Planning application 01/12/0782 Installation of a 78 metre high wind turbine and associated transformer container and substation container. Back Lane Quarry, Nether Kellet, Carnforth. Planning Application 1/12/0782 Carnforth Back Back Lane
SLIDE 2
SLIDE 3
Planning application 01/12/0782 Site Location Plan
East side (residential area)
- f Carnforth
Turbine location M6 Motorway
SLIDE 4
Planning application 01/12/0782 Aerial View of site and surrounding area
East side (residential area)
- f Carnforth
Leapers Wood Quarry Turbine location Back Lane Quarry and access road M6 Motorway Back Lane
SLIDE 5
Planning application 01/12/0782 Site Layout Plan
Laydown areas/ Crane pads/ Construction area Turbine location with green area showing extent of rotor swept path Transformer container Substation container Route (yellow) of underground cable
SLIDE 6
Planning application 01/12/0782 Elevations of Wind Turbine
SLIDE 7
Planning application 01/12/0782 Slope on north side of site entrance on which turbine would be sited
SLIDE 8
Planning application 01/12/0782 Visualisation Locations
Viewpoint 5 Warton Crag Path Viewpoint 3 Kellet Viewpoint 1 Windermere Road, Carnforth Viewpoint 4 North Road, Carnforth Viewpoint 3 Kellet Road M6 Bridge Turbine Location Viewpoint 2 Back Lane M6 Bridge
SLIDE 9
Planning application 01/12/0782 Visualisation 1 from West side of Langdale Road near junction with Windermere Road, Carnforth
SLIDE 10
Planning application 01/12/0782 Visualisation 2 from Back Lane M6 Motorway bridge
SLIDE 11
Planning application 01/12/0782 Visualisation 3 from B6254 Kellet Road M6 Motorway bridge
SLIDE 12
Planning application 01/12/0782 Visualisation 4 from North Road, Carnforth
SLIDE 13
