Profile Since 1993 Electrex designs, develops and produces, Made in - - PowerPoint PPT Presentation

Profile

Since 1993 Electrex designs, develops and produces, Made in Italy, instruments and software for energy monitoring and control, for both energy consumption and energy production systems. The Electrex solutions are used in the energy efficiency and energy automation applications for the industrial, commercial, public & residential buildings and renewable energy sectors allowing a rapid return on investment. Electrex, one of the first companies to develop energy meters, has acquired over the years a considerable experience and competences that few other companies can claim to have. With over 40% of the staff dedicated to R & D, we demonstrate our strong commitment to innovation and continuous improvement in order to anticipate the needs of our customers. We follow our products from design to after sale service and support, being a flexible and dynamic company. That is why Electrex continues to be chosen more and more from both local and international partners.

Vision & Mission

Electrex is focused in high-end, advanced energy management and automation solutions

In a current situation where there are multiple players offering basic devices we bring together expertise and solutions that can create value for our partners and give them the instruments to protect their margin. Our products can be used also as stand-alone devices but it is in the integrated solution where we see more added value and the possibility to offer also services that will differentiate our partner’s proposal. Our mission is to develop, best-in-class technology in energy management and automation to meet customer needs and challenges in profitable sectors. Innovation is the bedrock of our company’s growth. Our know- how and constant communication flow with our customers allows us to capture trends and develop niche markets. We seek opportunities were we can act as an OEM or provide customized solutions since Electrex is a technology driven company.

Industry 4.0 Smart buildings Digitization of systems

International partners and Sector experience

ITALY and WORLDWIDE AUSTRALIA - AUSTRIA - BELGIUM - CZECH REPUBLIC - DANMARK - EGYPT - GEORGIA GREAT BRITAIN - GREECE - GERMANY HUNGARY - INDIA - INDONESIA - IRAN IRELAND - KINGDOM OF SAUDI ARABIA LITHUANIA - MALAYSIA – PAKISTAN PANAMA - PHILIPPINES - POLAND PORTUGAL - ROMANIA - SINGAPORE SOUTH AFRICA - SOUTH KOREA - SPAIN THAILAND - THE NETHERLANDS - TUNISIA TURKEY - UNITED ARAB EMIRATES … Thousands of successful applications

• Airports
• Agriculture
• Hotels
• Food Industry
• Farms
• Banks
• Camping
• Leather industry
• Shopping malls
• Ceramic Industry
• Chemical industry
• Energy Utilities
• Construction industry
• Electronics
• Public organizations
• ESCO companies
• Railways
• Exhibition centers
• Foundries
• Wood industry
• Military and Defence
• Banks and insurance
• School buildings
• Automotive industry
• Naval industry
• Hospitals
• Plastics industry
• Renewable energy
• Refrigeration
• Server farms
• Telecoms sector
• Textile industry
• Cement industry
• Touristic resorts
• Tobacco industry
• etc.

Visit Application Examples section on our web site and discover further details on some of them.

400.000 devices installed worldwide

Trusted by worldwide premium companies

The following companies use Electrex solutions in their facilities:

Where to use Electrex’s products and solutions - 1

ENERGY EFFICIENCY Reducing consumption by optimizing the production, identifying waste, causes and raising users' awareness. In perspective of continuous improvement measuring to verify the results of interventions. ENERGY AUTOMATION Automate processes to better manage energy: power on / off, sending notifications and automation management based on calendars, on events occurrence or values ​detected by Electrex instruments. COST CENTER Quantify and manage energy as the other raw materials to improve its impact on the cost of the product and the service. Relating consumptions also to the effective operating time of a load / appliance using a single reference clock. REMOTE MANAGEMENT Simplify information management and remotely control systems reducing the time and cost of intervention.

Where to use Electrex’s products and solutions - 2

ANOMALIES CONTROL Improve the maintenance and support prevention to reduce inefficiencies and waste. ENERGY QUALITY MONITORING Monitor the quality of energy and identify the possible causes

• f malfunctions (interruptions, harmonic distortion, etc.).

ENVIRONMENTAL PARAMETERS AND PROCESS CONTROLLING Measure and manage the environmental parameters (temperature, lux, etc.) and process parameters (compressed air, calories, levels, etc.) related to energy consumption. RENEWABLE ENERGY Check the operation of the plant and the return on investment. Manage the energy produced in the most convenient way.

Our activities

• Measurement instruments for energy, environmental

and process parameters

• Instruments for Energy Automation, power

management / production and power quality

• Energy monitoring and remote management

systems

• Data displaying solutions on various platforms (PC,

tablet, smart-phone, display, etc.) with export and data integration option (EMS, SCADA, etc.).

• Web server, gateway, converters and interfaces

(Ethernet, Wireless, Serial, Bus, GSM, etc.)

• Energy data retrieving and management software
• Customized solutions and devices (OEM)
• Training and support on energy issues

Our expertise covers the following product areas:

Product line-up

Big / medium powers - High end Small powers I-O modules Sensors Gateway - Datalogger DC Loads Software Accessories Integrated solutions

Our solutions

The Electrex Monitoring solutions are the ideal solution for energy audits, continuous monitoring (e.g. ISO 50001) and for energy efficiency projects (e.g. EU-Directive 2012-27 and White Certificates or Energy Efficiency Certificates). The Electrex systems are modular and can expand over time thanks to the many possibilities of connecting the devices (Wi-Fi, RS485, E-Wi, ExpBus , Ethernet, NFC, Bluetooth LE, Wireless M Bus, Sub-Ghz), and of display and management of the data collected. With a single system, you can keep track of:

• all energy carriers (electricity, gas, water, etc.);
• environmental parameters related to them (temperature,

humidity, luminosity, CO2, etc.);

• of process parameters (compressed air , calories, level,

status, etc.);

• measure the operating time of a load / appliance using a

single reference clock;

• manage Energy Automation processes (automate the

management of ON/OFF switches, automatic adjustments, remote management, alarms and more); to achieve the main objective: to reduce energy costs by optimizing production. The Electrex solutions are: INTEGRATED including all the needed hardware & software for the monitoring activity SCALABLE AND MODULAR the system’s architecture allows to easily add more modules while the Ethernet backbone makes possible remote management and features upgrades MULTI-PARAMETER is not just for electric energy; through sensors and I-O modules we can integrate also other parameters (environmental, process, state, etc). ACTIVE through LADDER programming or I-O modules we can control and command relays

• r other modules

OPEN

• ur solutions can share and integrate data

with other systems (BMS, MES, etc) FLEXIBLE can be used in various sectors and easily customized to the needs of the user

E T H E R N E T B U S

• R

S 4 8 5

“Plug and Play” – “All in One” devices

Master/slave

RS485 port Ethernet

port

Internal modules I/O

• Digital
• Analog
• SI–Environmental

parameter sensors

• PT-NTC sensors

ENERGY MONITORING

Built-in

WEB interface FTP server High Speed

( CAN bus based )

ExpBus port

Built-in modules:

Wi-Fi, NFC, E-Wi, Bluetooth LE, Wireless M-Bus, Sub-Ghz Wi-Fi

external antenna

Accuracy Class 0.5S

EN 50470-1 EN 50470-3

POWER QUALITY ANALYSIS ENERGY AUTOMATION ALARMS AND E-MAIL NOTIFICATIONS CLOCK & CALENDARS OPERATING TIME COUNTERS

Built-in UPS

A single multi-purpose device for:

ENERGY MONITORING Meeting the most demanding applications of electrical energy monitoring (quantity and quality), other energy carriers (gas, water, compressed air, etc.), environmental and process parameters in the industry, commercial, residential, public buildings and renewable energy sectors. POWER QUALITY ANALYSIS Detection and logging of sags, swells, interruptions providing a graphical view of the single or total events registered on a time-line. Automatic classication of each event on the UNIPEDE table. Custom measurement campaigns of the harmonics and the main electrical parameters. ENERGY AUTOMATION Automation tasks programmable via the web interface running within the device for implementing complex Energy Automation functions for achieving higher energy efficiency results from any technological system. ALARMS AND E-MAIL NOTIFICATIONS This feature allows to manage simple alerts (power or PF threshold value monitoring, voltage value out of a predefined range) and more complex ones (implementing Energy Automation functions considering simultaneously more parameters like threshold values, I/O states, custom calendars) and the sending of e- mail notifications and local or remote commands for controlling I/O modules. CALENDARS This feature allows to define calendars for multiple applications, for e.g. for implementing tariffs and attribute to each work shift the specific amount of energy consumed. Together with the Energy Automation option can be used to setup automated tasks related to measurements and/or events detected or provided via the I/O module. OPERATING TIME COUNTERS For monitoring the operating time of a load/appliance and the relative amount of energy consumed. Up to 4 partial time counters are triggered every time the power consumption exceeds a certain threshold or from the ON/OFF state of an electrical contact via the inputs provided on the smart energy analyzer. The operating time counters allow to verify the effective working hours in the various modes and, for example, effectively program maintenance.

Built-in WEB interface

REAL TIME, ONLINE READINGS

Devices can be reached by any smartphone, tablet, PC

HISTORICAL, MULTIPERIOD GRAPHS Graphs can be customized and exported in CSv files

Built-in WEB interface – Power Quality

Graphical view of a single Power Quality event – trigger functionality TIME LINE GRAPH AUTOMATED EVENT CLASSIFICATION Power Quality (EN 50160 ed EN 61000-4-30)

Built-in WEB interface - Harmonics

Vector Diagram and Bar Graph

Vector diagram Tabel with filtering Current Harmonics Voltage Harmonics Phase Harmonics

Built-in WEB interface - Automation

Automated tasks editor – Built-in LADDER programming language Editor Customized web pages for data display and control of the devices Automation of tasks based

• n measurements, alarms,

calendars, I/O status, etc.

Libra series - Integrated Automation Panel

A “Plug & Play” solution with built-in advanced technology for the monitoring and management of:

• energy
• other utilities (water, compressed air, natural gas, steam, etc.)
• environmental parameters (temp., humidity, luminosity, etc.)

Integrated panel including:

• Ethernet and wireless communication
• RS485 port
• Digital/Analog I-O
• Sensor Inputs
• Built-in web interface , datalogger and gateway
• Power Quality, Harmonics and Energy Automation functions

Equipped with an internal UPS assuring a continuous power supply. Fast, low complexity and always-correct installation via polarized connectors. Expandable solution via Libra Expansion panels equipped with standard Electrex devices.

Snap-In Polarized Connectors

Libra

Libra

• ILL. 1,2,3

Libra

Software suite and Cloud platform

Data Analytics , reporting and sharing Beside the built-in web interface on the devices, the Electrex solutions use 2 external platforms. Each of them allow to automatically manage real-time and historical data, configure alarms and notifications, deliver custom reports

• PC based software: the Energy Brain

software integrates all the data coming from the devices in the field. The measurements are put into relation with each-other in order to detect trends and compare performances. It allows to refine the information applying data analytics and supports the user to understand system issues and therefore prioritize actions.

• Cloud platform: the cloud platform makes

possible to publish on the web clear, customized dashboard interfaces that help the user follow the components/systems most relevant to him.

Software suite

Energy Brain is a family of data acquisition, storage, and data management of electricity consumption data, other energy sources (gas, water, steam, etc.), various parameters (level of luminosity, compressed air, temperature, calories, etc.. ) and the management of Energy Automation features. Main functions:

• Configuration of Electrex devices and scheduler
• Standard and customizable graphs
• Formula editor for the calculation of cost of energy,

Baseline, EnPI (Energy Performance Indicator), KPI (Key Performance Indicators), etc.

• Editable TOU tariffs and Calendar
• Multi parameter real-time view
• Log of events related to software and instruments
• Validation / Editor of the data stored in the database
• Power Quality management (sags, swells, micro-

interruptions table)

• Import of external data (e.g. working hours, Baseline,

etc.) Energy Brain Personal Report: automates the sending of customized reports. It creates and automatically sends periodic reports (daily, weekly, monthly and yearly) based on the data collected in the Energy Brain’s database. Energy Brain Counters: for generating reports which contain the values ​of the energy counters of all, local or remote, instruments . Energy Brain Log Report: sends automatic e-mails containing specific reports on: the energy consumed/produced, thresholds exceeded, connection issues with the instruments.

Cloud platform

Energy Brain Cloud is the browser-based software that allows to view and manage live data, and historical charts with measures acquired by Electrex instruments from any PC, tablet, Smartphone. The cloud computing technology makes possible to manage the collected data via a standard Internet browser without installing any software on the user's computer or mobile device. It is composed of an instrument panel (dashboard) in which it is possible to manage several functions. The basic elements of the dashboard are graphical components called widgets. Through the widgets the user can display instantaneous and historical values as well as states (on / off), alarms, etc.. using standard or custom graphical interfaces.

Cloud platform - Widgets

There are three types of widgets: 1- Measure

The Measure widgets show instantaneous measurements, total counters, alarms, status (On/Off). It is possible to choose between three widget types: Gauge, Analog counter and Custom Background. The last one allows to upload a jpg, png and gif image and use it as the widget's background.

2 - Graphs

The Graph widgets display graphs with historical data retrived from the Electrex devices. All the data displayed on the graph are listed in a table positioned below the graph and can be exported in a CSV file.

3 - Scenario

In the Scenario widgets it is possible to upload an image (jpg, png and gif) and use it as a background on which are overlaid tooltips showing measurements from Electrex devices. The tooltips can be positioned just by "drag and drop" permitting to set up a mimic diagram.

Find more on our products

Products Documentation Case studies Technical Newsletters LinkedIn
