Pointcloud processing engine

• 1.0.1 release now available (September 2015) (OSGeo4W/64)
• BSD Licensed (Supports proprietary plugins)
• C++ development

○ git repo (https://github.com/PDAL/PDAL) ○ pull requests welcome

• pdal main command

○ many subcommands (kernels)

• Pipelines (a chain of processing steps)

○ XML processing language ○ VRT like ○ Nesting dolls

About the library

History / Goals

• libLAS development outgrew ASPRS LAS

(Oracle)

• Focused on data management
• Extensibility and integration
• Not just LAS-focused
• Leverage existing tools (GDAL, proj.4,

libgeotiff, Python, PCL)

• readers.buffer
• readers.faux
• readers.geowave
• readers.greyhound
• readers.las
• readers.mrsid
• readers.nitf
• readers.oci
• readers.optech
• readers.pcd
• readers.pgpointcloud
• readers.ply
• readers.qfit
• readers.rxp
• readers.sbet
• readers.sqlite

readers / writers

• writers.derivative
• writers.geowave
• writers.las
• writers.matlab
• writers.nitf
• writers.oci
• writers.ply
• writers.p2g
• writers.pcd
• writers.pgpointcloud
• writers.pclvisualizer
• writers.rialto
• writers.sqlite
• writers.text

filters

• filters.attribute
• filters.colorization
• filters.chipper
• filters.crop
• filters.decimation
• filters.ferry
• filters.hexbin
• filters.mortonorder
• filters.merge
• filters.pclblock
• filters.predicate
• filters.programmable
• filters.range
• filters.reprojection
• filters.sort
• filters.stats
• filters.transformation

• ground
• info
• split
• tindex
• translate
• pipeline

subcommands

• Classifies a pointcloud

○ ground and non-ground points ○ optionally removes non-ground points

• Uses the PCL (PMF) Progressive

Morphological Filter

○ same as a pipeline with PCLBlock ○ also an approximate version (much faster)

Ground

Ground - Before

Ground - After

pdal info --summary source.laz { "pdal_version": "PDAL 1.0.0.b1 (399539)", "summary": {"bounds": {"X": { "max": 581026.95000719489, "min": 580304.60002865398 }, "Y": { "max": 4505023.6300240532, "min": 4504450.3600357873 }, "Z": { "max": 92.11999999999999, "min": -0.78000000000000025 } }, "dimensions": "X, Y, Z, Intensity, ReturnNumber, NumberOfReturns, ScanDirectionFlag, EdgeOfFlightLine, Classification, ScanAngleRank, UserData, PointSourceId", "num_points": 255772, "spatial_reference": "PROJCS["NAD83 / UTM zone 18N" ….]" } }

Info

Top down view

Info --Boundary

Default output

$ pdal info --boundary source.laz

Info --boundary

Add options to command line $ pdal info --boundary source.laz

• -filters.hexbin.threshold=10
• -filters.hexbin.sample_size=10
• -filters.hexbin.edge_size=2

$ pdal info Liberty-Island.ALS70.NYC_2013085-15.laz -p 2633

Info --P (Point)

"Classification": 2, "EdgeOfFlightLine": 0, "GpsTime": 0, "Intensity": 23, "NumberOfReturns": 1, "PointId": 2633, "PointSourceId": 20, "ReturnNumber": 1, "ScanAngleRank": -10, "ScanDirectionFlag": 1, "UserData": 0, "X": 580814.96002865396, "Y": 4504512.6400357876, "Z": 0.02000000000000024

pdal split -i Liberty-Island.ALS70.NYC_2013085-15.laz -o Liberty-Island-Tile.las

• -capacity 50000

Split (Capacity)

pdal split -i Liberty-Island.ALS70.NYC_2013085-15.laz -o Liberty-Island2-Tile. laz --length 100

Split (Length)

• Creates a tile index of pointclouds in any

gdal vector format

• Can then be used for merge/clip
• perations

pdal tindex --merge --tindex filename.ogr --polygon "wkt"

• -filespec output.laz

tindex

pdal tindex --merge --tindex LibertyTindex2.db --filespec clipped_merged_LibertyTinde x.laz --polygon "POLYGON ((-74.0459708 40.690573,

• 74.045082 40.689164,
• 74.046622 40.688406,
• 74.047320 40.690348,
• 74.0459708 40.690573))"

tindex - example

• Basic pointcloud format changes

○ -i myfile.las -o myfile.laz

• also advanced options to the

reader/writer/projection steps

○ --writers.las.system_id="Custom" --writers. las.scale_z=0.00001

System ID: 'Custom' Generating Software: 'PDAL 1.0.0.b1 (399539)' Min X Y Z: 580497.62 4504606.39 -0.78000 Max X Y Z: 580686.27 4504845.65 46.72000

Translate

• Access to the full power of pdal
• allows stacking of range of operations

with one pass through data

• great for programmatically building

workflows

• command line specification of values for

batch processing

Pipeline

$ pdal pipeline range.xml --readers.las. filename=myfile.las --writers.las. filename=myrangefile.laz $ find . -name="*.laz" | xargs pdal pipeline --readers.las.filename={} -- writers.las.filename=newdir/{}

Pipeline - cli values

<Pipeline version="1.0"> <Writer type="writers.las"> <Filter type="filters.range"> <Option name="dimension">Z <Options> <Option name="min">0</Option> <Option name="max">99999</Option> </Options> </Option> <Reader type="readers.las"></Reader> </Filter> </Writer>

• Can use any gdal image source
• Must match projections though

colorization filter

<Pipeline version="1.0"> <Writer type="writers.las"> <Filter type="filters.colorization"> <Option name="raster"> <![CDATA[http://isse.cr.usgs. gov/arcgis/rest/services/Orthoimagery/USGS_EROS_Ortho_1Foot/ImageServer/ exportImage?bbox=580304.600,4504450.360,581026.950,4505023.630 &bboxSR=26918&size=1000, 1000&imageSR=26918&format=tiff&pixelType=U8&noDataInterpretation=esriNoD ataMatchAny&interpolation=+RSP_BilinearInterpolation&f=image]]> </Option> <Reader type="readers.las"> </Reader> </Filter> </Writer> </Pipeline>

New Syntax:

$ pdal translate -i infile.laz -o outfile_color.laz

• -filter filters.colorization --filters.colorization.

raster=myraster.tif

COLORization - cli

Assigning and reprojecing data:

$ pdal pipeline proj.xml

• -readers.las.filename=src.laz
• -writers.las.filename=dest.laz

Assign and project with translate also:

ls *.las | xargs -P10 pdal translate --filters filters.reprojection

• -filters.reprojection.in_srs=epsg:26910
• -filters.reprojection.out_srs=epsg:26911 -i {} -o newdir/{}

<Pipeline version="1.0"> <Writer type="writers.las"> <Filter type="filters.reprojection"> <Option name="in_srs">EPSG:26918</Option> <Option name="out_srs">EPSG:26919</Option> <Reader type="readers.las"/> </Filter> </Writer> </Pipeline>

reprojection filter

p2g writer (DEMs)

<Pipeline version="1.0"> <Writer type="writers.p2g"> <Option name="grid_dist_y">1.0</Option> <Option name="grid_dist_x">1.0</Option> <Option name="output_format">tif</Option> <Option name="output_type">idw</Option> <Option name="filename">destination</Option> <Filter type="filters.range"> <Option name="dimension">Classification <Options> <Option name="equals">2</Option> </Options> </Option> <Reader type="readers.las"> <Option name="filename">source.laz </Option> </Reader> </Filter> </Writer> </Pipeline>

pdal translate -i source.laz -o destination.tif

• -writer=writers.p2g --writers.p2g.grid_dist_y=0.5 --

writers.p2g.grid_dist_x=0.5 --writers.p2g.

• utput_format=tif --writers.p2g.output_type=idw

You can turn the above into a pipeline with

• -pipeline dem_pipeline.xml

p2g writer (DEMs)

plas.io Greyhound Entwine

the kennel

The LASzip compression algorithm refactored for compilation via Emscripten to JavaScript allowing LAS/LAZ viewing with a WebGL enabled browser (FF, Chrome, IE11, Safari)

plas.io

• RESTful HTTP environment for serving

and streaming point cloud data

• LAZ-style compression
• Dynamic schema
• Metadata

GreyHound

's new parallel indexing engine iowalidar.com: 163 Billion points in a browser (quadtree) speck.ly: NYC, USA 4.7 Billion points (octree)

Questions?
