SLIDE 1
2
Announcements
Homework 2 due this Wednesday (Nov 4) in class Project milestones due next Monday (Nov 9)
About half the work should be done 4 pages of writeup, NIPS format http://nips.cc/PaperInformation/StyleFiles
Probabilistic Graphical Models Lecture 10 Undirected Models - - PowerPoint PPT Presentation
Probabilistic Graphical Models Lecture 10 Undirected Models - - PowerPoint PPT Presentation
Probabilistic Graphical Models Lecture 10 Undirected Models CS/CNS/EE 155 Andreas Krause Announcements Homework 2 due this Wednesday (Nov 4) in class Project milestones due next Monday (Nov 9) About half the work should be done 4 pages
SLIDE 2
SLIDE 3
3
Markov Networks
(a.k.a., Markov Random Field, Gibbs Distribution, …) A Markov Network consists of
An undirected graph, where each node represents a RV A collection of factors defined over cliques in the graph
Joint probability A distribution factorizes over undirected graph G if
X1 X2 X4 X5 X7 X8 X6 X3 X9
SLIDE 4
4
Computing Joint Probabilities
Computing joint probabilities in BNs Computing joint probabilities in Markov Nets
SLIDE 5
5
Local Markov Assumption for MN
The Markov Blanket MB(X)
- f a node X is the set of
neighbors of X Local Markov Assumption: X EverythingElse | MB(X) Iloc(G) = set of all local independences G is called an I-map of distribution P if Iloc(G) I(P) X1 X2 X4 X5 X7 X8 X6 X3 X9
SLIDE 6
6
Factorization Theorem for Markov Nets “”
- Iloc(G) I(P)
G is an I-map of P (independence map) True distribution P can be represented exactly as a Markov net (G,P)
SLIDE 7
7
Factorization Theorem for Markov Nets “” Hammersley-Clifford Theorem
- Iloc(G) I(P)
True distribution P can be represented exactly as G is an I-map of P (independence map) and P>0 i.e., P can be represented as a Markov net (G,P)
SLIDE 8
8
Global independencies
A trail X—X1—…—Xm—Y is called active for evidence E, if none of X1,…,Xm E Variables X and Y are called separated by E if there is no active trail for E connecting X, Y Write sep(X,Y | E) I(G) = {X Y | E: sep(X,Y|E)} X1 X2 X4 X5 X7 X8 X6 X3 X9
SLIDE 9
9
Soundness of separation
Know: For positive distributions P>0 Iloc(G) I(P) P factorizes over G Theorem: Soundness of separation For positive distributions P>0
Iloc(G) I(P) I(G) I(P)
Hence, separation captures only true independences How about I(G) = I(P)?
SLIDE 10
10
Completeness of separation
Theorem: Completeness of separation
I(G) = I(P)
for “almost all” distributions P that factorize over G “almost all”: Except for of potential parameterizations
- f measure 0 (assuming no finite set have positive
measure)
SLIDE 11
11
Minimal I-maps
For BNs: Minimal I-map not unique For MNs: For positive P, minimal I-map is unique!! E B A J M E B A J M J M A E B
SLIDE 12
12
P-maps
Do P-maps always exist? For BNs: no How about Markov Nets?
SLIDE 13
13
Exact inference in MNs
Variable elimination and junction tree inference work exactly the same way!
Need to construct junction trees by obtaining chordal graph through triangulation
SLIDE 14
14
Pairwise MNs
A pairwise MN is a MN where all factors are defined
- ver single variables or pairs of variables
Can reduce any MN to pairwise MN! X1 X2 X4 X5 X3
SLIDE 15
15
Logarithmic representation
Can represent any positive distribution in log domain
SLIDE 16
16
Log-linear models
Feature functions φi(D) defined over cliques Log linear model over undirected graph G
Feature functions φ1(D1),…,φk(Dk) Domains Di can overlap Set of weights wi learnt from data
SLIDE 17
17
Converting BNs to MNs
Theorem: Moralized Bayes net is minimal Markov I-map
C D I G S L J H
SLIDE 18
18
Converting MNs to BNs
Theorem: Minimal Bayes I-map for MN must be chordal X1 X2 X7 X8 X6 X3 X9
SLIDE 19
19
So far
Markov Network Representation
Local/Global Markov assumptions; Separation Soundness and completeness of separation
Markov Network Inference
Variable elimination and Junction Tree inference work exactly as in Bayes Nets
How about Learning Markov Nets?
SLIDE 20
20
Parameter Learning for Bayes nets
SLIDE 21
21
Algorithm for BN MLE
SLIDE 22
22
MLE for Markov Nets
Log likelihood of the data
SLIDE 23
23
Log-likelihood doesn’t decompose
Log likelihood l(D | θ) is concave function! Log Partition function log Z(θ) doesn’t decompose
SLIDE 24
24
Derivative of log-likelihood
SLIDE 25
25
Derivative of log-likelihood
SLIDE 26
26
Computing the derivative
Derivative Computing P(ci | ) requires inference! Can optimize using conjugate gradient etc.
C
D
I
G S L J H
SLIDE 27
27
Alternative approach: Iterative Proportional Fitting (IPF)
At optimum, it must hold that Solve fixed point equation Must recompute parameters every iteration
SLIDE 28
28
Parameter learning for log-linear models
Feature functions (Ci) defined over cliques Log linear model over undirected graph G
Feature functions 1(C1),…,k(Ck) Domains Ci can overlap
Joint distribution How do we get weights wi?
SLIDE 29
29
Derivative of Log-likelihood 1
SLIDE 30
30
Derivative of Log-likelihood 2
SLIDE 31
31
Optimizing parameters
Gradient of log-likelihood Thus, w is MLE
SLIDE 32
32
Regularization of parameters
Put prior on parameters w
SLIDE 33
33
Summary: Parameter learning in MN
MLE in BN is easy (score decomposes) MLE in MN requires inference (score doesn’t decompose) Can optimize using gradient ascent or IPF
SLIDE 34
34
