North West Coast Connections Project PINS Briefing

12 August 2015 Robert Powell, Judith Vokes, Richard Gwilliam

The North West Coast Connections Project

Moorside 2

What do we need to build?

An electrical connection for Moorside needs four transmission circuits – two double circuits Double circuit 1 Double circuit 2

3

Technologies

How Do We Do It?

Technologies for Connection 400kV AC Overhead Line

132kV Conventional lattice 300-400 MW Height typically 27.5m 400kV Conventional lattice 6,900 MW Height typically 46-50m 400kV T Pylon 6,900 MW Height typically 35-38m 132kV Trident wood pole 120-150 MW Height typically 13m 400kV Low height lattice 6,900 MW Height typically 38- 41m

Technologies for Connection 400kV AC Overhead Line

400kV Conventional lattice

7

400kV Low height lattice

Technologies for Connection 400kV AC Overhead Line

8

400kV T Pylon

Technologies for Connection 400kV AC Overhead Line

9

132kV Conventional lattice

Technologies for Connection 400kV AC Overhead Line

10

Minimising the impact

Sensitive routeing of overhead lines Screening and landscaping Rationalisation of existing lines Alternative pylon designs Placing new line underground

11

Technologies for Connection Underground 400kV AC Cable

This site width 40m 5000A circuit site width 70m

12

Technologies for Connection Tunnelling

Head house diameter approx 16 metres & 7 metres high Tunnel is about 25- 30 metres below ground Longer tunnels require ventilation points and emergency access along route

13

Technologies for Connection Tunnelling

14

Technologies for Connection High Voltage Direct Current (HVDC)

• An alternative solution to AC for bulk transmission of electricity
• NG would expect this to be undersea / underground
• Much narrower cable route than AC
• The type of HVDC needed does not exist today at required power levels
• Technology has not yet been used to connect a nuclear power station

Technology: the options

Overhead line Cable (direct burial XLPE) Cable (gas insulated (GIL)) Cable (tunnel) HVDC

typical

£

£2.5m to £3.0m per km £13m to £32m per km Similar to Cable Cost of tunnel + cable £2m per km plus up to £332m per pair of convertor stations

PROS

Limited disturbance; quick build; operational flexibility together with rapid repair and restoration times Improved visual amenity No reactors or above ground installations; narrower working width. Use in highly constrained areas Advantages over AC transmission over long distance (e.g. interconnectors)

CONS

Visual impact Lengthy construction and disturbance; fault detection and repair; above ground infrastructure; above ground reactive compensation New technology, use

• f SF6

Difficult to alter/expand Lack of flexibility – difficult to transform voltage; large converter stations required

Development Programme

Regional Stakeholder Engagement

 Started in 2005 with drive to see new nuclear development in Cumbria  National Grid involved since 2009  30 local planning authorities  Range of environmental, business and community organisations including; Natural England, English Heritage, the Marine Management Organisation, Morecambe Bay Partnership, CALC, LALC

17

• Initial work and

studies looking at the ways to connect Moorside

2013 - 2014 2009 -2011 2012

18

Project Timeline

• Technical consultation
• n six broad connection
• ptions
• 23 Oct 2012

announced decision to take two strategic

• ptions forward for

further study

• Identified route

corridors in which a new connection could be built.

• 12 week outline

routeing consultation.

• Landowners contacted.
• EIA wildlife studies

started.

2013 - 2014 2009 -2011

19

Project Timeline

2015 2016

• Review 2014

consultation feedback

• Announce proposed

route corridor being progressed

• Ongoing studies to

determine detailed route of new connection and how it will be built

• Continue working

with stakeholders to shape proposals

• detailed route
• construction
• Mitigation
• further EIA surveys
• DCO submission to the

Planning Inspectorate

2017

• Formal public

consultation on route alignment and construction technologies

• Complete EIA

2013 - 2014 2009 -2011 2012

20

Project Timeline

2015 2016 2017

• Decision on

application made by the Secretary of State for Energy and Climate Change

2018 2019 2024

• Subject to consent

being granted start construction new connection

• Complete connection

to meet Moorside first generation in 2024.

Strategic Options Consultation 11 May 2012 -19 July 2012

Strategic Options Consultation

Strategic Options Consultation

Outline Routeing Public Consultation 4 Sept – 28 Nov 2014

25

Publicising the Consultation

26

Publicising the Consultation

27

Consultation Responses

What you told us – most common themes

28

The Lake District National Park Rationalisation (removal of existing ENW 132kV towers) Designing a route to minimise landscape impacts Minimising disruption to and impacts on communities The possibility of an offshore

• ption

What you told us - Onshore North

29

Preferences mostly for the green route Tends to be seen as sensible, as long as it results in an existing line coming down Some specific areas of concern

What you told us - Onshore South

30

 Wide opposition to Onshore South  People said running a line through the South Lakes would be unacceptable  The main reason for supporting this route was cost

What you told us - Offshore South

 People generally supported this option on landscape grounds  But many noted that it was technically challenging  Greatest problem is connecting HVDC  NuGen said this would not work for the nuclear power station

31

What you told us - Onshore South with Tunnel

 Qualified support from many members of the public  Broad support from stakeholders  People said that if an offshore connection wasn’t possible, then they liked the idea of a tunnel

32

Consultation Feedback

 Rationalisation of existing

• verhead lines is important

both north and south of Moorside  Future development south of Whitehaven  Feedback reaffirmed visually sensitive areas, particularly:

• Lake District National Park
• Ravenglass
• Duddon estuary

33

Consultation Feedback

 All feedback redacted and published on our website for 2012 and 2014 consultations  Propose to repeat this for formal consultation in 2016

34

Next Steps We will work with: Local Authorities Landowners Parish Councils Community

Agricultural shows Information events Special interest groups

35

Next Steps

 Which pylons we are going to use and where to put them?  132kV lines to take down?  New substations?  Temporary 132kV lines  415V, 11kV and 33kV crossings  Is there a need for more mitigation?  What landscaping should we do?  EIA Scoping  SOCC

36

Development Programme

37

2017 2019 2024 2016 Public Consultation on Detailed Proposal Submit DCO Application Start build? Ready for power station

 GIS  4Projects

Issues and Opportunities

38

Any Questions?
