slide-1
SLIDE 1

An Error Budget for Precise Radial Velocities from Keck-HIRES

Andrew W . Howard Townes Fellow, UC Berkeley

California Planet Search Team: Geoff Marcy, Debra Fischer, John Johnson, Jason Wright, Howard Isaacson, Julien Spronck, Jeff Valenti, Jay Anderson, Nikolai Piskunov, more!

slide-2
SLIDE 2

ASTRO2010

slide-3
SLIDE 3

ASTRO2010

Three primary science objectives for the next decade:

  • 1. Search for the first stars, galaxies,

and black holes

  • 2. Seek nearby habitable planets.
  • 3. Advance our understandings of the

fundamental physics of the universe.

slide-4
SLIDE 4

ASTRO2010

“This survey is recommending a program to explore the diversity and properties of planetary systems around other stars, and to prepare for the long-term goal of discovering and investigating nearby, habitable planets.” - page 7-7 “Using existing large ground-based or new dedicated mid-size ground-based telescopes equipped with a new generation of high- resolution spectrometers in the optical and near-infrared, a velocity goal of 10 to 20 centimeters per second is realistic.” - page 7-8

slide-5
SLIDE 5

ASTRO2010

“This survey is recommending a program to explore the diversity and properties of planetary systems around other stars, and to prepare for the long-term goal of discovering and investigating nearby, habitable planets.” - page 7-7 “Using existing large ground-based or new dedicated mid-size ground-based telescopes equipped with a new generation of high- resolution spectrometers in the optical and near-infrared, a velocity goal of 10 to 20 centimeters per second is realistic.” - page 7-8

slide-6
SLIDE 6

ASTRO2010

“This survey is recommending a program to explore the diversity and properties of planetary systems around other stars, and to prepare for the long-term goal of discovering and investigating nearby, habitable planets.” - page 7-7 “Using existing large ground-based or new dedicated mid-size ground-based telescopes equipped with a new generation of high- resolution spectrometers in the optical and near-infrared, a velocity goal of 10 to 20 centimeters per second is realistic.” - page 7-8

slide-7
SLIDE 7

ASTRO2010

To prepare for direct imaging, “NASA and NSF should support an aggressive program of ground-based high-precision radial velocity surveys

  • f nearby stars to identify potential candidates” - page 1-8
slide-8
SLIDE 8

ASTRO2010

Top Ground-based Recommendations (Large Projects):

  • 1. LSST
  • 2. Mid-scale Innovations Projects - including

“Develop RV surveys and spectrometers to determine the properties of extrasolar planets”

  • 3. Giant Segmented Mirror Telescope (TMT or GMT)
  • 4. ACTA (Cerenkov Telescope)
slide-9
SLIDE 9

ASTRO2010

SIM-Lite could characterize 50 nearby planetary systems down to an Earth-mass Rejected for 3 reasons:

  • 1. Large cost ($1.9B)
  • 2. Time to launch (8.5 yr)
  • 3. Target-finding for direct missions can

be done partially by RV with "challenging but achievable precision below 10 cm/s" SIM-Lite

slide-10
SLIDE 10

ASTRO2010

PRV Workshop Describe instrumental diffjculties

↓

Value

slide-11
SLIDE 11

Keck/HIRES

Keck 1 Telescope Iodine Cell

slide-12
SLIDE 12

HIRES

!

slide-13
SLIDE 13

HIRES

!

slide-14
SLIDE 14

HIRES

!

I2

slide-15
SLIDE 15

HIRES

!

I2 Slit

slide-16
SLIDE 16

HIRES

!

Guider I2 Slit

slide-17
SLIDE 17

HIRES

!

Guider Collimator I2 Slit

slide-18
SLIDE 18

HIRES

!

Guider Collimator E c h e l l e G r a t i n g I2 Slit

slide-19
SLIDE 19

HIRES

!

Guider Collimator E c h e l l e G r a t i n g Cross-disperser I2 Slit

slide-20
SLIDE 20

HIRES

!

Guider Collimator E c h e l l e G r a t i n g Cross-disperser I2

{

Camera Slit

slide-21
SLIDE 21

HIRES

!

Guider Collimator E c h e l l e G r a t i n g Cross-disperser CCD Dewar I2

{

Camera Slit

slide-22
SLIDE 22

Echelle Spectrum

slide-23
SLIDE 23

Iobs(") = k[TI 2(")# IS(" + $")] %PSF

RVs with Iodine

Dop

slide-24
SLIDE 24

Pushing down to K < 2 m/s

Star: HD 156668 (K3V) distance = 24 pc V = 8.3 [Fe/H] = 0.05 quiet Planet: M sin i = 4.15 ME P = 4.6455 d e = 0 (fixed)

Howard et al. 2010, ApJ (submitted), arXiv 1003:3444

slide-25
SLIDE 25

Pushing down to K < 2 m/s

Star: HD 156668 (K3V) distance = 24 pc V = 8.3 [Fe/H] = 0.05 quiet Planet: M sin i = 4.15 ME P = 4.6455 d e = 0 (fixed)

Howard et al. 2010, ApJ (submitted), arXiv 1003:3444

slide-26
SLIDE 26

Pushing down to K < 2 m/s

Star: HD 156668 (K3V) distance = 24 pc V = 8.3 [Fe/H] = 0.05 quiet Planet: M sin i = 4.15 ME P = 4.6455 d e = 0 (fixed)

Howard et al. 2010, ApJ (submitted), arXiv 1003:3444

slide-27
SLIDE 27

HIRES and HARPS

HD 156668 b (HIRES) GJ 581 e (HARPS)

RMS = 1.53 m/s K = 1.85 m/s

slide-28
SLIDE 28

HIRES and HARPS

HD 156668 b (HIRES) GJ 581 e (HARPS)

RMS = 1.53 m/s K = 1.85 m/s

slide-29
SLIDE 29

HIRES and HARPS

HD 156668 b (HIRES) GJ 581 e (HARPS)

RMS = 1.53 m/s K = 1.85 m/s

slide-30
SLIDE 30

Standard Stars

slide-31
SLIDE 31

Standard Stars

The best standards have an RMS of 1.5-2.0 m/s.

slide-32
SLIDE 32

Standard Stars

The best standards have an RMS of 1.5-2.0 m/s. These are almost always late G / early K dwarfs.

slide-33
SLIDE 33

Standard Stars

The best standards have an RMS of 1.5-2.0 m/s. These are almost always late G / early K dwarfs. We do not explicitly average

  • ver P-modes; Texp ~ 1-5 min
slide-34
SLIDE 34

!

Standard Stars

!

HD 10700 (Tau Ceti)

slide-35
SLIDE 35

Standard Stars

!

slide-36
SLIDE 36

Standard Stars

!

slide-37
SLIDE 37

Standard Stars

!

slide-38
SLIDE 38

Standard Stars

!

slide-39
SLIDE 39

2 4 6 8 10 Velocity RMS (m/s) 10 20 30 40 Number of Stars

HIRES Velocity RMS

slide-40
SLIDE 40

Velocity RMS

HIRES HARPS

2 4 6 8 10 Velocity RMS (m/s) 10 20 30 40 Number of Stars

Mayor and Udry, 2008,

  • Phys. Scr. T130, 014010

GK stars in Eta-Earth Survey Known planets removed

slide-41
SLIDE 41

Velocity RMS

HIRES HARPS

2 4 6 8 10 Velocity RMS (m/s) 10 20 30 40 Number of Stars

Mayor and Udry, 2008,

  • Phys. Scr. T130, 014010

2-3.5 m/s 1-3 m/s

GK stars in Eta-Earth Survey Known planets removed

slide-42
SLIDE 42

Challenge: Stability and Precision at 0.3-0.5 m/s

slide-43
SLIDE 43

Sources of RV Errors

Instrumental

(and modeling)

Astrophysical Poisson

(0.5-1.0 m/s)

slide-44
SLIDE 44

Sources of RV Errors

Instrumental

(and modeling)

Astrophysical Poisson

(0.5-1.0 m/s)

Not Limiting

slide-45
SLIDE 45

Sources of RV Errors

Instrumental

(and modeling)

Astrophysical Poisson

(0.5-1.0 m/s)

Not Limiting see talks today

slide-46
SLIDE 46

Sources of RV Errors

Instrumental

(and modeling)

Astrophysical Poisson

(0.5-1.0 m/s)

Not Limiting see talks today This Talk see also talks by Valenti, Spronck

slide-47
SLIDE 47

HIRES RV Errors

Guiding Zonal aberrations / vignetting Fibers (The Solution!) Scattered light - HIRES Sky subtraction for faint targets

slide-48
SLIDE 48

HIRES RV Errors

Guiding Zonal aberrations / vignetting Fibers (The Solution!) Scattered light - HIRES Sky subtraction for faint targets

slide-49
SLIDE 49

Intentional Mis-guiding

Guide Middle Guide Low Guide High Extreme mis-guiding -> 4 m/s

slide-50
SLIDE 50

!

Intentional Mis-guiding - PSF Asymmetry

PSF shape changes with mis-guiding

slide-51
SLIDE 51

Intentional Mis-guiding - PSF Asymmetry

PSF shape changes with mis-guiding

slide-52
SLIDE 52

! ! ! ! ! ! ! ! !

slide-53
SLIDE 53

!

Normal Guiding - PSF Variations

Jay Anderson, STSCI

slide-54
SLIDE 54

Normal Guiding - PSF Variations

Jay Anderson, STSCI

slide-55
SLIDE 55

!

Normal Guiding - PSF Variations

Jay Anderson, STSCI

slide-56
SLIDE 56

Normal Guiding - PSF Variations

Jay Anderson, STSCI

slide-57
SLIDE 57

!

Normal Guiding - PSF Variations

Jay Anderson, STSCI

slide-58
SLIDE 58

!

Normal Guiding - PSF Variations

Jay Anderson, STSCI

slide-59
SLIDE 59

HIRES RV Errors

Guiding Zonal aberrations / vignetting Fibers (The Solution!) Scattered light - HIRES Sky subtraction for faint targets

slide-60
SLIDE 60

!

Hartmann Mask Tests

Hartmann Mask

!

Standard Collimator Mask

slide-61
SLIDE 61

!

Vignetting

Dewar shadow

slide-62
SLIDE 62

!

HIRES Vignetting

slide-63
SLIDE 63

!

ThAr Spectra

No Hole With Hole

R ~ 150,000 R = 60,000

slide-64
SLIDE 64

!

Iodine Spectra

R ~ 150,000 R = 60,000 No Hole With Hole

slide-65
SLIDE 65

!

Vignetting & Pupil Illumination

Intentional mis-guiding along spatial direction → varying continuum

slide-66
SLIDE 66

HIRES RV Errors Summary So Far:

HIRES PSF will vary due to two effects:

  • 1. The non-uniformly imaged slit that is

imaged on the CCD

  • 2. The non-uniform pupil illumination of the

imperfect HIRES optics by the knife-edge effect on the pupil when the telescope is not in perfect focus.

slide-67
SLIDE 67

HIRES RV Errors

Guiding Zonal aberrations / vignetting Fibers (The Solution!) Scattered light - HIRES Sky subtraction for faint targets

slide-68
SLIDE 68

Lick Test Fiber

Julien Spronck - Yale

slide-69
SLIDE 69

Lick Test Fiber

Julien Spronck - Yale

slide-70
SLIDE 70

Breadboard

Lick Test Fiber

Julien Spronck - Yale

slide-71
SLIDE 71

Fiber Slit Mean Pixel Shift Guiding (-1: left, 0: center, +1: right)

  • 2
  • 1

1 2 0.6 0.4 0.2 0.0

  • 0.2
  • 0.4
  • 0.6

Fiber Input - Lick Mis-guiding Tests

PSF Stability: ~1.0 pixel → <0.01 pixels

slide-72
SLIDE 72

Image of Fiber output

Lick Test Fiber

Julien Spronck - Yale

slide-73
SLIDE 73

Keck Fiber Scrambler

Julien Spronck - Yale

slide-74
SLIDE 74

Keck Fiber Scrambler

Julien Spronck - Yale

slide-75
SLIDE 75

See Julien Spronck’ s Talk

  • n Wednesday

“Fiber Scrambling at Lick and Keck Observatory”

Julien Spronck

slide-76
SLIDE 76

HIRES RV Errors

Guiding Zonal aberrations / vignetting Fibers (The Solution!) Scattered light - HIRES Sky subtraction for faint targets

slide-77
SLIDE 77

A-band (O2) at 760 nm

Scattered Light < 70/4e4 = 0.002 Intrinsically Black? Probably No.

slide-78
SLIDE 78

A-band (O2) at 760 nm

Scattered Light < 70/4e4 = 0.002 Intrinsically Black? Probably No.

slide-79
SLIDE 79

Scattered Light - Laser Tests

Laser Exposures by Grant Hill (Keck Observatory) Stacked Image by Jeff Valenti (STScI)

slide-80
SLIDE 80

Scattered Light - Laser Tests

Laser Exposures by Grant Hill (Keck Observatory) Stacked Image by Jeff Valenti (STScI)

slide-81
SLIDE 81

Entire Laser Profile on Log Scale

1.3% of LSF is

  • utside ±7 pixels

6328.16 Å 5939.32 Å 5433.65 Å Red Laser Yellow Laser 5433.65 Å

slide-82
SLIDE 82

Entire Laser Profile on Log Scale

6328.16 Å 5939.32 Å 5433.65 Å Red Laser Yellow Laser Blue Laser

slide-83
SLIDE 83

Entire Laser Profile on Log Scale

10X Error Convolved Iodine Iodine 10X LSF LSF

slide-84
SLIDE 84

HIRES RV Errors

Guiding Zonal aberrations / vignetting Fibers (The Solution!) Scattered light - HIRES Sky subtraction for faint targets

slide-85
SLIDE 85

Sky Contamination - Faint Stars

Kepler-8, V=13.9 mag (45 min, full moon) 4 Echelle orders: Moonlight, Sky lines, Cosmic rays

slide-86
SLIDE 86

Sky Contamination - Faint Stars

Kepler-8, V=13.9 mag (45 min, full moon) 4 Echelle orders: Moonlight, Sky lines, Cosmic rays

Column cut

slide-87
SLIDE 87

Sky Contamination - Faint Stars

Full Moon, Clear skies: Sky is ~3% of 14th mag star (3 arcsec long slit)

0.8” seeing

slide-88
SLIDE 88

Sky Contamination - Faint Stars

Full Moon, Clear skies: Sky is ~3% of 14th mag star (3 arcsec long slit)

0.8” seeing

Stellar Orders

slide-89
SLIDE 89

Sky Contamination - Faint Stars

Full Moon, Clear skies: Sky is ~3% of 14th mag star (3 arcsec long slit)

0.8” seeing

Sky Stellar Orders

slide-90
SLIDE 90

Sky Contamination - Faint Stars

Full Moon, Clear skies: Sky is ~3% of 14th mag star (3 arcsec long slit)

0.8” seeing

Sky Stellar Orders

slide-91
SLIDE 91

Sky subtraction

Sky Sky Star

Cosmic ray

Subtract median sky value from each pixel in extraction region Essential for V ≥ 10 for 1 m/s

slide-92
SLIDE 92

Summary: HIRES RV Errors

Guiding Zonal aberrations / vignetting Fibers (The Solution!) Scattered light - HIRES Sky subtraction for faint targets

slide-93
SLIDE 93

Questions?
