Preliminary Data Hurricane Katrina Canal Breachings, 17 th Street, London Avenue and Industrial Canal Dr. Ivor van Heerden Director Center for the Study of Public Health Impacts of Hurricanes, Deputy Director LSU Hurricane Center

slide-1
SLIDE 1

Preliminary Data – Hurricane Katrina Canal Breachings, 17th Street, London Avenue and Industrial Canal

  • Dr. Ivor van Heerden

Director Center for the Study of Public Health Impacts of Hurricanes, Deputy Director LSU Hurricane Center Louisiana State University

slide-2
SLIDE 2

Advisory 18, Submitted Saturday 2200

“New Orleans Will Flood”

slide-3
SLIDE 3

10 M SPOT Satellite Image: 2 Sept 2005

DeWitt Braud and Rob Cunningham

slide-4
SLIDE 4

10 M SPOT Satellite Image: 2 Sept 2005 With Water depth overlays – Orleans East

Flood elevation: +1ft NAVD 88 2 Sept 2005

DeWitt Braud and Rob Cunningham

Industrial Canal Overwash Levee Degradation Levee Degradation Levee Overtopping

slide-5
SLIDE 5
slide-6
SLIDE 6

Scour Trench from Overtopping for 3 hours

slide-7
SLIDE 7

10 M SPOT Satellite Image: 2 Sept 2005 With Water depth overlays

17th Street canal break

Flood elevation: +3ft NAVD 88

DeWitt Braud and Rob Cunningham

London Ave Canal Breaks Industrial Canal Overwash

slide-8
SLIDE 8

General Levee Construction Preliminary Data

slide-9
SLIDE 9

Hurricane Katrina Surge at the Industrial Canal & Lake at the 17th Street Canal IC-Peak at 0830 AM; Lake Peak 0900 AM 2 4 6 8 10 12 14 16 8/29/05 0:00 8/29/05 6:00 8/29/05 12:00 8/29/05 18:00 8/30/05 0:00 Date & Time (CDT) Surge (ft)

  • Ind. Canal N216818

Lake @ 17th Canal N206324

17th Street Canal Breach

slide-10
SLIDE 10

17th Street Canal – Note displaced levee section in middle of the breach, which moved 35 feet

slide-11
SLIDE 11

08/30/05

slide-12
SLIDE 12
slide-13
SLIDE 13

Earth berm and fence moved 35 feet laterally (heave) by water pressure 17th Street Wood and organic matter

slide-14
SLIDE 14

17th Street Canal -‘Heaved’ yard behind levee wall that moved 35 feet laterally

slide-15
SLIDE 15

Old swamp cyprus stumps exposed by scour

slide-16
SLIDE 16
slide-17
SLIDE 17

17th Street Breach – Preliminary Data

slide-18
SLIDE 18

17th Street Canal - Aerial Sketch Preliminary Data

slide-19
SLIDE 19

London Ave Canal – Filmore Breach

slide-20
SLIDE 20

Clubhouse (as built) at base of levee soil embankment - London Ave Canal west

  • breach. Note pine tree location on left.

Daniel Cantrell

slide-21
SLIDE 21

Club house and pine tree after heave – London Ave Canal west breach, rose 6-8 feet! Daniel Cantrell

slide-22
SLIDE 22

London Ave Canal bowed wall segments near Filmore Road, east side of canal

slide-23
SLIDE 23

London Ave Canal – Large ‘sand boil’ at base of levee soil embankment, east side

slide-24
SLIDE 24

London Ave Canal – Heaves In yard, tilted flower bed and buildings, east side.

slide-25
SLIDE 25

London Ave - Filmore Breach – Preliminary Data

slide-26
SLIDE 26

Mirabeau Break on London Ave.

LOTS OF SAND!

slide-27
SLIDE 27
slide-28
SLIDE 28

Blowout hole?

slide-29
SLIDE 29

Mirabeau Breach – Blowout Preliminary Data

slide-30
SLIDE 30

Hurricane Katrina Surge at the Industrial Canal & Lake at the 17th Street Canal IC-Peak at 0830 AM; Lake Peak 0900 AM 2 4 6 8 10 12 14 16 8/29/05 0:00 8/29/05 6:00 8/29/05 12:00 8/29/05 18:00 8/30/05 0:00 Date & Time (CDT) Surge (ft)

  • Ind. Canal N216818

Lake @ 17th Canal N206324

Industrial Canal Breachings

slide-31
SLIDE 31

4 Sept 2005

slide-32
SLIDE 32

Levee Failure on East Side of Industrial Canal

slide-33
SLIDE 33

15 Sept 2005

slide-34
SLIDE 34
slide-35
SLIDE 35

Scour Trench from

  • vertopping of levee
slide-36
SLIDE 36
slide-37
SLIDE 37

Paint from barge?

slide-38
SLIDE 38

Note: ‘R’ bars bent horizontal while wall at 45 degree angle – barge bottom move across after wall collapsed?

slide-39
SLIDE 39

Curved wall – why? Scour Trench Embankment failure

slide-40
SLIDE 40

Levee wall tilted back. Cracks and soil failure in front of wall and development

  • f downward percolation holes
slide-41
SLIDE 41

Cyprus tree stump from Old swamp floor

slide-42
SLIDE 42

Industrial Canal Levee failure – preliminary data

slide-43
SLIDE 43

Escape Hole Over 1000 Louisianan’s perished from the Katrina floods Approximately 100,000 Families are now homeless, most of whom heeded evacuation orders. They believed in the security of the levee systems. What happens to them?
