Data Needs for Long Range Planning

For Small and Medium MPOs

Agenda

• Introductions
• Meet the Data
• Planning Regs
• Plan Elements

– People – Network – Other

• Odds and Ends
• YOUR ISSUES

Introductions

• Tameka Macon, FHWA
• Charlynn Burd, US Census
• Penelope Weinberger, AASHTO
• Jasmy Methipara, Macrosys/NHTS
• Jeremy Raw, FHWA

Disclaimer

Any opinions and conclusions expressed herein are those of the authors and do not necessarily represent the views of the U.S. Census Bureau. All results have been reviewed to ensure that no confidential information is disclosed.

9/22/2016 4

Meet the Data

• American Community Survey
• Census Transportation Planning Products
• National Household Travel Survey
• National Performance Management Research

Data Set, Highway Performance Monitoring System, FAF, HEPGIS, Smart Location Database

• Other data sets are also used (but will not be

covered today); State Dept of Admin population and employment projections, crash data, many more

But First

Why are we here today?

MPO Planning Regs

• Development of Long-Range Plans and TIPs.—metropolitan planning
• rganizations, in cooperation with the State and public transportation
• perators, shall develop long-range transportation plans and

transportation improvement programs.

– Contents.—The LRTPs and TIPs shall provide for the development and

integrated management and operation of transportation systems and facilities (including accessible pedestrian walkways and bicycle transportation facilities) that will function as an intermodal transportation system for the metropolitan planning area. – Process of development.—The process for developing the plans and TIPs shall provide for consideration of all modes of transportation and shall be continuing, cooperative, and comprehensive.

• FAST Act

– Requirements for a long-range plan and a short-term TIP continue with the long-range plan to incorporate performance plans required for specific

• programs. The long-range plan must describe the performance measures and

targets used in assessing system performance and progress in achieving the performance targets. The TIP must also be developed to make progress toward established performance targets and include a description of the anticipated achievements.

Plan Updates

• Development of Transportation Plan.—

– The metropolitan planning organization shall prepare and update such plan every 4 years (or more frequently, if the metropolitan planning organization elects to update more frequently) in the case of each of the following:

• (A) Any area designated as nonattainment, as defined in the Clean

Air Act (42 U.S.C. 7407(d).

• (B) Any area that is subject to an attainment maintenance plan

– In the case of any other area required to have a transportation plan, the metropolitan planning

• rganization shall prepare and update such plan every 5

years (unless the metropolitan planning organization elects to update more frequently).

minimum requirements (abridged)

• (A) Identification of transportation facilities.—(including major roadways,

transit, multimodal and intermodal facilities, and intermodal connectors)

• (B) Mitigation activities.

– (i) In general.—A long-range transportation plan shall include a discussion of types of potential environmental mitigation activities and potential areas to carry out these activities, – (ii) Consultation.—The discussion shall be developed in consultation with Federal, State, and tribal, wildlife, land management, and regulatory agencies.

• (C) Financial plan.
• (D) Operational and management strategies.— to improve the

performance of existing transportation facilities to relieve congestion and maximize the safety and mobility of people and goods.

• (E) Capital investment and other strategies.
• (F) Transportation and transit enhancement activities.
• (G) Performance measures and targets developed with the States.

So, now we know the rules

• Lets look at what elements are required in

Long Range Plans;

• And what data addresses those elements

Elements of Plans - People

• Population
• Race
• Age
• Disability
• Housing
• Income
• Employment
• Mobility/Commuting
• Environmental Justice

Elements: People

9/22/2016 12

ACS CTPP NHTS Other Data Sets and Tools Population

   HEPGIS

Race

   HEPGIS

Age

  

Disability

 

Housing

  

Income

  

Employment

   HEPGIS

Mobility/ Commuting

  

Environmental Justice

  

American Factfinder

factfinder.census.gov

13

Population, Worker Population

• Workplace based race/age/
• Commuting: The big enchilada
• EJ: Poverty; Income by Means for Workplace;

Industry by small geography; time leaving data gives you opportunities for outreach

43.1% 46.3% 0.9% 1.5% 0.3% 4.3% 3.6%

Race of Workers in MARC Region - Transit Commuters

White Black or African American American Indian and Alaska Native Asian Native Hawaiian and Other Pacific Islander Some other race

NHTS

Other Data and Tools

• HEPGIS provides rapid access to popular 2000

and 2010 census data (total population, black population, Hispanic population)

• HEPGIS also provides annual average

unemployment rate by county

Elements of Plans - Network

• Roads
• Freight
• Transit
• Bike
• Pedestrian
• Rail
• Airport
• Marine
• Pipeline

Elements: Network

9/22/2016 20

ACS CTPP NHTS Other Data Sets and Tools Roads

   

Freight



Transit

 

Bike

  

Pedestrian

  

Air



Marine



Pipeline

https://www.census.gov/geo/maps-data/data/tiger-line.html

CTPP

• Trip data for the commute trip for many

modes/means of transportation

• Auto availability

Total worker flow; County to Place

NHTS

POV 84% Other 1% Transit 4% Bicycle 1% Walk 10%

2009 Trip Modes 2016

Other Data and Tools

• Roads – NPMRDS, HPMS, HEPGIS

– Traffic volumes (HEPGIS=HPMS 2012, HPMS other years) – National Highway System (HEPGIS) – Functionally Classified Roads (HPMS) – Traffic times on NHS (NPMRDS) updated monthly

• Freight – HEPGIS (FAF network, OD Flows, National

Truck Network)

• Transit Network / General Transit Feed Specification

(http://transitfeeds.com/)

• Bike – HEPGIS (Fatal Crashes)
• Pedestrian – HEPGIS (Fatal Crashes)

More Elements!

• Growth
• Travel Forecasting and Modeling
• Land Use
• Average Daily Traffic and Vehicle Miles of

Travel

• Commodity Flows
• Economic Development
• Sustainability

Elements: Other

9/22/2016 27

ACS CTPP NHTS Other Data Sets and Tools Growth

  

Travel Forecasting

  

Land Use

 

ADT/VMT

HPMS

Commodity Flows

FAF

Economic Development

 

Sustainability



CTPP

• If Growth is a proxy for trends, there are CTPP

flows and workplace based data from 1990* forward

• Travel model validation/calibration
• Workers by Industry for small area geography

Profile

NHTS

2015 Compendium

Other Data and Tools

• HPMS

– Reference baseline for model data – Used for reasonableness, and for AQ baseline

Other things! (Odds and Ends)

• Workers, education
• Active Transportation, Health in Transportation
• EV charging station locations/grid demand: based on typical

travel ODs

• Regression models, policy analysis
• Benchmarking
• Safe Routes to School projects
• Safety analysis: fatalities per mile/trip/min etc. by various

modes, high crash locations

• Autonomous vehicles
• Travel behavior: commute, trip times/lengths, ODs, mode

distribution, air quality/GHGs, worker flows

Odds and Ends

9/22/2016 34

ACS CTPP NHTS Other Data Sets and Tools Education

 

Work

  

Active Transportation/Health

 

Policy Analysis

 

Bench Marking

  

Safe Routes to Schools



Safety Analysis



Autonomous Vehicles

Not much yet

Travel Behavior:

 

Trip time/length

  NPMRDS

Mode

 

Air Quality/GHG



CTPP

• Workers Workers Workers
• Ped/Bike Commutes
• Profiles

NHTS

• Conditions and Performance Report: https://www.fhwa.dot.gov/policy/2013cpr/
• Beyond Traffic: U.S. DOT's 30-Year Framework for the Future:

https://www.transportation.gov/beyondtraffic

• Technical Evaluation Of The Greenhouse Gas Emissions Reduction Quantification

For The San Joaquin Council Of Governments’ Sb 375 Sustainable Communities Strategy California Air Resources Board

• Exploring Origin-Destination Passenger Travel Flow Patterns in Traffic Analysis

District Clusters of Small/Medium Size Regions Ho-Ling Hwang, Shih-Miao Chin, Daniel Wilson, Tim Reuscher and Angel Canales

• Active Transportation Surveillance — United States, 1999–2012 , MPH; Geoffrey P.

Whitfield, PhD; Prabasaj Paul, PhD & Arthur Wendel, MD

• Factors affecting children’s journeys to school: a joint escort-mode choice model

He, Sylvia Y., and Genevieve Giuliano.

• Bicyclist Deaths Associated with Motor Vehicle Traffic — United States, 1975–

2012 Jason Vargo, PhD; Benjamin G. Gerhardstein, MPH; Geoffrey P. Whitfield, PhD; & Arthur Wendel, MD

• Conventional, hybrid, plug-in hybrid or electric vehicles? State-based

comparative carbon and energy footprint analysis in the United States NC Onat, M Kucukvar, and O. Tatari

• An optimization model of energy and transportation systems: Assessing the high-

speed rail impacts in the United States Venkat Krishnan, Eirini Kastrouni, V. Dimitra Pyrialakou, Konstantina Gkritza, & James D. McCalley

Other Data and Tools

• HPMS

– Reference baseline for model data – Used for reasonableness, and for AQ baseline

Your issues!

• Participant input
