Week 6 - Lecture Product Documentation ME 24-688 Introduction to CAD/CAE Tools Team Project Task 1 Submit conceptual sketch of side handle release design. Submit Project Task List ME 24-688 Introduction to CAD/CAE Tools Lecture

slide-1
SLIDE 1

ME 24-688 Introduction to CAD/CAE Tools

Week 6 - Lecture Product Documentation

slide-2
SLIDE 2

ME 24-688 Introduction to CAD/CAE Tools

Team Project – Task 1

  • Submit conceptual sketch of side handle

release design.

  • Submit Project Task List
slide-3
SLIDE 3

ME 24-688 Introduction to CAD/CAE Tools

Lecture Topics

  • Design Documentation Overview
  • Design for Manufacturing Overview
  • Design Documentation Future
slide-4
SLIDE 4

ME 24-688 Introduction to CAD/CAE Tools

Product Lifecycle – Week 6

Requirements Management Portfolio Management Conceptual Design Product Engineering Manufacturing Engineering Simulation & Validation Build & Produce Test & Quality Sales & Distribution Maintenance & Repair Disposal & Recycling

slide-5
SLIDE 5

ME 24-688 Introduction to CAD/CAE Tools

Design Documentation

  • Creation of digital and paper printed

documents for communicating product manufacturing and assembly information.

slide-6
SLIDE 6

ME 24-688 Introduction to CAD/CAE Tools

Documentation Types Examples

  • Component Detail Drawings
  • Assembly Drawings
  • Schematic Drawings
  • Layout Drawings
  • Process Drawings
  • Bill of Material Documents
slide-7
SLIDE 7

ME 24-688 Introduction to CAD/CAE Tools

Design Documentation Purpose

  • Contract for Manufacturing Agreement

– Provides formal documentation of the requirements of the form and fit of components from engineering to manufacturing.

  • Quality Control

– Provides the component tolerance, relationship, specification requirements of components to manufacturing.

  • Communication

– Used to communicate design elements outside of engineering and instructions for manufacturing and service related tasks.

slide-8
SLIDE 8

ME 24-688 Introduction to CAD/CAE Tools

Design for Manufacturing (DFM)

  • Design for Manufacturing is the process of

proactively developing products to:

– Optimize all the manufacturing functions – Assure the best cost, quality, reliability, time, and etc. – Ensure the lack of manufacturability doesn’t compromise functionality, styling, product delivery, and etc.

slide-9
SLIDE 9

ME 24-688 Introduction to CAD/CAE Tools

Items to Consider and Communicate

  • Material Type
  • Manufacturing Process
  • Tolerance Requirements
  • Finish & Treatment Requirements
  • Setup Required for

Manufacturing

slide-10
SLIDE 10

ME 24-688 Introduction to CAD/CAE Tools

Manufacturing Process Cost

Relative Cost

Rough Machining +/- 0.030” Standard Machining +/- 0.005” Fine Machining +/- 0.001” Honing +/- 0.0002” Grinding +/- 0.0005” 10 8 6 4 2

1.0 2X 3.5X 6X 10X

slide-11
SLIDE 11

ME 24-688 Introduction to CAD/CAE Tools

Quality Assurance

  • Design documentation is also used for

checking and inspecting the final manufactured components to validate design requirements.

slide-12
SLIDE 12

ME 24-688 Introduction to CAD/CAE Tools

Component Example

slide-13
SLIDE 13

ME 24-688 Introduction to CAD/CAE Tools

Component Example

slide-14
SLIDE 14

ME 24-688 Introduction to CAD/CAE Tools

Detailed Drawing

slide-15
SLIDE 15

ME 24-688 Introduction to CAD/CAE Tools

Dimensional Tolerance Chart

Decimal Precision Tolerance X +/- 0.8 mm X.X +/- 0.25 mm X.XX +/- 0.10 mm X.XXX +/- 0.015 mm Examples 10.0 = Min. 9.75 and Max. 10.25 10.00 = Min. 9.90 and Max. 10.10

slide-16
SLIDE 16

ME 24-688 Introduction to CAD/CAE Tools

Dimension Tolerance Example

slide-17
SLIDE 17

ME 24-688 Introduction to CAD/CAE Tools

Dimension Tolerance Example

slide-18
SLIDE 18

ME 24-688 Introduction to CAD/CAE Tools

Datum's and Relationships

slide-19
SLIDE 19

ME 24-688 Introduction to CAD/CAE Tools

Datum’s and Relationships

slide-20
SLIDE 20

ME 24-688 Introduction to CAD/CAE Tools

Tolerances

slide-21
SLIDE 21

ME 24-688 Introduction to CAD/CAE Tools

GD&T

  • Introduction to GD&T

– Feature Control Frame Symbols – ASME Y14.5M-1994 Geometric Dimension and Tolerancing (GD&T)

slide-22
SLIDE 22

ME 24-688 Introduction to CAD/CAE Tools

Modern Design Documentation

Several new technologies like the items listed below are being adopted today.

  • 3D Annotation (3DA)
  • 3D Assembly Instructions
  • Viewing and Markup (Mobile Access)
slide-23
SLIDE 23

ME 24-688 Introduction to CAD/CAE Tools

3D Annotation (3DA)

  • 3D Annotation is the method of adding all

required manufacturing annotations directly to the 3D model.

slide-24
SLIDE 24

ME 24-688 Introduction to CAD/CAE Tools

3D Assembly Instructions

  • Creating visual and interactive 3D technical

documentation directly from 3D models.

slide-25
SLIDE 25

ME 24-688 Introduction to CAD/CAE Tools

Mobile Viewing and Markup

  • Access, view, and markup your product

documentation on common mobile devices.

slide-26
SLIDE 26

ME 24-688 Introduction to CAD/CAE Tools

Computer-Cluster Projects (CP6)

slide-27
SLIDE 27

ME 24-688 Introduction to CAD/CAE Tools

Guided Lab Project 1

  • Guides instructions for creating drawing

views.

slide-28
SLIDE 28

ME 24-688 Introduction to CAD/CAE Tools

Guided Lab Project 2

  • Guided instructions for creating drawing

dimensions and annotations.

slide-29
SLIDE 29

ME 24-688 Introduction to CAD/CAE Tools

Guided Lab Project 3

  • Guided instructions for creating assembly

drawing with BOM and balloons.

slide-30
SLIDE 30

ME 24-688 Introduction to CAD/CAE Tools

Project Set Assignment

  • Create part drawing for manufacturing

molded plastic gear case.

slide-31
SLIDE 31

ME 24-688 Introduction to CAD/CAE Tools

Project Set Assignment

  • Create and exact replica of the Assembly

drawing.

slide-32
SLIDE 32

ME 24-688 Introduction to CAD/CAE Tools

Demo Topics

slide-33
SLIDE 33

ME 24-688 Introduction to CAD/CAE Tools

Bevel Gear Design Accelerator

  • Drawing Tab
  • Annotate Tab
slide-34
SLIDE 34

ME 24-688 Introduction to CAD/CAE Tools

Creating Base Views

  • Access

– Ribbon: Place Views tab > Create panel > Base – Marking Menu: Base View

slide-35
SLIDE 35

ME 24-688 Introduction to CAD/CAE Tools

Creating Projected Views

  • Access

– Ribbon: Place Views tab > Create panel > Projected – Marking Menu: Projected View

slide-36
SLIDE 36

ME 24-688 Introduction to CAD/CAE Tools

Creating Section Views

  • Access

– Ribbon: Place Views tab > Create panel > Section – Marking Menu: Section View

slide-37
SLIDE 37

ME 24-688 Introduction to CAD/CAE Tools

Creating Detail Views

  • Access

– Ribbon: Place Views tab > Create panel > Detail – Marking Menu: Section View

slide-38
SLIDE 38

ME 24-688 Introduction to CAD/CAE Tools

Creating General Dimensions

  • Access

– Ribbon: Annotate tab > Dimension panel > Dimension – Keyboard: D Marking Menu: General Dimension

slide-39
SLIDE 39

ME 24-688 Introduction to CAD/CAE Tools

Creating Ordinate Dimensions

  • Access

– Ribbon: Annotate tab > Dimension panel > Ordinate

slide-40
SLIDE 40

ME 24-688 Introduction to CAD/CAE Tools

Creating Hole and Thread Notes

  • Access

– Ribbon: Annotate tab > Features panel > Hole and Thread – Marking Menu: Hole / Thread Notes

slide-41
SLIDE 41

ME 24-688 Introduction to CAD/CAE Tools

Creating Centerlines

  • Access

– Ribbon: Annotate tab > Symbols panel > Centerline – Ribbon: Annotate tab > Symbols panel > Center Mark – Ribbon: Annotate tab > Symbols panel > Centerline Bisector

slide-42
SLIDE 42

ME 24-688 Introduction to CAD/CAE Tools

Documenting Views with Symbols

  • Access

– Ribbon: Annotate tab > Symbols panel

slide-43
SLIDE 43

ME 24-688 Introduction to CAD/CAE Tools

Adding Leaders and Text

  • Access

– Ribbon: Annotate tab > Text panel > Text – Ribbon: Annotate tab > Text panel > Leader Text

slide-44
SLIDE 44

ME 24-688 Introduction to CAD/CAE Tools

Adding Leaders and Text

  • Access

– Ribbon: Annotate tab > Text panel > Text – Ribbon: Annotate tab > Text panel > Leader Text

slide-45
SLIDE 45

ME 24-688 Introduction to CAD/CAE Tools

Bill of Materials

  • Access

– Ribbon: Assemble tab > Manage panel > Bill of Materials

slide-46
SLIDE 46

ME 24-688 Introduction to CAD/CAE Tools

Parts List

  • Access

– Ribbon: Annotate tab > Table panel > Parts List

slide-47
SLIDE 47

ME 24-688 Introduction to CAD/CAE Tools

Balloons

  • Access

– Ribbon: Annotate tab > Table panel > Balloon – Marking Menu: Balloon – Keyboard: B

slide-48
SLIDE 48

ME 24-688 Introduction to CAD/CAE Tools

Auto Balloons

  • Access

– Ribbon: Annotate tab > Table panel > Auto Balloon
