Preclinical Studies in VCP Disease Using Mouse Models

Virginia Kimonis, MD., MRCP Professor, Dept. of Pediatrics, Division of Genetics and Genomic Medicine

• Univ. of California, Irvine

vkimonis@uci.edu ENMC Conference Heemskerk, The Netherlands

Animal Models of VCP mutations

• Deinhardt et al 2004, Mol Neuropath Lab, Cancer Research, UK

– No homozygous p97-/- pups - early embryonic lethal – Heterozygous KO mouse normal size and fertility with normal p97/VCP expression

• Weihl C et al. Hum Mol Genet. 2007

– Transgenic mice expressing p97/VCP-WT or the most common IBMPFD mutant, p97/VCP R155H, under a muscle specific promoter – R155H developed age dependant muscle weakness starting at 6 mo, abnormal muscle architecture, autophagocytic vacuoles, and Ub containing protein inclusions.

Transgenic expression of inclusion body myopathy associated mutant p97/VCP causes weakness and ubiquitinated protein inclusions in mice Weihl C, Miller SE, Hanson PI, Pestronk A.

Diaphragm muscle from (A, D, F) TgVCP-WT or (B, C, E, G, H) TgVCP-RH (B, I, J) at 6 months, (C–E) 10 months or (F and G) 12 months of age (H) Congo red in the sarcoplasm and myonuclei

• f 15-month-old TgVCP-RH12 animal skeletal
• muscle. Panels I and J are quadriceps skeletal

muscle from 6-month-old TgVCP-WT (I) and TgVCP-RH animals immunostained for ubiquitinated proteins with FK2 antibody. Dual immunofluorescence of 3-month-old quadriceps muscle from (B) control, (C) TgVCP- WT and (D) TgVCP-RH animals using anti- p97/VCP (red) and anti-collagen IV (green) antibodies showing increase in sarcolemma VCP

Custer S, Neumann M, Lu H, Wright A and Taylor J. Transgenic mice expressing mutant forms VCP/p97 recapitulate the full spectrum of IBMPFD including degeneration in muscle, brain and bone. Hum Mol Genet. 2010 May 1;19(9):1741-55.

9 mo mice- centralized nuclei irregular fiber size and inflammatory infiltrates (arrows).

Custer S et al. 2010

Marked degeneration of the normal sarcomeric structure in both VCP-R155H and VCP-A232E muscle, and also the accumulation of degenerated mitochondria

Giles Watts &Kimonis designed Knock-in mouse model for IBMPFD.

I KI

Badadani M, Nalbandian A, Watts GD, Vesa J, Kitazawa M, Su H, Tanaja J, Dec E, Wallace DC, Mukherjee J, Caiozzo V, Warman M, Kimonis VE. VCP Associated Inclusion Body Myopathy and Paget Disease of Bone Knock-In Mouse Model Exhibits Tissue Pathology Typical of Human Disease. 2010. PLoS ONE 5(10). Nalbandian A, Llewellyn KJ, Badadani M, Yin HZ, Nguyen C, Katheria V, Watts G, Mukherjee J, Vesa J, Caiozzo V, Mozaffar T, Weiss JH and Kimonis VE. A Progressive Translational Mouse Model of Human VCP Disease: The VCP R155H/+

• Mouse. Muscle Nerve. 2012 Jul 12.

Progression of muscle weakness in knock-in Neo+ R155H mice.

Grip Strength Rotarod testing

Histological analysis of the VCPR155H/+ mouse quadriceps muscles.

Bone micro CT imaging, histology and giant osteoclast formation of VCPR155H/+ and wild-type mice.

Histological analyses of spinal cord ventral horn astrocytes in 15 mo. WT and Het. VCP R155H mouse demonstrates neuronal atrophy and astrocyte proliferation

Yin HZ, Nalbandian A, Hsu C-I, Li S, Llewellyn K, Mozaffar T, Kimonis VE, Weiss J. A mutant valosin-containing protein (VCP) gene knockin mouse model of ALS .Cell Death Dis. 2012.

THE HOMOZYGOTE VCPR155H/R155H MOUSE MODEL EXHIBITS ACCELERATED HUMAN VCP- ASSOCIATED DISEASE PATHOLOGY

Nalbandian A, et a

• al. (2012) The Homozygote

VCP(R155H/R155H) Mouse Model Exhibits Accelerated Human VCP-Associated Disease Pathology. PLoS

• S O

ONE 7(9):e46308.

Survival Curve of Homozygote VCPR155H/R155H VCP IBMPFD Mouse Model. Animals do not survive after 21 days

Phenotype and histological analyses of the VCPR155H/R155H homozygote knock-in mice

MicroCT and hind limb bone imaging in VCPR155H/R155H and WT mice.

Summary of findings in Neo- Heterozygote & Homozygote R155H VCP KI mice

Heterozygotes

• The 15- and 24-mo mice have muscle weakness
• Muscle :variation in fiber size, centrally located nuclei and rare

vacuoles.

• Muscle and brain: cytoplasmic accumulation of TDP-43,

ubiquitin-positive inclusion bodies and increased autophagocytic activity.

• Spinal cords neurodegenerative changes and TDP-43

pathology of the motor neurons cells. EMG-ALS like

• MicroCT and bone histology: Paget-like lesions

Homozygotes

• Lethality 21 days
• Muscle and brain pathology
• Useful model also for myopathy, ALS, and PDB

Translational Studies with the R155H mouse

Nalbandian A, Nguyen C, Katheria V, Llewellyn KJ, Badadani M, Caiozzo V, Kimonis VE. Exercise Training Reverses Skeletal Muscle Atrophy in an Experimental Model of VCP Disease. PLoS One. 2013 Oct 9;8(10) WT mice.

Weights, muscle strength measurements and histological analyses of sedentary and exercised VCPR155H/+ and

M M 700 1000 200

Recombination 550bp No recombination 2000bp

VCP

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17

a

6 3 2 6 3 2 5 4 Exon 6 Exon 3 Exon 2 Exon 5 Exon 4

R155H LoxP LoxP

b c

500

Targeted Excision of VCP R155H mutation by Cre- LoxP Technology as a Promising Therapeutic Strategy for Inclusion Body Myopathy

Nalbandian A, Llewellyn K, Nguyen C, Monuki E, Kimonis V. Hum Gene Ther

• Methods. 2014 Dec 29.

Wild Type VCP R155H/+

c

Tamoxifen Corn Oil

b

* *

Wild Type CRE-ERTM-VCP

R155H/+

a

100 µM

Targeted Excision of VCP R155H mutation by Cre-LoxP Technology improves myopathy

VALOSIN CONTAINING PROTEIN

Membrane Fusion

(NSFL1C)

Nuclear Envelope Reconstruction Ubiquitin Dependent Protein Degradation Endoplasmic Reticulum Associated Degradation Transcription Activation Cell Cycle Control Apoptosis

Autophagy

B

MUT1

Nalbandian A, Llewellyn KJ, Nguyen C, Yazdi PG Kimonis VE. Rapamycin and Chloroquine: the in vitro and in vivo effects of autophagy-modifying drugs show unexpected results in valosin containing protein multisystem proteinopathy. PLoS One. 2015 Apr 17;10(4)

Rapamycin and Chloroquine: the in in v vit itro and in in v viv ivo effects of autophagy-modifying drugs show unexpected results in valosin containing protein multisystem proteinopathy

Rapamycin-induced autophagy aggravates pathology and weakness in a mouse model of VCP-associated myopathy. Ching JK, Weihl CC. Autophagy. 2013 May; 9(5):799-800.

• Mice treated every other day for 21 days
• Mice developed weakness, increase CPK,

increase in vacuolated and atrophic fibers

• Inhibition of mTOR with rapamycin resulting in

autophagosome biogenesis worsens muscle degeneration

Llewellyn KJ, Nalbandian A, Jung KM, Nguyen C, Avanesian A, Mozaffar T, Piomelli D, Kimonis VE. Lipid-enriched diet slows down progression in a murine model of VCP-associated

• disease. Hum Mol Genet. 2013 Oct 24.

Survival curve for the untreated and treated homozygous VCPR155H/R155H IBMPFD mouse model. VCPR155H/R155H animals fed an increased fat diet several survive >3 months

6 % Diet 9 % Diet

Fatty acids Percentage difference 2020x (normal) VS 2019 (higher-fat) diet C16:0 Palmitic 0.3% increase C18:0 Stearic 0.1% increase C18:1ω9 Oleic 0.6% increase C18:2ω6 Linoleic 1.3% increase C18:3ω3 Linolenic 0.1% increase Total saturated 0.4% increase Total monounsaturated 0.6% increase Total polysaturated 1.5% increase Amino Acids Phenylalanine 0.1% increase Isoleucine 0.1% increase Proline 0.1% decrease

A Wild Type VCPR155H/R155H B C 3 weeks ND 3 weeks LED 4 months LED 9 months LED D E F G

200μm

Measurements, and histological analyses of WT and VCPR155H/R155H mice on normal and HFDs.

Lipid analyses of quadriceps and livers from VCPR155H/R155H and WT animals on normal and lipid-enriched diets

Summary

• VCP inclusion body myopathy is an important

heterogeneous and under-recognized disorder

• VCP R155H mice are excellent models of human

disease for translational studies

• Uphill exercise improved grip strength/Rotarod
• Cre excision of VCP improved pathology. Exon

skipping or allele silencing may be a promising strategy in patients

• ?Autophagy modifying drugs as therapy.
• High fat diet improves survival and pathology in

homozygotes with translational potential
