Power Available vs. Required for Standalone Low Cost Flight Display System Who are We? EE Team #192 ME Team #34 Gao Cai Justin Dubrosky Dylan Hammerman Brandon Naples Andrew Radlbeck Faculty Advisor : Chengyu Cao Shu Wan Faculty

slide-1
SLIDE 1

Power Available vs. Required for Standalone Low Cost Flight Display System

slide-2
SLIDE 2

Who are We?

EE Team #192

Gao Cai Dylan Hammerman Andrew Radlbeck Shu Wan Faculty Advisor: Helena Silva

ME Team #34

Justin Dubrosky Brandon Naples Faculty Advisor : Chengyu Cao

Sikorsky Liaison

Paul Inguanti

slide-3
SLIDE 3

Introduction

Design a stand alone unit to determine the ceiling IGE at specific weights for low cost helicopters. Requirements:

  • Continuous atmospheric pressure and air temperature measurements
  • Altitude calculation
  • Ceiling IGE
  • Indicator: LED and LCD
  • Accurate and repeatable function
  • Low cost and lightweight
  • Portable (self-powered)
slide-4
SLIDE 4

Helicopter Pictures

Schweizer S-300C

slide-5
SLIDE 5

Design: Old Prototype

I2C SPI

  • Data Logging Unit
  • Records altitude/temperature

data onto an SD card

  • Data easily graphable in Excel
  • This graph represents the

altitude of the back ITEB elevator shaft from “C” to “4”

≈ 18m

Elevator Altitude

slide-6
SLIDE 6

Design: Old Concept

I2C GPIO SPI

slide-7
SLIDE 7

Design: Final

I2C GPIO SPI SPI

slide-8
SLIDE 8
slide-9
SLIDE 9

Code Snippets

  • Main control unit code
slide-10
SLIDE 10

Code Snippets

  • Sensor control unit
slide-11
SLIDE 11

Schematics

slide-12
SLIDE 12

Schematics (cont)

slide-13
SLIDE 13

Schematics (cont)

TI PCA9544

slide-14
SLIDE 14

Schematics (cont)

slide-15
SLIDE 15

Design: Mechanical

[A] [B] [C]

Specs

  • 6061 Aluminum

○ light and low cost

  • Dimensions

○ 6” diameter & 2.5” height Construction A. Top Plate: Cut-outs for the pressure sensors B. Center: To create enclosure for all electrical components C. Base Plate: Board is mounted here

slide-16
SLIDE 16

Simulations: Mechanical

slide-17
SLIDE 17
slide-18
SLIDE 18

Results

slide-19
SLIDE 19

Results

slide-20
SLIDE 20

Results

slide-21
SLIDE 21

Results

slide-22
SLIDE 22

The Future

  • Interfacing -- Control & Sensor
  • Velocity Testing
  • Altitude testing

○ Low - offset calculation ○ High - final test

slide-23
SLIDE 23

Schedule

Order Parts 12/4 Presentation 2 12/3 Begin Winter Testing 1/21 Finish Winter Testing 1/25 Winter Break 12/15-1/21 Design Modification 02/01 Begin Spring Testing 02/14 Spring Break 03/16 - 22 Finish Spring Testing 03/28 Project Complete 05/02 Report and Poster 04/01

*Not to Scale

Assemble Code for SAM D20 12/5

slide-24
SLIDE 24

Budget

  • Sikorsky → $4,000 budget
  • Prototyping cost breakdown:
  • Adapter Board

$5

  • Battery

$24

  • Breadboard/wires

$20

  • Charger

$8

  • Development/Debugger board

$30

  • Enclosure

$90

  • Keypad

$4

  • LCD

$25

  • Multiplexer

Free

  • Sensors

$90

  • SD Card

$13 Total: $309

slide-25
SLIDE 25

Cost per Unit

  • Enclosure

$90

  • Four Sensors

$60

  • LCD

$25

  • Two batteries

$24

  • Microprocessors

$20

  • Charger

$8

  • Keypad

$4

  • Multiplexer

$1

  • Wires

$1 Total: $233

slide-26
SLIDE 26

Questions?
