Angular gripper 1 5 10 20 35 50 100 150 250 >250 3-point shaft gripper 1 5 10 20 35 50 100 150 250 >250 Basket gripper 1 5 10 20 35 50 100 150 250 >250 3.1 3.4 3.2 3.5 3.3 3.6 Tilting module 45° pneum. 1 5 10 20 35 50 100 150 250 >250 Tilting module 90° pneum. 1 5 10 20 35 50 100 150 250 >250 C-axis NC 1 5 10 20 35 50 100 150 250 >250 Articulated robot 1 5 10 20 35 50 100 150 250 >250 Lineareinheit Roboter 1 5 10 20 35 50 100 150 250 >250 2.10 2.11 2.13 2.12 2.14 Control system Control cabinet 6.1 Maximum handling weight in kg 1 5 10 20 35 50 100 150 250 >250 The components of the module system in detail: base frame, motion modules, gripper technology, workpiece magazines, auxiliary stations, electrical equipment and control system, software, and services. The products are standardized for each individual field, they are tried and tested, and they undergo continuous

• ptimization.

There are two ways of workpiece handling: first via the gantry robot, where the workpieces are fed from above, and second via loading by means of an articulated robot. Control system Siemens 840D 6.2 Control system Siemens S7 6.3 Control system Beckhoff 6.4 Visualization 6.5 Gantry interlinked machines PL 30 Linear gantry with H-loader for loading and unloading workpieces of up to 30 kg to and from three grinding machines. Single machine operation is possible via area guards (loading hatches in the drip pans). Workpieces are provided on plate conveyors (one raw part and one finished part conveyor). Additionally, a centrifugal station is integrated for parts cleaning. Linear gantry PL 10 Linear gantry with NC slewing drive and double gripper for loading workpieces of up to 10 kg to a turning lathe. The workpiece magazine is a flexible pallet conveyor WS-Uni. Between the magazine and the machine a measured parts drawer (SPC) is installed. Robot cell RZ 50 Robot cell for lateral loading of a gear cutting machine and a washing machine with workpieces up to 50 kg. The workpieces are arranged in stacks on a pallet cycle belt with stacking pallets and lifting station. An alignment station, a calibrating station, a dip tank, as well as several depositing racks are included additionally.

Cost per part

Regardless of general conditions, batch sizes and manufacturing technologies there is one common objective in our focus: to reduce the cost of each individual workpiece. To this end, absolutely all cost factors have to be determined and

• analysed. Apart from the time slices during which the machines

are occupied, the times of employees spent with the individual work sequences are relevant. Depending on whether small/big batches or new parts/repeat parts are manufactured, different time slices may be relevant. While setup times and the time for programming carry more weight in case of small batches, part change times and unit times will be more important in case

• f series production.

Cost accounting

Customers SAP

General planning Detailed planning BDE MDE Machines Machine groups Articles Orders Documents NC programs Raw material Tools Clamping devices Area ERP

• Quotations
• Orders
• Work schedules
• Documents
• Invoices
• Clamp. geom.

Tool geom. QA data Activities CAM Postprocessor Simulation Documents Clamping devices Raw material Tools DNC

The process chain

To reduce the cost per part at short notice and to raise further optimization potential in the long run, it is advisable to analyse the entire process chain. The elements EPR software, CAM software, MDE/MES software, tool manage ment, clamping devices, machines, automation, and the

• perating

procedures shall be coordinated and

• ptimized, to the end that all elements

cooperate in such a way that the employees can use very much of their time for value-adding activities , and the machines have low downtimes. Automation is a key component in reducing cost. How should automation be designed that has a major share in reducing cost? Not only at short notice, but mainly with a view to becoming a key component in supporting continuous improvement and implementing the long-term production philosophy. Realize your vision of future manufacture with Promot Automation. Our module systems enable us to address you individual needs. Linear gantry PL 1 5 10 20 35 50 100 150 250 >250 Maximum handling weight in kg 1 5 10 20 35 50 100 150 250 >250 50 100 150 250 400 1000 2500 10 20 35 50

Q2 Q3 Q1 Q4

very often

• n a regular

basis sometimes possibly never again repetition factor batch sizes 1 4 20 50 300 2000

SLIDE 4 4 ProMotion Special Edition

Module system Software

Workpiece handling

Interface ERP/PPS Machine data acquisition Visualization Remote alarm NC/PLC basic NC/PLC acc. to functional specification Control computer Interface machine 7.1 7.5 7.2 7.6 7.3 7.7 7.4 7.8

Base frame

Linear gantry PL 1 5 10 20 35 50 100 150 250 >250 Linear meter gantry PL-LM 1 5 10 20 35 50 100 150 250 >250 Jib arm gantry PA 1 5 10 20 35 50 100 150 250 >250 Area gantry PF 1 5 10 20 35 50 100 150 250 >250 Linear gantry PL-Jet 1 5 10 20 35 50 100 150 250 >250 Robot cell RZ 1 5 10 20 35 50 100 150 250 >250 Loading hatch 1 5 10 20 35 50 100 150 250 >250 Door module 1 5 10 20 35 50 100 150 250 >250 Media module 1 5 10 20 35 50 100 150 250 >250 1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 Maximum handling weight in kg 1 5 10 20 35 50 100 150 250 >250 The components of the module system in detail: base frame, motion modules, gripper technology, workpiece magazines, auxiliary stations, electrical equipment and control system, software, and services. The products are standardized for each individual field, they are tried and tested, and they undergo continuous

• ptimization.

There are two ways of workpiece handling: first via the gantry robot, where the workpieces are fed from above, and second via loading by means of an articulated robot. Gantry interlinked machines PL 30 Linear gantry with H-loader for loading and unloading workpieces of up to 30 kg to and from three grinding machines. Single machine operation is possible via area guards (loading hatches in the drip pans). Workpieces are provided on plate conveyors (one raw part and one finished part conveyor). Additionally, a centrifugal station is integrated for parts cleaning. Linear gantry PL 10 Linear gantry with NC slewing drive and double gripper for loading workpieces of up to 10 kg to a turning lathe. The workpiece magazine is a flexible pallet conveyor WS-Uni. Between the magazine and the machine a measured parts drawer (SPC) is installed.

SLIDE 5 ProMotion Special Edition 5 Revolving station 1 5 10 20 35 50 100 150 250 >250 Centrifugal station 1 5 10 20 35 50 100 150 250 >250 Cleaning station 1 5 10 20 35 50 100 150 250 >250 Gantry system box 1 5 10 20 35 50 100 150 250 >250 SPC (NOK) drawer 1 5 10 20 35 50 100 150 250 >250 NOK (SPC) chute 1 5 10 20 35 50 100 150 250 >250

Auxiliary stations

5.1 5.4 5.2 5.5

Moving

Linear slide 1 5 10 20 35 50 100 150 250 >250 Jib arm slide 1 5 10 20 35 50 100 150 250 >250 Cross slide 1 5 10 20 35 50 100 150 250 >250 Slide for jet robot 1 5 10 20 35 50 100 150 250 >250 Slide for swivel arm 1 5 10 20 35 50 100 150 250 >250 Gantry arm 1 5 10 20 35 50 100 150 250 >250 Telescopic arm 1 5 10 20 35 50 100 150 250 >250 Swivel arm 1 5 10 20 35 50 100 150 250 >250 Swivel drive NC 1 5 10 20 35 50 100 150 250 >250 2.1 2.2 2.3 2.4 2.5 2.6 2.7 2.8 2.9 Cellmaster CM-S 1 5 10 20 35 50 100 150 250 >250 Cellmaster CM-D 1 5 10 20 35 50 100 150 250 >250 Cellmaster CM-EKM 1 5 10 20 35 50 100 150 250 >250 4.7 4.8 4.9 Bottom roller conveyor WS-BRB 1 5 10 20 35 50 100 150 250 >250 Pallet conveyor WS-Uni 1 5 10 20 35 50 100 150 250 >250 Accumulating conveyor WS-FR 1 5 10 20 35 50 100 150 250 >250 Plate conveyor WS-PL 1 5 10 20 35 50 100 150 250 >250 Shaft magazine WS-W 1 5 10 20 35 50 100 150 250 >250 Pallet accumulating conveyor WS-PSB 1 5 10 20 35 50 100 150 250 >250 Multi deck pallet magazine WS-ES 1 5 10 20 35 50 100 150 250 >250

Workpiece magazines

4.1 4.4 4.10 4.2 4.5 4.3 4.6 5.3 5.6

Gripping

3-point centric gripper 1 5 10 20 35 50 100 150 250 >250 Front gripper 1 5 10 20 35 50 100 150 250 >250 Parallel gripper 1 5 10 20 35 50 100 150 250 >250 Angular gripper 1 5 10 20 35 50 100 150 250 >250 3-point shaft gripper 1 5 10 20 35 50 100 150 250 >250 Basket gripper 1 5 10 20 35 50 100 150 250 >250 3.1 3.4 3.2 3.5 3.3 3.6 Tilting module 45° pneum. 1 5 10 20 35 50 100 150 250 >250 Tilting module 90° pneum. 1 5 10 20 35 50 100 150 250 >250 C-axis NC 1 5 10 20 35 50 100 150 250 >250 Articulated robot 1 5 10 20 35 50 100 150 250 >250 Linear unit robot 1 5 10 20 35 50 100 150 250 >250 2.10 2.11 2.13 2.12 2.14

Control system

Control cabinet 6.1 Control system Siemens 840D 6.2 Control system Siemens S7 6.3 Control system Beckhoff 6.4 Visualization 6.5 Robot cell RZ 50 Robot cell for lateral loading of a gear cutting machine and a washing machine with workpieces up to 50 kg. The workpieces are arranged in stacks on a pallet cycle belt with stacking pallets and lifting station. An alignment station, a calibrating station, a dip tank, as well as several depositing racks are included additionally.

SLIDE 6 6 ProMotion Special Edition

Gantry robots

Workpiece handling

Gantry robots are an efficient variant for the automation of machine tools. Access to the machine is maintained thanks to loading from the top. This is of particular importance for setup processes and monitoring

• activities. By utilizing

the space above the machine, valuable hall space can be used for other activities. The linear axes facilitate

• perating,

programming and training at the machine. Jib arm gantry PA 10 The jib arm gantry for loading and unloading of workpieces up to 10 kg to and from a turning lathe. To increase the capacity, the workpiece magazine WS-Uni is designed as L-shaped pallet conveyor (80 pallets in total). The workpieces are aligned radially at an aligning station upstream of loading. After machining they are cleaned in a blow off box. Jib arm gantry PA 15 Jib arm gantry with H-loader and telescopic arm (maximum workpiece weight 15 kg) for loading and unloading of four grinding machines (parallel operation). Single machine

• peration and/or manual operation is possible

via area guards (loading hatches in the trip pans). The gripper distance at the gripper yoke can be adjusted via NC axis. The workpiece magazine used is the 6-chamber stacking cell Cellmaster 1200 x 800. Additionally, an aligning station with 3 NC axes is integrated.

SLIDE 7 ProMotion Special Edition 7

Material flow solutions – interlinked machines

Examples from among the range of workpieces

We offer our customers the optimum automation solution for each specific application, realizing the most efficient concatenated system, taking into account all lean-production criteria. This offer is completed by our competent advisory

• service. We carefully

consider all general requirements of production technology, the desired degree of flexibility, as well as the logistic parameters. Due to our modular system we are able to

• ffer customized solutions. And because of
• ur experience in the automation of machine

tools we have the proper know-how for your specific requirements.

Cellmaster CM-S

The fully automatic Cellmaster of Promot Automation is a standardized magazine with three chambers for baskets or pallet stacks. Gantry cell PZ 5 Gantry cell for loading and unloading of a gear grinding

• machine. The workpieces are

ring gears of up to 5 kg at max. Workpieces are provided via a stacking cell Cellmaster 600 x 400. The integrated auxiliary stations are a measured parts drawer, a scrap drawer, and a centrifugal station for drying of workpieces. Linear gantry PL 50 Linear gantry with H-loader for loading and unloading crank shafts with a workpiece weight of up to 50 kg to and from two turning/milling centres. The stacking cell Cellmaster 1300 x 1000 is loaded via AGV systems. Additionally, an aligning station and a measured parts drawer (SPC) are integrated. Gantry interlinked machines Conveyor belt interlinkage Interlinked manufacturing cells This permits interruption-free production. The Cellmaster provides the individual containers in such a way that a gantry robot or articulated robot can take raw parts out of them and put finished parts into them.

SLIDE 8 8 ProMotion Special Edition

Robot cells

Workpiece handling

Robot cell RZ 25 Robot cell with standard articulated robot

• n a linear unit for loading workpieces of

up to 25 kg to four machining centres. Workpieces are provided on pallet conveyors on the raw part side; finished parts are deposited on a belt conveyor. Additional integration of a measured parts drawer, as well as a deburring and blow off station. Robot cell RZ 5 Robot cell for lateral loading of balance shafts to two machining centres. Workpieces are provided via the stacking cell Cellmaster 600 x 800 in stacked wire mesh baskets. Additionally, interim deposits as well as a laser marking station and a testing station are integrated. Robot cells are a flexible variant for the automation

• f machine tools.

Of course, our robot cells, too, are assembled from components

• f our flexible and

standardized modular system. Being provided with a higher number of movement axes, the articulated robot affords high flexibility. Nevertheless, due to cell control and visualization the plants can be

• perated as easily

as a gantry robot. The robot and

• ther modules of

the system can be reused.

SLIDE 9 ProMotion Special Edition 9 Robot cell RZ 5 Robot cell for loading of workpieces up to 5 kg at max. to an induction welding unit, using the standard setup

• f the combination articulated robot

and stacking cell Cellmaster. Robot cell RZ 3 Compact design robot cell for loading a cleaning plant. Workpiece storage is by means of a pigeonhole storage system. Robot cell RZ 10 Robot cell with top-mounted articulated robot for loading ring gears to a gear grinding machine. The workpieces are provided via the stacking cell Cellmaser 800 x 600. Additionally, a measured parts magazine as well as a washing and centrifugal station are integrated. All our robot cells are equipped with cell control and visualization. We implement independent and open interfaces and standardized control

• concepts. Due to a software that is compatible

with any control system, our visualization offers a consistent operational

• concept. Visualization

can be easily controlled and programmed via stationary displays. Benefits:

• Robot makes and types are interchangeable
• Standardized interfaces
• Quick start-up
• Easy diagnosis and maintenance
• Same HMI as in case of gantry loaders
• MDE and easy process diagnosis
• Visualization open and freely scalable

Plant visualization Machine data acquisition Operation of a plant

Cell control – visualization

Safety is our utmost priority when it comes to automating cutting machine tools. Therefore, all our automation cells and our entire flexible module system are permanently tested and inspected thoroughly. Testing includes gantry robots as well as robot cells or pallet hand- ling. To provide for safety at all levels we simulate situations around the machines using various crash tests. Thus we ensure that Promot Automation designs steadier and safer systems than anyone else.

Safety

SLIDE 10 10 ProMotion Special Edition

Module system

Pallet handling

Base frame SL 50 100 150 250 400 1000 2500 Frame robot cell RZ 50 100 150 250 400 1000 2500 Frame robot cell RL 50 100 150 250 400 1000 2500 Door module 50 100 150 250 400 1000 2500 Loading hatch 50 100 150 250 400 1000 2500 Guard module 50 100 150 250 400 1000 2500

Base frame

The efficient auto- mation of machining centres for small and medium batch sizes is a fascinating and demanding task. With the Palmaster product series, we

• ffer a suitable

solution for all pallet- handling tasks, both for single machines and for flexible manufacturing systems consisting

• f several machines.

The whole product series is designed

• n a modular basis

and uses the same components for all areas. 1.1 1.2 1.3 1.4 1.5 1.6 1.7 Maximum handling weight in kg 50 100 150 250 400 1000 2500

Software

Prosys DNC Interface CAM Prosys DNC Interface ERP Prosys TM Tool resource checking Prosys TM Tool maser data Prosys Basic Base module Prosys TM Connection preadjustment unit Prosys Basic Plant visualization Prosys NC Automatic version control Prosys NC NC program management Prosys Basic GSM alarm module Prosys MDE Machine data acquisition Prosys DNC Interface machine Prosys APS Simulation module 8.2 8.10 8.6 8.3 8.12 8.11 8.7 8.4 8.13 8.8 8.5 8.14 8.9 Prosys RM Raw material management Prosys WH Workpiece handling 8.15 8.16 PLC Basic 8.1 Media module 50 100 150 250 400 1000 2500 Palmaster RZ Our flexible robot cell from the module system for transport weights up to 400kg. Palmaster RL Extension of the robot cell Palmaster RZ by one linear unit

SLIDE 11 ProMotion Special Edition 11

Moving Control system Gripping Auxiliary stations Pallets

Swingarm loader 50 100 150 250 400 1000 2500 Control cabinet Control system Beckhoff Articulated robot 50 100 150 250 400 1000 2500 Setup station with revolving door 50 100 150 250 400 1000 2500 Linear unit robot 50 100 150 250 400 1000 2500 Dual setup station 50 100 150 250 400 1000 2500 Rüststation Vario 50 100 150 250 400 1000 2500 Rack feeder 50 100 150 250 400 1000 2500 Inward transfer of material pallets 50 100 150 250 400 1000 2500 Gripper fork 50 100 150 250 400 1000 2500 Intermediate transition device 50 100 150 250 400 1000 2500 Clamping system, front side 50 100 150 250 400 1000 2500 Cleaning station 50 100 150 250 400 1000 2500 Workpiece gripper 1 50 100 150 250 400 1000 2500 Intermediate deposit 50 100 150 250 400 1000 2500 Basic pallet equipment 50 100 150 250 400 1000 2500 Clamping system 50 100 150 250 400 1000 2500 Pallet coding 50 100 150 250 400 1000 2500 Workpiece gripper 2 50 100 150 250 400 1000 2500 Double telescope 50 100 150 250 400 1000 2500 Prong distance adjustment 50 100 150 250 400 1000 2500 2.1 7.1 7.2 2.3 Control panel on a cantilever arm 7.3 with additional panel 7.4 Freestanding control panel 7.5 6.1 2.4 6.2 6.3 2.5 6.4 3.1 6.5 3.4 5.1 3.2 6.6 3.5 5.2 3.3 6.7 3.6

Workpiece magazines

Pallet rack 50 100 150 250 400 1000 2500 High-rack storage 50 100 150 250 400 1000 2500 Additional shelf 50 100 150 250 400 1000 2500 4.1 4.2 4.3 5.3 Palmaster FFS Flexible manufacturing system with fully automatic high-rack storage

• Max. transport weights

up to 2500kg Gripper storage 50 100 150 250 400 1000 2500 6.8 Linear unit SL 50 100 150 250 400 1000 2500 2.2 2.2 Palmaster SL Swingarm loader with max. 3 m rack height reach. Max. transport weight up to 2500kg

SLIDE 12 12 ProMotion Special Edition Everything from one single source, namely from the house of Promot Automation. All components of the flexible system have been tried and tested, and we have developed them with a view to optimum

• perability.

Important for you as

• ur customer: The

software Promot Prosys, too, has been developed in our house and is also designed according to the modular principle.

Module system Palmaster RZ/RL – the flexible robot cell

The Palmaster RZ is a robot cell with a floor installed articulated-arm robot, designed for handling pallets

• f up to 400kg. The cell can be configured into many

different variants and is also suitable for linking one or two machines, or can be expanded by a linear unit. The cell can be configured in various ways, and it is suit- able for connecting one or two machines. Due to a sophis- ticated guarding system one machine can be operated manually, while the second machine keeps working in the automatic mode. If higher flexibility is needed, different pallet dimensions can be used in the system, or the cell can be extended, in addition to pallet handling, by one change gripper for workpiece handling.

Our advisory service

The pronounced goal is to reduce the cost per part. Therefore, we scrutinize the entire process chain in detail together with our

• customers. At the same time

we provide advice at workshops or simulations. On the basis of our experience we analyse your situation together with you, so we can afterwards offer you the best solution for your specific task.

Palmaster FFS – high-rack storage

Palmaster FFS creates magazine capacity, thus providing for the related autonomy by using the full height of the room. The pallets with the fixtures are stored in a fully automatic high-rack storage. The handling of the pallets is by means of a stacker crane storage and retrieval system for transport weights up to max. 2500kg. Palmaster RZ for two machines arranged at 180° Palmaster FFS + Toolmaster + Setupmaster A combination of pallets, tools and workpiece handling all on a single manufacturing cell. Palmaster RZ for two machines arranged at 90° Palmaster RZ with one machine

Pallet handling

SLIDE 13 ProMotion Special Edition 13

Palmaster SZ/SL – Swingarm loader

The Promot Swingarm loader is a linear movable, floor installed loading arm. It is available in versions with two different reaches and for transport handling weights up to 2500kg. The swingarm loader is an ideal solution for storage tasks up to 3 m rack heights (typically on 2

• r 3 levels). As with all Promot Palmaster plant full

advantage can be taken of the easy expansion and variable layout design the versatile modular system brings. The linear movable swingarm loader is available in three weight classes and with two different reaches. Palmaster RZ with additional workpiece magazine Palmaster RL with robot on linear unit Palmaster FFS 1000 (Pallet handling) Toolmaster PA 10/1000 (Tool handling) Setupmaster RZ 10 (Workpiece handling)

Software family – Promot Prosys

Software is of very high importance in flexible manufacturing sytems. Together with the hardware and the control computer software Promot Prosys developed in our own house you get a state-of-the-art modular system. And all this without any additional interface. The base module Prosys Basic contains an extensive data base managing master data

• f articles, operations, pallets and fixtures.

Extension modules for tool management, NC program management, simulation, machine data acquisition, etc., can be implemented immediately or also at a later date. With our software, too, we clearly focus on “cost per part”.

SLIDE 14 14 ProMotion Special Edition

Module system

Tool handling

With Toolmaster, Promot Automation

• ffers two

alternatives for tool handling. First, as a central tool

• magazine. The tools

are distributed to the machine via a gantry robot. The second alternative is the extension of an existing tool magazine via articulated robot and round magazine. The tools are managed via the software modules from the product series Promot Prosys.

Software

Prosys TM Toolmaster Prosys TM Tool resource checking Prosys TM Connection preadjustment unit Prosys DNC Interface machine Prosys DNC Interface CAM Prosys DNC Interface ERP 7.1 7.4 7.2 7.5 7.3 7.6 Linear gantry PL 10 20 35 50 Jib arm gantry PA 10 20 35 50 Area gantry PF 10 20 35 50 Linear gantry PL-Jet 10 20 35 50 Robot cell RZ 10 20 35 50 Loading hatch 10 20 35 50 Door module 10 20 35 50

Base frame

1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 Toolmaster PA 10/1000 Central tool magazine for 1000 tools HSK63. The tools are distributed via a jib arm gantry EPA 10. Maximum handling weight in kg 10 20 35 50 Media module 10 20 35 50

SLIDE 15 ProMotion Special Edition 15

Moving

Linear slide 10 20 35 50 Jib arm slide 10 20 35 50 Cross slide 10 20 35 50 Slide for jet robot 10 20 35 50 Gantry arm 10 20 35 50 Telescopic arm 10 20 35 50 Gantry minus system box 10 20 35 50 Cleaning station 10 20 35 50 Tilting module 45° pneum. 10 20 35 50 SPC drawer 10 20 35 50 Tilting module 90° pneum. 10 20 35 50 Revolving station 10 20 35 50 C-axis NC 10 20 35 50 Articulated robot 10 20 35 50 Linear unit robot 10 20 35 50 2.1 2.2 2.3 2.4 2.5

Auxiliary stations

Setup station 10 20 35 50 DMC reading station/unit 10 20 35 50 RFID reading station 10 20 35 50 5.1 5.2 5.3 2.6 5.4 5.5 2.9 2.7 5.6 2.10 2.8 5.7 2.11 Tool magazine TM 10 20 35 50 Storages places in traversing channel 10 20 35 50 Tool round magazine 10 20 35 50 Tool rack magazine 10 20 35 50 4.1 4.3 4.2 4.4

Gripping

Parallel gripper 10 20 35 50 3-point centric gripper 10 20 35 50 3.1 3.2

Control system

Control cabinet Control system Beckhoff Control panel 6.1 6.2 6.3 Toolmaster RZ 10/120 with round magazine Toolmaster round magazine is used as tool magazine extension. Handling unit Toolmaster TM Toolmaster TM with setup station and control panel Tool round magazine Tools HSK in Toolmaster tool bar

Workpiece magazines

SLIDE 16

ProMotion Special Edition

Promot Automation GmbH · Erich-Weickl-Str. 1 · 4661 Roitham, Austria Phone: +43 7613 8300-0 · Fax: +43 7613 8300-100 E-mail: office@promot.at · www.promot.at Responsible for the content: Hubert Pesendorfer Idea, conception and artwork: Das Kommunikationshaus Bad Aussee · www.kommhaus.com Photos: Promot Automation, Joe Haider Subject to alterations. Errors and misprints excepted. Stand 2013 Impressum: ABB AGCO Fendt Atlas Copco Audi BMW BOGE Kompressoren Borbet Bosch Claas Continental Daimler Dräger EADS FAG Feuer GF Getrag Ford Getrag GKN Heidenhain Hirschvogel Hoerbiger Husky Ingersoll Rand John Deere Krones Linamar Linde LUK Magna MAN Meusburger Miba MTU Opel Plansee Pöttinger SAF Sandvik SEW Siemens SKF Still Thyssen Krupp Presta Trumpf Vibracoustic Voith Volkswagen Volvo ZF Promot Automation GmbH Customer reference list (extract) We’d like to thank

• ur customers.

Horst Pesendorfer Management Alexander Illi Sales Michael Schneider Sales Christian Jell Sales Hubert Pesendorfer Management Martin Waldl Management Bernhard Blöchl Sales Robert Mayr Product Development Josef Trinkfass Sales Sven Fischer Sales Thomas Freinbichler Sales
