Probabilistic Palm Rejection Using Spatiotemporal Touch Features and Iterative Classification Julia Schwarz, Robert Xiao, Jennifer Mankoff, Scott E. Hudson, Chris Harrison ? ? ? ? pen palm palm palm Prior Software-Only Approaches

slide-1
SLIDE 1

Probabilistic Palm Rejection Using Spatiotemporal Touch Features and Iterative Classification

Julia Schwarz, Robert Xiao, Jennifer Mankoff, Scott E. Hudson, Chris Harrison

slide-2
SLIDE 2
slide-3
SLIDE 3
slide-4
SLIDE 4

? ? ? ?

slide-5
SLIDE 5

palm palm palm pen

slide-6
SLIDE 6

Prior Software-Only Approaches

slide-7
SLIDE 7

Ewerling et. al, ITS ‘12

slide-8
SLIDE 8

palm rejection region

slide-9
SLIDE 9

Vogel et al. CHI ‘09

slide-10
SLIDE 10

Penultimate for iOS Bamboo Paper for iOS

slide-11
SLIDE 11

Our Approach

Collection of decision trees, spatiotemporal features. Handedness and orientation agnostic. No calibration required.

slide-12
SLIDE 12
slide-13
SLIDE 13

green = stylus blue = palm Palms have large radius. Palms flicker in and out. Stylus is isolated. Palms move little, styluses have
 smooth trajectories.

slide-14
SLIDE 14
slide-15
SLIDE 15

t = 0

slide-16
SLIDE 16

Instantaneous Features Touch radius Distance to other touches on screen t = 0

slide-17
SLIDE 17

t = 0 t = 5ms t = 10ms

Touch Sequence Features [µ,σ, min, max] touch radius over sequence [µ,σ, min, max] distance to other touches in sequence [µ,σ, min, max] velocity, acceleration

slide-18
SLIDE 18

t = 0 t = 5ms t = 10ms t = -10ms

Touch Sequence Features [µ,σ, min, max] touch radius over sequence [µ,σ, min, max] distance to other touches in sequence [µ,σ, min, max] velocity, acceleration

slide-19
SLIDE 19

* leftmost point is at t = 1ms

train: 11,000 instances from 3 people test: 11,000 instances from 2 different people

train and test data gathered in different locations and on different days

slide-20
SLIDE 20

Window size of ~250ms would be ideal. Want to provide immediate feedback to the user.

slide-21
SLIDE 21

t 0ms 50ms 100ms …

  • 50ms
  • 100ms
slide-22
SLIDE 22

t 0ms = palm 50ms 100ms …

  • 50ms
  • 100ms
slide-23
SLIDE 23

t 0ms = palm 50ms 100ms …

  • 50ms
  • 100ms

= stylus

slide-24
SLIDE 24

t 0ms = palm 50ms 100ms …

  • 50ms
  • 100ms

= stylus = stylus

slide-25
SLIDE 25

t 0ms = palm 50ms 100ms …

  • 50ms
  • 100ms

= stylus = stylus

= stylus

final classification

slide-26
SLIDE 26

Demo

slide-27
SLIDE 27

Evaluation

Penultimate vs. vs. Bamboo Our App

slide-28
SLIDE 28

symbols:

slide-29
SLIDE 29

symbols: false negative

slide-30
SLIDE 30

% pen strokes classified as pen strokes

error bars = 95% confidence interval

slide-31
SLIDE 31

symbols: false positive

slide-32
SLIDE 32

palm accuracy

# of palm ‘splotches’ per pen stroke

*error bars = 95% confidence interval

slide-33
SLIDE 33

Takeaways

Waiting to see how sensed input evolves before making a decision improves recognition accuracy. Need a system that can show immediate feedback, but that can refine the interface as more information is presented.

slide-34
SLIDE 34

Thank you!

julia@qeexo.com Special thanks to Jim Baur for photography assistance

  • Also, thank you to our sponsors:
slide-35
SLIDE 35

Why a decision tree?

slide-36
SLIDE 36

Limitations

No multitouch gestures (yet) Algorithm overly reliant on touch radius Accuracy hit of 1% when not using radius features Difficult to implement on platforms that do not expose touch radius
