PRESENTS

GENERAL INDEX

1 COMPANY 2 PRODUCTS 3 TEGOLA CANADESE ROOF SYSTEM 4 REASONS TO CHOOSE TEGOLA CANADESE 5 SERVICES & GUARANTEES 6 CERTIFICATIONS

TEGOLA CANADESE: THE HISTORY

Location: Vittorio Veneto - Italy From 1976 45.000 m2 of surface More than 8.250.000 m2

• f bituminous shingles

produced yearly European leader and one of the largest worldwide producer Present in 70 countries worldwide (Click on the photo above)

TEGOLA CANADESE MARKET SHARES

Our quality is recognized by the market share

Tegola Canadese 43% Other Manufacturers (All together) 57%

TEGOLA CANADESE SPECIALIST IN THE ROOF SYSTEM

Bituminous shingles (11 models, 58 colours ) Ventilated roof Accessories and components Vapour treatment Roof windows

BITUMINOUS SHINGLES: THE HISTORY

In North America they have been used for over 150 years; In Europe they have been used for over 40 years; At present they are produced in 9 European countries. The bituminous shingles, today, with an average annual use of 1.200.000.000 m2 represent absolutely the most used roofing system in the world.

COMPOSITIONS OF TEGOLA CANADESE

Master • Traditional • Standard • Liberty

Ceramic granules Oxidized Tia-juana bitumen 125 g/m2 pre-soaked fiberglass Oxidized Tia-juana bitumen Siliceous sand

COMPOSITIONS OF TEGOLA CANADESE

Mosaik • Gothik

Ceramic granules Oxidized Tia-juana bitumen 100 g/m2 pre-soaked fiberglass SBS Modified bitumen Siliceous sand Polymeric film

THE COMPONENTS: THE ROOF DECK STRUCTURE

The fiberglass, of the “heavy” type, is pre-impregnated and enclosed in two bitumen layers. The shingles with the “heavy” fiberglass result dimensionally stable, even at high temperature fluctuations.

NATURAL BITUMENS “TIA - JUANA”

COMPARED BITUMENS REACTIONS TO EVERYDAY TEMPERATURE FLUCTUATIONS

Uv cycles (time) Day Day Night Time Legend High waterproofing capacity Exceptional resistance to UV rays High stability regardless of the daily Temperature fluctuations Guarantee for a long lasting Tegola Canadese roof Thermal fluctuations Ageing Index “Tia-juana” bitumens used by Tegola Canadese Compared bitumens

THE GRANULES

Basalt stone: the stone of exceptional strength Protection against UV rays Coloured through a ceramic process at high temperature with inorganic pigments Colour resistance during the years

PRESTIGE, THE COPPER SHINGLES

Prestige Elite • Prestige Compact

Adhesive strip Copper foil 99,7% Tia-Juana HP bitumen Fiberglass Low density filler Fiberglass Oxidized Tia-Juana bitumen Polypropylene film

PRESTIGE, THE COPPER SHINGLES

99.7% pure copper foil 70 micron thick. During the years, copper gains the typical self-protective green patina. Effective thermo adhesive points guarantee resistance to the wind. The thermo adhesive points are distributed so that they are not visible

• n the finished roof.

COPPER: THE VALUE OF TIME

The use of copper started around 2.500 b.c. and was a symbol of wealth. Already at that time, this metal was used as roofing material. During the years it still guarantees safety, long life span, resistance and uncomparable beauty.

ZT Elite • ZT Compact

Adhesive strip Zinc-Titaniumr foil Tia-Juana HP bitumen Fiberglass Low density filler Fiberglass Oxidized Tia-Juana bitumen Polypropylene film

ZT, THE NEW ZINC TITANIUM SHINGLE

ZINC TITANIUM: EVOLUTION DURING THE TIME

During the years it still guarantees safety, long life span, resistance and uncomparable beauty.

ZT Compact ZT Elite

THE WIDEST RANGE OF ROOF SOLUTIONS

Prestige Compact Prestige Elite Prestige Traditional Standard Liberty Master Traditional Gothik Mosaik ZT Elite ZT Compact

ZT COMPACT

ZT Elite

PRESTIGE ELITE

Copper

Copper: the value of time

Intermediate phase Copper with the “patina” 100 14.5 34

PRESTIGE ELITE

PRESTIGE COMPACT

A great format for a great architecture

Copper Intermediate phase Copper with the “patina” 100 34 29

PRESTIGE COMPACT

PRESTIGE TRADITIONAL

34

The shape inspired by the tradition

Copper Intermediate phase Copper with the “patina” 100 14.5

PRESTIGE TRADITIONAL

MASTER

A pleasant effect relief

100

33.7 14.3

153 Light Slate 151 Dark Slate 180 Blue 104 Terracotta 174 Stone Grey 129 Wood Shake 167 Ancient Stone 156 Stone Green

COLOURS AVAILABLE

GOTHIK

230 2-tone Brown 280 2-tone Blue 254 2-tone Grey 251 2-tone Black 203 2-tone Red 274 2-tone Green 100 33.7 14.3

The irregular geometric shape

COLOURS AVAILABLE

LIBERTY

34

Innovative shapes for the roof

100 14.5 COLOURS AVAILABLE 004 Europ Red 051 2-tone Black

TRADITIONAL

34 010 2 tone Red 006 Brick Red 066 Slate Grey 073 2 tone Green 023 2 tone Brown 008 Krakow

The shape inspired by the tradition

100 14.5 COLOURS AVAILABLE

MOSAIK

A precious mosaik effect

061 2 tone Grey 060 Black 070 2 tone Green 010 2 tone Red 020 2 tone Brown COLOURS AVAILABLE 33.7 100 14.3

STANDARD

A broad colour palette

COLOURS AVAILABLE 34 100 14.5

002 2 tone Red 070 2 tone Green 051 2 tone Black 004 Europe Red 050 dark Grey 053 Light Grey 061 Slate Grey 020 2 tone Brown 080 Blue 001 Red 060 Black 021 Dark Brown 003 Spanish Red

FIXINGS INSECT NET AND CLIPS BAR LINE VENTILATORS AND SNOW STOPS “PRESTIGE” ACCESSORIES ZENITH WATERPROOFING MEMBRANES BITUMINOUS ADHESIVES ROOF DECKS

A “ROOF SYSTEM” RICH IN ACCESSORIES AND COMPONENTS

ROOF DECK: BITUMINOUS MEMBRANE

System used for the installation of Tegola Canadese shingles on decks where it is not possible to nail. Membrane with app modified bitumen.

THE MINIMUM SLOPES

Tegola Canadese is a roofing system with “small elements” which make the roof waterproof due to their overlapping. The “system” requires a minimum slope.

REASONS TO CHOOSE TEGOLA CANADESE: THE COMPARED ADVANTAGES

• Wide range of shapes and colours
• All climates use product
• With Tegola Canadese is possible

to cover with success any kind and any shape of roof

• Unchanging colour over the years
• Tegola Canadese shingle is light
• Maintenance free
• No special accessories required
• Practical packing
• Usable slopes

WIDE RANGE OF SHAPES AND COLOURS

among which to choose the most suitable roofing for your project.

11 models 58 colours

ALL CLIMATES USE PRODUCT

Does not fear cold ( test at -70°C ) Does not fear heat ( test at +90°C ) Does not fear the wind Resists impact with hail Resists pollution Resists sudden temperature fluctuations Resists strong rains, does not need under shingle systems

UNCHANGING COLOUR OVER THE YEARS

Basalt granules Coloration process with ceramization at a temperature over 650°C. Inorganic pigments Long lasting guarantee even for difficult colours.

TEGOLA CANADESE SHINGLES ARE LIGHT

Reduction of the deck structure dimensions. Less weight = less loads = more safety.

FOLLOWING ADVANTAGES OF A TEGOLA CANADESE ROOF:

Weight of a 300 m2 house roof

Tegola Canadese

18

Tons

plain roofing tiles (cement)

21

Tons

cement tile

24

Tons

clay tile

30

Tons

natural stone

MAINTENANCE FREE

Walkable roof Easy to inspect The shingles do not slide down Resistant to fire ( class I ) according to the Italian Standard Resistant to ice / frost

NO SPECIAL ACCESSORIES REQUIRED

PRACTICAL PACKING

1 pallet contains 158.6 m2 of roof. No damages during transportation. Easy to transport and to stock.

OTHER ADVANTAGES

Does not create condensation. Rust cannot attack it. Silent when raining or windy. Tegola Canadese roofing is made of small elements which absorb easily the structure movements. COMPARED TO MEMBRANE ROOFS It is a discontinuous roof, it allows the passage

• f vapour.

COMPARED TO METALLIC ROOFS

Natural stone Clay and plain roof tiles Cement tiles Tegola Canadese

USABLE SLOPES

OFFERED SERVICES

• Assistance to the designer
• Guarantee
• Guarantee for the designer
• Opportunity on Tegola Canadese web site
• On line service for the designer
• Logistic service

GUARANTEES

GUARANTEE

Tegola Canadese S.p.A. guarantees all the roofs realised with its own shingles for 10 years from the installation completion. The guarantee covers the damages related to the defects of the product, on condition that the product has been used according to the installation norms. The guarantee includes all the defects that compromise the waterproofing of the roof or that effect the beauty of the roof.

“www.tegolacanadese.com”

LOGISTIC SERVICE

All models and colours with immediate availability. Stocks in 70 countries worldwide. Transportation everywhere in the world. Installation service worldwide.

TEGOLA CANADESE IS A CERTIFIED COMPANY

Quality insurance system that controls the various company's activities starting from research and development to sales/distribution and installation of the product on the roof.

TEGOLA CANADESE RECOGNISES ITS OWN QUALITY

Tegola Canadese quality insurance system is able to identify each production lot thanks to the codified mark on each shingle bundle on the job site. Tegola Canadese S.p.A. in its electronic archive has registered the data of its production in the last 10 years.

99999

TEGOLA CANADESE S.p.A. IS A CERTIFIED COMPANY

The respect and the protection of the environment is an important value for Tegola Canadese.

ISO 14001

WHAT DOES ISO 14001 GUARANTEE

No pollution of the waters. Absence of harmful radiation in the atmosphere. Correct handling of the wastes. Use of raw materials harmless to human beings. Correct use of the natural energy resources.

EUROPEAN NORM EN 544

Legally applied since 1999. Minimum quality levels fixed Tegola Canadese products are above the norm Fiberglass weight 110 gr/m2 125 gr/m2 Mechanical resistance 600 N/5cm 900 N/5cm Nails resistance 100 N 150 N Slide (at 90°C) < 2 mm 0 mm MAIN PARAMETERS EN544 TEGOLA CANADESE

THANK YOU FOR YOUR ATTENTION
