Product presentation EPSILON 9 The Joy of Flying It is nothing special to introduce a fmying-mad earthling to paragliding. What is special is to deliver the positive experiences and high feel-good factors of the sport that keep him there for

slide-1
SLIDE 1 Product presentation
slide-2
SLIDE 2

EPSILON 9 – The Joy of Flying

It is nothing special to introduce a fmying-mad earthling to paragliding. What is special is to deliver the positive experiences and high feel-good factors of the sport that keep him there for years – long after the licence. That’s exactly what our EPSILON series does ... The EPSILON 8 became well known for its balanced character, and quickly developed the sales fjgures and customer satisfaction that puts it among the most successful EPSILONs yet: not an easy task for our development team to top. But we are happy that they have done it with the EPSILON 9. Their performance boost and technical upgrades both work – better perfor- mance and even more precise handling. This latest generation of our Intermediate is characterised by its quiet ride through turbulent air. We are especially pleased that this has been achieved with no alteration in passive safety. You can fjnd the development background and all relevant information about the EPSILON 9 in this product presentation. 2 ADVANCE EPSILON 9 – The Joy of Flying
slide-3
SLIDE 3

comfortable performing convenient

Feeling good from the pull up

Nothing upsets the EPSILON 9: with pitch and directional stability it for- ges on through turbulent air. Steering demands are answered precisely, without delay. These features combined are responsible for its defjning fun and feel-good factor in the air, and as life-long partners of passive safety they share the credit for a long-lasting and uninterrupted enjoyment of fmight.

Latest techniques for good performance

Whether we consider the internalised Miniribs, latest Hybrid lining layout
  • r Low Drag Stabilos, the marked EPSILON 9 performance boost results
from intensive development work and subsequent technology upgrades. Needless to say the Intermediate also has all the expected state-of-the-art features like Sliced Diagonals, Advanced Airscoop and Double 3D Shaping.

Straightforward in every respect

Starting with wing size choice, then to line sorting, clipping in, big ears to speedbar: the EPSILON 9 is intuitive and simple to manage. The new Automatic Dust Remove even sweeps the wing interior for you while you are fmying! 3 ADVANCE EPSILON 9 – The Joy of Flying
slide-4
SLIDE 4

Compared with the EPSILON 8

Seamless Weight Ranges

+1

size

Performance Boost

Covered Dyneema base lines Automatic Dust Remover Internalised

Miniribs +2

cells Low Drag Stabilos

4 ADVANCE EPSILON 9 – The Joy of Flying
slide-5
SLIDE 5 5 ADVANCE EPSILON 9 – The Joy of Flying
slide-6
SLIDE 6 Miniribs Low Drag Stabilos

Technology Upgrade

The EPSILON 9 enjoys a comprehensive technology upgrade: Miniribs make a smooth trailing edge, Low Drag Stabilos reduce energy-sap- ping vortices. The design team took a lot of time over the miniribs: these are not only weight optimised, but their seams are sewn inside! Upper and lower training edge surface threads are no longer the victims of sticks, stones and thorns. 6 ADVANCE EPSILON 9 – The Joy of Flying
slide-7
SLIDE 7 Sliced Diagonals Double 3D-Shaping Airscoop Technology

State of the Art Technologies

Like its predecessor the EPSILON 9 Sliced Diagonals keep the canopy shape correct for years, double 3D-Shaping creates a smooth leading edge profjle. Airscoop Technology combined with the typical ADVANCE semi-circular air intakes also results in a signifjcantly lower fmow stagnation point, contributing to a later stall point with unmista- kable and progressive brake load increase as a warning. 7 ADVANCE EPSILON 9 – The Joy of Flying
slide-8
SLIDE 8

Hybrid Line array

Simple and easy-to-see sorting plus maximum performance: the EPSILON 9 has an intelligent line mix of covered Liros Dyneema base lines, with robust, uncover- ed Edelrid Aramid gallery lines. 8 ADVANCE EPSILON 9 – The Joy of Flying
slide-9
SLIDE 9

Automatic Dust Remover

As a fjrst for ADVANCE paraglider models the EPSILON 9 has a continuous all-cell channel along the trailing edge as an exit route for dust and
  • debris. By opening the wingtip exits now and again
dust and other debris can be brushed along and released to the outside world while in fmight. Open the Velcros before takeoff and pull out the fabric
  • ducting. The EPSILON 9 will do the rest.
9 ADVANCE EPSILON 9 – The Joy of Flying
slide-10
SLIDE 10

Riser Features

EPSILON 9 risers have all the features that make life easy for the pilot: plastic covered brake handle magnets for perfect hold, brake handle sizes that match the particular wing area, swivels to relieve brake line twists, brake pulleys for easy-running brakes and, of course, the Speed Performance Indicator. During fmight this shows a broad brush indication of the chosen accelerated speed related to the wing’s polar curve. This mainly simplifjes the choice of best speed to fmy relative to current headwind and sinking air, and initially helps the pilot to set up his harness speed lines to suit the EPSILON 9. Different Sizes Swivel Brake Pulley Speed Performance Indicator Magnet Magnet 10 ADVANCE EPSILON 9 – The Joy of Flying
slide-11
SLIDE 11

Tried and tested by the EPSILON 8

Like the EPSILON 8 the EPSILON 9 also has our EASY CONNECT System to help the pilot correc- tly connect the paraglider risers to the harness. Separate, easy-to-reach outer A-risers make big ears very straightforward. Our useful QUICK SNAP magnets connect this A-riser to it’s A neighbour for easy ground handling. They separate automatically under fmying loads during takeoff, and take up their normal fmying position. QUICK SNAP
  • pen
QUICK SNAP 11 ADVANCE EPSILON 9 – The Joy of Flying
slide-12
SLIDE 12

5 sizes with Seamless Weight Ranges

Should I choose the smaller or larger size? This question does not
  • ccur with the EPSILON 9. The new Seamless Weight Ranges provide a
continuous transition of fmying weight through the fjve wing sizes without overlap. Within these ideal all-up weight ranges the EPSILON 9 will provide an optimal balance of climb performance and fmying speed for all typical fmying conditions.

60 kg 70 80 90 100 110 120 130 kg 22 24 26 28 30 Certified takeoff weight Ideal weight range

60 kg 70 88 75 85 65 75 77 80 100 85 97 92 97 110 114 105 kg 110 125 128

12 ADVANCE EPSILON 9 – The Joy of Flying
slide-13
SLIDE 13

Paramotor Certification

The EPSILON 9 is eminently suited to paramotor fmying due to its exceptionally good takeoff behaviour, and high pitch and directional stability in fmight. DGAC paramotor certifjcation work for 24, 26, 28 and 30 sizes is currently underway. Paramotor risers with trims are available for the EPSILON 9 as an option. For free fmying (no motor) the trimmer loops can simply be fjxed in the main support carabiners. Trimmers stowed Trimmers in use 13 ADVANCE EPSILON 9 – The Joy of Flying
slide-14
SLIDE 14

Materials

Fabric

Leading edge Skytex 38, Universal 9017 E25 Upper surface Skytex 38 Universal 9017 E25 Lower surface Skytex Easyfmy 9018 E65 Supported ribs Skytex 40 hard fjnish 9017 E29 Unsupported ribs Skytex 40 hard fjnish 9017 E29

Lines: Liros/Edelrid

Main lines PPSLS 260 / 200 / 125: covered Suspension lines A-8000U-190 / 130 / 090 / 070 / 050: uncovered Brake lines A-8000U-090 / 070 / 050: uncovered Steering lines A-7850-240: covered A-8000U-190: uncovered 14 ADVANCE EPSILON 9 – The Joy of Flying
slide-15
SLIDE 15 15 ADVANCE EPSILON 9 – The Joy of Flying
slide-16
SLIDE 16 royal spectra aubergine acid

Colours

16 ADVANCE EPSILON 9 – The Joy of Flying
slide-17
SLIDE 17

EPSILON 9 22 24 26 28 30

m2 22.1 23.9 25.9 27.8 29.8 m2 18.5 20.0 21.7 23.3 25.0 kg 60–77 70–88 80 –100 92–114 105 –128 kg 65–75 75–85 85 –97 97–110 110–125 kg 4.15 4.40 4.65 4.95 5.25 m 10.73 11.15 11.61 12.03 12.45 m 8.26 8.59 8.94 9.26 9.59 5.2 5.2 5.2 5.2 5.2 3.68 3.68 3.68 3.68 3.68 m 2.59 2.69 2.8 2.9 3.0 47 47 47 47 47 3+1 3+1 3+1 3+1 3+1 EN /LTF B EN /LTF B EN /LTF B EN /LTF B EN /LTF B

Technical details

Flat surface Projected surface Certifjed takeoff weight Ideal weight range Glider weight Span Projected span Aspect ratio Projected aspect ratio
  • Max. chord
Number of cells Number of risers Certifjcation 17 ADVANCE EPSILON 9 – The Joy of Flying
slide-18
SLIDE 18 18 ADVANCE EPSILON 9 – The Joy of Flying
slide-19
SLIDE 19

The Joy of Flying

19 ADVANCE EPSILON 9 – The Joy of Flying
