Platform & Modular Design Development Of Subsystems and Interface Architecture Product Platform - Definition An Architecture of a set of Subsystems (Modules) and their Interfaces the Form a Common Structure from Which a Stream of

slide-1
SLIDE 1

Platform & Modular Design

Development Of Subsystems and Interface Architecture

slide-2
SLIDE 2

Product Platform - Definition

  • An Architecture of a set of Subsystems

(Modules) and their Interfaces the Form a Common Structure from Which a Stream

  • f Derivative Products (or Services) can

be Efficiently Developed and Produced

  • ver a Period of Time
slide-3
SLIDE 3

Product Family - Definition

  • A Product Family is a Set of Individual

Products (or Services) that Share Common (Modules and Interfaces) & Technology and Address a Related Set of Market Applications

slide-4
SLIDE 4

Platform Extensions – Definition

  • Product Derivatives with one or more

Common Subsystems (Modules) and Their Interfaces that are Substantially Improved with New Technology

slide-5
SLIDE 5

New Product Platform - Definition

  • A new Architecture, i.e., a New

Combination of New Subsystems (Modules) and Their Interfaces Linked with Some Prior Generation Subsystems and Interfaces

slide-6
SLIDE 6

Product Platform - System Architecture (Shared)

D = Derivative N

Product Platforms

A

D N

B

D N

C

D N

D

D N

E

D N

slide-7
SLIDE 7

Product Platform - System Architecture (Shared)

D = Derivative N

Product Platforms

A

D N

B

D N

C

D N

D

D N

E

D N

N 1

N 1-1

N 2

N 2-1

N 3

N 3-1

N N

N N-1

Shared Systems / Subsystem Architectures

slide-8
SLIDE 8

Product Platform - System Architecture (Shared)

D = Derivative N

Product Platforms Shared Systems / Subsystem Architectures

A

D N

B

D N

C

D N

D

D N

E

D N

N 1

N 1-1

N 2

N 2-1

N 3

N 3-1

N N

N N-1

slide-9
SLIDE 9

(Power Tool) Product Platform - System Architecture (Shared)

D = Derivative N

Product Platforms

Drills

D N

Jig Saws

D N

Sanders

D N

Edgers

D N

Hedge Trimmers

D N

slide-10
SLIDE 10

(Power Tool) Product Platform - System Architecture (Shared)

D = Derivative N

Product Platforms

Drills

D N

Jig Saws

D N

Sanders

D N

Edgers

D N

Hedge Trimmers

D N

Motors

N 1-1

Housing

N 2-1

Gear Boxes

N 3-1

Auxil.

N N-1

Shared Systems / Subsystem Architectures

slide-11
SLIDE 11

(Power Tool) Product Platform - System Architecture (Shared)

D = Derivative N

Product Platforms Shared Systems / Subsystem Architectures

Drills

D N

Jig Saws

D N

Sanders

D N

Edgers

D N

Hedge Trimmers

D N

Motors

N 1-1

Housing

N 2-1

Gear Boxes

N 3-1

Auxil.

N N-1

Fields Armatures Shafts Brushes Insulators Wire Housings Labels Gears Bearings Shafts Spindles Switches Cord Sets Fasteners Packaging

slide-12
SLIDE 12

Scania - Modular Design & Product Platforms

Modules - Elements of Product Architecture Scandia Truck Modules

  • Engines - generate power
  • Cabs - comfortably carry and protect driver
  • Transmissions - transmit power
  • Chassis - carry loads
slide-13
SLIDE 13

A B C D A B C A B C D

l l l l l l l l l l l l l l l

Cabs (3) Engines (4) T r a n s ( 4 ) Chassis (15)

Scania - Modular Design & Product Platforms

slide-14
SLIDE 14
slide-15
SLIDE 15
slide-16
SLIDE 16
slide-17
SLIDE 17
slide-18
SLIDE 18
slide-19
SLIDE 19
slide-20
SLIDE 20
slide-21
SLIDE 21
slide-22
SLIDE 22
slide-23
SLIDE 23
slide-24
SLIDE 24
slide-25
SLIDE 25

Product Family - Definition

  • A Product Family is a Set of Individual

Products (or Services) that Share Common Technology and Address a Related Set of Market Applications

slide-26
SLIDE 26

Product Family Evolution – Dimmer Switches

D = Derivative N

Product Platforms

Rotary 1961

D N

Slider 1971

D N

Toggle 1991

D N

Rocker 1992

D N

Touch Tap 1995

D N

Centurian Fandial Lumea Skylark Nova Glyder

Ariandi Diva

Maestro Vario

slide-27
SLIDE 27

Product Family Evolution – Dimmer Switches

D = Derivative N

Product Platforms Shared Systems / Subsystem Architectures

D N D N D N D N D N

Housing

N 1-1

Yoke- Heatsink

N 2-1

Circuit Board

N 3-1

Switch Knob

N N-1

Rotary 1961 Slider 1971 Toggle 1991 Rocker 1992 Touch Tap 1995 Common Housings? Common Yoke-Heatsink? Common Circuit Board? Common Switch Knobs?

slide-28
SLIDE 28

Modular Design Non- collaboration

Division A 3788 Part Numbers Division B

1032

Part Numbers Division C 3413 Part Numbers

100 100 100 100

Common Parts Parts Parts Parts 53 Common Parts 88 Common Parts

Less than 2% Inter- Divisional Use of Common Parts

slide-29
SLIDE 29
slide-30
SLIDE 30
slide-31
SLIDE 31
slide-32
SLIDE 32
slide-33
SLIDE 33
slide-34
SLIDE 34
slide-35
SLIDE 35
slide-36
SLIDE 36

Functional Platform Architecture In Product Design

slide-37
SLIDE 37

Definition: “Functional Platform”

Functional Platform Architecture in Product Design

  • A discrete functional element of a composite and/or

complex system that provides a specific contribution to the whole system

slide-38
SLIDE 38

Functional Platform Architecture in Product Design

  • Aphorisms* procedural steps in architecture

development or product design analysis

* Aphorisms: concise statement of principle

Source: Rules and Methods

slide-39
SLIDE 39

Procedural Steps in Architecture Analysis or Development

Aphorisms and Procedural Steps in Architecture Development or Product Design Analysis

  • Strive to design interface architecture that is elegantly

simple, reliable, cost effective, and will be a long lived design architecture. A “standard” geometry that could persist for years. (Example: 35mm film cartridges, electric

  • utlets, lamp sockets, telephone jacks, QWERTY keyboard.)
  • Avoid “domino effect” of functional element platform designs
  • r evolutionary changes that violate interface architecture.

Platform designs should not bridge or leak to other platforms across interfaces.

slide-40
SLIDE 40

Procedural Steps in Architecture Analysis or Development

Aphorisms and Procedural Steps in Architecture Development or Product Design Analysis

  • Isolate and reduce each functional element of the

total system to a singular function

  • Identify and specify each interface (linkage),

essential and nonessential, of each functional element to another

slide-41
SLIDE 41

Procedural Steps in Architecture Analysis or Development

Aphorisms and Procedural Steps in Architecture Development or Product Design Analysis

  • Decouple as many interfaces as possible - strive to

max out at two (2) interfaces. (Avoid complexities

  • f four (4) or more interfaces.)

1 2 3 4 5 6 7 8 9 Excellent Poor Terrible

slide-42
SLIDE 42
slide-43
SLIDE 43

Procedural Steps in Architecture Analysis or Development

Aphorisms and Procedural Steps in Architecture Development or Product Design Analysis

  • When a functional platform transitions from “generic” to a

“unique” state, restrict functional platform architecture to two (2) interfaces: one (1) generic and one (1) unique interface. (Avoid coupling multiple functional architectures to unique systems.)

  • Within each functional platform architecture allow for many

degrees of freedom and latitude, i.e. capability, variety of functions, materials, hierarchy of capability, etc.

slide-44
SLIDE 44

Procedural Steps in Architecture Analysis or Development

Aphorisms and Procedural Steps in Architecture Development or Product Design Analysis

  • At end user interfaces, provide architectures to enable a rich

variety of capabilities, forms, visuals, and features for the product’s evolutionary life cycle extensions, competitive advantages, and future product line developments and multiple product platforms.
