Enloe Hydroelectric Project

Project Implementation

November 5, 2013

Public Utility District No. 1 of Okanogan County

Project Location

Enloe Site

Installation of Second Penstock

Dam Operation with Flashboards

FERC License Project Concept

Typical New Powerhouse

Comparison of Old and New Power Plants

Power Plant Year Completed No of Units Type of Unit Axis Generating Capacity (MW) Rated Net Head (ft) Annual Generation (GWh) Old 1923 2 Francis Horizontal 3.2 78 22.5 New 2018 2 Kaplan Vertical 9 77 45

Main Project Development Tasks

 Planning   Feasibility assessment   Site Investigation   Permitting  Compliance – Dam Safety, PM&Es  Design  Procure equipment  Construction  Commissioning  Operation

Preliminary Project Construction Schedule

Design-Bid-Build Schedule

2013 2014 2015 2016 2017 ACTIVITY J F M A M J J A S O N D J F M A M J J A S O N D J F M A M J J A S O N D J F M A M J J A S O N D J F M A M J J A S O N D ENGINEERING Design Supplemental Site Investigations Prepare Bid Documents Bid Equipment Packages Bid Construction Construction Management PROCUREMENT Turbine/Generator Package Gates, Trashracks and Hoists Crest Gates Penstock Transformers/Switchgear CONSTRUCTION Mobilization Access road improvements Temporary Cofferdam Training Wall Site excavation Intake Channel Penstock Intake Penstock Tailrace channel Instream Flow Facilities Powerhouse Foundation Excavation Concrete Substructure Turbine/Generator embedded parts Powerhouse Structure Turbine/Generator Installation Electrical/mechanical services Substation/transmission Commissioning Commence Operation Install Crest Gates

Owner’s Responsibilities

 Develop concept/preliminary design  Acquire development rights/permits/approvals  Establish performance criteria  Establish construction standards  Develop RFP and construction contract  Project oversight

Design acceptance/approval Construction Acceptance (quality assurance)

 Regulatory compliance  Dam safety  Project finance  Project administration

Regulatory Compliance

 FERC License – 97 Pages

 Issued - July 9, 2013 Effective - July 1, 2013 Expires - June 30, 2062

 Terms and Conditions – Called Articles

202-206

 Finalize Exhibits F & G, Headwater benefits, Land Rights,

Financing

301-307

 Construction, Dam Safety, Public Safety Plans etc.

400-416

 Update Ecology Plans, Spoils plans, Revegetation, Recreation

plans, Fire , Aesthetics Plans, Programmatic Agreement etc.

Form L-2 General Articles 1 – 32 Appendix A – 401 Water Quality Certificate Conditions Appendix B – NOAA Fisheries Terms and Conditions

License Articles and Conditions



The FERC license contains 61 Articles



Currently we have identified approximately 350 tasks for the life of the project (50 years).



Approximately 120 tasks have been identified that have compliance deadlines between July 2013 and July 2015.



The 350 and 120 tasks identified above do not include tasks associated with the BLM R/W, 401 rulings, ACOE 404 conditions, HPA conditions or any pre, during or post Engineering or Operations assignments.



We anticipate that there will be between 500 and 1000 tasks once all the conditions are analyzed.

License Articles Completed

 Article 202, Exhi

hibi bit t F F Drawing ngs. . Withi hin n 45 5 days s of f the he da date e of f issu ssuance e of f the e license, , the e licensee e shall l file e the e approved d exhibit t F F dr drawings s in n aperture e card d and d electronic c file e formats…… …

 Article 203, Exhi

hibi bit t G G Drawing ngs. . Withi hin n 90 0 days s of f the he effective e da date e

• f

f the e license, , the e licensee e shall l file, , for r Commission n approval, , revised d Exhi hibi bit t G G drawing ngs s enc nclosing ng withi hin n the he pr project t bo bound ndary y all l pr princ ncipa pal l project t works s necessary y for r operation n and d maintenance e of f the e project, , includi ding g the e proposed d side de channel l enhancement t site; ; the e entire e leng ngth h of f the he ODIT IT Ditch R h Road f from m the he Loomis-Orov

• ville

e Roa

• ad t

to

• the

e En Enloe e Dam m Recreation n Area, , the e entire e length h of f the e En Enloe e Dam m Road; d; and d a a river a access s take-out t at t the e Miners s Flat t site……. .

License Articles Completed continued

 Article 306, Owner’s

s Dam am Saf afety y Program.

• am. Wit

ithin in 90 da days ys f from m the e is issu suance ce da date o e of t the e licen icense, se, the e licen icensee see shall l submit it to t the C e Commis issio ion’s s Div ivisio ision n of f Dam m Safet ety a y and d Inspect ectio ions s (D2SI)–Portland nd Regiona nal E Eng ngine neer, , an O n Owne ner’s s Dam m Safety y Program m which h among o

• ther i

items d demonstrates s a a clear r acknowledgement t of t the e dam m

• wners

s responsibility y for r the s safety y of t the e project, a an o

• utline

e of f the r roles a and d resp esponsib sibil ilit ities es of f it its da dam s safet ety y staff, , and d access ccess of it its da dam s safet ety y officia icial t l to

• it

its C s Chief ief Executive e Officer. F For g guidance e on t the e Owner’s s Dam m Safety y Programs, , the l licensee e should d reference e information n posted d on t the F FERC C website. .

 Article 307, Public

c Safety y Plan. . Wit

ithin in 90 0 da days ys f from t the e is issu suance ce of t this o is order der, , the l e licen icensee ee sh shall l submit it one e co copy y to t the e Commiss issio ion’s s Div ivis isio ion n of D Dam S Safet ety a y and d Ins nspe pections ns ( (D2SI)-Portland d Reg egio ional l Engin ineer eer and t d two co copies ies to

• the C

e Commis issio ion n (one e

• f

f these e copies s shall b be e a c courtesy y copy y to t the e Commission’s s Director, , D2SI) o

• f

f a P Public c Safety P Plan. . The e plan s shall l include e an e evaluation n of p public c safety c concerns s at t the p project t sit ite, e, in incl cludin ding g desig designated ed recr ecrea eatio ion n area eas, , and d asses ess t s the n e need eed for t the e in inst stallatio ion o

• f

f safet ety y dev devices ices or r other er s safet ety m y mea easures.

• es. T

The s e submit itted ed plan sh shall l in incl clude de a a des descr crip iptio ion n of f all l public ic safet ety y dev devices ices and d sig signage, e, as w wel ell a as a a m map p showin ing g the e loca catio ion n of f all l public ic safety m measures. . For r guidance e on n preparing g public c safety p plans, t the l licensee e can r review w the G Guidelines s for r Public c Safety a at t Hydropower r Projects o

• n

n the F FERC C website………… …

• Okanogan PUD Near Term Tasks Compliance Spreadsheet October 2, 2013

Compliance Document Engineering Component Required? Task Task Management Area Oversight Group(s) Consultation Requirement Due Date (for Initial Occurrence) Pre-Construction, Construction, or Operation Periodicity Reference Information License No The PUD shall develop an Operational Compliance Monitoring Plan and submit it to FERC for approval. Engineering FERC; Ecology; WDFW; FWS; NMFS; BLM; Colville Tribes Consultation and Approval Within one year of license issuance. Pre Construction One time License, Article 403 License No The PUD shall develop a Recreation Management Plan and submit it to FERC for approval. Recreation FERC; BLM; NPS; Ecology; Rec and Conservation; SHPO; Colville Tribes Consultation and Approval Within one year of license issuance. Pre Construction One time License, Article 410 License No The PUD shall develop a Fire Suppression Plan and submit it to FERC for approval. Engineering FERC; BLM; DNR Consultation and Approval Within one year of license issuance. Pre Construction One time License, Article 412 License No The PUD shall submit the final HPMP to FERC for approval. Cultural NA NA Within one year of license issuance. Pre Construction One time License, Article 415 License Yes The PUD shall consult with the appropriate State and Federal agencies and, within one year of the license issuance, submit for FERC approval a plan for clearing the reservoir area. Engineering FERC; State and federal agencies Consultation and Approval Within one year of license issuance Construction One time License, Article 20 Recreation Management Plan No The PUD shall coordinate with BLM and other landowners, as appropriate, to identify options for preventing public access to the old powerhouse. Safety BLM; landowners Consultation The RMP implementation schedule (Figure 4 of the RMP) must be adapted for the actual license issuance date. Pre Construction and Construction One time RMP, 20 401 Yes The PUD shall obtain a Hydraulic Project Approval prior to in stream work. Engineering Ecology Approval Prior to construction Pre Construction One time 401, Page 16 Aquatic Invasive Species Management Plan No The PUD shall conduct a walking survey of the perimeter of the project boundary to inspect the shoreline and adjacent shallow water areas for all AIS presence. Fish and Aquatics NA NA Prior to construction Pre Construction Annually AISMCP, 15 Blasting Plan Yes The PUD shall develop and implement a Final Blasting Plan. Safety/Engineering NA NA Prior to construction Pre Construction One time Blasting, 1 HPMP No The PUD shall coordinate with the DAHP, THPOs, and other consulting parties, as appropriate, during implementation of the HPMP to ensure compliance with Section 106 requirements. Cultural DAHP; THPOs; Consulting parties NA Prior to construction Pre Construction Ongoing HPMP, 30 License No The PUD shall develop a Wildlife Management Plan and submit it to FERC for approval. Wildlife and Botanical FERC; FWS; BLM; WDFW Consultation and Approval At least 90 days before starting construction. Pre Construction One time License, Article 409 401 No The PUD shall distribute draft plans and reports to all of the FW members for review and comments. Fish and Aquatics FW Consultation Upon finalization of FW membership Entire License Period Ongoing 401, Page 14 Stormwater Pollution Prevention Plan Yes The PUD shall implement the Stormwater Pollution Prevention Plan. Water Quality NA NA Prior to construction Pre construction or Construction Ongoing xx NMFS Biological Opinion No The PUD shall establish a Biological Resources Program, Technical Review Group (TRG). Fish and Aquatics NA NA Prior to construction Pre Construction One time BiOP, 14

Engineering

 Performance criteria & engineering standards  Transmission Interconnection  Transmission line  Protection  Control system interface  SCADA  Schedule  Budget  Cost Control  Quality Assurance  Contract Administration  Dam Safety

Accounting

 FERC Uniform System of Accounts

 Title 18 – Conservation of Power and Water Resources

• Part 101

 FERC Financial reporting  Annual FERC Charges  Payment of resource agency participants  Privilege taxes  Grant management – if applicable  Article 7 of License – FERC will determine

legitimate original cost of project in accordance with FPA.

Anticipated Timelines for Legal Challenges

401 WQ Permit Appeal and Rehearing



Completed October 2013

FERC License Rehearing and Appeals



FERC commission rejects all appellants except American Whitewater September 4, 2013



FERC ruling/order on environmental groups’ rehearing request?



PUD seeks rehearing 30 days after order/rehearing? (if FERC grants rehearing)



Environmental groups appeal decision 60 days after order/rehearing?



Next step for parties, appeal to Federal Court of Appeals

Water Rights ROE’s Appeal



WR Appeal to PCHB (30 days after issuance)



Hearing August 6 & 7, 2014, all same processes followed in 401.

581 Capital –Contractual Services

 Dam facilities inspections and reports  Agencies participation & cost recovery agreements  Historical structures monitoring  Emergency Action Plan updates  Environmental & Permitting Consultants  Engineering Consultants  Legal  PM&E Implementation  Additional agency requests

Dam Removal Examples

 Elwha

a Dam am Re Removal al B Budget t ( ( USBR 2 R 2012) )

 Project Acquisition $29.9M, 9.20%  Dam and Transmission Line Removal $26.9M, 8.30%  Water Quality Protection ( treatment plants) $106.6M,

32.80%

 Flood Protection (Levees) $23.3M, 7.20%  Fish hatchery $16.4M, 5.00%  Ecosystem Restoration $15.9M, 4.90%  Other contract and non-contract costs $106M, 32.60%

 Total Budget $325 Million 100%

Dam Removal Examples Continued

 Co

Condit D Dam m concrete gravity diversion located on the

White Salmon River in Washington. A 13-ft. high by 18- ft.wide drain tunnel was excavated in the toe of the dam for rapid release of the impounded water. Sediment removal was not required. Total cost of dam removal is reported to be $35 Million.

 Milltown

n Dam, M , Montana. The project includes removal

• f the 668 feet long dam and a 1.4 MW hydroelectric power
• plant. As part of the project 1600acre-ft. (2.6 million cubic

yards) of contaminated sediment is being removed and transported 90 miles by railroad for disposal in an existing ARCO tailings disposal facility. The project is estimated to cost $150 million at 2012 prices.

Prelim imin inary C Cost t Ranges s for r En Enloe D Dam Re Remo moval l

 The p

potential c cost o

• f removing Enloe Dam and

Reservoir is uncertain. The main cost risk appears to be the potential cost of removal and off-site disposal of up to 1500 acre-ft. (2.4 million cubic yards) of accumulated sediment.

 Preliminary removal costs include both direct (dam

and powerhouse removal, sediment removal etc.) and

indirect costs (Environmental studies and permitting,

monitoring etc.)

 Entrainment range in Millions $27 - $67  Full removal range in Millions $375 - $1053
